GK® 11"-5000 PSI Annular Blowout Preventer

R

Pressure Control Equipment

OPERATOR'S MANUAL

Manual 6609E

R

Operator's Manual OPERATOR'S MANUAL GK® 11"-5000 PSI Annular Blowout Preventer

6609E


R

Hydril Company LP/ P.O. Box 60458 / Houston, Texas 77205 Phone: (281) 449-2000 / FAX: (281) 985-2828 / WEB: www.hydril.com © 2007 Hydril Company LP

Printed in U.S.A., Rev E, October 2007

All Rights Reserved

PAGE iii

R

Operator's Manual PAGE iv


Preface This manual contains the information necessary to operate and maintain the Hydril® GK® 11"-5000 PSI Annular Blowout Preventer (ABOP). Hydril recommends that the information in this manual be studied thoroughly before any attempt is made to operate or perform maintenance or repair operations on this equipment and that all safety precautions be followed. Generic in construction, this manual is applicable for the operation and maintenance of all GK 11"-5000 ABOPs manufactured by Hydril. The illustrations of assemblies and operation and maintenance procedures in this manual are typical and represent most configurations. Variations in configuration are noted in the procedures where applicable. In addition, illustrated parts lists are provided for component replacement.

R

Operator's Manual PAGE v


CONTENTS PAGE Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

iv

OPERATOR QUICK REFERENCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

vii

SECTION 1.0 – INSTALLATION AND OPERATION 1.1 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.1.1 Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.1.2 Weights and Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.1.3 Annular BOP Removal and Installation Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A. Annular BOP Removal Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B. Annular BOP Installation Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.2 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.2.1 Operating Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A. Opening the Annular BOP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B. Closing the Annular BOP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.2.2 Operating Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.2.3 Operational Characteristics Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.2.4 Principle of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.2.5 Surface Operation and Hookup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.2.6 Surface Stripping Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1-1 1-1 1-1 1-1 1-1 1-1 1-3 1-3 1-3 1-3 1-3 1-3 1-4 1-6 1-7

SECTION 2.0 – PHYSICAL DATA 2.1 2.2 2.3 2.4 2.5 2.6 2.7

Engineering Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Bolt and Wrench Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Lubricant List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Dimensions - Screwed Head . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Dimensions - Latch Head . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . API Ring t Flange Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Clamp Hub Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-1 2-1 2-1 2-2 2-3 2-4 2-5

SECTION 3.0 – PACKING UNITS AND SEALS 3.1 Packing Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.1.1 Packing Unit Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.1.2 Packing Unit Replacement-Screwed Head . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.1.3 Packing Unit Replacement-Latch Head . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.2 Seals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.3 Wear Bands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-1 3-2 3-3 3-4 3-5 3-6

SECTION 4.0 – MAINTENANCE AND TESTING 4.1 4.2 4.3 4.4 4.5 4.6 4.7

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Maintenance Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Seal Testing - GK® Without Wear Bands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Seal Testing - GK® With Wear Bands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Packing Unit Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . BOP Modifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4-1 4-1 4-3 4-4 4-5 4-6 4-7

SECTION 5.0 – DISASSEMBLY AND ASSEMBLY 5.1 5.2 5.3 5.4

Disassembly - Screwed Head Without Wear Bands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Assembly - Screwed Head Without Wear Bands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Disassembly - Screwed Head With Wear Bands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Assembly - Screwed Head With Wear Bands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5-1 5-3 5-6 5-8

R

Operator's Manual PAGE vi


CONTENTS (CONTINUED) SECTION 5.0 – DISSASSEMBLY AND ASSEMBLY (CONTINUED) 5.5 5.6 5.7 5.8

Disassembly - Latched Head Without Wear Bands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Assembly - Latched Head Without Wear Bands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Disassembly - Latched Head With Wear Bands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Assembly - Latched Head With Wear Bands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5-11 5-13 5-16 5-18

SECTION 6.0 – PARTS AND STORAGE 6.1 6.2A 6.2B 6.3 6.4 6.5A 6.5B 6.6 6.7 6.8

Parts List - Screwed Head Without Wear Bands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Parts List - Screwed Head With Wear Band Modification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Parts List - Screwed Head Wear Band Modification Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Parts List - Screwed Head With Wear Bands At Manufacture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Parts List - Latched Head Without Wear Bands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Parts List - Latched Head With Wear Band Modification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Parts List - Latched Head Wear Band Modification Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Parts List - Latched Head With Wear Bands At Manufacture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Preventor Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Rubber Goods Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6-1 6-2 6-3 6-4 6-5 6-6 6-7 6-8 6-9 6-10

R

Operator's Manual

1-vii


PAGE vii

OPERATOR QUICK REFERENCE

Figure 1 Standard Hookup

Closing Pressure Opening Pressure

Control Pressures ▲ Surface Control Pressure —psi WELL PRESSURE—psi

Initial* Closure

500

1500

2500

3500

5000

2 3/8”

900

825

650

475

300

50

2 7/8"

800

725

550

375

200

50

3 1/2"

825

450

275

100

50

50

4 1/2"-5 "

450

375

225

100

50

50

5 1/2"-8 5/8"

350

275

125

50

50

50

1150

1150

Pipe Size

Close cautiously to prevent collapse of casing. CSO

1150

1150

1150

1150

▲ *Use closing pressure shown at initial closure to establish seal off and reduce closing pressure proportionally as well pressure is increased. Well pressure will maintain closure after exceeding the required level. See Section 1 for control pressure graph. Closing pressures are average and will vary slightly with each packing unit. Optimum stripping is obtained by adjusting the control pressure to achieve a slight drilling fluid leakage as the tool t es through the packing unit.

R

PAGE viii

Operator's Manual

1-viii


ANNULAR BOP TESTING AND OPERATION Proper Procedure for pressure testing any annular blowout preventer (BOP) ensures subsequent seal off and maximum packing unit life. Reliable seal off tests are made by initially closing the packing unit with prescribed closing chamber pressure on the recommended size test pipe, proportionally reducing closing pressure as well pressure is increased, and by determining the remaining piston travel after seal off is achieved. Optimum packing unit life is obtained by testing at low rubber stress levels. Minimum packing unit stress is achieved by use of the minimum closing chamber pressure that will initiate and maintain seal off on the recommended size test pipe. The GK® blowout preventer is designed to be well pressure assisted in maintaining packing unit seal off once initial seal off has been effected. Initial seal off is effected by applying pressure to the closing chamber. As well pressure or test pressure is increased, the closing force on the packing unit also increases. As well pressure exceeds the required level the packing unit is maintained closed on the recommended size test pipe by well pressure alone. Once initial seal off is achieved, it is recommended that closing pressure be proportionally reduced as well pressure is increased in order to maintain the optimum closing

force on the packing unit. Optimum closing forces for high well pressures may require careful application of pressure to the opening chamber. Closing pressure required to effect initial seal off may vary slightly between individual packing units. Begin the test with the recommended initial closing pressure. Piston Stroke can be measured on GK® blowout preventers through a vertical age in the top of the BOP head.* The maximum and minimum distances from the top of the head to the top of the piston are stamped on the BOP head and are also listed in the table below. Piston stroke remaining at seal off is a direct indicator of remaining packing unit life. Record the piston stroke and the closing pressure at seal off for each test. Compare with previous results and with maximum piston stroke for the BOP to ensure subsequent seal offs. A valid test on any annular BOP is only achieved when the remaining piston stroke is measured at test seal off.

*Older model BOPs may not have vertical age in head. See Section 4, “Maintenance and Testing” for information on modification.

OPERATIONAL DATA 3

Bore

11 in.

279.4 mm

Closing Chamber Volume

9.81 gal. (U.S.)

37.1 liters

Opening Chamber Volume

8.08 gal. (U.S.)

30.6 liters

Recommended Test Pipe Size

3 1/2 in.

88.9 mm

Full Piston Stroke

7 1/8 in.

181 mm

TAPE MEASURE

Distance From Top of Head To Top of Piston Maximum — Piston Full Down

11 1/8 in.

283 mm

Minimum — Piston at Full Stroke

4 in.

102 mm

Figure 2 Piston Stroke Measurement

2

1

5/16" ROD

R

Operator's Manual GK® 11"-5000 PSI Annular Blowout Preventer

1.0 INSTALLATION AND OPERATION 1.1 Installation 1.1.1 Safety Precautions WARNING: THIS IS VERY HEAVY EQUIPMENT, AND EXTREME SAFETY PROCEDURES MUST BE FOLLOWED DURING LIFTING OPERATIONS. BE SURE THAT LIFTING EQUIPMENT IS IN GOOD CONDITION AND CAPABLE OF HANDLING THE LOAD. WARNING: DO NOT USE THE FOUR LIFT EYES MOUNTED ON THE ANNULAR BOP BODY TO LIFT THE BOP STACK ASSEMBLY. THESE LIFT EYES ARE FOR LIFTING THE GK 11"-5000 PSI ANNULAR BOP ASSEMBLY ONLY.

1.1.2 Weight and Dimensions For dimensions and weight, refer to Section 2,"Physical Data."

1.1.3 Annular BOP Removal and Installation Procedures NOTE: For initial installation, refer to “Surface Operation and Hookup” and “Surface Stripping Operations” in this section for information on connection of hydraulic operating lines to the blowout preventer. The GK 11"-5000 PSI Annular BOP is usually installed at the top of a BOP stack. Normally, the annular BOP does not require removal from the BOP stack and subsequent installation for field repair. The procedures below are intended for those circumstances where the annular BOP would require removal from the BOP stack for inspection of the bottom connection or for other reasons and subsequently would require installation again. A. Annular BOP Removal Procedure 1. Gather a lifting apparatus for lifting the annular BOP assembly. CAUTION: Ensure that the lifting apparatus is adequate to safely the weight of the annular BOP assembly. NOTE: Refer to Section 2, "Physical Data" for estimated weight. 2. Disassemble the BOP stack to the point where the annular BOP can be removed. 3. Attach the lifting apparatus to the four padeyes/anchor shackles on the body of the annular BOP (Refer to Figure 1-1 for sling arrangement). 4. Disconnect all hydraulic lines. 5. Disconnect bottom connection and lift the annular BOP free.

B. Annular BOP Installation Procedure 1. Gather the following tools and materials: a. Lifting apparatus for lifting the annular BOP assembly. CAUTION: Ensure that the lifting apparatus is adequate to safely the weight of the annular BOP assembly. NOTE: Refer to Section 2, "Physical Data" for estimated weight. b. Lightweight oil (Gulf "Harmony No. 46" or Exxon "Coray 100") c. One new API ring gasket for bottom connection d. Emery cloth, 240-grit or finer 2. Inspect the ring groove in the mating flange. Remove minor damage by polishing the groove with 240-grit or finer emery cloth. Apply light machine oil to the ring groove and wipe it clean, leaving only a film of oil on the surface. 3. Apply lightweight oil to a new API ring gasket and wipe it clean, leaving only a film of oil on the surface. Install the new ring gasket into the ring groove of the mating flange. 4. Attach lifting apparatus to the four padeyes/anchor shackles on the annular BOP (refer to Figure 1-1 for sling arrangement). 5. Lift and position the annular BOP over the mating connection. 6. Inspect the ring groove in the connection of the annular BOP. Remove minor damage by polishing the groove with 240-grit or finer emery cloth. Apply lightweight oil to the ring groove and wipe it clean, leaving only a film of oil on the surface. 7. Lower the annular BOP onto the mating connection, aligning the hydraulic connection ports with the hydraulic lines and taking care not to damage the ring gasket. 8. Make up the bottom connection. 9. Remove the lifting apparatus. 10. Connect the Open and Close hydraulic lines to the annular BOP.

PAGE 1-1

R

Operator's Manual PAGE 1-2


Figure 1-1 Sling Arrangement for Lifting BOP

R



1.2 Operation 1.2.1 Operating Procedures 2. A. Opening the Annular BOP 1. To open the annular BOP, vent operating pressure from the Close chamber. 2. Apply opening pressure to the Open chamber. Refer to “Surface Operation and Hookup” in this section. B. Closing the Annular BOP 1. To close the annular BOP, vent operating pressure

from the Open chamber. Apply closing pressure to the Close chamber. Refer to “Surface Operation and Hookup” in this section.

1.2.2 Operating Data Refer to Section 2, "Physical Data." 1.2.3 Operational Characteristics Summary The GK sucessfully ed the fatigue and stripping life tests. For sealing characteristics test data, Hydril.

Head Wear Plate Packing Unit Clamping Screw Radial Latch

Opening Chamber Piston Closing Chamber Inner Sleeve Body

Figure 1-2 Cutaway view of GK® with packing unit fully open.

R



1.2.4 Principle of Operation The Hydril® GK 11"-5000 PSI annular BOP (Figure 1-2) is an annular blowout preventer as defined by API Specification 16A. It will close and seal off on drill pipe, tool ts, tubing, casing, or wireline in the wellbore or completely seal off the open hole to full rated working pressure. Seal off is effected by raising the piston which causes the packing unit to be squeezed inward to a sealing engagement with anything in the bore or with itself on open hole (refer to Figures 1-3 through 1-7). The piston is raised by applying hydraulic pressure to the closing chamber. The optimum closing pressure is the minimum pressure that will maintain a complete seal under existing operational conditions. During well control operations, drill pipe can be rotated and tool ts stripped through a closed packing unit while maintaining a full seal on the pipe. Any normal closing unit having a separate regulator valve for the annular blowout preventer and sufficient accumulator volume can be used to operate the GK 11"-5000 PSI annular blowout preventer. Any clean, light petroleum hydraulic oil will serve as a hydraulic operating fluid. Fresh water may be used in a 50/50 water and ethylene glycol mixture with a corrosion inhibitor added. (CAUTION: Do not use synthetic fluids or fuel oils. Use of these types of operating fluids will cause serious damage to seals.) For additional discussion and specific hydraulic fluid recommendations, refer also to Hydril Engineering Bulletin EB 99009 on the Hydril Website www.hydril.com. This blowout preventer has been developed primarily for use on surface installations. In addition, the GK® meets the requirements of API Recommended Practices – R.P. 53* (available from the American Petroleum Institute, Production Department, 1220 L Street, Northwest, Washington, DC 20005) as well as NACE 10-75-43. NOTE: Some GK® assemblies manufactured before 1980 are not be certified to NACE. Certification of these units must be performed at a Hydril Authorized Repair Facility (ARF). If certification is desired, Hydril or visit Hydril Website www.hydril.com for the nearest ARF.

