Global Business Services
IS OIL - TSW (Traders and Schedulers Workbench)
Venkata Anjibabu.Alluru
© Copyright IBM Corporation 2007
Global Business Services
Course Objectives
The course will prepare you to Understand the Integration of Supply Chain scheduling and supply execution in R/3 Define the Key components of TSW Describe the processes in TSW and explain what are the necessary customization settings.
2
© Copyright IBM Corporation 2006
Global Business Services
Course Contents 1. 2. 3. 4.
3
TSW Overview TSW Master Data TSW Components Key Configurations
© Copyright IBM Corporation 2006
Global Business Services
TSW Introduction-Definition Definition - TSW: TSW (Trader’s and Scheduler’s Workbench) is a scheduling tool designed to plan, schedule and control hydrocarbon bulk movements through the supply chain, via interfaces with business partners and other systems. TSW is the central access point for all the capabilities that schedulers need to manage the supply chain operations. It is used to plan and execute the movement of material through the supply chain, E.g. creation of nominations, ticketing and the automation of material movements upon actualization of freight movements.
4
© Copyright IBM Corporation 2006
Global Business Services
General Business Scenario
Planning , scheduling and executing the distribution of crude oil and refined products plays a major role in Oil companies for Inbound movements (Purchasing),Outbound Movements (Sales and Delivery) and Internal transfers (Stock Replenishments). Normally we use pipeline and marine means of transports. Scheduling and executing shipments using TSW functions to manage and track the various good movements.
5
© Copyright IBM Corporation 2006
Global Business Services
Oil And Gas Business Processes - Overview
6
© Copyright IBM Corporation 2006
Global Business Services
TSW Push-Pull Model
7
© Copyright IBM Corporation 2006
Global Business Services
TSW Integration .
Customers
Sales contracts / Orders
Deliveries & Goods issues
Sales & Distribution Nominations &
IS OIL
Ticketing
TSW FI/CO
Materials
Payments
Management Vendors
8
Purchase
Deliveries &
contracts
Goods receipts
© Copyright IBM Corporation 2006
Global Business Services
TSW Interfaces . Nominations Created in GSAP
Outbound interface
External loading/gantry (TAS)
SAP
External Partners
Inbound interface Updates to Nominations Ticket actualisation for product movement
9
© Copyright IBM Corporation 2006
Global Business Services
Process To model the supply chain using TSW, the following tools and master data are provided: Planning tools - Stock Projection Worksheet (SPW), Location Balancing, Worklist Scheduling tools - Three-Way Pegging (3WP),Berth Planning Board (BPB), Nomination, Ticketing, Work list Master data -Transport system, locations, partner roles
10
© Copyright IBM Corporation 2006
Global Business Services
TSW Process Flow
11
© Copyright IBM Corporation 2006
Global Business Services
Business Process Scenarios Key Business process scenarios that can be executed by TSW (mainly bulk products by massive means of transport) : Buy processes FOB/CIF Import purchase Domestic purchase In-tank purchase at company owned location as well as at 3rd party location Purchase of Services such as freight, demurrage etc Sell processes FOB/CIF sale to 3rd party customers or to group companies Delivered sale In-tank sale at company owned location as well as at 3rd party location Transfer processes Intercompany transfer - gain/loss ed by recieving/sending company Plant to Plant transfer Note: Regrade transfers ** (** requires custom enhancement )
12
© Copyright IBM Corporation 2006
Global Business Services
TSW Master Data Master data Transport system (TS) Location Partner role Assignments of
location to transport system material to transport system material to location
13
© Copyright IBM Corporation 2006
Global Business Services
TSW Master Data :Transport System
14
© Copyright IBM Corporation 2006
Global Business Services
TSW Master Data : Location
15
© Copyright IBM Corporation 2006
Global Business Services
TSW Master Data : Partner Role
16
© Copyright IBM Corporation 2006
Global Business Services
Transport System – Location Assignments
© Copyright IBM Corporation 2006
Global Business Services
Transport System – Material Assignments
© Copyright IBM Corporation 2006
Global Business Services
Transport System/Location/Partner Assignments You can create Partner Assignments from the Transport System transaction
© Copyright IBM Corporation 2006
Global Business Services
Master Data Partner Role Assignments
© Copyright IBM Corporation 2006
Global Business Services
Topic Summary In this sub-topic, you learnt :
What Master Data is relevant for TSW, including: • Create Transport System • Create Location • Assign Location to Transport System • Create Partner Roles • Assign Materials to Transport System • Assign Materials to Locations
© Copyright IBM Corporation 2006
Global Business Services
TSW Components There are 4 main components in TSW:
Stock Projection Worksheet : Allow for inventory and replenishment planning 3-way Pegging : Used for scheduling Nomination : Allows for nomination process management (this indicates the planned movements) Ticketing :Enables integration with execution processing, i.e. movements have taken place / have materialized
22
© Copyright IBM Corporation 2006
Global Business Services
Planning and scheduling tools
23
© Copyright IBM Corporation 2006
Global Business Services
Stock Projection Worksheet The SPW is an interactive and flexible online report that shows the inventory forecast and associated movements at a daily level for a specified part of the supply chain. You can view the stock projection worksheet for base metal products at any level within a location hierarchy and for various transportation systems. The SPW is generally viewed and used by the scheduler and others who are responsible for stock movements The Stock Projection Worksheet indicates (by location and material) Inventory stock Scheduled incoming and outgoing stock The nominations consuming the stock The vessel on which the stock will be transported
24
© Copyright IBM Corporation 2006
Global Business Services
Stock Projection Worksheet - Definition
© Copyright IBM Corporation 2006
Global Business Services
Stock Projection Worksheet-Display
26
© Copyright IBM Corporation 2006
Global Business Services
3 Way Pegging (3PWP) We use 3 way pegging to plan and schedule bulk shipments based on supply and demand information (OR) Three-way pegging is a process used to create a nomination. It is called 3WP simply because it pegs 3 types of elements together to make the nomination – these are • Demand elements • Supply elements • Transportation vehicles
27
© Copyright IBM Corporation 2006
Global Business Services
3 Way Pegging-Display
28
© Copyright IBM Corporation 2006
Global Business Services
Nomination The Nomination is the central planning application in TSW to schedule, group and communicate bulk movements and transportation within a supply network. You use nominations to: • Capture movement schedules based on demand and supply data, such as from sales, purchase or transfer documents. • Navigate to and validate against master data, such as the transport systems, locations, partners or vehicles. • Handle status ( confirmation process) • Navigate to the TSW work list and update the SPW (Stock Projection Worksheet) • Automatically generate subsequent documents , such as deliveries , bulk shipments, goods movements or billing document • Show document flow • Integrate with R/3 inventory management
29
© Copyright IBM Corporation 2006
Global Business Services
TSW Master Data Requirements for Creating a Nomination
Nominations require the following information: • Transport System, model the supply chain and represent;- A fixed supply route in which product is moved from one location to another • Location, to which materials are assigned:- Assigned to a transport system as either origin / destination or both for the movement of product - One location can be assigned to many transport systems • Partner Role, represent customers, vendors, plants / storage locations - Are created as a Role Assignment (Receiver / Supplier) for a transport system and business location combination
© Copyright IBM Corporation 2006
Global Business Services
Nomination: Transaction Display
© Copyright IBM Corporation 2006
Global Business Services
Nominations - Types The Nomination Type is used to define the type of material that will be scheduled in the Nomination The differentiation between material types is made to enable different Nomination validation rules to be applied to each Below are few examples:
Type
Description
1)
ADCR
Additives Carrier Nomination
2)
CRCR
Crude Carrier Nomination
3)
PRCR
Products Carrier Nomination
4)
CRST
Crude Carrier Nomination for STi
5)
PRST
Products Carrier Nomination for STi
© Copyright IBM Corporation 2006
Global Business Services
Nominations - Process Flow
Origin / Destination Location Product / Quantities Scheduling dates
Validate and check for correctness
Purchase or Sales Contract Vehicle etc
Create Nomination CreateNomination TSW
(O4NCN)
Destination Location Save Output sent to Carrier
Origin line in
Product moved from
Nomination
Origin location to vehicle
actualised © Copyright IBM Corporation 2006
Global Business Services
Nominations - Item Status’ • Planned -
During supply chain planning the nomination can be created with the highest level of provisional information and used as a placeholder regarding the movement planned to take place
-
Details of the Nomination can still be amended
• Incomplete -
The status allows the scheduler to save the nomination as incomplete, although it is not possible to actualise or save. Additional details can be entered into the Nomination
-
Where details of the planned movement and schedule are still unknown
• Confirmed -
Final details of the schedule are known and entered into the nomination
-
All necessary communication regarding the schedule has been sent to relevant parties
-
Confirmation flags on the Nomination line items are set
-
Validation has been successfully completed © Copyright IBM Corporation 2006
Global Business Services
