Fuse Box Volkswagen at B6 6h4u5n

Fuse box Volkswagen at B6

1 of 31

Browse

http://fusesdiagram.com/volkswagen/fuses-and-relay-volkswagen-at-...

Fuse box diagram Locate fuses and relays

Fuses and relay Volkswagen at B6

See What's Next

WATCH NOW

›

2/5/2018 6:53 PM

Fuse box Volkswagen at B6

2 of 31

http://fusesdiagram.com/volkswagen/fuses-and-relay-volkswagen-at-...

For the Volkswagen at B6 (3C) 2005, 2006, 2007, 2008, 2009, 2010, 2011 model year. Fuse box location.

Fuse box in engine compartment Volkswagen at B6. Fuse box location. The electronics box is mounted at the front right in the engine compartment.

2/5/2018 6:53 PM

Fuse box Volkswagen at B6

3 of 31

http://fusesdiagram.com/volkswagen/fuses-and-relay-volkswagen-at-...

fuse box diagram (type 1 – pre 04.2005)

AdChoices

2/5/2018 6:53 PM

Fuse box Volkswagen at B6

4 of 31

http://fusesdiagram.com/volkswagen/fuses-and-relay-volkswagen-at-...

legend (type 1)

R1

Ignition main circuits relay

R2

R3

R4

F1

(5A/15A) Transmission control module (TCM)

F2

(30A) Anti-lock brake system (ABS)

F3

(20A) Multifunction control module 2

F4

(5A) Multifunction control module 1

F5

(20A) Horn

F6

(20A) Engine management

F7

(5A) Clutch position potentiometer (AXX/BPY/BWA)

F8

(10A) Engine coolant blower motor control module, engine management

F9

(5A/10A) Engine management

F10

(5A/10A) Engine management

F11

(25A) Engine management-petrol

2/5/2018 6:53 PM

Fuse box Volkswagen at B6

5 of 31

F12

http://fusesdiagram.com/volkswagen/fuses-and-relay-volkswagen-at-...

(15A) Engine management

F13

F14

F15

(10A) Engine management

F16

(15A) Steering column function control module

F17

(10A) Instrumentation control module

F18

(30A) Audio unit output amplifier

F19

(15A) Audio system, navigation system

F20

(5A) Aerial module, telephone

F21

(10A) Audio unit, television tuner

F22

(7,5A) Telematics control module

F23

F24

(10A) CAN data bus gateway control module

F25

F26

(10A) Engine management

F27

2/5/2018 6:53 PM

Fuse box Volkswagen at B6

6 of 31

http://fusesdiagram.com/volkswagen/fuses-and-relay-volkswagen-at-...

F28

–

F29

–

F30

(20A) Auxiliary heater control module

F31

(30A) Windscreen wipers

F32

(10A) Engine management

F33

(15A) Engine management

F34

–

F35

–

F36

–

F37

–

F38

–

F39

–

F40

–

F41

–

F42

–

F43

–

2/5/2018 6:53 PM

Fuse box Volkswagen at B6

7 of 31

http://fusesdiagram.com/volkswagen/fuses-and-relay-volkswagen-at-...

F44

(10A) Engine management

F45

(10A) Engine management

F46

(10A) Engine management

(40A) LH headlamp, LH tail lamp, multifunction control module 1, RH front side lamp, RH tail F47 lamp

F48

(40A) LH side lamp, LH tail lamp, multifunction control module 1, RH headlamp, RH tail lamp

F49

(50A) Multifunction control module 1

F50

(60A) Split charge relay

F51

–

F52

(60A) Heated rear window

(50A) Fascia fuse box/relay plate 1 (F40-F42), fascia fuse box/relayplate2(F39), multifunction F53 control module 1

F54

(50A) Glow plug control module

legend (type 2) – fuse box type 1 (pre 04.2005).

1

Ignition main circuits relay

2

2/5/2018 6:53 PM

Fuse box Volkswagen at B6

8 of 31

http://fusesdiagram.com/volkswagen/fuses-and-relay-volkswagen-at-...

3

4

F1

(5A/15A) Transmission control module (TCM)

F2

(30A) Anti-lock brake system (ABS)

F3

(20A) Multifunction control module 2

F4

(5A) Multifunction control module 1

F5

(20A) Horn

F6

F7

F8

F9

F10

F11

F12

F13

F14

2/5/2018 6:53 PM

Fuse box Volkswagen at B6

9 of 31

http://fusesdiagram.com/volkswagen/fuses-and-relay-volkswagen-at-...

