Mep Manual 4e2o5l

MECHANICAL-ELECTRICAL & PLUMBING

A HANDBOOK FOR MEP ENGINEERS

Photograph-Dubai sports city : Source – www.dubaisportscity.com

By: Dr. S.L.Sharma, B.E (E), M.Phil, Ph.D.

Author Dr. Sanwar Lal Sharma B.E (Ele.), D.E (Ele), D.M&M B.A (Economics), M.A (Criminology), M.Phil (I.R) &Ph.D (H.R) A. Resident Engineer (MEP)

DIAR Consult Victory height Project- Dubai International sports city DUBAI-UAE

2

PREFACE This tiny effort has been made in the direction to appreciate the importance of electro-mechanical and plumbing work in the construction industry. This will serve as a hand book with ready reckoned to all professionals engaged in the MEP work. It will also provide a ready made guidance to all contractors and sub contractors at site. This book clearly defines the roll and responsibility of each one involved in the execution of the project. It is observed in my long years of experience in the field that there is always a dispute within the agencies regarding istrative procedures to be followed. Keeping that thing in mind we tried to segregate all istrative obligations to be adhered by each agency. It is hoped that this small effort will bring a big change in the professionals’ approach engaged in the construction industry. Sincerely, Dr. S.L.Sharma Date: 10-09-2007

3

Contents  Preface

Pages 3

 Reference Standards/documents

5-6

 Project Co-ordination

7-11

 MEP Organization

12-25

 MEP staff Responsibilities

26-32

 Inspection Methodology (Electrical)  Inspection Methodology (Mechanical)  Standards of submittals

33-56

 Annexure (Templates)

86-105

 Abbreviation

106-107

 About Author

108

57-74 75-85

4

REFERENCE STANDARD& DOCUMENTS

5

3- Source of Documents

The philosophy of the electro mechanical project management is drawn from ISO 9001 (2000) and British standards. However, every particular project is guided by its own project contract and supervised by quality manual.

Main documents referred for smooth operation and implementation of quality standards of the project are : 1.ISO 9001( 2000) 2. BS standards 3.ASTM standards 4. ASHRE standards 5.IEE regulation 16 th edition (Electrical) 6. IP Standards. 7. Local authorities’ rules and regulations. 8. MEP Guide 9. Contractual documents(applicable to specific project) such as : (a) Specification manual (b) BOQ (c) Tender drawings (d) Fidic-2005

6

PROJECT COORDINATION

7

4- Co-ordination

4.1 The project co-ordination is the main operational and management tool to Execute the project smoothly and timely. Co-ordination among all agencies such as client, consultant, main contractor and other subcontractor are most essential to have proper reporting system to Over look and supervise all activities in progress at site. Generally the following chain is maintained:

Client(Management)

Consultant

Main Contractor

All sub contractor

8

4.2

Co-ordination between client and consultant

4.2.1 It is the main obligation of the consultant to appraise the progress of the Project to the client periodically. 4.2.2 Where Specified with in the tender documents or in contract documents, specific client reporting templates (formats) and coordination procedures will Be implemented. In other cases the formats published/distributed by Consultant will be utilized and followed. 4.2.3 Should client need any direct reporting on specific formats the same will be Distributed to all concern by consultant. 4.2.4 Generally all reporting to the client or his representative will be followed or routed through consultant. However client as the owner of the project can direct any agency involved in the project to submit specific reports. All agencies are requiring submitting the desired report to client under intimation to consultant if not directed to do so by the client.