Nomination Header – Available Header Tabs
© Copyright IBM Corporation 2006
Global Business Services
Nomination Item - Detail Tabs
© Copyright IBM Corporation 2006
Global Business Services
Create Nominations - Scenarios Nominations can be created for a number of scenarios, including: Purchases;
Sales;
– In-tank
– Delivered Sales
– FOB CIF Purchase - Crude
– Barge or Vessel Delivery
– Domestic Purchase CIF/FOB
– FOB Planned Pick-up
(Barge & Cargo)
– Re-sale of Floating Cargo
Transfers; – By Pipeline – By Barge, Rail, Cargo – Inter-company Transfers for G/L Receiving Company
Direct Movements;
– Inter-company – Intra-company
© Copyright IBM Corporation 2006
Global Business Services
Ticket - Definition A ticket is an official notice sent by a partner, containing information about a product movement. •
In the ticket generation process, data is entered in the system either manually or through automatic interface:
Meter or Gauge readings (opening, closing or actual quantities)
Quantities or Inspection reports provided by external systems or partners
•
The system stores the data in a load ticket table and used the data during the actualization process
•
Actualization:
The system created the required transfer document, such as call-offs , delivery notes and invoices with actual figures
The system updates the book inventory
•
Reversal and Correction
Tickets can be cancelled and corrected including the subsequent postings in one go.
© Copyright IBM Corporation 2006
Global Business Services
Ticketing- Carrier Communication 1
39
© Copyright IBM Corporation 2006
Global Business Services
Ticketing- Carrier Communication 2
40
© Copyright IBM Corporation 2006
Global Business Services
Functions in Ticketing
© Copyright IBM Corporation 2006
Global Business Services
Ticketing - Process
Ticketing confirms the actual quantities and scheduled date associated with the nomination
Underlying documents created in background in GSAP
Nomination line item Actualised
Product loaded / discharge d
(Ticketing)
Automatic
SAP
(interfaces)
Manual Ticketing (O4TEN)
Auto Ticketing (O4TAPN) © Copyright IBM Corporation 2006
Global Business Services
Actualise a Ticket - Points to Note •
A ticket cannot be actualised until a nomination has been validated and saved
•
The load line (O) of a Nomination must be ticketed before the discharge line (D) to be able to determine any gains/loss during bulk movements
•
Once fully processed, the ticketed quantity will be displayed as the actual quantity in the nomination alongside the scheduled quantity
•
During Ticketing, GSAP will calculate the quantities of alternative UoM’s based on ASTM – temperature and density details against the defaults for the material and plant on which the Ticket is based –
When entering quantities of the same like for like measurements with fixed conversion factors (e.g 1000kg = 1 TO), entering values that do not correspond to the standard conversion rate will have an impact on stock reconciliation and the calculation of gain and loss
• Each ticket triggers a document flow in GSAP with reference to the information held within line 1 (Origin) and line 2 (Discharge) of a Nomination • Tickets actualised in error can either be corrected, reversed or marked as corrupt
• Tickets automatically generated via an interface or O4TAPN are actualised against their scheduled quantities and UoM
© Copyright IBM Corporation 2006
Global Business Services
Actualisation of Tickets
Automatically via Interfaces
Cannot overwrite: • Scheduled quantity • ASTM default quantities in other UoM’s
ACTUALISATION OF TICKET
Manually in SAP (O4TEN)
Automatically in SAP (O4TAPN)
© Copyright IBM Corporation 2006
Global Business Services
Nomination/Ticketing Integration - Actualise a Ticket
Origin or Destination line item Quantity Schedule date
Validate and check for Confirm HM Discharge
Actualise Ticket (Reference Nomination)
Confirm HM Loading
correctness
(O4TEN)
TD Shipment
Material Doc
Other Docs
Actualisation Background documents Nomination line item completed
BoL sent to Carrier
created Ticket is actualised
© Copyright IBM Corporation 2006
Global Business Services
Reverse, Correct & Mark Corrupt Tickets: Definitions
• A ticket that has been fully actualized can be reversed in order to undo all documents that has been generated. The reversal process will result in the nomination item to be open for re-ticketing • A ticket that has been fully actualized can be corrected for quantity or dates. Ticket correction will perform reversal of the original tickets and create new documents with the new corrected quantities or dates • If the load and discharge line of a nomination needs to be cancelled, the correct sequence is to reverse the discharge ticket before reversing the load ticket • A Ticket can be marked as corrupt when a reversal / correction cannot be processed for the actualized Ticket due to unforeseen errors. All related documents must be reversed or deleted manually before a ticket is corrupted
© Copyright IBM Corporation 2006
Global Business Services
Reversing Actualised Ticket Process
Origin or Destination line item actualised in error?