Figure 1-3 Upward force exerted by the piston squeezes packing unit rubber inward into a sealing engagement.

R


Figure 1-4

Figure 1-5

Cutaway view of GK® BOP with packing unit fully open. The Hydril® GK® opens to full bore to allow age of large-diameter tools through open bore as well as maximum annulus flow of drilling fluids. Packing unit always returns to the open position due to normal resiliency of rubber packing unit. Retention of opening chamber pressure will provide positive control of piston and reduce wear caused by vibration.

Cutaway view of GK® BOP with packing unit closed on drill pipe. The packing unit seals off on tool ts, drill pipe, casing, tubing, or wireline to rated pressure.

Figure 1-6

Figure 1-7

Cutaway view of GK® BOP with packing unit closed on square kelly. The packing unit seals off on square or hexagonal kellys to rated pressure.

Cutaway view of GK® BOP with packing unit closed on open hole. Complete closure of packing unit safely holds well pressure, without leakage, equal to the rated working pressure of the preventer.

PAGE 1-5

R


1.2.5 Surface Operation and Hookup The surface hookup of the GK® shown in Figure 1-8 connects the hydraulic control lines to the opening and closing chambers of the BOP Pressure applied to the closing chamber raises the piston and effects the initial seal between the packing unit and drill pipe. Well pressure or test pressure also acts on the piston below the sealed-off packing unit and further increases the closing force acting on the packing unit. As the well pressure or test pressure exceeds the required level, the preventer is maintained closed by well pressure alone. As well pressure further increases, the closing force on the packing unit also increases. Closing pressure should be proportionally reduced as well pressure is increased in order to maintain optimum closing force on the packing unit and prolong packing unit life. The Control Pressure Graph, Figure 1-9, shows the relationship of closing pressure and well pressure required to effect optimum seal off for the GK® 11”-5000 PSI BOP. During normal drilling operations, it is recommended that the pressure regulator valve for the GK® be set at the initial closing pressure shown for the size pipe being used. This

Closing Pressure Opening Pressure

Figure 1-8 Standard Hookup pressure will ensure that initial seal off is achieved should a “kick” be encountered. During BOP testing operations, once initial seal off is achieved, closing pressure should be proportionally reduced as well pressure is increased.

1500

▲ CLOSING PRESSURE-PSI

PAGE 1-6

CSO

1000 *Closing pressures are average and will vary slightly with each packing unit. Use closing pressure shown at initial closure to establish seal off and reduce closing pressure proportionally as well pressure is increased. Well pressure will maintain closure after exceeding the required level. **Close cautiously to prevent collapse of casing. Operating pressure may vary at temperatures other than 70oF.

500

23 /8" PIP E

**5 1

/2" th

ru 8

4 1/ 2" th ru 5 " 5/8"

PIPE

PIP E

3 1/ 2" P IPE

2 7/ 8" P IPE

0 0

1000

Figure 1-9 Average Control Pressure - GK 11"-5000 PSI

2000

3000

WELL PRESSURE-PSI

4000

5000

R



1.2.6 Surface Stripping Operations Drill pipe can be rotated and and tool ts stripped through a closed GK® packing unit (Figure1-10) while maintaining a full seal off on the pipe. Longest life for the packing unit is obtained by adjusting the closing forces low enough to maintain a seal on the drill pipe with a slight amount of drilling fluid leakage as the tool t es through the packing unit. This drilling fluid leakage indicates optimum seal off for minimum packing unit wear and provides lubrication for the drill pipe motion through the packing unit. When rotating in a closed packing unit, it is recommended that the pipe be reciprocated (moved up and down) to minimize heat build up between the drill pipe and the

packing unit. Slow tool t stripping speeds reduce surge pressures, and thus prolong packing unit life. The pressure regulator valve should be set to provide and maintain the proper control pressure. If the pressure regulator valve does not respond fast enough for effective BOP control, a surge absorber (accumulator) shown in Figure 1-11 should be installed in the closing chamber control line adjacent to the blowout preventer. Precharge the accumulator to one-half of the closing pressure required to effect a seal off at the existing well pressure for the pipe size in use.

Surface Hookup

Closing Pressure

Closing Pressure

Opening Pressure

Opening Pressure

Figure 1-10 Example Precharge Calculation: 500 psi well pressure, 3 1/2" drill pipe Precharge = 0.50 (Closing Pressure). From Figure 1-8: Closing Pressure = 450 psi Precharge = 0.50 x 450 psi Precharge = 225 psi

Figure 1-11

R



R



2.0 PHYSICAL DATA 2.1 Engineering Data English

Metric

Bore . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 inches Working Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5000 PSI

279.4 mm 351.55 kg/cm2

Shell Test Pressure (Factory Test Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10,000 PSI Closing Chamber Test Pressure (Factory Test Only) . . . . . . . . . . . . . . . . . . . . . . . . 5000 PSI

703.1 kg/cm2 351.5 5 kg/cm2

Opening Chamber Test Pressure (Factory Test Only) . . . . . . . . . . . . . . . . . . . . . . . . 5000 PSI Volume—Closing Chamber . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9.81 gallons

351.55 kg/cm2 37.1 liters

Volume—Opening Chamber . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8.08 gallons Piston Stroke . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 1/8 inches

30.6 liters 181 mm

Port Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1” NPT* Weight-Single (Approximate—varies with connectors) . . . . . . . . . . . . . . . . . . . . . . . 8,200 lb

— 3,720 kg

* 1 1/4" or 1 1/2" NPT available on request

2.2 Bolt and Wrench Data Ref. No.

Description

Thread

Wrench Size

17

Pipe Plug—Piston Indicator

1/2" NPT

3/8" Hex Key

18

Inner Sleeve Screw

1/2"-13UNC

3/4" Hex

19

Head Lock Screw

1"-8UNC

30

Wear Plate Cap Screw

...

Recommended Torque Lb/Ft N•m 50

69

55-75

75-102

1 1/4" Hex

100

136

1/2-13UNC

1/2" -12pt. Socket

70

95

Eyebolt, Piston x 10" Lg.

5/8"-11UNC

....

Snug

Snug

...

Eyebolt, Head x 1 3/4" Lg.

1 1/4"-7NC

....

Snug

Snug

...

Protector Plate Screw

1/2"-13UNC

3/4" Hex

Snug

Snug

350-475

475-644

150

203

LATCHED HEAD ONLY 22

Jaw Clamping Screw

2 1/4"-8UN

2 1/2" Hex

23

Spacer Sleeve Screw

5/8"-18 UNF

3/4" Hex Key

2.3 Lubricant List Type

Source

Lightweight Oil

Gulf "Harmony No. 46" or Exxon "Coray 100" or Equivalent

Thread Lubricant

Neverseez (0.069 Coefficient of Friction) or Equivalent Moly Paste 503 (0.065 Coefficient of Friction) or Equivalent

Nonpetroleum Base Oil

Castor Oil

Corrosion Inhibitor Grease

Cortec VCI 369

Vapor Phase Corrosion Inhibitor

Cortec VCI 609

R


2.4 Dimensions - Screwed Head

H AS CAST J K

E F

A AS CAST

G

B CLAMP HUB

D AS CAST

*OPENING PORT

C STUDDED

PAGE 2-2

*CLOSING PORT M AS CAST

N AS CAST

Figure 2-1

O AS CAST

Outside DimensionsScrewed Head

* 1" NPT, 1 set of ports, 45o from lifting lug unless otherwise specified. NOTE: Lifting lugs split lower connection stud holes and are equally spaced 90o apart. Lifting lugs are 1-1/4" thick with 1-1/2" diameter holes.

Nominal Dimensions — Inches A

B

C

D

E

F

19.06

5.69

13 3/16

▲5M

▲10M

▲5M

▲10M

▲5M

▲10M

47.75

48.50

44.88

...

39.63

40.25

G

H

J

K

L

M

N

O

11.81

44.25

37.50

35.75

...

2.00

32.00

36.75

▲ Lower Connector Pressure Rating

R



2.5 Dimensions - Latched Head

H AS CAST J K E F

g *CLOSING PORT

R

A FLANGED

C STUDDED

*OPENING PORT

B CLAMP HUB

D AS CAST

L AS CAST

M AS CAST

Figure 2-2

N AS CAST

Outside Dimensions Latched Head

*1” NPT, 1 set of ports, 18” from lifting lug. NOTE: Lifting lugs are equally spaced 90o apart. Lugs are 2.12” thick with 1.75” diameter holes.

Nominal Dimensions — Inches A

B

C

D

▲5M

▲10M

▲5M

▲10M

▲5M

▲10M

48.25

49.00

45.31

...

40.06

40.69

19.88

G

H

J

K

L

M

N

11.25

44.25

42.25

36.38

2.00

32.00

36.75

▲ Lower Connector Pressure Rating On BOPs built after serial number 69730: D= 27.50

E

4.00

F

14.19

R



2.6 API Ring t Flange Connections

C

C

B A

Bolted Flange, Using Stud Bolts.

Studded Flange, Using Studs.

Figure 2-3 Bolted and Studded Flange Specifications

FLANGE Nominal Size (Inches)

Bore Dia. (Inches)

Max. API Service Pressure Rating (PSI)

11

11

5000

11

11

10,000

SEAL RING O.D. (Inches)

Thickness (Inches)

† Dia. C (Inches)

API Ring

23

4 11/16

12 3/4

RX-54

25 3/4

5 9/16

14.064

BX-158

BOLTS & STUDSa No. Req.

Lengthb (Inches)

Size

Stud Bolts A

Studs B

Bolt Circle Dia. (Inches)

12

1 7/8

14 1/2

10 1/4

19

16

1 3/4

15 3/4

10 1/4

22 1/4

POINT HEIGHT OF STUD BOLTS Bolt Diameter, Inches

Max. Point Height Inches

1/2 to 7/8 . . . . . . . . . . . . . . . . . . . . . . Over 7/8 to 1 1/8 . . . . . . . . . . . . . . . . Over 1 1/8 to 1 5/8 . . . . . . . . . . . . . . Over 1 5/8 to 1 7/8 . . . . . . . . . . . . . . Over 1 7/8 to 2 1/2 . . . . . . . . . . . . . .

1/8 3/16 1/4 5/16 3/8

a

Bolt material shall be of a quality and strength not less than specified by ASTM A-193, Grade B7. Nuts shall be of a quality not less than ASTM A-194, Grade 2H. Stud bolts are threaded full length.

b

Lengths shown herein are overall lengths, including point at both ends, as shown in table. Dimensions shown are outside diameters of 6BX flange grooves, or pitch dim. in case of 6B grooves.

†

R



2.7 Clamp Hub Connections

J

A

C

A

G

G

B

B

E

E

F

F

H

H

Figure 2-4 Hub Connection Specifications

HUB Bore Size A (Inches)

Rated Working Pressure (PSI)

11

11

11

11

Hub Size (Inches)

Seal Ring No.

Hub Dimensions (Inches) RX Only Standoff D C

RX

BX

B

5000

53

...

16 1/4

3 3/4

15/32

...

10,000

...

158

16 1/4

...

...

3 5/8

NOTE: API 16A 1st Edition Nov 1, 1986 Does Not Include Clamps.

Clamp Dimensions (Inches) ▲

E

F

G

H

20 13/16

28 1/2

6 3/4

...

20 13/16

28 1/2

6 3/4

...

▲ Clamp dimensions may vary from those shown.

J

R



R


3.0 PACKING UNITS AND SEALS 3.1 Packing Units The heart of the GK® blowout preventer is the packing unit. The unit is manufactured by Hydril from high quality rubber, reinforced with flanged steel segments. Each unit has a large volume of tough, feedable rubber to meet any requirement. The molded-in steel segments have flanges at the top and bottom These segments anchor the packing unit within the blowout preventer and control rubber extrusion and flow when sealing off well pressures. Since the rubber is confined and kept under compression, it is

Figure 3-1 Cutaway drawing showing how rubber is molded around steel segments.

resistant to tears and abrasion. All annular blowout preventer packing units are subjected to wear during closure and stripping. The design of the Hydril® GK® blowout preventer causes closure wear to occur on the outside of the packing unit while stripping wear occurs on the inside. Because the packing unit uses the principle of feeding rubber from the back of the packing unit to the bore, stripping life may be affected by a packing unit that is worn on the backside.

PAGE 3-1

R



3.1.1 Packing Unit Selection Because of the importance of the packing unit to the operation of the blowout preventer and to the safety of the crew and rig, only genuine Hydril® packing units should be used as replacements for original equipment. All Hydril® packing units are tested to full rated pressure inside a test blowout preventer as part of standard performance tests before being furnished to the consumer. Packing units for Hydril® blowout preventers are manufactured from compounded natural rubber or nitrile rubber. Natural Rubber is compounded for drilling with waterbase drilling fluids. Natural rubber can be used at operating o o temperatures down to –30 F (–35 C). When properly operated, the compounded natural rubber packing unit will usually provide the longest service life. This all-black packing unit is identified by a serial number with the suffix "R" or "NR." Nitrile Rubber (a synthetic compound) is for use with oilbase or oil-additive drilling fluids. It provides reliable service with oil-base muds, when operated at temperao o tures below 20 F (–7 C). The nitrile rubber packing unit is identified by a red colored band and a serial number with the suffix "S" or "NBR." Seals for Hydril® blowout preventers are manufactured from a special nitrile rubber material which provides dependable service in sealing against oil gas, or water. Expected H2S Service does not affect selection of packing unit material. H2S service will reduce the service life of rubber products, but the longest service life is obtained by matching the packing unit material with the requirements of the specific drilling fluid. Performance of elastomeric materials can vary significantly, depending on the nature and extent of exposure to hydrogen sulfide. The operator should monitor pressure sealing integrity by frequently performing a packing unit seal test on the pipe diameter currently in use to assure no performance degradation has occurred. Storage Conditions such as light, heat or adverse conditions are significant factors in the storage life of packing units, as covered in Section 6.3 and should be avoided.