F15

F16

(15A) Steering column function control module

F17

(10A) Instrumentation control module

F18

(30A) Audio unit output amplifier

F19

(15A) Audio system, navigation system

F20

(5A) Aerial module, telephone

F21

F22

(7,5A) Telematics control module

F23

(10A) Engine management

F24

(10A) CAN data bus gateway control module

F25

F26

(10A) Engine management

F27

(10A) Engine management-Diesel

F28

(25A/30A) Engine management

F29

(10A/15A) Engine management

F30

(20A) Auxiliary heater control module

2/5/2018 6:53 PM

Fuse box Volkswagen at B6

10 of 31

http://fusesdiagram.com/volkswagen/fuses-and-relay-volkswagen-at-...

F31

(30A) Windscreen wipers

F32

–

F33

–

F34

–

F35

–

F36

–

F37

–

F38

(10A) Engine coolant blower motor control module, engine management

F39

(10A) Engine management

F40

(10A/15A) Engine management

F41

–

F42

–

F43

–

F44

–

F45

–

F46

–

2/5/2018 6:53 PM

Fuse box Volkswagen at B6

11 of 31

http://fusesdiagram.com/volkswagen/fuses-and-relay-volkswagen-at-...

(40A) LH headlamp, LH tail lamp, multifunction control module 1, RH front side lamp, RH tail F47 lamp

F48

(40A) LH side lamp, LH tail lamp, multifunction control module 1, RH headlamp, RH tail lamp

F49

(50A) Multifunction control module 1

F50

(60A) Split charge relay

F51

–

F52

(60A) Heated rear window

(50A) Fascia fuse box/relay plate 1 (F40-F42), fascia fuse box/relayplate2(F39), multifunction F53 control module 1

F54

(50A) Glow plug control module

fuse box diagram (type 2 – since 2005).

2/5/2018 6:53 PM

Fuse box Volkswagen at B6

12 of 31

http://fusesdiagram.com/volkswagen/fuses-and-relay-volkswagen-at-...

legend.

R1

Secondary air injection (AIR) pump relay

R2

Ignition main circuits relay

F1

(7,5A) Telematics control module

F2

(30A) Anti-lock brake system (ABS)

F3

(20A) Multifunction control module 1

F4

(20A) Multifunction control module 2

F5

(5A) Multifunction control module 1

2/5/2018 6:53 PM

Fuse box Volkswagen at B6

13 of 31

http://fusesdiagram.com/volkswagen/fuses-and-relay-volkswagen-at-...

F6

(5A/15A) Transmission control module (TCM)

F7

(15A) Audio system, navigation system

F8

–

F9

(15A) Steering column function control module

F10

(20A) Engine management

F11

(5A) Instrumentation control module

F12

(5A) Telephone control module

F13

(10A) Engine management

F14

(30A) Engine management

F15

(10A) CAN data bus gateway control module

F16

(10A/15A) Engine management

F17

–

F18

–

F19

(30A) Audio unit output amplifier

F20

(5A/15A) Clutch position potentiometer engine management

F21

(20A) Auxiliary heater control module

2/5/2018 6:53 PM

Fuse box Volkswagen at B6

14 of 31

http://fusesdiagram.com/volkswagen/fuses-and-relay-volkswagen-at-...

F22

(30A) Windscreen wipers

F23

(10A) Engine coolant blower motor control module, engine management

F24

(10A/15A) Engine management

F25

(40A) Multifunction control module 1

F26

(40A) Multifunction control module 1

F27

(60A) Heated rear window

F28

(40A) Engine management-petrol

F29

(50A) Multifunction control module 1

F30

(50A) Multifunction control module 1

Back-up fuse box Volkswagen at B6.

2/5/2018 6:53 PM

Fuse box Volkswagen at B6

15 of 31

http://fusesdiagram.com/volkswagen/fuses-and-relay-volkswagen-at-...

fuse box pre 04.2005.

F1

(150A/180A) Alternator

F2

(80A) Power steering

F3

(50A/80A) Engine coolant blower motor control module

(100A) Fascia fuse box/relay plate 1 (F32-F37),fascia fuse box/relay plate2(F32-F37), fascia F4 fuse box/relay plate 3 (F44/F46)

F5

(80A) Fascia fuse box/relay plate 2 (F22-F27)

F6

(50A) Fascia fuse box/relay plate 1 (F12-F17/F20/F22-F27/F43-F45)

F7

–

fuse box since 05.2005.

2/5/2018 6:53 PM

Fuse box Volkswagen at B6

16 of 31

http://fusesdiagram.com/volkswagen/fuses-and-relay-volkswagen-at-...

F1

(150A) Altemator

F2

(80A) Power steering

F3

(50A/80A) Engine coolant blower motor control module

(100A) Fascia fuse box/relay plate 1 (F32-F37), fascia fuse box/relay plate 2 (F32-F37), fascia F4 fuse box/relay plate 3 (F44/F46)

F5

(80A) Fascia fuse box/relay plate 2 (F22-F27)

F6

(50A) Fascia fuse box/relay plate 1 (F12-F17/F29-F31)

F7

(60A) Split charge relay

F8

(40A) Anti-lock brake system (ABS)

Fuse box in enger compartment Volkswagen at B6. Fuse box, in right-hand side of dash .

