http://www.ni.com/example/14494/en/ Digital Electronics Basics - Chapter 2: Flip-Flops Publish Date: mar 27, 2013 | 2 Valutazioni | 5.00 di 5 | Print | Submit your review Overview The Digital Electronics Basics series present the fundamental theories and concepts taught at entry level electronics courses at both 2 year and 4 year institutions. This series of content provides examples to professors to enable them to easily teach concepts to students, who can develop a solid underlying knowledge of digital electronics using NI solution. This series focuses on some of the basic theory as well as providing the NI Multisim circuits to enable practical implementation and experimentation as homework for students. Table of Contents 1. In this Chapter 2. Example Courses 3. Flip-Flops 4. Example Problem 5. NI Suggested Solution 6. References 1. In this Chapter We begin this chapter by studying the basic flip-flop and understanding the fundamentals. Then we examine two example circuits which can be used by any educator or student to our results using NI Multisim. If you do not have NI Multisim installed on your computer you can a free 30 day evaluation at http://www.ni.com/multisim/try/ 2. Example Courses Listed below are example courses that teach this concept at their schools. Course School Learn More Name Macomb Digital http://www.macomb.edu/noncms/search/courses/coursekey.asp?coursekey=ELEC-1211 Community Electronics College Basics Digital Henry Ford https://my.hfcc.edu/site_manager/Catalog_Manager/courses/view_course1.asp?id=21589 Circuits 1 Community College 3. Flip-Flops In sequential logic operations, flip-flops are the basic memory elements. There are multiple types of Flip-Flops, we will review a couple here: [1] SR Type (Set/Reset): Basic storage device that holds (re) data until reset occurs. It is triggered to ‘high’ by the Set ‘S’ signal and will retain the data until it is resets by the Reset Signal ‘R’ [1].

[2] JK Flip-Flop: This flip-flop has two inputs usually named ‘J and ‘K’ (hence the name). If the two input signals are the same, no changes occur, however when they differ from each other then the output ‘Q’ will take the value of ‘J’ at the next edge of the clock [1].

[2] 4. Example Problem Let us start by examining an example circuit using the SR Flip Flop in a phase detector circuit. STEP 1: Using NI Multisim, open circuit file “sr_flip_flop.ms12”, you will notice the circuit below:

STEP 2: Double-click on each of the Oscilloscope instruments XSC1 and XSC2 to open their front s, then run the simulation. You will notice the graphs below:

STEP 3: Stop the simulation. Then, double-click on the “Out of Phase” source V2 to open it’s properties. Change the "Delay time" value to equal 0.15ms and then to 0.7 ms and run the simulation for each time. You will notice that the output voltage will increase as the two signals get farther out of phase. Delay time = 0.15 ms:

Delay time = 0.7 ms:

Let us now examine an example circuit utilizing the JK Flip Flop in a divide by 10 ripple down counter. STEP 4: Using NI Multisim, open circuit file “jk_flip_flop.ms12”, you will notice the circuit below [3]:

Answer Sub-Step 1: Determine the output states for each flipflop and draw the diagram in comparison to the clock signal. Based on the characteristics of the JK Flip Flop and their connections in the above circuit, we can draw the output signals as follows:

[3]

Let us now confirm our results using NI Multisim.

STEP 5: Using circuit file “jk_flip_flop.ms12”, double click on the Logic Analyzer instrument to open the front , then run the simulation. You will notice the results below which confirm our drawing of the signals above:

5. NI Suggested Solution National Instruments offers a number of products that combine to provide a scalable and powerful teaching platform for educators. The solution includes: NI Multisim circuit teaching environment: Combining an intuitive circuit definition environment, with powerful SPICE simulation technology, educators can use NI Multisim to easily teach the ins-and-outs of circuits in a safe environment. NI ELVIS teaching and measurement platform allows educators to provide students with a compact, all-in-one unit for their measurement and analysis needs. Combining an oscilloscope, function generator, DMM, bode analyzer and 8 other instruments into a small platform; it simplifies the laboratory experience for students and lab instructors. 6. References [1] Georgia State University. Department of Physics and Astronomy. Flip-Flops http://hyperphysics.phy-astr.gsu.edu/hbase/electronic/flipflop.html (12/03/2013) [2] University of Colorado Boulder. Department of Physics. Digital Electronics I: Logic, Flip-Flops, and Clocks. http://www.colorado.edu/physics/phys3330/phys3330_sp12/phys3330_sp12/Lab_Manual_files/Exp_9_Spring12_re.pdf (12/03/2013)

[3] The Ohio State University. Department of Physics. Lecture 10 http://www.physics.ohio-state.edu/~gan/teaching/summer04/Lec10.pdf (12/03/2013)