9

4.3 Coordination between consultant and main contractor

4.3.1 It is the main obligation and sole responsibility of the contractor to convert designed project in to a reality. 4.3.2 To fulfill this task the consultant becomes the main controller of the all project. 4.3.3 It is the sole responsibility of the consultant that all local and international norms including safety and environment protection are adhered and followed. 4.3.4 The quality standards are maintained as per designed specification laid down in the construction documents. 4.3.5 The consultant or his representative will act as main controller of the project. 4.3.6 The main contractor will keep a close association with the consultant. All drawing/material will be approved by engineer before putting them in use. 4.3.7 The contractor will invite engineer for all technical activities prior decided. 4.3.8 It is the duty of consultant to remove all project bottlenecks. 4.3.8 The contractor is obliged to bring a clear picture of all activities going on at the site by submitting periodic reports. 4.3.9 The contractor will use all specific reporting formats advised by consultant for all project activities. 4.3.10It is the sole responsibility of contractor to provide all infrastructure facilities for his and engineer’s staff. 4.3.11The contractor is to provide all method statement as per enclosed template.

10

4.4 Co ordination between main contractor and sub contractor

4.4.1 All sub contractors will work under the supervision of main contractor. 4.4.2 All sub contractors are compulsorily ed with local government. 4.4.3 All submittals submitted by sub contractor should be routed through main contractor. 4.4.4 Main contractor should act as intermediate agency between consultant and sub contractor. 4.4.5 All the periodic report submitted by sub contractor should be forwarded to engineer by main contractor. 4.4.6 It is mandatory for main contractor to take the approval of all sub contractors engaged for project activities. 4.4.7 Main contractor is required to on all standard formats of engineer to sub contractor. 4.4.8 It is the sole authority of engineer to deal directly with any of the sub contractor wherever required or desired so by engineer.

11

MEP ORGANIZATION

12

Index

Page no.

5. 01

Introduction

14-14

5.02

Management and reporting scheme

14-15

5.03

MEP orgonogram

16-16

5.04

Key personnel’s Job descriptions

17-25

5.05

Department’s responsibilities and functions

26-26

13

5.01 - INTRODUCTION

Comply with local Government guide lines with clear defined responsibilities especially in the area of quality assurance, site management, testing &commissioning and finally handing over the completed project to the client.

5.02 - Management reporting scheme

MANAGING DIRECTOR

Director

Design manager Architecture

Design manager-Inte.

Head MEP

14

Project REs

General Affairs

It is desired that the final goal of organization will be reached together with company’s growth and development of all functions.

The function of general affairs include: Human Resources, Computer systems, Legal affairs, Public relations etc. However, targeted structure of Operational organization is outlined separately and not in the scope of this manual.

15

5.03- (MEP) ORAGONOGRAM The MEP organization structure, which is a good transitional solution adequate to the current company’s size, needs and resources.

In this document organization of MEP Operations is outlined in details. It is based on the planned scope of activities with the expectation that desired goals will be reached. Consultant Managing Director

Resident Engineer

HEAD OF MEP Department

Assistant Resident Engineers MEP

Senior Mechanical Engineers

Senior Electrical Engineers

Mechanical Inspectors

Electrical Inspectors

16

5.04 Key personnel’s Job descriptions 5.04.01- Head MEP Division HEAD MEP DEVISION

Job title:  Job code:  Job holder:  Managing Director /RE

Reports to:  First reports:

All MEP project heads from various projects

Job description:

This is key position for ensuring Proper design with quality & safety. Development and control of quality program, technologies, products and system evaluation and highest adherence of all local and international standards. SEE IN STAFF RESPONSIBILTIES  Can hire or fire staff with the approval of MD  Can suspend staff notifying MD  Approves revenue items within budget  Approves capital expenditure against budget  Agrees and approves product changes.  Recruitment and training of MEP staff.  Re location and realignment of MEP staff as per project requirements.  All Project heads  All senior management  All other personnel deem fit.

