Friction Less Electromagnetic Breaking System 572e2u

FRICTIONLESS ELECTROMAGNETIC BREAKING SYSTEM SYNOPSIS: Nowadays the automobile field is improved with more technical ideas. By improving these techniques, we can increase the safety level and also more facilities inside the vehicle. Here is a project to construct a prototype of electronic braking system. We know that in these heavy traffic cities, more accidents are happening due to break failure. This project is electromagnetic breaking which improve the breaking reliability and many more features.

When the break is applied in the vehicle, the electronic control board will sense the force of the break applied. Depends on the force applied, the signal is given to the electromagnet. The electromagnet in the disc will energies and become magnet to attract the iron piece fixed in the wheel. In the strong magnetic field, the wheel of the vehicle will decrease its speed, which will be a better breaking for the vehicle. This breaking has more advantages like no friction, low cost, less weight, high speed and reliable.

Disc

Axel

Electronic Control Board

Electromagnet Wheel

Soft Iron

Battery

Break