No Band

Figure 3-2 Natural Rubber Packing Unit – No Band

Red Band

Figure 3-3 Synthetic Rubber Packing Unit – Red Band

R



3.1.2 Packing Unit Replacement– Screwed Head To replace the packing unit, use the following procedure: NOTE: The procedure that follows is the short version of more detailed procedure in Section 6. 1. Remove head lock screw. 2. Install eyebolts and unscrew blowout preventer head counter-clockwise (Figure 3-4). 3. Lift off blowout preventer head (Figure 3-5). 4. Lift out packing unit (Figure 3-6). 5. Lubricate piston bowl with castor oil. 6. Install new packing unit, lubricated with castor oil. 7. Clean and lubricate head and body threads with Neverseez lubricant. 8. Replace head and tighten to align hole for lock screw. 9. Install head lock screw and torque to 100 lb-ft.

OPENING TORQUE

Figure 3-4

NOTE: If the head was improperly installed at last reassembly, it may be necessary to apply considerably more torque on the head by the use of a catline or winch while alternately applying and releasing pressure to the opening chamber (1500 psi maximum). CAUTION: Do not attempt to loosen the head by applying heat. Refer to Section 5, “Disassembly and Assembly” for further information.

Figure 3-5

Figure 3-6

R



3.1.3 Packing Unit Replacement – Latched Head The latched head design of the GK® blowout preventer allows for easy replacement of the packing unit and eliminates loose parts that can be lost downhole or overboard. To replace the packing unit, use the following procedure: NOTE: The procedure that follows is the short version of more detailed procedurew in Section 6. 1. Retract jaw clamping screws four turns to release the jaws from the head (see Figures 3-8 and 3-9). 2. Remove head clamps and screws from top of head. 3. Lift off preventer head (see Figures 3-5 and 3-10). 4. Lift out the packing unit (see Figure 3-6) and lubricate the piston bowl with castor oil. 5. Install the new packing unit (see Figure 3-6), lubricated with castor oil. 6. Install the head (see Figure 3-11). HEAD 7. Tighten jaw clamping screws four turns and torque to 350 - 475 lb-ft (475-644 N•m). See Figure 3-7.

Figure 3-9 Head in place but jaw and jaw clamping screws have been retracted (four turns).

Head Clamp Screw Head Clamp

Clamping Screw Pipe Plug SleeveScrew Spacer Sleeve Jaw

Figure 3-10 Head removed, but all latching mechanisms remain in body.

Head

Standoff

Figure 3-7 Head latched in place and jaw clamping screws tightened.

Figure 3-11 Figure 3-8 Retract jaw clamping screws (4-turns counterclockwise).

On assembly, if standoff between head and body occurs, use head clamps to pull head fully into place and eliminate standoff.

R



3.2 Seals The seals for Hydril® blowout preventers are manufactured from a special synthetic rubber material for long troublefree sealing service. The hydraulic operating fluid may be clean, light petroleum hydraulic oil, or water with soluble oil added. In cold climates, antifreeze should be added to prevent freezing (CAUTION: To prevent seal damage, Do Not use synthetic fluids in the hydraulic operating system). For additional discussion and specific hydraulic

fluid recommendations, refer also to Hydril Engineering Bulletin EB 99009 on the Hydril Website www.hydril.com. The dynamic seals are all molded, lip-type, pressureenergized rings. The static seals are of O-ring and square ring configuration. For seal replacement procedure, see Section 5, “Diassembly and Assembly.” For seal maintenance and testing, refer to Section 4.

DYNAMIC SEALS

STATIC SEALS

DOUBLE U-SEAL cross-section with nonextrusion rings

U-SEAL cross-section

O-RING cross-section

Figure 3-12

SQUARE RING cross-section

R



3.3 Wear Bands Manufactured from tough durable thermoplastic and installed on new and modified models, wear bands improve the performance of the GK® BOP by protecting sealing surfaces on the piston and body from metal to metal . As a result, seal life is increased and wear to the sealing surfaces on the piston and body is reduced significantly. Installed on models with wear bands, the rubber wiper

ring prevents drilling mud and debris from entering the space between the upper piston and the head and possibly damaging the wear bands. Models not equipped with wear bands can be modified at a Hydril Authorized Repair Facility (ARF). Hydril or refer to Hydril Website www. hydril.com for the nearest ARF. Refer also to Section 4.7 for additional modifications available.

Wiper Ring

Head Wear Band

Head to Piston Seal Piston Sealing Surface Body Sealing Surfaces

Wear Band Lower Piston Seal

Figure 3-13

R



4.0 MAINTENANCE AND TESTING WARNING: HYDRIL IS NOT RESPONSIBLE FOR ANY ALTERATIONS, MODIFICATIONS OR REPAIRS TO THE BLOWOUT PREVENTER (BOP), ITS INTERCONNECTS AND COMPONENTS, UNLESS PERFORMED WITH HYDRIL SUPPLIED PARTS AND THE WORK PERFORMED BY A HYDRIL AUTHORIZED REPRESENTATIVE. ALTERATIONS, MODIFICATIONS, OR REPAIRS PERFORMED OTHERWISE MAY RESULT IN DAMAGE TO THE BOP OR FAILURE OF THE BOP TO OPERATE AS DESIGNED AND MAY RESULT IN SERIOUS PROPERTY DAMAGE, PERSONAL INJURY OR DEATH. UNAUTHORIZED ALTERATIONS, MODIFICATIONS, REPAIRS OR USE OF PARTS OTHER THAN THOSE SUPPLIED BY HYDRIL WILL VOID THE STANDARD WARRANTY OF THE BOP AS OUTLINED IN THE AND CONDITIONS AGREEMENT. WARNING: BEFORE THE INITIAL START UP, OR PRIOR TO POST REPAIR START UPS, CONTAMINANTS, DEBRIS, AND OTHER FOREIGN MATERIALS HAVE BEEN FLUSHED FROM THE

FLUID SUPPLY LINES. FAILURE TO DO SO MAY RESULT IN DAMAGE TO THE BOP OR FAILURE OF THE BOP TO OPERATE AS DESIGNED AND MAY RESULT IN SERIOUS PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.

4.1 Troubleshooting Troubleshooting the annular BOP is provided in the form of a fault analysis tree. If the packing unit fails to close and seal, refer to Figure 4-1.

4.2 Maintenance Schedule Periodic maintenance is a very important part of keeping the Hydril® GK 11"-5000 PSI Annular BOP in good operating condition. Not only will regular maintenance extend the service life of the equipment, but it will also help to eliminate unnecessary down time. This section contains a maintenance schedule (Table 4-1) that is designed to help maintain the annular BOP by displaying in tabular form the recommended service interval for each required maintenance operation.

TABLE 4-1 MAINTENANCE SCHEDULE Maintenance Operations I = Inspect; R = Replace; T = Pressure Test: P = Inspect Precharge Item

Equipment/Component

Service Interval & Maintenance Operations As Required

a b c

1

GK Annular BOP

2

Packing Unit

T

3

Seals

T

4

Wear Bands

Yearly

Refa

Between Wellsc I

4.3

Rb

I

4.0;3.0

Rb

I

4.0;5.0

Rb

I

5.0

Paragraph where maintenance procedure is located. Not to exceed 24 calendar months. Hydril only provides recommendations for inspections and maintenance. Depending on the drilling program, it may not be possible to inspect the BOP between wells.

R



PACKING UNIT FAILS TO CLOSE & SEAL

PACKING UNIT FAILS TO CLOSE

PACKING UNIT FAILS TO SEAL

WORN WEAR PLATE

PACKING UNIT LEAKAGE

Increase closing pressure or replace as necessary.

Inspect wear plate and replace as necessary.

CONTROL SYSTEM PROBLEMS

Refer to operations and maintenance manual.

MECHANICAL PART FAILURE

SEAL LEAKAGE

Test seals and replace as necessary.

Latched Head

PISTON STROKE

LATCH FAILURE

Check piston stroke.

Inspect latch and make repairs.

CLAMPING SCREW FAILURE

Inspect latch and make repairs.

Latched Head & Screwed Head

GALLED PISTON

Inspect piston and make repairs.

GALLED WEAR PLATE

Inspect wear plate and make repairs.

BENT PACKING UNIT INSERTS Inspect packing unit and replace if necessary.

Figure 4-1 GK 11"-5000 Annular BOP Fault Analysis Tree - Packing Unit Fails to Close and Seal

R



4.3 Inspection NOTE: The Hydril® GK® blowout preventer is a primary pressure vessel. The blowout preventer surfaces exposed to wellbore fluids will meet NACE Standard MR-01-75. Proper handling and repair are required to maintain any original integrity. Field welding is not recommended as it, 1) induces undesirable stresses which must be relieved by proper heat treating procedure or controlled by special welding procedures and 2) negates certification to NACE . If your assembly was manufactured before 1980, it may not be certified to NACE. Welding, machining, stress relieving or NACE certification must be performed at a Hydril Authorized Repair Facility (ARF). Hydril or go to Hydril Website www.hydril.com for the nearest ARF. Prior to placing the GK® blowout preventer into service, the following visual inspections should be performed (step numbers match Figure 4-2): 1. Inspect upper and lower connections for pitting, wear, and damage, especially in ring grooves and stud bolt holes. Worn or damaged ring grooves must be welded, machined, and stress relieved (see “NOTE” above). Worn or damaged stud bolt holes can be drilled and tapped to the next larger size and fitted with step-studs. 2. Check the body for wear and damage, especially in the internal cylinder walls for pits and vertical scores. Minor pits and scores can be removed in the field with emery cloth. Repaired surface should be coated with castor oil. Severe pits, scores, and cracks may require machining and/or welding (see “NOTE” above). 3. Inspect the vertical bore for excessive wear and damage from drill string and drill tools, especially in the area of the ring grooves. If wear is excessive, see “NOTE” above. 4. Check the inner body sleeve for wear, damage, and looseness. Check slots in sleeve for cuttings which may restrict piston movement. Some model BOPs have a welded body sleeve and may be modified by conversion to a bolted sleeve. the nearest Hydril ARF (see “NOTE” above) for modification. 5. Check for piston damage and wear, especially the inner and outer walls for pits and vertical scores and the tapered bowl for pits and gouges. Minor pits and scores on the walls can be removed in the field with emery cloth. Repaired surface should be coated with castor oil. Severe pits and scores may require machining and/or welding. the nearest Hydril ARF (see “NOTE” above) for repair. Pits and gouges in the tapered bowl should be filled with a permanent type adhesive, such as epoxy. Sharp or rolled edges should be removed with emery cloth or a grinder. Repair is satisfactory when the surface is relatively smooth. 6. Check the wear plate on the inner bottom face of the head for wear. In addition to the aging process of time and use, wear of this metal surface is produced by the combination of vertical (upward thrust) and lateral forces. These forces are generated each time the packing unit is closed. Severe wear is exhibited in the form of grooves or channels

shaped by the steel segments of the packing unit. The inner bottom face of the head serves as a wall to prevent upward movement of the packing unit. Friction between these metal surfaces is controlled at a level which does not impair lateral movement of the packing unit. Repair of this surface is accomplished by replacing the wear plate. Some models of this BOP do not have the wear plate, but may be modified. the nearest Hydril ARF (see “NOTE” above) for modification. 7. Inspect the packing unit for wear, cracking, hardness, and correct elastomer composition. See Section 3 for packing unit information and this section for packing unit testing. 8. Check seals and wear bands (if equipped) for nicks, cuts, fraying of lips, and abrasion. Worn or damaged seals and wear bands should be replaced. Hydril recommends that all seals and wear bands be replaced after one year service or whenever the BOP is disassembled. See Section 4 for pressure testing of seals. 1 3 6 8 7 8 5

2

8

8

4

3

1

Figure 4-2

R



4.4 Seal Testing - GK® Without Wear Bands When it is known or suspected that a seal within the GK blowout preventer is leaking, it is recommended that all seals be replaced. However, if only the seal in question is to be replaced, it must first be determined which seal is leaking. The following procedure is provided: Refer to Figure 4-3 while following this procedure.

1. Gather the following tools and materials: a. 5000 PSI (345 Bar) pressure source b. 3 1/2-inch test pipe c. Blind flange, 11”-5000 PSI d. RX-54 ring gasket 2. Install the annular BOP onto test stump with hydraulic pressure source connected to the Open and Close ports. 3. Install test pipe into test stump. 4.

5.

6.