Responsibility: Authority:

internal Communication

external

Requirements:

       

Regulatory authorities Professional bodies Customers Suppliers Graduated in Mechanical / Electrical engineering. Minimum 15 years experience out of which 10 years in Middle East. UAE experience preferred. Leadership & Management abilities Excellent oral and written English

17

  

In depth understanding of local government rules and requirement. Familiar with computers A postgraduate qualification would be an advantage

Managing Director’s Review

Human Resources Review  Employee’s review

18

5.04.01 Assist. Resident Engineer Job title:

Assist. Resident Engineer

Job code :( if any)  Job holder:  Reports to:  First reports:

Head MEP /RE From mechanical engineer and electrical engineer of respective project. This is key position for ensuring Proper design with quality & safety. Development and control of quality system, technologies, products and system evaluation. Design of specification and product selection .Highest adherence of all local regulation and international standards. SEE IN STAFF RESPONSIBILITIES  Can hire or fire staff with the approval of Head MEP  Can suspend staff notifying Head MEP  Agrees, recommend and approves product changes.  Recruitment and training of MEP staff under intimation to MEP Head.  Re location and realignment of MEP staff as per project requirements with in own responsibilities.

Job description:

Responsibility: Authority:

internal

  

Respective Project heads All senior management All other personnel deem fit.

19

Communication external

Requirements:

   

Regulatory authorities Professional bodies Customers Suppliers

 

Graduated in Mechanical / Electrical engineering. Minimum 10 years experience out of which 05 years in Middle East. UAE experience preferred. Leadership & Management abilities Excellent oral and written English In depth understanding of local government rules and requirement. Familiar with computers A postgraduate qualification would be an advantage

     Head of MEP ’s review Human resource review Employee’s Review

20

5.04.03 Sr. Engineers/Engineers Job title:

Sr. Engineers

Job code :( if any)  Job holder:  Reports to:  First reports:

ARE(MEP)/RE From engineer/inspectors (electrical/Mechanical) of respective project.

Job description:

This is key position for ensuring implementation of design with quality & safety. Follow of quality program and system. Highest adherence of all local regulation and international standards.

Responsibility: Authority:

SEE IN STAFF RESPONCIBILTIES  

  

Agrees, recommend and approves product changes. Recruitment /interview recommendations. Training of MEP staff under intimation to MEP Head. Re location and realignment of MEP staff as per project requirements with in own responsibilities. Respective MEP head /Project heads Technical co-ordination with other departs. All other personnel deem fit under intimation to ARE –MEP

   

Regulatory authorities Professional bodies Customers Suppliers



Graduated in Mechanical / Electrical engineering.



internal Communication external

Requirements:

21

     

Minimum 7 years experience out of which 03 years in Middle East. UAE experience preferred. Leadership & Management abilities Excellent oral and written English In depth understanding of local government rules and requirement. Familiar with computers A postgraduate qualification would be an advantage.

Head of MEP ’s review

Human resource review

Employee’s Review

22

5.04.04 - MEP Inspectors MEP Inspectors

Job title:  Job code :( if any)  Job holder:  Reports to:  First reports:

Sr. Engineer/ Engineer Nil.

Job description:

This is key position for ensuring Implementation design with quality. Follow quality program. Highest adherence of all local regulation.

Responsibility: Authority:

SEE IN STAFF RESPONCIBILTIES  Can recommend approval/suspension /rejection of inspection notifying sr. engineer/engineer.  Recommend product changes.  Training of MEP staff under guidance of MEP Head.  

Respective sr. engineers/MEP heads All other personnel deem fit guided by superiors.

internal

23

Communication external

Requirements:



Regulatory authorities &Professional bodies notifying MEP head in the project.

 

Graduated in Mechanical / Electrical engineering. Minimum 3 years experience out of which 02 years in Middle East. UAE experience preferred. Or Technical diploma with 10 years relevant experience.  Excellent oral and written English  In depth understanding of local government rules and requirement.  Familiar with computers desirable

