Thermostat - Eberle 3i6h1n

Wall thermostats NON-PROGRAMMABLE RTR-E Series The Eberle RTR-E Series Electromechanical Wall Thermostats offer bi-metal technology and will continue to remain highly reliable technology in controlling temperatures under difficult conditions. The RTR-E Series features a modern, aesthetic design.

Features and Benefits

111170351100

•

Bimetal technology with thermal and high precision

•

Surface mounting or directly on a conduit box with vertical fixing holes or on a DIN rail with a snap-on clip

•

Clear terminal arrangement and ample terminal space for quick and easy installation

•

Housing color: pure white (similar to RAL 9010)

•

Range limitation inside setting knob

Specifications Scan for all models, literature and cross reference

Part Numbers

Series

Application

Temperature Range

Electrical Rating

101110151102

RTR-E 3521

1 Heat Only SPST

5°C to 30°C

230V AC 50/60Hz, SPST, 16(4) Amps

111170951100

RTR-E 6705

1 Heat / 1 Cool SPDT

5°C to 60°C

230V AC 50/60Hz, SPDT, 10(4) Heating, 5(2) Amps Cooling

111170291100

RTR-E 6722

1 Heat / 1 Cool Dual Voltage

5°C to 30°C

24 or 230V AC 50/60Hz, SPDT, 10(4) Heating, 5(2) Amps Cooling

111770791100

RTR-E 6747

1 Heat / 1 Cool Tamper Proof

5°C to 30°C

24 or 230V AC 50/60Hz, SPDT, 10(4) Heating, 5(2) Amps Cooling

111170351100

RTR-E 6763

1 Heat / 1 Cool Auto Fan On/Off

5°C to 30°C

230V AC 50/60Hz, SPDT, 10(4) Heating, 5(2) Amps Cooling

28 www.Uni-Line.com

Customer Service 1300 788 130

Wall thermostats NON-PROGRAMMABLE KLR-E Series The Eberle KLR-E Series Wall Thermostats offer timeless design and a high degree of regulation accuracy in a variety of options. The regulators are robust, reliable and long-lasting. Clear display elements and ease of operation are an additional plus. The main application areas are two and four pipe systems in living and office areas, as well as heat pumps and ventilation systems.

Features and Benefits •

Electromechanical regulator with thermal return

•

Range able to be narrowed using the adjusting knob

•

Surface-mounted or mounted directly onto flush-mounted box with adaptor frame

•

Switches: Mains ON/OFF

•

Switches: Fan speed high/med/low

517724351100

111770791100

Scan for all models, literature and cross reference

517724051100

Specifications Part Numbers

Series

Application

Temperature Range

Electrical Rating

111770451100

KLR-E 7004

Manual Change Heat/Cool/Fan with On/Off and 3 Speed Fan 1 Heat / 1 Cool (4 Pipe)

5°C to 30°C Bi-Metal Sensing

230V AC 50/60Hz, SPDT 6(3) Amps

111770791100

KLR-E 7007

Manual Change Heat/Cool/Fan with On/Off and Continuous/Auto Fan, 1 Heat / 1 Cool (4 Pipe), Cool + Electric Heat or Heat Pump Dual Voltage)

5°C to 30°C Bi-Metal Sensing

24 or 230V AC 50/60Hz, SPDT 6(3) Amps

111771251100

KLR-E 7012

Manual Change Heat/Cool with On/Off and 3 Speed Fan, 1 Heat / 1 Cool (4 Pipe) or Cool + Electric Heat)

5°C to 30°C NTC Internal Sensing

230V AC 50/60Hz, SPDT 6(3) Amps

111701951100

KLR-E 7019

Cool Only, On/Off and 3 Speed Fan (Cooling Only)

5°C to 30°C Bi-Metal Sensing

230V AC 50/60Hz, SPDT 6(3) Amps

517720251100

KLR-E 7202

Auto Change Heat/Cool with On/Off and On 1 Heat / 1 Cool (4 Pipe)

5°C to 30°C NTC Internal Sensing

230V AC 50/60Hz, SPDT with Neutral Zone 10(4) Amps Heat/Cool 6(3)Amps Fan

517720351100

KLR-E 7203

Auto Change Heat/Cool with On/Off Heat/Cool and and 3 Speed Fan 1 Heat / 1 Cool (4 Pipe)

5°C to 30°C NTC Internal Sensing

230V AC 50/60Hz, SPDT with Neutral Zone 10(4) Amps

517724151100

KLR-E 7603

Auto Change Heat/Cool Heat pump (Compressor & Reversing Valve)

5°C to 30°C NTC Internal Sensing

24 or 230V AC 50/60Hz, SPDT with Neutral Zone 10(4) Amps

517724351100

KLR-E 7611

Auto Change Heat/Cool with On/Off Heat pump (Compressor & Reversing Valve)

5°C to 30°C NTC Internal Sensing

24 or 230V AC 50/60Hz, SPDT with Neutral Zone 10(4) Amps

517724051100

KLR-E 525 52 hp

Auto Change Heat/Cool with On/Off and 3 Speed Fan Heat Pump (Compressor & Reversing Valve)

5°C to 30°C NTC Internal Sensing (External Sensor connection)

230V AC 50/60Hz, SPDT with Neutral Zone 10(4) Amps Heat/Cool and, 6(3) Amps Fan