2/5/2018 6:53 PM

Fuse box Volkswagen at B6

17 of 31

http://fusesdiagram.com/volkswagen/fuses-and-relay-volkswagen-at-...

fuse box diagram. left hand drive

2/5/2018 6:53 PM

Fuse box Volkswagen at B6

18 of 31

http://fusesdiagram.com/volkswagen/fuses-and-relay-volkswagen-at-...

right hand drive

F1

–

F2

(5A) Anti-lock brake system (ABS), parking brake control module

F3

(5A) Parking aid control module, navigation system

F4

(5A) Cruise control

F5

(10A) RH gas discharge headlamp

2/5/2018 6:53 PM

Fuse box Volkswagen at B6

19 of 31

http://fusesdiagram.com/volkswagen/fuses-and-relay-volkswagen-at-...

F6

(5A) Transmission mode selection switch

F7

(5A) Headlamp level control module

F8

(5A) Engine management

F9

(10A) Supplementary restraint system (SRS)

F10

(5A) Engine management (BLF/BLR/B LY/AXX/B PY/B LX/BVX/BVY/BVZ/BWA)

F12

(10A) Door function control module, left front

F13

(10A) Parking aid control module

F14

(10A) Assisted door closing control module relay

F15

(5A) Heater/air conditioning (AC)

F16

(5A) Transmission mode selection switch

F17

(10A) Anti-lock brake system (ABS), parking brake control module

F18

–

F19

–

F20

–

F21

–

F22

(30A) Accessories connector

2/5/2018 6:53 PM

Fuse box Volkswagen at B6

20 of 31

http://fusesdiagram.com/volkswagen/fuses-and-relay-volkswagen-at-...

F23

(30A) Door function control module, left rear, door function control module, right rear

F24

(30A) Assisted door closing control module, left rear

F25

(30A) Assisted door closing control module, right rear

F26

–

F27

(25A) Heated seats

F28

(15A) Engine management

F29

(30A) Door function control module, driver, door function control module, left front

F30

(20A) Parking brake control module

F31

(20A) Parking brake control module

F32

–

F33

(20A) Accessories connector

F34

(15A) Engine management (AXX/BLF/BLR/BLX/BLY/BPY/BVX/BVY/BVZ/BWA)

F35

(20A) Cigarette lighter

F36

–

F37

–

F38

–

2/5/2018 6:53 PM

Fuse box Volkswagen at B6

21 of 31

http://fusesdiagram.com/volkswagen/fuses-and-relay-volkswagen-at-...

(10A) Heater/air conditioning (AC), heated seats, heated wind screen waterjets, split charge F39 relay

F40

(5A) Crash control module (taxi/police)

(15A) Alarm system (taxi), auxiliary power sockets (glove box) – taxi, auxiliary power F41 sockets(luggage compartment)-taxi, interior lamps-taxi, roof sign lamp-taxi, taximeter

F42

(20A) Auxiliary power sockets(glove box)-taxi

(5A) Alarm system (taxi), auxiliary power sockets (police), auxiliary power sockets (glove box) F43 – taxi, auxiliary power sockets (luggage com partment) -taxi

F44

(20A) Alarm system (taxi), auxiliary power sockets- taxi, auxiliary power sockets (police)

Fuse box, on left in dash pane Volkswagen at B6. fuse box location.

2/5/2018 6:53 PM

Fuse box Volkswagen at B6

22 of 31

http://fusesdiagram.com/volkswagen/fuses-and-relay-volkswagen-at-...

fuse box diagram.

F1

(10A) Datalink connector (DLC)

F2

(5A) Anti-lock brake system (ABS)

F3

(5A) Power steering

2/5/2018 6:53 PM

Fuse box Volkswagen at B6

23 of 31

F4

http://fusesdiagram.com/volkswagen/fuses-and-relay-volkswagen-at-...

(5A) Brake pedal position (BPP)switch

(10A) LH gas discharge head lamp, head lamp level control module, head lamp adjustment F5 motor, left or single, head lamp adjustment motor, right

F6

(5A) Trailer control module

F7

(5A)Databusconnection,enginemanagement,instrumentationcontrolmodule

F8

(5A) Garage door opener, interior rearview mirror, rear window blind

F9

(5A) Four-wheel drive control module

F10

(5A) Engine management

F11

(5A) Accident data recorder button, taximeter

F12

(10A) Door function control module, driver

F13

(10A) Datalink connector (DLC), light switch

F14

(5A) Steering column function control module

F15

(5A) Multifunction control module 1

F16

(10A) Ignition system

F17

(10A) Alarm system, auxiliary heater, wind screen wiper rain sensor

F18

–

2/5/2018 6:53 PM

Fuse box Volkswagen at B6

24 of 31

http://fusesdiagram.com/volkswagen/fuses-and-relay-volkswagen-at-...