Head of MEP ’s review Human resource review Employee’s Review

24

5.05

Department’s responsibilities and functions

5.5.01 MEP department will work with civil engineering in a close coordination. 5.5.02 it is the main responsibility of the department to approve all drawings/material related to HVAC, Plumbing and electrical. 5.5.03 the department will carryout all schedule inspections requested by MEP contractor. 5.5.4 It is the obligation of the department to and approve the sub contractor For MEP work at site. 5.5.5 All services coordination under ground and other floors above ground is to be checked and approved by department. 5.5.6 MEP department (Electrical) will assist sub contractor in solving DEWA bottle necks. 5.5.7 MEP department (Mechanical) will assist sub contractor in solving the DM problems related to water and drainage. 5.5.8 MEP department will also civil and main contractor to solve civil defense and fire fighting problems. 5.5.9 MEP department will scrutinize all the CVs of sub contractor and approve them as per listed specification. 5.5.10 MEP department will participate in all weekly progress meetings. 5.5.11 MEP department will also participate in all other meetings called by client and or his representative. 5.5.12 MEP department will coordinate with other infrastructure contractor working with the specified area. 5.5.12 MEP department will submit periodic reports to MEP head at head office. 5.5.13 MEP department will keep all the records of inspection, material submittal and drawing submittals. 5.5.14 Any other obligations not listed here but falls under the jurisdiction of the MEP Department.

25

STAFF RESPONSIBILITIES

26

Index

Page no.

6.1

Head of Department ( MEP)

29-29

6.2

Assistant Residence Engineer (MEP)

30-30

6.3

Senior Engineer(Electrical/ Mechanical)

31-32

6.4

Electrical/Mechanical Inspector

33-33

27

6.1- Head of Department (H.O.D)-MEP

Technical /istrative Responsibilities:

6.1.1

Electro Mechanical (MEP) project management as per Dubai Govt. /International norms. 6.1.2 To review and approve material submittals reviewed & recommended by ARE/ Sr. engineer / Engineer. 6.1.3 To review and approve drawing submittals reviewed & recommended by ARE/ Sr.engineer / Engineer. 6.1.4 Participating in weekly project review meetings for tracking project progress & de-bottlenecking & implementation of procedures as per norms and Standards. 6.1.5 To authenticate monthly payment bill after reviewed and recommended by ARE/ Senior engineers. 6.1.6 Involve in strategic technical planning for achieving targeted schedules and Their implementation 6.1.7 Departmental reporting to management on periodic basis. 6.1.8 Final authorization & counter g for all MEP activity. 6.1.8 To provide management guidance and leadership to MEP team . 6.1.9 To review and forward all MEP variations applicable to all on going projects. 6.1.10 To review and counter sign all the MEP correspondences made with the Client, main Contractor or Sub-Contractors. 6.1.11 to review and approve all contractor claim & variation (related to MEP). 6.1.12 Institute change-management practices in the department, including restructuring & manpower rationalization initiatives, and facilitate acceptance by the staff across hierarchical levels. Formulate and benchmark functional best practices to focus on core MEP function. 6.1.13 Evolution of performance of contractors and other associated agencies 6.1.14 Oversee smooth implementation of manpower planning, recruitment, selection, induction, orientation and development of new employee, promotion in the department through Career and Succession Planning.

28

6.2- Assistant Resident Engineers (ARE) – MEP Technical and istrative responsibilities 6.2.1 To provide leadership and technical guidance to site MEP department at site. To handle all incoming and out going correspondence related to MEP. 6.2.2 To review the Design of all MEP services and bring any concern to the attention of H.O.D. 6.2.3 To ensure that DIAR Consult concept / procedures are strictly followed by all the MEP staff. 6.2.4 Electro Mechanical (MEP) project management at site as per Dubai Govt. /International norms 6.2.5 To review and approve the material submittals reviewed & recommended by Sr. engineer / Engineer. 6.2.6 To review and approve the Drawing submittals reviewed & recommended by Sr.engineer / Engineer. 6.2.7 Participating in weekly project review meetings for tracking site progress & de-bottlenecking & implementation of procedures as per norms and standards. 6.2.8 To ensure that the contractors / subcontractors are ed and obtained license from local authorities before commencement of the work at site. 6.2.9 To obtain approval of H.O.D on all material submittal. (if they are not specified) 6.2.10 To coordinate the MEP services with Civil / Architectural works. 6.2.11 To review the program of work submitted by the contractor and approve comments 6.2.12 To ensure that all testing and commissioning procedure are strictly followed by concerned all MEP staff. 6.2.13 To review, write and forward the performance appraisals to head of the department for all the staff working under him. 6.2.13 To prepare periodic reports for the Head of the department related to site progress and execution.

