FSG Reports Do you know many financial reports have been written using Oracle's Financial Statement Generator in Oracle EBS since very begining. This is one of robust tool that allows us to create reports which meet defined criteria. Lets take quick overview of FSG and its usage. What Are Oracle FSGs? FSG is short form of Financial Statement Generator. In brief , is a powerful reporting engine that s interchangeable report objects, server-based processing for high performance, and report scheduling for efficient use of system resources. A defined report that allows for the rollup of GL Balances (i.e. combinations of ing segments –GL Code Combinations) into logical groupings for reporting The FSG allows you to?

   

This is End tool , which enables end business for financial reporting without any programming Most of these reports are oriented toward financial statements These are very very easy to use :-) Transfer ing information to a popular spreadsheet if you prefer to use your personal computer for analysis and

planning.

 

Report on both translated and entered foreign currency amounts.

Access a wide variety of standard management and ing reports for the detail information you need, including chart of listings, journals, general ledgers and trial balances.



Define the complex financial statements you need to analyse your business,including responsibility reports for business units, profit centres and cost centers.

    

The good things is that all these reports run through concurrent manager Most important there is no additional setup required We can design our reports to meet your business needs Design to print directly to MS Excel Schedule reports to run directly from the application

“You can’t do what with FSG?―

  

Limited flexibility in formatting Access GL balances only - no details Minimal security

What are the reports which is based out of FSG Reports

    

Financials-P&L, Bal Sht, Cash Flow, Rev/Exp detail, cost center detail Auditor Schedules - trial balance mapped to financial stmts Income tax workpapers Partial trial balances Income Statement

What are the FSG Component or Structure

    

Row Sets Column Sets Content Sets Row Orders Display Sets

 

Reports Report Sets Row Set

  

Description to appear on left hand side Define ing flexfield ranges or summary s here Define row calculation - total, etc.

What are the Column Set 1.

Column Sets typically define the format and content of the columns in an FSG report

2.

Oracle provides seeded column sets, or you can build your own

Column Set Attributes-The commonly assumed attributes for a column set are: -Time period (PTD, QTD, YTD, etc) - type (Actual, Budget or Encumbrance) -These two elements are defined by an Amount Type What is Column Set: Proforma Proforma is an ing term that refers to an annual fiscal amount that is comprised of actual amounts and budget amounts together. What is a Content Set?



Content Sets are used to override row/column assignments and display types to create multiple variations of existing reports

 

You can generate many similar reports in a single run by using content sets



Override applied separately to each segment in flexfield

Use to “expand― a range to give multiple values on one report OR separate reports for each value in the range

What is a Row Order?

    o o o 

Row Orders are used to control how detail rows are displayed and/or sorted on a report Used with Row Set expand and Content Sets Allow to expand detail of a row Can display Segment value Segment description Both List alphabetically or numerically

Report Display Group

  

Grouping of rows or columns i.e. “hide column 20― Specify a sequence number range from your row set or column set i.e. from 20 to 20 Used in your display set

Report Display Set

  

Assign Display Group(s) to your Set i.e. “display column 1, 3, 4― Can assign multiple row and/or column groups to one set i.e. “hide column 20― For each assignment, can specify whether to display the values on the report (Display = Yes) or (Display = No)

The Rule of Thumb for FSG One FSG = One row set + one column set + one content set Underline technology of FSG?? any guess , C, SQL, Java...