Test seals 9 (lower) and 10 (upper). a. Pressurize closing chamber. The test pressure to be used in the closing chamber should be the initial closing pressure required using the recommended test mandrel if a packing unit is installed (1500 PSI/ 104 Bar if no packing unit is installed). b. Open opening chamber to atmosphere. IF: Closing fluid is seen at opening chamber—seal 9 (lower) is leaking. IF: Closing chamber pressure gauge is dropping and no fluid is seen at opening chamber—seal 10 (upper) is leaking. Test seals 8 (lower), 9 (upper), and 6. a. Pressurize opening chamber (1500 PSI). b. Open closing chamber to atmosphere. IF: Fluid is seen coming from area between body and head—seal 6 is leaking. IF: Fluid is seen coming into the wellbore—seal 8 (lower) is leaking. IF: Fluid is seen at closing chamber—seal 9 (upper) is leaking. Test seals 8 (upper) and 10 (lower). a. Open closing chamber to atmosphere. b. Open opening chamber to atmosphere. c. Install blind flange on top and pressurize wellbore (5000 PSI/345 Bar maximum). WARNING: THE RATED WORKING PRESSURE OF THE GK ANNULAR BOP IS 5000 PSI (345 BAR). USE EXTREME CAUTION WHEN WORKING WITH HIGH PRESSURE. TAKE EVERY PRECAUTION TO PROTECT PERSONNEL FROM COMING IN WITH PRESSURE DURING TESTING OPERATIONS. IF: Fluid is seen coming from the opening chamber— seal 8 (upper) is leaking.

6

8 UPPER

8 LOWER

9 UPPER 9 LOWER 10 UPPER 10 LOWER

Figure 4-3

IF: Fluid is seen coming from the closing chamber— seal 10 (lower) is leaking.

7. 8. 9. 10.

Reduce wellbore pressure to zero. Drain wellbore fluid. Remove blind flange. Test packing unit or return the BOP to service. For packing unit testing, see procedure in this section.

R



4.5 Seal Testing - GK® With Wear Bands When it is known or suspected that a seal within the GK Annular BOP is leaking, it is recommended that all seals be replaced. However, if only the seal in question is to be replaced, it must first be determined which seal is leaking. Use the following procedure for testing the seals in the GK Annular BOP. Refer to Figure 4-4 while following this procedure.

1. Gather the following tools and materials: a. 5000 PSI (345 Bar) pressure source b. 3 1/2-inch test pipe c. Blind flange, 11”-5000 PSI d. RX-54 ring gasket 2. Install the annular BOP onto test stump with hydraulic pressure source connected to the Open and Close ports. 3. Install test pipe into test stump. 4.

5.

6.

Test middle piston seal (B) and lower piston seal using closing operating pressure: a. Open opening chamber to atmosphere. b. Apply 1500 psi (104 Bar) operating pressure to the closing chamber to close the packing unit around the test pipe. IF: Closing fluid seen coming from the Open port indicates that middle piston seal (B) is leaking. IF: Closing fluid seen in the wellbore indicates that lower piston seal is leaking. Test head to piston seal, head gasket, and middle piston seal (A) using opening operating pressure: a. Reduce closing pressure to zero and open the closing chamber to atmosphere. b. Apply 1500 PSI (104 Bar) operating pressure to the opening chamber to open the packing unit. IF: Opening fluid coming from the Close port indicates that middle piston seal (A) is leaking. IF: Opening fluid seen in wellbore or coming from relief valve indicates that the head to piston seal is leaking, or the head gasket seal is leaking, or both the head to piston seal and head gasket are leaking. NOTE: The relief valve is a spring check valve which allows venting of pressure which could be trapped in the latching mechanism. This valve is reusable provided the spring is not frozen or damaged. Test head to piston seal and lower piston seal , using rated working pressure: a. Reduce opening pressure to zero and open the opening and closing chambers to atmosphere. b. Remove test pipe and attach a blind flange to top of annular BOP. c. Fill wellbore with tap water. d. Install blind flange on top and pressurize wellbore (5000 PSI/345 Bar) maximum. WARNING: THE RATED WORKING PRESSURE OF THE GK ANNULAR BOP IS 5000 PSI (345 BAR). USE EXTREME CAUTION WHEN WORK-

Head O-Ring Seal Clamping Screw O-Ring Seal Wiper Seal Head Gasket Wear Band Head to Piston Seal Middle A Piston Seals B Wear Band Lower Piston Seal

Figure 4-4

ING WITH HIGH PRESSURE. TAKE EVERY PRECAUTION TO PROTECT PERSONNEL FROM COMING IN WITH PRESSURE DURING TESTING OPERATIONS.

7.

9. 10. 11. 12.

IF: Wellbore fluid coming from the Open port indicates that head to piston seal is leaking. IF: Wellbore fluid coming from the Close port indicates that lower piston seal is leaking. Testing of the head O-ring, clamping screw O-ring, and wiper seal is not required.

Reduce wellbore pressure to zero. Drain wellbore fluid. Remove blind flange. Test packing unit or return the BOP to service. For packing unit testing, see procedure in this section.

R



4.6 Packing Unit Testing Proper procedure for pressure testing any annular blowout preventer ensures subsequent seal off and maximum packing unit life. Reliable pressure seal off tests are made by closing the packing unit with prescribed closing chamber pressure on recommended size test pipe and by determining the remaining piston travel after seal off is

achieved. Optimum packing unit life is obtained by testing at low rubber stress levels. Minimum packing unit stress is achieved by use of the minimum closing chamber pressure that will initiate and maintain a seal off on the recommended size test pipe.

4.6.1 Packing Unit Testing—Surface The GK® blowout preventer is designed to be well pressure assisted in maintaining packing unit seal off once initial seal off has been effected. Initial seal off is effected by applying pressure to the closing chamber. As well pressure or test pressure increases, the closing force on the packing unit also increases. As well pressure exceeds the required level, the packing unit is maintained closed on pipe by well pressure alone. During routine BOP testing, once initial seal off is achieved, closing pressure should be proportionally reduced as well pressure is increased (see the Control Pressure Graph, Figure 1-9). Closing pressure required to effect initial seal off may vary between packing units. Begin the test with the recommended initial closing pressure shown in Figure 1-8, depending on the style packing unit installed. Piston Stroke can be measured on GK® blowout preventers through a vertical age* in the top of the BOP head. The maximum and minimum distances from the top of the head to the top of the piston are stamped on the BOP head and are also listed in the table below. Piston stroke remaining at seal off is a direct indicator of remaining packing unit life. Record the piston stroke and the closing pressure at initial seal off for each test. Compare with previous results and with maximum piston stroke for the BOP to ensure subsequent seal offs. A valid test on any annular BOP is only achieved when the remaining piston stroke is measured at test seal off.

3

TAPE MEASURE 2

5/16" ROD

1

Distance From Top of Head to Top of Piston Maximum (piston in full down position) Minimum (piston at full stroke)

11-1/8" 4"

* Older model BOPs may not have the piston indicator hole as shown in Figure 4-5. See “BOP Modifications” in this section for piston indicator hole modification as well as other modifications available. Themodification to add the piston indicator hole must be performed at a Hydril Authorized Repair Facility (ARF). Hydril or go to Hydril Website www.hydril.com for the nearest ARF.

Figure 4-5 Piston Stroke Measurement

R


4.7 BOP Modifications Older model BOPs without piston indicator holes, wear plates, bolted inner sleeves, or wear bands can be modified at a Hydril Authorized Repair Facility (ARF). Hydril or visit Hydril Website www.hydril.com for the nearest ARF.

PAGE 4-7

R



R



5.0 DISASSEMBLY AND ASSEMBLY 5.1 Disassembly - Screwed Head Without Wear Bands Refer to Figure 5-1 while following this procedure. Numbers in figure correspond to items numbers in procedure.

17

WARNING: THIS IS VERY HEAVY EQUIPMENT, AND EXTREME SAFETY PROCEDURES MUST BE FOLLOWED DURING LIFTING OPERATIONS. BE SURE THAT LIFTING EQUIPMENT IS IN GOOD CONDITION AND CAPABLE OF HANDLING THE LOAD.

6

A. Gather Tools and Materials. NOTE: Except for the tools listed below, disassembly of the GK® annular BOP can be performed with standard tools. 1. Three eyebolts (5/8”-11UNC x 10” Lg.), Hydril Part No. 30952 (for lifting piston) 2. Three eyebolts (1 1/4"-7UNC x 1 3/4” Lg.), Hydril Part No. 32006 (for lifting head) 3. Chain sling, Hydril Part No. 33565-M (CAUTION: The chain sling is for disassembly and assembly purposes only. Do not use the chain sling to lift the annular BOP assembly.) 4. Two eyebolts (5/8"-11 UNC x 1 3/4” Lg.), Hydril Part No. 1900076-08 (for lifting packing unit).

19

1

8 29 30 2

1 3

9 B. Vent Pressure. 1. Vent the closing and opening chambers to atmosphere, ensuring that no trapped pressure exists which will cause injury to personnel and/or damage the equipment. 2. Open the valves in the control system to exhaust the pressure and/or loosen the hydraulic connections to allow the pressure to bleed off.

10

4

18

WARNING: STAND CLEAR OF ESCAPING PRESSURE TO AVOID INJURY. C. Remove Head. 1. Remove head lock screw (Item 19). 2. Install three eyebolts (1 1/4"-7UNC x 1 3/4” Lg.) into the head (Item 1) 3. Unscrew the head counterclockwise from the BOP body. NOTE: Use a piece of strong pipe or rod (3" to 4" in diameter x 10' to 12' long) as a lever against the eyebolts to apply counterclockwise (left hand) torque on the head (refer to Figure 5-2). A vertical lift, using the chain sling, may be applied to the eyebolts to take the weight of the head off of the threads while applying torque to the head. This lift will reduce the required turning torque. If the head

5

Figure 5-1: Screwed Head GK® 11"-5000 PSI Without Wear BandsDisassembly

R



4. 5. 6.

7.

was improperly installed at the last assembly, it may be necessary to apply considerable more torque on the head by the use of a winch or catline while alternately applying and releasing pressure to the opening chamber (1500 PSI/104 Bar maximum). CAUTION: Do not loosen the head by applying heat to the thread area. Attach the Hydril chain sling and lift the head straight up and off the body. Remove the head gasket (Item 6) and upper Useals (Items 8). Remove the capscrews (Item 30) and the wear plate (Item 29). NOTE: Some models do not have a wear plate. Remove chain sling from eyebolts.

Head Installation

Head Removal

D. Remove Packing Unit. 1. Install two eyebolts (5/8"-11UNC x 1 3/4” Lg.) into packing unit (Item 2). 2. Using the Hydril chain sling, lift the packing unit out of the piston. 3. Remove sling and eyebolts. E. Remove Piston. 1. Install three eyebolts (5/8”-11UNC x 10” Lg. ) into the piston (Item 3). 2. Using Hydril chain sling, gently lift piston out of the preventer body. If a vertical lift is not possible or the piston does not lift out freely, slowly apply low (50 PSI) hydraulic pressure to the closing chamber. WARNING: DO NOT USE AIR OR GAS. 3. 4.

Remove middle U-seals (Items 9) and lower Useals (Items 10). Remove the sling and eyebolts from the piston.

F. Remove Inner Sleeve. NOTE: This step is not applicable to model BOPs that have a welded body sleeve which is not removable. 1. Remove the capscrews (Item 18) from around the inner sleeve (4). 2. Insert the hooks of the Hydril chain sling (equally spaced) in the slots of the inner sleeve and lift the sleeve out of the annular BOP. 3. Remove the chain sling.

Figure 5-2: Head Removal/Installation

R



5.2 Assembly - Screwed Head Without Wear Bands Refer to Figure 5-3 and 5-4 while following this procedure. Numbers in figures correspond to item numbers in procedure. WARNING: THIS IS VERY HEAVY EQUIPMENT, AND EXTREME SAFETY PROCEDURES MUST BE FOLLOWED DURING LIFTING OPERATIONS. BE SURE THAT LIFTING EQUIPMENT IS IN GOOD CONDITION AND CAPABLE OF HANDLING THE LOAD. A. Gather Tools and Materials. NOTE: Except for the tools listed below, assembly of the GK® annular BOP can be performed with standard tools. 1. Three eyebolts (5/8”-11UNC x 10” Lg.), Hydril Part No. 30952 (for lifting piston) 2. Three eyebolts (1 1/4"-7UNC x 1 3/4” Lg.), Hydril Part No. 32006 (for lifting head) 3. Two eyebolts (5/8"-11 UNC x 1 3/4” Lg.), Hydril Part No. 1900076-08 (for lifting packing unit) 4. Chain sling, Hydril Part No. 33565-M (CAUTION: The chain sling is for disassembly and assembly purposes only. Do not use the chain sling to lift the annular BOP assembly.) 5. Castor oil 6. Moly Paste 503 thread lubricant (Coefficient of Friction is .065) or equivalent 7. Neverseez lubricant 8. Spare parts including seal kit. Refer to Section 6, "Parts and Storage." B. Clean, Inspect BOP, and Lubricate. 1. Clean all components thoroughly. 2. Perform the inspection procedures that are applicable in Section 4, "Maintenance and Testing". 3. Ensure that working surfaces are free of burrs, rough edges, or other defects. 4. Inspect all seals installed in the head and piston, and replace any damaged seals in use over one year. (NOTE: Hydril recommends that all seals be replaced whenever a BOP is disassembled and assembled.) Seals must be installed as shown in Figure 5-3 and 5-4. Coat packing unit, seals, and non-extrusion rings with castor oil before installation. CAUTION: Use of petroleum base oil or grease will reduce seal life. 5. Lubricate the threads of nuts, bolts, and capscrews with Moly Paste 503 thread lubricant. 6. Coat interior surfaces with castor oil except wear band grooves in the head and piston . 7. Lubricate body threads on the head and body with Neverseez lubricant.