29

6.3- Senior Engineers (Electrical/Mechanical) (SEE/SEM) Responsibilities 6.3.1

To check and review all the related material submittals documents and their conformity with the specification and Contract documents and forward to the MEP head. 6.3.2 To ensure that all the material submittals must be submitted as per standards listed in specification book. Such as: a. Submittal to have Main index list b.Submittal to have Specified material list c. Submittal to have Specification copy. d.Submittal to have Catalogue copy e. Submittal to have Data sheet i.e. to describe about the proposed Technical characteristics of the material and also to show the catalogue number of the proposed material. f. Submittal to have Compliance statement showing the exact comparison between specified and proposed material submittal and to be properly stamped and signed by the main Contractor and Supplier. g.Manufacturer/supplier address to be clearly shown on submittal form. 6.3.3 To advise sample approval of all related material before any installation in the site for MEP Head. 6.3.4 To check and review all the related shop drawing as per the contract, tender drawing and all addenda. To ensure that shop drawings are accurate and detailed and are fully coordinated with all other services. 6.3.5 To note and review all the changes or variations coming in drawings or BOQ (i.e. Quantity) during execution of the project. 6.3.6 To approve request for inspection for any Electrical/mechanical activity done at site. 6.3.7 To check the quality of work at site and insure that site execution is as per project specification and authorities regulations. 6.3.8 To check as per actual installation and forward the “As Built Drawings” received from contractor to head MEP. To attend weekly site coordination meetings.

30

6.3.9 6.3.10 6.3.11 6.3.12 6.3.13

6.3.14

6.3.15

To guide and liaise with contractor/sub contractor for obtaining all approvals related to MEP from authorities. To make correspondence with the Client, Main Contractor Sub-Contractor under guidance of head MEP/ project RE. To provide guidance and supervision to related inspectors for site inspection work. To counter sign on all the inspection reports performed at site by inspectors. To report to immediate superiors all matters of non conformity and irregularities of executed works and to record such matters consistently and systematically in proper filing system. To accept full responsibilities of site supervision of electrical / mechanical works on project as assigned by management in a professional and competent manner. To work in full coordination with all of staff at site / head office and subscribe to the over all procedures.

31

6.4- Inspectors (Electrical/ Mechanical) (EI / MI) Responsibilities 6.4.1

To accept full responsibilities of site supervision of Electrical/mechanical Works executed at site. 6.4.2 To conduct inspections for all Electrical /mechanical works done at site as per inspection request submitted by contractor. 6.4.3 To supervise & improve the quality and quantity of Electrical / Mechanical installation at site 6.4.4 To check and be ensured at site that only approve material/drawing is (being) used. 6.4.5 To conduct and witness all types of electrical/mechanical site testing and commissioning and make written report to superiors at sites. 6.4.6 To conduct / check all the insulation resistance test, continuity test of LV cable Polarity test, earth resistance test, air balancing test, chilled water balancing test, pressure test, hydraulic test, units & equipment test etc. 6.4.7 To review the location and the installation levels for all Electrical/Mechanical equipments, s, accessories etc at site.

32

INSPECTION METHODOLOGY (ELECTRICAL)

33

INSPECTION METHODOLOGY-(ELECTRICAL) INDEX 7.1 7.2 7.3 7.4 7.5 7.6 7.7 7.8 7.9 7.10 7.11 7.12 7.13 7.14 7.15 7.16 7.17 7.18 7.19 7.20 7.21 7.22