Important to know FSG reports are created from a program written in 'C' code, not from Oracle Reports, as is the case with standard reports. Many modules and tables are used to create reports based on the definition and component of a particular FSG. What is FSG (Financial Statement Generator) Controller Program? The FSG (Financial Statement Generator) Controller runs when you generate an FSG with a content set 'Type' set to Parallel. The FSG Controller kicks off the sub requests for the FSG's that are created with the content set. What is in Background–The FSG Query As these report are developed in C, it's impossible to break the code, but if you do some trace on you will find , the code is based out of GL balances table, addition to the some other tables which keeps the structure on the front end. here is the hidden query: SELECT nvl(bal.PERIOD_TYPE, ''), nvl(bal.PERIOD_YEAR, -1), bal.PERIOD_NAME, nvl(bal.PERIOD_NUM, -1), nvl(bal.PERIOD_NUM, -1), bal.ACTUAL_FLAG, decode(cc.TEMPLATE_ID, NULL, 'N', 'Y'), nvl(bal.BUDGET_VERSION_ID, -1), nvl(bal.ENCUMBRANCE_TYPE_ID, -1), bal.CURRENCY_CODE, bal.SET_OF_BOOKS_ID, nvl(bal.TRANSLATED_FLAG, ''), nvl(bal.PERIOD_NET_DR, 0) -nvl(bal.PERIOD_NET_CR, 0), nvl(bal.PERIOD_NET_DR, 0), nvl(bal.PERIOD_NET_CR, 0), nvl(bal.QUARTER_TO_DATE_DR,0)-nvl(bal.QUARTER_TO_DATE_CR, 0), nvl(bal.QUARTER_TO_DATE_DR, 0), nvl(bal.QUARTER_TO_DATE_CR, 0), nvl(bal.BEGIN_BALANCE_DR, 0) -nvl(bal.BEGIN_BALANCE_CR, 0), nvl(bal.BEGIN_BALANCE_DR, 0), nvl(bal.BEGIN_BALANCE_CR, 0), nvl(bal.PROJECT_TO_DATE_DR, 0) -nvl(bal.PROJECT_TO_DATE_CR, 0), nvl(bal.PROJECT_TO_DATE_DR, 0), nvl(bal.PROJECT_TO_DATE_CR, 0) , nvl(SEGMENT1,''), nvl(SEGMENT2,''), nvl(SEGMENT3,''), nvl(SEGMENT4,''), nvl(SEGMENT5,''),nvl(SEGMENT6,''),nvl(SEGMENT7,'') FROM GL_BALANCES bal, GL_CODE_COMBINATIONS cc WHERE bal.CODE_COMBINATION_ID= cc.CODE_COMBINATION_ID AND cc.CHART_OF_S_ID= 118 AND bal.SET_OF_BOOKS_ID= 1 AND nvl(bal.TRANSLATED_FLAG, 'x')in('Y','N','x') AND cc.TEMPLATE_IDis NULL AND ( (nvl(SEGMENT3,'') >= '4001' AND nvl(SEGMENT3,'') <= '5999')OR (nvl(SEGMENT3,'') >= '6020' AND nvl(SEGMENT3,'') <= '6370') OR (nvl(SEGMENT3,'') >= '6390' AND nvl(SEGMENT3,'') <= '7250')OR (nvl(SEGMENT3,'') >= '7510' AND nvl(SEGMENT3,'') <= '9100') OR (nvl(SEGMENT3, '') in ('9310','9320')))AND ( (nvl(SEGMENT2,'') >= '000' AND nvl(SEGMENT2,'') <= '01')) AND((bal.period_name in ('Jun-07','Jun-07') AND ((nvl(bal.period_name,'') = 'Jun-07' AND((bal.ACTUAL_FLAG= 'B' AND bal.BUDGET_VERSION_ID= 1111 AND(bal.PERIOD_NET_DR!= 0 or bal.PERIOD_NET_CR!= 0))OR((bal.ACTUAL_FLAG= 'B'

AND bal.BUDGET_VERSION_ID= 1111)OR((bal.ACTUAL_FLAG= 'A')) ))) OR(nvl(bal.period_name,'') = 'Jun-07' AND((bal.ACTUAL_FLAG= 'A') OR ( (bal.ACTUAL_FLAG = 'A' AND (bal.PERIOD_NET_DR != 0 or bal.PERIOD_NET_CR != 0)))))) ) ) < /P > < /P > The data is loaded into memory, and then sorted according to report format How do you define a FSG Report?



Reports are created by specifying a combination of report components (ie Row Set, Column Set, etc). Typically, values specified when defining a report override values specified at the individual component level



The value entered in the Title field will appear at the top of the report

Where to run FSG Reports: In Oracle EBS Running FSG Reports can be achieved from 3 different ways:

  o 

Run Financial Reports form Concurrent Manager The name of the request is "Program -Run Financial Statement Generator" ADI’s Request Center Few more to know

Online Report RequestsYou can request FSG reports on-line using only a few keystrokes. For example, you can choose from a list of report sets or predefined reports that Oracle General Ledger displays in a pop-up window. Or, you can create an ad hoc report by selecting from a list of predefined report components. Exception Reporting The Financial Statement Generator Exception Reporting feature allows you to highlight information requiring special attention. You can define the exception criteria and how you want to flag the rows in your report that you want noticed. This makes it easy to choose to display only the exception rows in your reports. Responsibility Reporting It is possible to construct one report to serve the summary reporting needs of multiple managers. With Responsibility Reporting you can ensure that each level of management spends time reviewing only the necessary level of detail.