Reverse Ticket
Nomination line available for amendment or deletion
Confirm HM Loading Confirm HM Discharge
• Ticket reversal functionality cannot be used when: The Invoice has been paid The Customer has been billed Note: In both the above scenarios, the reversal process will follow non-TSW steps that would include the creation of a ‘ZRE’ order for sales (StBC process), or a “credit note” for purchase (PGS process) © Copyright IBM Corporation 2006
Global Business Services
Correct an Actualised Ticket - Process
Actualised Origin or Destination line item needs to be corrected?
Correct Ticket
Original underlying documents reversed. New underlying documents generated and posted
Confirm HM Loading Confirm HM Discharge
© Copyright IBM Corporation 2006
Global Business Services
Mark an Invalid Ticket as Corrupt
Origin or Destination line item cannot be actualised for technical reason?
Mark Ticket as Corrupt
Amend corrupt ticket’s underlying document manually
Process Corrupted Ticket
© Copyright IBM Corporation 2006
Global Business Services
Post a Ticket with Gain/Loss Outside Tolerance Levels
< 0.3% = Automatic
GAINS
> 0.3% to 1.5% = One release (e.g Supervisor)
LOSS
> 1.5% to 100% = Release by General Manager / Superintendent level
Discharge of Product
Origin to Destination Gain / Loss?
Tolerance Authorisation Levels set by Stream Line
Note: This example is for fuels transported via vessels. Tolerances can vary with mode of transport and product group
© Copyright IBM Corporation 2006
Global Business Services
Ticket Reversal
© Copyright IBM Corporation 2006
Global Business Services
Ticket Reversal Screen
© Copyright IBM Corporation 2006
Global Business Services
Ticket Corrections
© Copyright IBM Corporation 2006
Global Business Services
Ticket Corrections - Screen
© Copyright IBM Corporation 2006
Global Business Services
TSW Planning
© Copyright IBM Corporation 2006
Global Business Services
TSW Planning TSW Planning provides a linear view of the supply chain. That is, each planning object can have one source for planning purposes. In the case of locations, this represents the most common way a location is sourced. When you generate Planning data for the first time, the system builds up a linear planning chain by analyzing the master data entries. The system then stores the sequence. The system only recalculates the sequence if any one of a number of key points were changed since the last generation of planning data. For example, creating a new location, making a location planning relevant, or defining a new source.
You define production versions in material master data records and reference the production versions in the planning master data to handle seasonal grade changeovers. During TSW Planning, the system generates proposal quantities and dates that the scheduler can use as suggestions for possible nominations
© Copyright IBM Corporation 2006
Global Business Services
Replenishment Planning Functions
© Copyright IBM Corporation 2006
Global Business Services
Planning Functions TSW provides six different planning functions, that is, three planning types combined with two planning methods. Planning types: 1. Maximum replenishment: the inventory is filled to the maximum inventory level 2. Target replenishment: the inventory is filled to the target level 3. Replacement replenishment: the inventory is filled so that bulk issues scheduled in nominations are replaced Planning methods: 1. With calendar: the system only makes replenishment proposals for the days specified by the planning calendar selected 2. Reorder point planning: the system makes replenishment proposals for the days When the inventory falls below the reorder point specified in the SPW object planning screen.
© Copyright IBM Corporation 2006
Global Business Services
TSW Transactions - Worklist
© Copyright IBM Corporation 2006
