01 Mototrbo Overview 21s56

DIGITAL REMASTERED

Why Digital ?

DIGITAL REMASTERED

TDMA Advantage Double Capacity Channel No risk of interference

DIGITAL REMASTERED

TDMA Advantage GSM technology

Longer Talk time (Time Division Multiple Access)

• MOTOTRBO Portable Radio is capable of achieving 13 or 19 hours* of operation (Std/HiCap Battery) • Minimum 40% increase in talk time • Transmit every other timeslot, effectively transmitting half of the time ANALOG SLOT 1

SLOT 1

SLOT 1

SLOT 1

DIGITAL SLOT 2

SLOT 2

SLOT 2

SLOT 2

* Based on 5:5:90 duty cycle (5% Transmit : 5% Receive : 90% Standby

DIGITAL REMASTERED

TDMA Advantage Lower infrastructure and licensing cost REPEATER

FREQUENCY

REPEATER 1

FREQUENCY 1 COMBINER

REPEATER 2

FREQUENCY 2

Added Costs DIGITAL REMASTERED

MOTOTRBO Value Proposition All Call

Call Management • Basic Fleet management capabilities • Caller ID and Group ID • All Call, Group Call and Private Call • Call Alert (Paging), Radio Check

Group Call

• Advance Call Control • Emergency • With Alarm • With Call • With Voice to Follow

Private Call

• Radio Enable/Disable

DIGITAL REMASTERED

MOTOTRBO Value Proposition Security & Authorization • Radios & Lock • 4-digit to protect radios from unauthorized s • Effective control and access to your workforce communications

• Repeater Authorization • Prevents unauthorized radio from keying up the repeater • Initiated utilizing an IP-based ADP application Note: P8200 & P8600 Series only

DIGITAL REMASTERED

MOTOTRBO Value Proposition Text Messaging • Discreet communication • Increase channel efficiency by reducing voice traffic • Increase operation efficiency  XIR-P8668 & XIR-M8668 Series up to 5 lines

DIGITAL REMASTERED

MOTOTRBO Dual Mode s Dual Mode • Digital and Analog • MOTOTRBO s Dual mode: analog and digital • 12.5khz, 25khz analog mode • 12.5khz in Digital mode • CTCSS (PL)/DPL and MDC signaling

• Scans between analog and digital channels

Note: P8200 & P8600 Series only

DIGITAL REMASTERED

MOTOTRBO Transmit Interrupt Suite *Purchasable Option

The Transmit Interrupt Suite enables you to intervene and deliver important critical information to your workforce as soon as it's available.

The result is business-critical information being delivered exactly when it's needed.

DIGITAL REMASTERED

Wide Area Channel “All Site Light Up”

Top Floor

Basement 1

Basement 2

DIGITAL REMASTERED

What is Radio Roaming?  Allows end s to roam from site to site seamlessly without the need to press a button or change channel positions Site B

Site A

IP Link

AEL2600 12

Roam Site Searching

Home Site =

A

Site 1

Home Site =

Site 2

B

IP NETWORK

IP NETWORK

Home Site =

Home Site =

Site 1

SITE 1

Site 2

C

SITE 2 AEL2600 13

Design Considerations Master Repeater Simplified WAN

Known Repeaters

192.168.1.100 145.55.66.1

192.168.15.1

192.168.1.100 192.168.15.1 123.234.34.1

123.234.34.1 LAN or INTERNET

192.168.15.35 192.168.1.101 Repeater B

123.234.34.66 192.168.1.102 Repeater C AEL2600 14

MOTOTRBO IP-Site Connect *Purchasable Option

• Connects up to 15 repeaters via IP network • Configurable Local and/or Wide Area communication per repeater • Building a larger or more effective RF coverage area. • Broadcasting announcements to all sites. • Connecting repeaters operating in different RF bands.

IP

DIGITAL REMASTERED

MOTOTRBO Telephone Interconnect *Purchasable Option

Digital Telephone Interconnect • Allows MOTOTRBO Radios to connect to Corporate Office Phone System (PBX) or Public Switched Telephone Network (PSTN) by: • Analog Phone Patch (APP) box • TCE RTP-010 • Works on MOTOTRBO Digital Conventional, IP-Site Connect and Capacity Plus systems.

DIGITAL REMASTERED

MOTOTRBO Value Proposition Enabling Data Applications • Enabling PC Based Text Messaging Application • IP Based Text Messaging Server/Client application • Enables communication between radios and remote s who are not in radio coverage • Email based interface for two way radio system

• Built-in GPS receiver (option) with Integrated antenna • Enables Location tracking applications, • Increase operational safety and efficiency • Indoor location tracking

• Compatible use Hotel Application Hot Sos FCS

DIGITAL REMASTERED

XiR P8600 Series Features Specific feature sets for XiR P8600 Series Radios • Ultra-wide band for UHF 350-400 MHz • Integrated Bluetooth & GPS • Intelligent Audio • Voice Announcements • Dual Capacity Direct Mode • Over The Air Programming

DIGITAL REMASTERED

MOTOTRBO Portable Series VHF 350-400 MHz

XiR P8600/8

XiR P8660/8

DIGITAL REMASTERED

MOTOTRBO Mobile & Repeater Series XiR M8660/8

XiR M8620/8

Repeater XiR R8200 Slim Design Repeater SLR 5300

DIGITAL REMASTERED

THANK YOU For more information, visit: www.motorola.com/mototrbo