NOTE: Seal Rings MUST BE installed in position shown by cross-section. 17

19

1 6 8 29

30 2

1 3

9 10

4

18

5

Figure 5-3: Screwed Head GK® 11-5000 PSI- Without Wear BandsAssembly

R



C. Install Inner Sleeve. NOTE: This step is not applicable for models that have a welded body sleeve . 1. Insert hooks of Hydril chain sling (equally spaced) into slots in inner sleeve (Item 4) and install the sleeve into the bore of the body. 2. Install the capscrews (Item 18) and torque to 150 lbft (203 N•m). 3. Remove chain sling. D. Install Piston. 1. Install the lower U-seals (Item 10), on the lower segment of the piston (Item 3). 2. Install the middle U-seals (Items 9) on the upper segment of the piston. 3. Install three eyebolts (5/8”-11UNC x 10” Lg.) into the piston. Attach the Hydril chain sling to the eyebolts and install the piston over the inner sleeve (Item 4) and into the body. Ensure that the piston is aligned vertically with the body prior to lowering. Vent Close port. With proper vertical alignment, the piston will slide its normal full stroke to the bottom of the preventer body. CAUTION: Be careful not to damage the seals during assembly. 4. Remove the chain sling and eyebolts from the piston. E. Install Packing Unit. 1. Lubricate the bowl of the piston (Item 3) and packing unit (Item 2) with castor oil. Install two eyebolts (5/8"-11 UNC x 1 3/4” Lg.) into packing unit. Using Hydril chain sling, lift the packing unit and set it into the bowl of the piston. 2. Remove the chain sling and eyebolts from the packing unit. F. Install Head. 1. Install the wear plate (Item 29) and capscrews (Item 30) on the inner face of the annular head (Item 1). Torque the capscrews to 50 lb-ft (68 N•m). NOTE: This step is not applicable to models that do not have a wear plate. 2. Install the head gasket (Item 6) in the seal groove on the outside diameter of the head, just below the major diameter. 3. Install the upper U-seals (Item 8) on the inside bottom diameter of the head. 4. Install three eyebolts (1 1/4"-7UNC x 1 3/4” Lg.) into the head. 5. Lubricate the body threads on the outside diameter of the head and the inside diameter of the body (Item 5) with Neverseez lubricant. 6. Install the head into the body so that the body threads on the head engage the threads of the body. Remove the chain sling.

7.

8. 9.

Tighten the head clockwise (right hand) as shown in Figure 5-2, using the pipe or rod from Step C of the disassembly procedure, until the shoulder on the head engages the body. A vertical lift, using the chain sling attached to the eyebolts, will reduce the weight on the threads and reduce the required turning torque. Align the head lock bracket with the hole in the body. Lubricate the lock screw threads (Item 19) with Moly Paste 503 and install. Tighten the lock screw using 60 lb-ft (80 N•m) torque. Remove the chain sling and eyebolts from the head. Perform seal and packing unit test procedures in Section 4, "Maintenance and Testing."

R


Pipe Plug (17)

Head Lock Screw (19) BOP Head – Screwed (1) Head Gasket (6) Wear Plate Capscrew (30) Wear Plate (29) U-Seal, Upper (8) Packing Unit (2) Piston (3) U-Seal, Middle (9) Body (5)

Inner Sleeve (4)

U-Seal, Lower (10)

Inner Sleeve Capscrew (18)

Figure 5-4 Cutaway of Screwed Head GK® 11-5000 PSI BOP Without Wear Bands Showing Position of Parts.

PAGE 5-5

R



5.3 Disassembly - Screwed Head With Wear Bands Refer to Figure 5-5 while following this procedure. Numbers in figure correspond to item numbers in procedure.

17

WARNING: THIS IS VERY HEAVY EQUIPMENT, AND EXTREME SAFETY PROCEDURES MUST BE FOLLOWED DURING LIFTING OPERATIONS. BE SURE THAT LIFTING EQUIPMENT IS IN GOOD CONDITION AND CAPABLE OF HANDLING THE LOAD.

6 15

A. Gather Tools and Materials. NOTE: Except for the tools listed below, disassembly of the GK® annular BOP can be performed with standard tools. 1. Three piston lift assemblies, Hydril Part No. 3105638-6 2. Three eyebolts (1 1/4"-7UNC x 1 3/4” Lg.), Hydril Part No. 3112077 (for lifting head) 3. Chain sling, Hydril Part No. 1900179-0354 (CAUTION: The chain sling is for disassembly and assembly purposes only. Do not use the chain sling to lift the annular BOP assembly.) 4. Two eyebolts (5/8"-11 UNC x 1 3/4” Lg.), Hydril Part No. 1900076-08 (for lifting packing unit).

19

1

13 12

11 29

30 2

3

9

14 B. Vent Pressure. 1. Vent the closing and opening chambers to atmosphere, ensuring that no trapped pressure exists which will cause injury to personnel and/or damage the equipment. 2. Open the valves in the control system to exhaust the pressure and/or loosen the hydraulic connections to allow the pressure to bleed off.

34 33 4 18

WARNING: STAND CLEAR OF ESCAPING PRESSURE TO AVOID INJURY. C. Remove Head. 1. Remove head lock screw (Item 19). 2. Install three eyebolts (1 1/4"-7UNC x 1 3/4” Lg.) into the head (Item 1) 3. Unscrew the head counterclockwise from the BOP body. NOTE: Use a piece of strong pipe or rod (3" to 4" in diameter x 10' to 12' long) as a lever against the eyebolts to apply counterclockwise (left hand) torque on the head (refer to Figure 5-2). A vertical lift, using the chain sling, may be applied to the eyebolts to take the weight of the head off of the threads while applying torque to the head. This lift will reduce the required turning torque. If the head was improperly installed at the last assembly, it

5

Figure 5-5: Screwed Head GK® 11"-5000 PSI With Wear BandsDisassembly

R



4. 5.

6. 7.

may be necessary to apply considerable more torque on the head by the use of a winch or catline while alternately applying and releasing pressure to the opening chamber (1500 PSI/104 Bar maximum). CAUTION: Do not loosen the head by applying heat to the thread area. Attach the Hydril chain sling and lift the head straight up and off the body. Remove the head gasket (Item 6), head to piston double U-seal (Items 11 and 12), wiper ring (Item 15) and wear band (Item 13) . Remove the capscrews (Item 30) and wear plate (Item 29). Remove chain sling and eyebolts.

Eyebolt

Lift Device

Piston Shoulder

D. Remove Packing Unit. 1. Install two eyebolts (5/8"-11UNC x 1 3/4” Lg.) into packing unit (Item 2). 2. Using the Hydril chain sling, lift the packing unit out of the piston. 3. Remove sling and eyebolts. E. Remove Piston. 1. Install three piston lift assemblies onto the piston (Item 3) as follows and as shown in Figure 5-6: a. Screw each eyebolt into the piston. b. Tighten the eyebolts until the retaining ring and spacer block are snug against the piston. c. Check the tightness of the eyebolts prior to lifting. 2. Using Hydril chain sling, gently lift piston out of the preventer body. If a vertical lift is not possible or the piston does not lift out freely, slowly apply low (50 PSI) hydraulic pressure to the closing chamber. WARNING: DO NOT USE AIR OR GAS. 3.

4.

Remove middle U-seals (Items 9), lower piston double-U-seal (Items 33 and 34), and wear band (Item 14). Remove the sling and the lifting assemblies from the piston.

F. Remove Inner Sleeve. 1. Remove the capscrews (Item 18) from around the inner sleeve (4). 2. Insert the hooks of the Hydril chain sling (equally spaced) in the slots of the inner sleeve and lift the sleeve out of the annular BOP. 3. Remove the chain sling.

Piston

Figure 5-6. Piston Lift Device

R



5.4 Assembly - Screwed Head With Wear Bands Refer to Figure 5-7 and 5-8 while following this procedure. Numbers in figures correspond to item numbers in procedure. WARNING: THIS IS VERY HEAVY EQUIPMENT, AND EXTREME SAFETY PROCEDURES MUST BE FOLLOWED DURING LIFTING OPERATIONS. BE SURE THAT LIFTING EQUIPMENT IS IN GOOD CONDITION AND CAPABLE OF HANDLING THE LOAD.

NOTE: Seal Rings MUST BE installed in position shown by cross-section. 17

19

1 6 15 13

A. Gather Tools and Materials. NOTE: Except for the tools listed below, assembly of the GK® annular BOP can be performed with standard tools. 1. Three piston lift assemblies , Hydril Part No. 31056386 2. Three eyebolts (1 1/4"-7UNC x 1 3/4” Lg.), Hydril Part No. 3112077 (for lifting head) 3. Two eyebolts (5/8"-11 UNC x 1 3/4” Lg.), Hydril Part No. 1900077-08 (for lifting packing unit) 4. Chain sling, Hydril Part No. 1900179-0354 (CAUTION: The chain sling is for disassembly and assembly purposes only. Do not use the chain sling to lift the annular BOP assembly.) 5. Castor oil 6. Moly Paste 503 thread lubricant (Coefficient of Friction is .065) or equivalent 7. Neverseez lubricant 8. Spare parts including seal kit. Refer to Section 6, "Parts and Storage." B. Clean, Inspect BOP, and Lubricate. 1. Clean all components thoroughly. 2. Perform the inspection procedures that are applicable in Section 4, "Maintenance and Testing". 2. Ensure that working surfaces are free of burrs, rough edges, or other defects. 3. Inspect all seals and wear bands installed in the head and piston, and replace any damaged seals and wear bands in use over one year. (NOTE: Hydril recommends that all seals and wear bands be replaced whenever a BOP is disassembled and assembled.) Seals must be installed as shown in Figures 5-7 and 5-8. Coat packing unit, seals, nonextrusion rings, and wear bands with castor oil before installation. CAUTION: Use of petroleum base oil or grease will reduce seal life. 4. Lubricate the threads of nuts, bolts, and capscrews with Moly Paste 503 thread lubricant. 5. Coat interior surfaces with castor oil. 6. Lubricate body threads on the head and body with Neverseez lubricant. C. Install Inner Sleeve. 1. Insert hooks of Hydril chain sling (equally spaced)

12

11 29

30 2

3

9 14 34 33 4

18

5

Figure 5-7: Screwed Head GK® 11"-5000 PSI With Wear BandsAssembly

R


2. 3.

into slots in inner sleeve (Item 4) and install the sleeve into the bore of the body. Install the capscrews (Item 18) and torque to 150 lbft (203 N•m). Remove chain sling.

D. Install Piston. 1. Install the lower piston double U-seal (Items 33 and 34), and the wear band (Item 14) on the lower segment of the piston (Item 3). 2. Install the middle U-seals (Item 9) on the upper segment of the piston. 3. Install the piston lift assemblies onto the piston as shown in Figure 5-6. Attach the Hydril chain sling to the eyebolts and install the piston over the inner sleeve (Item 4) and into the body. Ensure that the piston is aligned vertically with the body prior to lowering. Vent Close port. With proper vertical alignment, the piston will slide its normal full stroke to the bottom of the preventer body. CAUTION: Be careful not to damage the seals during assembly. 4. Remove the chain sling and piston lift assemblies from the piston. E. Install Packing Unit. 1. Lubricate the bowl of the piston (Item 3) and packing unit (Item 2) with castor oil. Install two eyebolts (5/8"-11 UNC x 1 3/4” Lg.) into packing unit. Using Hydril chain sling, lift the packing unit and set it into the bowl of the piston. 2. Remove the chain sling and eyebolts from the packing unit. F. Install Head. 1. Install the wear plate (Item 29) and capscrews (Item 30) on the inner face of the annular head (Item 1). Torque the capscrews to 50 lb-ft (68 N•m). 2. Install the head gasket (Item 6) in the seal groove on the outside diameter of the head, just below the major diameter and above the body threads. 3. Install the head to piston seal, consisting of a double U-seal (Item 11) and two non-extrusion rings (Item 12), the wear band (Item 13), and the wiper ring (Item 15) into the grooves on the inside bottom diameter. 4. Install three eyebolts (1 1/4"-7UNC x 1 3/4” Lg.) into the head. 5. Lubricate the body threads on the outside diameter of the head and the inside diameter of the body (Item 5) with Neverseez lubricant. 6. Install the head into the body so that the screw threads on the head engage the threads of the body. Remove the chain sling. 7. Tighten the head clockwise (right hand) as shown in Figure 5-2, using the pipe or rod from Step C of

8. 9.

the disassembly procedure, until the shoulder on the head engages the body. A vertical lift, using the chain sling attached to the eyebolts, will reduce the weight on the threads and reduce the required turning torque. Align the head lock bracket with the hole in the body. Lubricate the lock screw threads (Item 19) with Moly Paste 503 and install. Tighten the lock screw using 60 lb-ft (80 N•m) torque. Remove the chain sling and eyebolts from the head. Perform seal and packing unit test procedures in Section 4, "Maintenance and Testing."

PAGE 5-9

R



Pipe Plug (17) Head Lock Screw (19) BOP Head – Screwed (1) Head Gasket (6) Wear Plate Capscrew (30) Wear Plate (29) Wiper Ring (15) Wear Band (13) Head to Piston Double U-Seal (11 and 12) Packing Unit (2) Piston (3) Middle Piston Seals (9) Body (5) Inner Sleeve (4) Wear Band (14) Lower Piston Double U-Seal (33 and 34) Inner Sleeve Capscrew (18)

Figure 5-8 Cutaway of Screwed Head GK® 11 5000 PSI BOP with Wear Bands, Showing Position of Parts.

R



5.5 Disassembly - Latched Head Without Wear Bands Refer to Figure 5-9 while following this procedure. Numbers in figure correspond to item numbers in procedure. WARNING: THIS IS VERY HEAVY EQUIPMENT, AND EXTREME SAFETY PROCEDURES MUST BE FOLLOWED DURING LIFTING OPERATIONS. BE SURE THAT LIFTING EQUIPMENT IS IN GOOD CONDITION AND CAPABLE OF HANDLING THE LOAD. A. Gather Tools and Materials. NOTE: Except for the tools listed below, disassembly of the GK® annular BOP can be performed with standard tools. 1. Three piston lift assemblies, Hydril Part No. 31056386 2. Three eyebolts (1-1/4"-7UNC x 1 3/4’ Lg.), Hydril Part No. 3112077 (for lifting head) 3. Chain sling, Hydril Part No. 1900179-0354 (CAUTION: This chain sling is for disassembly and assembly purposes only. Do not use to lift the annular BOP assembly.) 4. Two eyebolts (5/8"-11 UNC x 1 3/4” Lg.), Hydril Part No.1900077-08 (for lifting packing unit). B. Vent Pressure from Annular BOP Assembly. 1. Vent the closing and opening chambers, ensuring that no trapped pressure exists in the BOP which will cause injury to personnel and/or damage the equipment. 2. Open the valves in the control system to exhaust the pressure and/or loosen the hydraulic connections to allow the pressure to bleed off.