F19

–

F20

–

F21

–

F22

(5A/10A) engine management

F23

(10A) engine management

F24

(5A/20A) Transmission control module(TCM), reverse gear position switch

F25

(10A) engine management

F26

(10A) Rear window blind

F27

(5A) Heater/air conditioning (AC)

F28

–

F29

(20A) Trailer control module

F30

(15A) Trailer control module

F31

(25A) Trailer control module

F32

(30A) Multifunction control module1

F33

(20A)Sunroof

F34

(15A) engine management

2/5/2018 6:53 PM

Fuse box Volkswagen at B6

25 of 31

http://fusesdiagram.com/volkswagen/fuses-and-relay-volkswagen-at-...

F35

(30A) Head lamp washers

F36

(20A) Auxiliary heater

F37

(30A) Heated seats

F38

–

F39

(40A) Heater/air conditioning (AC)

F40

(5A)Fog lamps

F41

(40A) Heater/air conditioning(AC)

F42

(15A) Windscreen washers, rear screen wiper motor

F43

(20A) Auxiliary heater

F44

(20A) Auxiliary heater

F45

(25A) Auxiliary power sockets

(5A) Two-way radio (police), crash control module(taxi/police), ignition switch circuits, F46 tachograph

(15A) Alarm system (taxi), auxiliary power sockets (glove box) – taxi, auxiliary power F47

sockets(luggage compartment)-taxi, auxiliary power sockets(two-way radio)- police, interior lamps, luggage compartment lamp

F48

(20A) Auxiliary power sockets (police)

F49

–

2/5/2018 6:53 PM

Fuse box Volkswagen at B6

26 of 31

http://fusesdiagram.com/volkswagen/fuses-and-relay-volkswagen-at-...

Relay carrier on onboard power supply control unit, on left under dash Volkswagen at B6.

R1

Ignition main circuits relay

R2

–

R3

–

R4

Multifunction control module relay

R5

Heated rear window relay

R6

Horn relay

R7

Windscreen washer pump relay 1

2/5/2018 6:53 PM

Fuse box Volkswagen at B6

27 of 31

http://fusesdiagram.com/volkswagen/fuses-and-relay-volkswagen-at-...

R8

Windscreen washer pump relay 2

R9

Ignition auxiliary circuits relay

R11

Auxiliary heater relay

R12

R13

Heater blower motor relay

R14

R15

Fuel pump(FP) relay-Diesel

R16

Headlamp washer pump relay

R17

Starter motor relay

F1

F2

F3

(30A) Electric seats circuit breaker (enger)

F4

(15A) Electric seats circuit breaker (driver)

2/5/2018 6:53 PM

Fuse box Volkswagen at B6

28 of 31

http://fusesdiagram.com/volkswagen/fuses-and-relay-volkswagen-at-...

Posted in Volkswagen Tagged Fuse box diagram Volkswagen

FUSES AND RELAY VOLKSWAGEN POLO 6R

FUSES AND RELAY VOLKSWAGEN GOLF 6

Ads AdChoices

2/5/2018 6:53 PM

Fuse box Volkswagen at B6

29 of 31

http://fusesdiagram.com/volkswagen/fuses-and-relay-volkswagen-at-...

Categories Alfa Romeo Audi BMW Chevrolet Chrysler Dodge Fiat Ford Honda Hyundai Jeep Kia Land Rover Mazda Mercedes Mercury Nissan Opel/Vauxhall Peugeot Range Rover

2/5/2018 6:53 PM

Fuse box Volkswagen at B6

30 of 31

http://fusesdiagram.com/volkswagen/fuses-and-relay-volkswagen-at-...

Renault Toyota Volkswagen

Recent Posts Fuses and relay Mercedes W168 Fuses and relay Mercedes W210 Fuses and relay Mercedes W202 Fuses and relay Mercedes W201 Fuses and relay Opel/Vauxhall Meriva B Fuses and relay Opel/Vauxhall Meriva A Fuses and relay Opel/Vauxhall Frontera B Fuses and relay Toyota Land Cruiser Prado 2002-2009 Fuses and relay Toyota Corolla 2007-2013 Fuses and relay Toyota Rav4 2005-2012

You may also enjoy...

2/5/2018 6:53 PM

Fuse box Volkswagen at B6

31 of 31

Fuses and relay Volkswagen …

http://fusesdiagram.com/volkswagen/fuses-and-relay-volkswagen-at-...

Fuses and relay Volkswagen …

Fuses and relay Volkswagen … Fuses and relay Volkswagen …

2/5/2018 6:53 PM
