CoDeSys V3 Overview Linux CoDeSys V3 Linux Runtime Overview U for the CoDeSys Linux Runtime: The processors x86, ARM and PowerPC are ed.

Linux without Realtime: Basically any distribution can be used. A customized Linux is necessary for embedded systems. Additional libraries for example for PCI bus or PCAP for Ethernet are also required. All libraries are open source.

Linux with Realtime: CoDeSys V3 under Linux with realtime properties can only be used with the realtime kernel Preempt_rt patch from the OSADL organisation. RT Linux, RTAI Linux and Xenomai are not ed! The OSADL realime kernel is free of charge but it must be adapted to the particular hardware. Such an adaption is offered for example by Linutronix, Pengutronix or Denx. 3S-Smart Software Solutions GmbH does not offer said adaptation service! Before starting a project the hardware to be used should be considered suitable by the company who is to perform the adaptation!

Memory Requirements: Remanent Memory (Hard disk, Flash): # # # # #

Minimal: 16 MB (smaller on demand) Typical: 64 MB for runtime code: minimal 1MB for boot project and/or IEC program code: rest QT for target visualisation: 10MB (platform dependent) - smaller versions are possible with QT adaptions done by the Linux service companies.

RAM: # # # #

Minimal: 3 MB (minimal project) Typical: 32 MB WithTarget visualisation: 64 MB (minimum recommendation) for example: Targetvisu on ARM: 4,5 MB (minimal project)

ed Fieldbuses / Fieldbus cards: # # #

Retain Memory (NVRAM, SRAM):

#

# #

#

Typical: (any desired) kB For IEC-Program Data type RETAIN and RETAIN PERSISTENT

#

EtherCAT with 3S configurator und 3S stack Sercos III Master (in development) Profibus Master (Hilscher EC1 or netX) with 3S configurator and Hilscher stack (released soon) Profinet Master (Hilscher netX) with 3S configurator and Hilscher stack CANopen Master (only with SocketCAN - Open Source driver for Philips SJA1000 Chip) others on demand

Important for CoDeSys: There must be a debugger! Debugger for ARM or PowerPC over GDB Server with thread-! Debugging on the x86 platform is normally no problem. More information: Linux From Scratch (LFS) is a project that provides you with step-by-step instructions for building your own custom Linux system, entirely from source code: Http://www.linuxfromscratch.org/

List of combinations of compiler for different platforms (crosstool build results): http://www.kegel.com/crosstool/crosstool0.43/buildlogs/ Websites for more information: www.pengutronix.de www.linutronix.de www.denx.de

What is the best way to build a Linux distribution for an embedded system in a reproducable way,caring about long term maintenance and small footprint? PTXdist is a GPL licensed build system for lands, started by Pengutronix. It uses the Kconfig configuration system from the Linux kernel. Although PTXdist (without patches) still fits on one disc, a whole root filesystem can be built as easy as "ptxdist go": Http://www.pengutronix.de/software/ptxdist/index_en. html

Author: PhB/PW V1.05 - Date: 2009-01

3S-Smart Software Solutions GmbH · Memminger Str. 151 · DE-87439 Kempten · Tel. +49- 831-54031-0 · www.3s-software.com