32

17

31

1 7 6 8 29 30 2

3 9 10 18

WARNING: STAND CLEAR OF ESCAPING PRESSURE TO AVOID INJURY. C. Remove Head. 1. Release the annular head (Item 1) by backing off the jaws (Item 21). Unscrew the clamping screws (Item 22) by rotating them counterclockwise four turns or until the jaws shoulder against the body (Item 5). CAUTION: Take care not to continue turning the screws after the jaws have shouldered. Excessive torque at shouldering may cause thread damage. NOTE: If a jaw does not retract as described due to the lack of engagement with spacer sleeve screw (Item 23), tighten the shoulder screw to approximately 50 lb-ft (68 N•m). 2. Remove the four head clamp screws and head clamps (Items 31 and 32) from the annular head. NOTE: Alternately loosen the screws on opposite sides to unload the head evenly. 3. Install three eyebolts (1 1/4"-7UNC x 1 3/4” Lg.) into head.

4

23 22

25 24

26

27

21 5

Figure 5-9: Latched Head GK 11"-5000 PSI Without Wear BandsDisassembly

R



4. 5. 6.

Using Hydril chain sling , lift the head out of the body. Remove sling and eyebolts. Remove the six cap screws (Item 30) and the wear plate (Item 29). Remove the head dirt seal (Item 7), Head gasket (Item 6), and upper U-seals (Items 8).

D. Remove Packing Unit. 1. Install two eyebolts (5/8"-11UNC x 1 3/4” Lg.) into packing unit (Item 2). 2. Using Hydril chain sling, lift the packing unit out of the piston (Item 3). 3. Remove sling and eyebolts. E. Remove Piston. 1. Install three piston lifting devices onto the piston (Item 3) as follows and as shown in Figure 5-6: a. Position each lift device over the top edge of the piston above the eyebolt holes in the piston shoulder, taking care not to damage the sealing surface on the outside diameter. b. Tighten the eyebolts until the lift devices are snug against the piston shoulder. c. Check the tightness of the eyebolts prior to lifting. 2. Using Hydril chain sling 1900179-0354, gently lift piston out of the preventer body. If a vertical lift is not possible or the piston does not lift out freely, slowly apply low (50 PSI) hydraulic pressure to the closing chamber. WARNING: DO NOT USE AIR OR GAS. 3.

4.

Remove the lift devices from the piston, taking care not to damage the sealing surface on the outside diameter. Remove the middle U-seals (Items 9) and the lower U-seals (Items 10).

F. Remove Inner Sleeve. 1. Remove the capscrews (Item 18) from around the inner sleeve (Item 4). 2. Using Hydril chain sling 1900178-0354, attach the hooks (equally spaced) into the slots in the sleeve and lift the inner sleeve out of the annular BOP. 3. Remove sling.

G. Remove Jaws. Perform the following procedure for each jaw (Item 19). 1. Remove pipe plug (Item 25). 2. Hold clamping screw (Item 22) and remove spacer sleeve screw (Item 23) from the clamping screw. 3. Remove the clamping screw and spacer sleeve (Item 24) from the body (Item 5). Remove spacer sleeve from the clamping screw. Remove the jaw (21) from the inside of the body. NOTE: Keep the jaws in sequence so that they can be returned to their original position.

R



5.6 Assembly - Latched Head Without Wear Bands Refer to Figure 5-10 and 5-11 while following this procedure. Numbers in figures correspond to item numbers procedure.

WARNING: THIS IS VERY HEAVY EQUIPMENT, AND EXTREME SAFETY PROCEDURES MUST BE FOLLOWED DURING LIFTING OPERATIONS. BE SURE THAT LIFTING EQUIPMENT IS IN GOOD CONDITION AND CAPABLE OF HANDLING THE LOAD. A. Gather Tools and Materials. NOTE: Except for the tools listed below, assembly of the GK® annular BOP can be performed with standard tools. 1. Three piston lift assemblies, Hydril Part No. 3105638-6 2. Three eyebolts (1-1/4"-7UNC x 1 3/4” Lg.), Hydril Part No. 3112077 (for lifting head) 3. Chain sling, Hydril Part No. 1900179-0354 (CAUTION: This chain sling is for disassembly and assembly purposes only. Do not use to lift the annular BOP assembly.) 4. Two eyebolts (5/8"-11 UNC x 1 3/4” Lg.), Hydril Part No. 1900077-08 (for lifting packing unit) 5. Castor oil 6. Moly Paste 503 thread lubricant (Coefficient of Friction is .065) or equivalent 7. Neverseez lubricant 8. Spare parts including seal kit. Refer to Section 6, "Parts and Storage." B. Clean, Inspect BOP, and Lubricate. 1. Clean all components thoroughly. 2. Perform the inspection procedures that are applicable in Section 4, "Maintenance and Testing". 3. Ensure that working surfaces are free of burrs, rough edges, or other defects. 4. Inspect all seals installed in the head and piston. Replace any damaged seals in use over one year. (NOTE: Hydril recommends that all seals be replaced whenever a BOP is disassembled and assembled.) Seals and must be installed as shown in Figures 5-10 and 5-11. Coat packing unit, seals, and non-extrusion rings with castor oil before installation. CAUTION: Use of petroleum base oil or grease will reduce seal life. 5. Lubricate all threads of fasteners with Moly Paste 503 thread lubricant except where noted in this procedure.

32

17

31

1 7 6 8 29 30

2

3 9 10 18 4

23 22

25 24

26

21 5

27

Figure 5-10: Latched Head GK 11"-5000 PSI Without Wear BandsAssembly

R



careful not to damage the sealing surfaces on the inside diameter of the body and the seals on the outside diameter of the piston during assembly. Install Jaws. 4. Remove the sling and lift devices from the piston, Install the jaws (Item 21) into the annular body taking care not to damage the sealing surface on with the short side of the teeth down and in the the outside diameter. same sequence as disassembled. NOTE: If a new jaw is installed within a set of well worn jaws, polish the new jaw to match existing jaws to F. Install Packing Unit. 1. Lubricate the bowl of the piston (Item 3) and packensure equal load sharing. ing unit (Item 2) with castor oil. Install two eyebolts Install the O-ring (Item 26) in the external groove (5/8"-11UNC x 1 3/4” Lg.) into packing unit. Using of each clamping screw (Item 22). Hydril chain sling 1900179-0354, lift the packing Install the clamping screws and screw them allunit and set it into the bowl of the piston. the-way in hand tight. CAUTION: Be careful not 2. Remove the sling and eyebolts from the packing to overtighten the clamping screws, or the jaw will unit. extend beyond the sides of the body. Insert the spacer sleeve (Item 24) and spacer sleeve screw (Item 23) through each clamping G. Install Head. screw. Turn the screws into the jaws (Item 21) 1. Unscrew the clamping screws (Item 22) by rotating them counterclockwise four turns or until the jaws until tight (approximately 50 lb-ft/68 N•m). IMshoulder against the body (Item 5). CAUTION: PORTANT: Do not lubricate the threads of the Take care not to continue turning the screws after spacer sleeve screws. the jaws have shouldered. Excessive torque at Install pipe plugs (Item 25) into clamping screws. shouldering may cause thread damage. NOTE: If Ensure that all of the jaws are retracted fully by a jaw does not retract as described due to the lack turning the clamping screws counterclockwise of engagement with spacer sleeve screw (Item 23), until the jaws are shouldered against the body. tighten the spacer sleeve screw counterclockwise (left hand thread) to approximately 150 lb-ft (203 Install Inner Sleeve. N•m). Using Hydril chain sling 1900179-0354, attach the three hooks (evenly spaced) into the slots in 2. Install the wear plate (Item 29) on the inner face of the sleeve and install the inner sleeve (Item 4) the annular head (1) and install the capscrews into the body. (Item 30). Torque the capscrews to 50 lb-ft (68 Install the capscrews (Item 18) and torque to 150 N•m). lb-ft (203 N•m). 3. Install the head dirt seal (Item 7), head gasket (6), Remove chain sling. and upper U-seals (Items 8) onto the head. 4. Install three eyebolts (1-1/4"-7UNC x 1 3/4” Lg.) Install Piston. into head. Install thelower U-seals (Item 10) on the lower 5. Using Hydril chain sling 1900179-0354, lift and segment of the piston (Item 3). install the head into the annular body (Item 5). Install the middle U-seals (Item 9) onto the upper Remove the sling and eyebolts. segment of the piston. Orient the seal lips as 8. Install four head clamps (item 31) and screws (Item shown in Figure 5-9 and/or 5-10. 32) to secure the head fully into place. Tighten the Install the piston into the body using the piston lift head clamp screws until tight. devices. Install each device onto the piston as 9. Turn the clamping screws (Item 22) clockwise to shown in Figure 5-6, taking care not to damage engage the jaws (Item 21) fully into the locking rings the sealing surface on the outside diameter. of the preventer head and apply 350 lb-ft (475 N•m) Lubricate all mating surfaces with castor oil beof torque. CAUTION: To prevent unequal clearfore lowering the piston over the inner sleeve. ance between the head and the body, tighten the Ensure that the piston is aligned vertically with jaws/latches alternately on opposite sides or in a the inner sleeve prior to lowering. Vent the Close crisscross pattern. ports to atmosphere. With proper vertical alignment, the piston will slide its normal full stroke to the bottom of the preventer body. CAUTION: Be

6. Coat interior surfaces with castor oil. C. 1.

2. 3.

4.

5. 6.

D. 1.

2. 3. E. 1. 2.

3.

R


Pipe Plug (17) Head Clamp Screw (31) Head Clamp (30) Head Dirt Seal (7) Wear Plate Capscrew (30) BOP Head – Latched (1) Jaw Mechanism (21,22,23,24,25,26)

Wear Plate (29) Head Gasket (6) U-Seal, Upper (8) Packing Unit (2) Piston (3)

U-Seal, Middle (9)

Body (5)

Inner Sleeve (4)

U-Seal, Lower (10)

Inner Sleeve Capscrew (18)

Figure 5-11 Cutaway of GK® 11-5000 PSI Latched Head BOP Without Wear Bands, Showing Position of Parts.

PAGE 5-15

R



5.7 Disassembly - Latched Head With Wear Bands Refer to Figure 5-12 while following this procedure. Numbers in figure correspond to item numbers in procedure. WARNING: THIS IS VERY HEAVY EQUIPMENT, AND EXTREME SAFETY PROCEDURES MUST BE FOLLOWED DURING LIFTING OPERATIONS. BE SURE THAT LIFTING EQUIPMENT IS IN GOOD CONDITION AND CAPABLE OF HANDLING THE LOAD. A. Gather Tools and Materials. NOTE: Except for the tools listed below, disassembly of the GK® annular BOP can be performed with standard tools. 1. Three piston lift assemblies, Hydril Part No. 31056386 2. Three eyebolts (1-1/4"-7UNC x 1 3/4’ Lg.), Hydril Part No. 3112077 (for lifting head) 3. Chain sling, Hydril Part No. 1900179-0354 (CAUTION: This chain sling is for disassembly and assembly purposes only. Do not use to lift the annular BOP assembly.) 4. Two eyebolts (5/8"-11 UNC x 1 3/4” Lg.), Hydril Part No. 1900077-08 (for lifting packing unit).

17

31

1 7 15 6 13 12

11

29

30 2

3

B. Vent Pressure from Annular BOP Assembly. 1. Vent the closing and opening chambers, ensuring that no trapped pressure exists in the BOP which will cause injury to personnel and/or damage the equipment. 2. Open the valves in the control system to exhaust the pressure and/or loosen the hydraulic connections to allow the pressure to bleed off.

9 14 33

34

18 4

23

WARNING: STAND CLEAR OF ESCAPING PRESSURE TO AVOID INJURY. C. Remove Head. 1. Release the annular head (Item 1) by backing off the jaws (Item 21). Unscrew the clamping screws (Item 22) by rotating them counterclockwise four turns or until the jaws shoulder against the body (Item 5). CAUTION: Take care not to continue turning the screws after the jaws have shouldered. Excessive torque at shouldering may cause thread damage. NOTE: If a jaw does not retract as described due to the lack of engagement with spacer sleeve screw (Item 23), tighten the shoulder screw to approximately 50 lb-ft (68 N•m). 2. Remove the four head clamp nuts and head clamps (Items 31 and 32) from the annular head. NOTE: Alternately loosen the nuts on opposite sides to unload the head evenly. 3. Install three eyebolts (1 1/4"-7UNC x 1 3/4” Lg.) into head.

32

22

25 24

26

27

Figure 5-12: Latched Head GK 11"-5000 PSI With Wear BandsDisassembly

21 5

R


4. 5.

6.

Using Hydril chain sling , lift the head out of the body. Remove sling and eyebolts. Remove the head dirt seal (Item 7), wiper ring (Item 15), head gasket (Item 6), head to piston double Useal (Items 11 and 12), and the wear band (Item 13) from the head. Remove the six cap screws (Item 30) and the wear plate (Item 29).

