Prestige Installation Guide r65p

Prestige The new style of flat roof tile with a natural feel simple beauty with a resort touch in every inch. Unwind yourself to feel relaxed… and indulge in the aesthetic design full of pleasure.

by

10

Marketing Catalog

Prestige Roof Tiles and Ridges

Specification

Tile Size Lowest Roof Slope Highest Roof Slope Length of Purlin Net Tile Width after overlapping Number of tiles per roof

Tile Weight (Approximate) Tile Weight Dead Load for Buildings Structure

33x42 cm. 25 degrees 40 degrees 31-33 cm. 30 cm. 10-11 tiles/sq.m. 5.2 55

Installation

Ridges are installed by using the modern Dry Tech System with Mechanical Fixing without cement, leaving no concern on roof deterioration from cement stain or blown-away ridges due to wind. Our standard is of high quality, without the need to depend on craftsmanship and, most importantly, guaranteed leakage-free 100%

kg./tile kg./sq.m.

Fixing Standard

Minimurn fixing with 2 cross-head screws (with length of 2 Inches to end) per tile in alternate rows. (Tile fixing follows company's standard.)

-Actual color of roof tile may differ from the color in the picture due to printing. -The company reserves the right to adjust detail of information without prior notice. -Complete purchase of tiles for each installation is recommended to acquire the same production lot of tiles.

Important Data

- Prestige roof tiles are geographically designed and produced for the tropical climate in Thailand ing a rain-wind simulator test with meteorology data of Thailand in a wind tunnel simulation in England with Wind Tunnel Procedure test standard of British Standard BS 6567. - Prestige roof tiles are high-quality tiles, made with high technology and Wet on Wet glaze by using Inorganic Pigment to ensure total absorption of pigment into tile for longer-lasting color. - Prestige ridges are specially designed to match the character of tiles and their functions.

Marketing Catalog 11

12

AC Monier Satellite Dish Tile Set

AC Monier Ventilation Ridge Set

AC Monier Flashing

AC Monier Gap Setting

Marketing Catalog

AC Monier Pipe Vent Round Set

AC Monier Batten

AC Monier Drytech System

AC Mo Reflflective In

onier nsulation

AC Monier Valley Trough Flashing

AC Monier Eaves Fil er Unit

AC Monier Fixing Set Accessories

AC Monier Ornamental Ridge Set

AC Monier Abutment Fixing Set

AC Monier Pipe Vent Tile Set

AC Monier Valley Trough Stainless

AC Monier Rooflights

AC Monier Clip Lock

AC Monier Valley Trough

Marketing Catalog 13