D. Remove Packing Unit. 1. Install two eyebolts (5/8"-11UNC x 1 3/4” Lg.) into packing unit (Item 2). 2. Using Hydril chain sling, lift the packing unit out of the piston (Item 3). 3. Remove sling and eyebolts. E. Remove Piston. 1. Install three piston lifting devices onto the piston (Item 3) as follows and as shown in Figure 5-6: a. Position each lift device over the top edge of the piston above the eyebolt holes in the piston shoulder, taking care not to damage the sealing surface on the outside diameter. b. Tighten the eyebolts until the lift devices are snug against the piston shoulder. c. Check the tightness of the eyebolts prior to lifting. 2. Using Hydril chain sling 1900179-0354, gently lift piston out of the preventer body. If a vertical lift is not possible or the piston does not lift out freely, slowly apply low (50 PSI) hydraulic pressure to the closing chamber. WARNING: DO NOT USE AIR OR GAS. 3.

4.

Remove the middle U-seals (Item 9), lower piston double U-seal (Items 33 and 34), and the wear band (Item 14) from the piston. Remove the lift devices from the piston, taking care not to damage the sealing surface on the outside diameter.

F. Remove Inner Sleeve. 1. Remove the capscrews (Item 18) from around the inner sleeve (Item 4). 2. Using Hydril chain sling 1900178-0354, attach the hooks (equally spaced) into the slots in the sleeve and lift the inner sleeve out of the annular BOP. 3. Remove sling. G. Remove Radial Latches. Perform the following procedure for each radial latch (Item 19). 1. Remove pipe plug (Item 25). 2. Hold clamping screw (Item 22) and remove spacer

3. 4.

sleeve screw (Item 23) from the clamping screw. Remove the O-ring (Item 26) from the clamping screw. Remove the clamping screw and spacer sleeve (Item 24) from the body (Item 5). Remove spacer sleeve from the clamping screw. Remove the jaws (Item 21) from the inside of the body. NOTE: Keep the jaws in sequence so that they can be returned to their original position.

PAGE 5-17

R



5.8 Assembly - Latched Head With Wear Bands Refer to Figure 5-13 and 5-14 while following this procedure. Numbers in figures correspond to item numbers in procedure.

WARNING: THIS IS VERY HEAVY EQUIPMENT, AND EXTREME SAFETY PROCEDURES MUST BE FOLLOWED DURING LIFTING OPERATIONS. BE SURE THAT LIFTING EQUIPMENT IS IN GOOD CONDITION AND CAPABLE OF HANDLING THE LOAD. A. Gather Tools and Materials. NOTE: Except for the tools listed below, assembly of the GK® annular BOP can be performed with standard tools. 1. Three piston lift assemblies, Hydril Part No. 3105638-6 2. Three eyebolts (1-1/4"-7UNC x 1 3/4” Lg.), Hydril Part No. 3112077 (for lifting head) 3. Chain sling, Hydril Part No. 1900179-0354 (CAUTION: This chain sling is for disassembly and assembly purposes only. Do not use to lift the annular BOP assembly.) 4. Two eyebolts (5/8"-11 UNC x 1 3/4” Lg. ), Hydril Part No. 1900077-08 (for lifting packing unit) 5. Castor oil 6. Moly Paste 503 thread lubricant (Coefficient of Friction is .065) or equivalent 7. Neverseez lubricant 8. Spare parts including seal kit. Refer to Section 6, "Parts and Storage."

17

32 31

1 7 15 6 13 12

11

28

29 2

3 9 14 33

34

18 4

23 22

B. Clean, Inspect BOP, and Lubricate. 1. Clean all components thoroughly. 2. Perform the inspection procedures that are applicable in Section 4, "Maintenance and Testing". 3. Ensure that working surfaces are free of burrs, rough edges, or other defects. 4. Inspect all seals and wear bands installed on the head and piston. Replace any damaged seals and wear bands in use over one year. (NOTE: Hydril recommends that all seals and wear bands be replaced whenever a BOP is disassembled and assembled.) Seals and must be installed as shown in Figures 5-13 and 5-14. Coat packing unit, seals, and non-extrusion rings with castor oil before installation. CAUTION: Use of petroleum base oil or grease will reduce seal life.

25 24

26

27

Figure 5-13: Latched Head GK 11"-5000 PSI With Wear BandsAssembly

21 5

R


ports to atmosphere. With proper vertical alignment, the piston will slide its normal full stroke to the bottom of the preventer body. CAUTION: Be careful not to damage the sealing surfaces on the inside diameter of the body and the seals on the outside diameter of the piston during assembly. Install Jaws. 4. Remove the sling and lift devices from the piston, Install the jaws (Item 21) into the annular body taking care not to damage the sealing surface on with the short side of the teeth down and in the the outside diameter. same sequence as disassembled. NOTE: If a new jaw is installed within a set of well worn latches, polish the new jaw to match existing F. Install Packing Unit. 1. Lubricate the bowl of the piston (Item 3) and packjaws to ensure equal load sharing. ing unit (Item 2) with castor oil. Install two eyebolts Install the O-ring (Item 26) in the external groove (5/8"-11UNC x 1 3/4” Lg.) into packing unit. Using of each clamping screw (Item 22). Hydril chain sling 1900179-0354, lift the packing Install the clamping screws and screw them allunit and set it into the bowl of the piston. the-way in hand tight. CAUTION: Be careful not 2. Remove sling and eyebolts from packing unit. to overtighten the clamping screws, or the jaw will extend beyond the sides of the body. Insert the spacer sleeve (Item 24) and spacer G. Install Head. sleeve screw (Item 23) through each clamping 1. Unscrew clamping screws (Item 22) by rotating them counterclockwise four turns or until the jaws screw. Turn the screws into the jaws (Item 21) shoulder against body (Item 5). CAUTION: Take until tight (approximately 50 lb-ft/68 N•m). IMcare not to continue turning screws after the jaws PORTANT: Do not lubricate the threads of the have shouldered. Excessive torque at shouldering spacer sleeve screws. may cause thread damage. NOTE: If a jaw does Install pipe plugs (Item 25) into clamping screws. not retract as described due to the lack of engageEnsure that all of the jaws are retracted fully by ment with spacer sleeve screw (Item 23), tighten turning the clamping screws counterclockwise the spacer sleeve screw counterclockwise (left until the jaws are shouldered against the body. hand thread) to approximately 150 lb-ft (203 N•m). Install Inner Sleeve. 2. Install the wear plate (Item 28) on the inner face of Using Hydril chain sling 1900179-0354, attach the annular head (1) and install the capscrews the three hooks (evenly spaced) into the slots in (Item 29). Torque capscrews to 50 lb-ft (68 N•m). the sleeve and install the inner sleeve (Item 4) 3. Install the head gasket (6) and head dirt seal (Item into the body. 7) on the lower outside diameter of the head. Install Install the capscrews (Item 18) and torque to 150 the head to piston double U-seal (Items 11 and 12), lb-ft (203 N•m). wiper ring (Item 15), and wear band (Item 13) onto Remove chain sling. the lower inside diameter of the head. Refer to Figures 5-13 and 5-14 for seal orientation. Install Piston. 4. Install three eyebolts (1-1/4"-7UNC x 1 3/4” Lg.) Install the lower piston double U-seal (Items 33 into head. and 34) and wear band (Item 14) on lower 5. Using Hydril chain sling 1900179-0354, lift and segment of the piston (Item 3). install the head into the annular body (Item 5). Install the middle U-seals (Item 9) onto the middle Remove the sling and eyebolts. segment of the piston. Orient the seal lips as 6. Install four head clamps (item 31) and screws (Item shown in Figures 5-13 and 5-14. 32) to secure the head fully into place. Tighten the Install the piston into the body using the piston lift screws until tight. devices. Install each device onto the piston as 7 Turn clamping screws (Item 22) clockwise to enshown in Figure 5-6, taking care not to damage gage jaws (Item 21) fully into locking rings of the sealing surface on the outside diameter. preventer head and apply 350 lb-ft (475 N•m) of Lubricate all mating surfaces with castor oil betorque. CAUTION: To prevent unequal clearance fore lowering the piston over the inner sleeve. between head and the body, tighten the jaws alterEnsure that the piston is aligned vertically with nately on opposite sides or in a crisscross pattern. the inner sleeve prior to lowering. Vent the Close

5. Lubricate all threads of fasteners with Moly Paste 503 thread lubricant except where noted in this procedure. 6. Coat interior surfaces with castor oil. C. 1.

2. 3.

4.

5. 6.

D. 1.

2. 3. E. 1.

2.

3.

PAGE 5-19

R



Pipe Plug (17) Head Clamp Screw (31) Head Clamp (30) Head Seal (7) Wear Plate Capscrew (30) BOP Head – Latched (1) Wear Plate (29) Jaw Mechanism (21,22,23,24,25,26) Wiper Ring (15) Head Gasket (6)

Wear Band (14) Head to Piston Double U-Seal (11, 12) Packing Unit (2) Piston (3) U-Seal, Middle (9) Body (5)

Inner Sleeve (4) Wear Band (13) Lower Piston Double U-Seal (33, 34) Inner Sleeve Capscrew (18)

Figure 5-14 Cutaway of Latched Head GK® 11-5000 PSI BOP with Wear Bands, Showing Position of Parts.

R



6.0 PARTS AND STORAGE 6.1 Parts List — Screwed Head Without Wear Bands No. Req.

Approx. Net Wt. (Lb)

BOP Assembly

1

8,200

1002140

BOP Head Screwed

1

1,880

1002143

6

2▲ Packing UnitNatural (NR)

1

305

1003260-01

8

Nitrile (NBR) Piston

1 1

311 1,380

1003260-02 1002145-1

29

4** Inner Sleeve 5 Body

1 1

... 4,645

1004201 1002141

6 8

Head Gasket U-Seal, Upper

1 2

2 2.13

31402 31403

9 10

U-Seal, Middle U-Seal, Lower

2 2

2 1.75

30736 32599

17

Pipe Plug, Piston Indicator

...

190006505

12

...

192002612012

19 Head Lock Screw 29* Wear Plate

1 1

1.19 24.15

1002149 1004203

30* Wear Plate Capscrew

0.13

192002608007

10

6

Field Replacement Sleeve Kit

1

...

1006100

4

Seal Kit- Complete

1

14.41

1002150

Item No.

1

3

Part Name

▲

17

19

1

1

18** Inner Sleeve Screw

•

Part Number

30 2

1 3

9

18 ACCESSORIES Chain Sling Assy

1

45

Eyebolt, Piston Eyebolt, Head, 1 1/4”-7NC

3 2

1.94 4.25

33565-M 30952 32006

Protector Plate Protector Plate Screw

1 4

66 0.13

31406 1900043

5

08010 ▲ Recommended spares for one year service.

•

For converting welded sleeve on some model BOPs to bolted sleeve only. Sleeve does not interchange with Item 4. * Requires head conversion to accept wear plate; some models of this BOP do not have the wear plate. ** Some BOPs are equipped with Sleeve P/N 1004075 and Capscrew 1920026-12016. Check P/N stamped on bottom of sleeve for replacement.

Figure 6-1: Screwed Head GK® 11"-5000 PSI without Wear Bands

R



6.2A Parts List — Screwed Head With Wear Band Modificationa Item No.

Part Name

Approx. No. Net Wt. Req. (Lb)

Part Number

17

BOP Assembly Head - Screwed

1 1

8,200 1,880

1002140-WB 3136824


1

305

1003260-01

6 15


1 1

311 1,380

1003260-02 3136680

13

4** Inner Sleeve 5 Body

1 1

... 4,645

1004201 1002141

12

6 9

Head Gasket U-Seal, Middle Piston

1 1

2 ...

31402 30736

30

11 12

Double U-Seal, Head Non Extrusion Ring

1 2

2.13 ...

1002921 1002922

13 14

Wear Band, Head Wear Band, Piston

1 1

... ...

1931099-05 1931099-04

15 17

Wiper Ring Pipe Plug, Piston

1

...

3136747

Indicator 18** Inner Sleeve Screw

1 1

...

1900065-05 1004201

19 Head Lock Screw 29* Wear Plate

1 1

1.19 1002149 24.15 1004203

1

3

30* Wear Plate Capscrew

6

0.13

192002608007

33 34

Double U-Seal, Piston Non Extrusion Ring

1 2

... ...

3136746 3136745

•

Field Replacement

▲

Sleeve Kit Seal Kit- Complete

1 1

... 14.41

1006100 3137431

19

a

1

11 29

2

3

9

14 34 33 4

18

ACCESSORIES Chain Sling Assy Eyebolt, Piston 5/8”-11UNC

1 2

45 1.94

33565-M 30952

Eyebolt, Head, 1 1/4”-7UNC Protector Plate

2 1

4.25 66

32006 31406

Protector Plate Screw

4

0.13

1900043 08010

5

▲ Recommended spares for one year service.

•

For converting welded sleeve on some model BOPs to bolted sleeve only. Sleeve does not interchange with Item 4. * Requires head conversion to accept wear plate; some models of this BOP do not have the wear plate. ** Some BOPs are equipped with Sleeve P/N 1004075 and Capscrew 1920026-12016. Check P/N stamped on bottom of sleeve for replacement. a Wear band modification at Hydril Authorized Repair Facility (ARF). The abbreviation “WB” will be stamped on the name plate after the BOP assembly number (XXXXXXX-WB) to indicate wear band

Figure 6-2: Screwed Head GK® 11"-5000 PSI with Wear Band Modification modification. See Parts List 6.2B (PNI04-007-02 Rev A1) for modification kit parts.

R


6.2B Parts List — Screwed Head Wear Band Modification Kit PNI04-007-02 Rev A1 Item No.a 1

a

Part Name

No. Req.


Part Number

Head - Screwed

1

1,880

3136824

3 13

Piston Wear Band, Head

1 1

1,380 ...

3136680 1931099-05

14 ...

Wear Band, Piston Seal Kit- Complete

1 1

... 14.41

1931099-04 3137431

Item number refers to Parts List 6-2A and Figure 6-2.

PAGE 6-3

R



6.3 Parts List — Screwed Head With Wear Bands At Manufacturea Item No.

1

Part Name BOP Assembly Head - Screwed

Approx. Part No. Net Wt. Number* Req. (Lb) 1 1

8,200 1,880

17

19

* *

1


1

305

1003260-01

6 15


1 1

311 1,380

1003260-02 *

13

3 4 5

Inner Sleeve Body

1 1

... 4,645

1004201 *

12

6 9

Head Gasket U-Seal, Middle Piston

1 2

2.0 ...

31402 30736

30

11 12

Double U-Seal, Head Non Extrusion Ring

1 2

2.13 ...

1002921 1002922

13 14


1 1

... ...

1931099-05 1931099-04

15 17

Wiper Ring Pipe Plug, Piston Indicator

1

...

3136747

1

...

1900065-05

18

Inner Sleeve Screw

6

0.13

192002612012

14 34

11 29

2

3

19 29

Head Lock Screw Wear Plate

1 1

1.19 24.15

1002149 3123805

30

Wear Plate Capscrew

6

0.13

192002608007

4

33 34

Double U-Seal, Piston Non Extrusion Ring

1 2

... ...

3136746 3136745

18

▲

Seal Kit- Complete

1

14.41

3137431

1

...

19001790354

Eyebolt, Head, 1 1/4-7UNC Protector Plate

3 2

4.25 66

3112077 3113411-37

Piston Lift Device

3

...

3105638-6

9

33

ACCESSORIES Chain Sling Assembly

5

▲ Recommended spares for one year service. a

*

Wear bands are installed at manufacture. This parts list is generic in construction and part numbers are listed for all components that are standard except for non-standard components or those that require regulatory certification, which may change from one assembly to another. These parts are specific to the assembly part number stamped on the BOP name plate. If you want a complete parts list specific to your equipment, Hydril. Include the assembly part number and/or serial number from the name plate. If name plate is missing or damaged, the serial number is stamped on the body.

Figure 6-3: Screwed Head GK® 11"-5000 PSI with Wear Bands

R



6.4 Parts List — Latched Head Without Wear Bands Item No.

Part Name

BOP Assembly 1 BOP Head-Latched 2▲ Packing Unit Natural Rubber (NR) Nitrile (NBR) 3 Piston 4 Inner Sleeve 5 Body 6 Head Gasket 7 Head Dirt Seal 8 U-Seal ,Upper 9 U-Seal, Middle 10 U-Seal, Lower 17 Pipe Plug, Piston Indicator 18 Inner Sleeve Screw 21 22 23

Jaw Jaw Clamping Screw Spacer Sleeve Screw

24 25 26 27 29 30

Spacer Sleeve Pipe Plug Jaw Clamping Screw O-Ring Relief Fitting Wear Plate Wear Plate Capscrew

31 32

Head Clamp Head Clamp Screw

▲ Seal Kit- Complete

Approx. No. Net Wt. Req. (Lb) 1 1

8,200 1900

1004060 1002223

1 1 1 1 1 1 1 2 2 2 1

305 311 1380 ... 4645 2.44 ... 2.13 2 1.75 ...

12 16 16

... ... 3.75

16 16 16

... ... ...

16 1 1

0.02 0.03 ...

6 4

0.09 0.85

4 ...

0.67 18

1003260-01 1003260-02 1002145 1004201 1004061-02 31402 51189 31403 30736 32599 1900065-05 192002612012 1004065 1004067 190018410024 1004068 1900065-08 1900001329 1900086-03 1004203 192002608007 1002351 190004914024 1004074

ACCESSORIES Chain Sling Assembly 1 Piston Lift Device Eyebolt, Head, 1 1/4”-7UNC Protector Plate Protector Plate Screw

Part Number

3 2 1 4

... ... 4.25 66 0.13

19001790354 3105638-6 3112077 31406 190004308010

32

17

31

1 7 6 8 29 30

2

3 9 10 18 4

23 22

25 24

26

27

▲ Recommended spares for one year service.

Figure 6-4: Latched Head GK 11"-5000 PSI Without Wear Bands

21 5

R



6.5A Parts List — Latched Head With Wear Band Modification* Item No.

Part Name

BOP Assembly 1 BOP Head-Latched 2▲ Packing Unit Natural Rubber (NR) Nitrile (NBR) 3 Piston 4 Inner Sleeve 5 Body 6 Head Gasket 7 Head Dirt Seal 9 U-Seal, Middle Piston 11 Double U-Seal, Head 12 Non Extrusion Ring 13 Wear Band, Head 14 Wear Band, Piston 15 Wiper Ring 17 Pipe Plug, Piston Indicator 18 Inner Sleeve Screw 21 22 23


27 29 30


31 32


24 25 26

33 Double U-Seal, Piston 34 Non Extrusion Ring ▲ Seal Kit- Complete


8,200 1900

1004060-WB* 3136678

1 1 1 1 1 1 1 2 1 2 1 1 1 1

305 311 1380 ... 4645 2.44 ... ... ... ... ...

12 16 16

... ... 3.75

16 16 16

... ... ...

16 1 1

0.02 0.03 ...

6 4

0.09 0.85

4 1 2 ...

0.67 ... ... 18

1003260-01 1003260-02 3136680 1004201 1004061-02 31402 51189 30736 1002921 1002922 1931099-05 1931099-04 3136747 1900065-05 192002612012 1004065 1004067 190018410024 1004068 1900065-08 1900001329 1900086-03 1004203 192002608007 1002351 190004914024 3136746 3136745 3137417

ACCESSORIES Chain Sling Assembly 1 Piston Lift Device Eyebolt, Head, 1 1/4”-7UNC Protector Plate Protector Plate Screw

Part Number

3 2 1 4

... ...

... ... 4.25 66 0.13

19001790354 3105638-6 3112077 31406 190004308010

▲ Recommended spares for one year service. * Wear band modification at Hydril Authorized Repair Facility (ARF). The abbreviation “WB” will be stamped on the name plate after the BOP assembly number (XXXXXXX-WB) to indicate modification. See parts list 6.5B (PNI04-007-03 Rev A1) for modification kit parts.

32

17

31

1 7 15 6 13 12

11

29

30 2

3 9 14 33

34

18 4

23 22

25 24

26

21 5

27

Figure 6-5: Latched Head GK 11"-5000 PSI With Wear Band Modification

R


6.5B Parts List — Latched Head Wear Band Modification Kit PNI04-007-03 Rev A1 No. Req.


Head - Screwed Piston

1 1

1,880 1,380

13 14


1 1

... ...

...

Seal Kit- Complete

1

14.41

Item No.a 1 3

a

Part Name

Part Number 3136678 3136680 1931099-05 1931099-04 3137417

Item number refers to Parts List 6-5A and Figure 6-5.

PAGE 6-7

R



6.6 Parts List — Latched Head With Wear Bands At Manufacturea Item No.

Part Name

BOP Assembly 1 BOP Head-Latched 2▲ Packing Unit Natural Rubber (NR) Nitrile (NBR) 3 Piston 4 Inner Body Sleeve 5 Body 6 Head Gasket 7 Head Dirt Seal 9 U-Seal, Middle Piston 11 Double U-Seal ,Head 12 Non Extrusion Ring 13 Wear Band, Head 14 Wear Band, Piston 15 Wiper Ring 17 Pipe Plug, Piston Indicator 18 Inner Sleeve Screw 21 22 23


27 29 30


31 32


24 25 26


8,200 1900

* *

1 1 1 1 1 1 1 2 1 2 1 1 1 1

305 311 1380 ... 4645 2.44 ... ... ... ... ...

12 16 16

... ... 3.75

16 16 16

... ... ...

1003260-01 1003260-02 * 1004201 * 31402 51189 30736 1002921 1002922 1931099-05 1931099-04 3136747 1900065-05 192002612012 3136678 1004067 190018410024 1004068 1900065-08 1900001329 1900086-03 1004203 192002608007 1002351 190004914024 3136746 3136745 3137417

... ...

16 1 1

0.02 0.03 ...

6 4

0.09 0.85

4 0.67 ... 33 Double U-Seal, Piston 1 34 Non Extrusion Ring 2 ... ▲ Seal Kit- Complete ... 18 ACCESSORIES Chain Sling Assembly 1 ... Piston Lift Device Eyebolt, Head Protector Plate Protector Plate Screw

Part Number

3 2 1 4

... 4.25 66 0.13

19001790354 3105638-6 3112077 31406 190004308010

▲ Recommended spares for one year service. a

*

Wear bands are installed at manufacture. This parts list is generic in construction and part numbers are listed for all components that are standard except for non-standard components or those that require regulatory certification, which may change from one assembly to another. These parts are specific to the assembly part number stamped on the BOP name plate. If you want a complete parts list specific to your equipment, Hydril.

17

32 31

1 7 15 6 13 12

11

29

30 2

3 9 14 33

34

18 4

23 22

25 24

26

21 5

27

Figure 6-6: Latched Head GK 11"-5000 PSI With Wear Bands Include the assembly part number and/or serial number from the name plate. If name plate is missing or damaged, the serial number is stamped on the body.

R


6.7 Preventer Storage The following preservation procedure protects the Hydril® 11 5/8"-5000 PSI annular BOP for up to two years of storage. The protection period is dependent primarily upon the sealing integrity of the end connections and sealing of other pressure boundary penetrations. 3. 6.7.1 Preservation Procedure 4. A. Materials Required 1. Cortec VCI 369 grease (for unpainted machined face surfaces) 2. Cortec VCI 609 vapor phase corrosion inhibitor, 10 ounce (for bore and exposed interior surfaces) 3. Two protective covers for the end connections. 4. Water displacement oil such as Hougton Rust Veto 4221 or Stack Guard 180; Witco Macco 1961; or any AW Hydraulic Oil 46 (required for removal of water after hydrostatic testing) 5. One tube of silicone caulk (additional sealing for protective covers)

5. 6. 7. 8.

9. 10.

B. Procedure 1. Disassemble, clean, inspect, lubricate, and assemble the annular BOP. Refer to the maintenance procedure in Section 4, "Maintenance and Testing" and Section 5, "Disassembly and Assembly." Replacement of worn packing units, seals, and other parts can be made conveniently at this time. Hydril recommends the replacement of all seals when the annular BOP is disassembled. 2. Test the packing unit and seals, using a 50/50 mix of fresh water (DO NOT USE SEA WATER OR BRINE) and glycol mixed with corrosion inhibitor or BOP hydraulic fluid as an operating fluid. Refer to Section 4,

11.

12. 13.

"Maintenance and Testing" for testing procedures. NOTE: For additional discussion on operating fluid and specific fluid recommendations, refer to Hydril Engineering Bulletin EB9909A on Hydril Website www.hydril.com. Drain the bore and rinse thoroughly behind the packing unit and inner sleeve with water displacement oil. Drain the operating fluid and flush out the operating fluid paths and chambers (Open and Close) with water displacing oil. Allow the bore, operating fluid paths and chambers (Open and Close) to dry. Install pipe plugs into Open and Close ports. Apply Cortec VCI 369 grease to bottom connection mating surface . Install a protective cover on the bottom connection. Ensure that a tight seal exists between the BOP and the cover. Use silicone cauk if necessary. Drop 10 ounces of Cortec VCI 609 vapor phase corrosion inhibitor into the bore of the BOP. Apply Cortec VCI 369 grease to the top connection mating surface. Install a protective cover on the top connection. Ensure that a tight seal exists between the BOP and the cover. Use silicone cauk if necessary. Touch up paint where necessary. Hydril for paint specifications. Coat unpainted exterior surfaces with Cortec VCI 369 grease.

6.7.2 Depreservation Procedure and Return to Service Remove the end connection covers and blow or rinse out the vapor phase corrosion inhibitor.

PAGE 6-9

R



6.8 Rubber Goods Storage The term rubber goods includes synthetic compounds such as Nitrile Copolymers and Neoprene, as well as natural rubber parts. The ideal storage situation for rubber goods would be in air tight containers maintained 4. in a cool, dry, dark storage area. The following recommendations will allow vendors and s of oil field equipment to maximize normally5. available storage facilities for rubber goods: 1. Keep the rubber storage area as dark as possible — preferably indoors, not outdoors, and away from direct sunlight, skylights, windows, and direct artifi-6. cial lighting. 2. Select a cool location (approximately 65oF) that is away from heaters, stoves, and direct blasts of7. space heaters. 3. Keep rubber goods away from electrical machinery

(motors, switch gear, or any high voltage equipment producing corona and ozone). Avoid locations susceptible to drafts that will carry the atmosphere from electrical machinery to the rubber goods storage area. The practice of first-in, first-out is essential with rubber goods. Store rubber goods in a relaxed position in their normal shape. For example, do not hang O-rings on nails. Do not keep assemblies in stretched attitudes, e.g., O-rings on glands, BOP testers, and operator parts. Rubber goods storage areas should be kept as dry as possible. Remove oil, grease or other foreign materials from the storage area to preclude spillage on rubber goods. If storage for extended periods is anticipated, sealed containers are recommended. Impervious surface coverings such as waxing will increase shelf life.

OPERATOR'S MANUAL

R

Pressure Control Equipment

Hydril - Gk Bop.pdf 3w4a1g

Overview 4q3b3c

More details 26j3b

Related Documents 171j1w

Hydril - Gk Bop.pdf 3w4a1g

Hydril - Gk Bop zh12

Gk 3f4952

Hydril 523 n2v6o

Hydril 533 42282v

Hydril Cs 2p3x5f

More Documents from "Boris Zaslichko" 1pr1y

Hydril - Gk Bop.pdf 3w4a1g

Cameron - F And Fc Gate Valves.pdf 3s4y6

Tds-11sa Service Manual.pdf 5b3772

2c82t

Anais Nin Djeca Albatrosa 442zg

Control 8 Control Estadistico De Procesos Bueno 674o2g
