• LATHES

Variable Speed Mini Lathe FEATURES: • Inch metric graduations on dials. • Includes 3 jaw chuck, toolpost, chip tray and splash guard.

STANDARD EQUIPMENT: • Wrenches. • 3" three-jaw chuck. • MT #2 dead center. • Four-position turret post. • Complete set of change gears.

SPECIFICATIONS: Swing Over Bed .......................................... 7" Distance Between Centers ........................ 12" Spindle Bore ............................ .788" / 20 mm Tailstock Taper ...................................... MT #2 Tailstock Travel ..................................... 2-1/2" Cross-slide Travel ................................. 2-3/4" Speed Range ............................. 0-2500 RPM Motor .......................................... 3/4 HP, 115V Number of threads pitch .......... (18) 12-52 TPI Net Weight ........................................... 74 lbs.

Model ML-712

Part No. 6-275-001 Our Net Price

$57600

Belt Drive Bench Lathe

STANDARD EQUIPMENT: • 4" 3 Jaw Chuck. • 7" 4 Jaw Chuck. • Steady rest & follow rest. • 1 set lathe centers. • 1 set change gears. • Face plate. • Toolbox with tools. • Manual.

Model GRIP-918 Part No. 6-335-000 Our Net Price

$99900

SPECIFICATIONS: Swing Over Bed .................................................................................. 9" Swing Over Crosslide .................................................................. 5-5/16" Distance Between Centers ................................................................ 20" Spindle Mount/Bore ..................................................... M39 – 4/ 13/16" Spindle Taper ................................................................................ #3 MT Spindle Speeds (6) .................................................... 130 – 2000 RPM Tailstock Spindle Taper/Travel ............................................... 2MT/1-1/2" Thread Range ........................................................................... 8-56 TPI Drive Motor .............................................................. 3/4 HP, 1 PH, 115V Net Weight (approx.) .................................................................. 270 lbs. Shipping Weight (with stand) ..................................................... 390 lbs.

®

Belt Drive Bench Lathe

Model BD-920N 9" x 20" Part No. 6-200-020 Our Net Price

$1,37500

Complete with threading gearbox, square toolpost, lathe centers and floor stand.

STANDARD EQUIPMENT: • 4" 3 jaw chuck & 7" 4 jaw chuck with threaded back plate. • Face plate. • 4-way tool post. • Single tool post. • Steady and follow rest. • Metric change gears. • Centers, threading dial. • Toolbox with tools.

SPECIFICATIONS: Swing Over Bed .............................................................9" Swing Over Cross Slide.........................................5-5/16" Distance Between Centers ..........................................20" Hole Through Spindle .............................................25/32" Spindle Mt/Taper...............................1-1/2" x 8 T.P.I./3MT Spindle Speeds (6) .................................130 - 2000 RPM Longitudinal Feeds (27).......................................0.005 - 0.011 in/rev Inch Threads (27)............................................8 - 56 T.P.I. Metric Threads (11).............................................5 - 3 mm Taper in Tailstock Spindle .........................................MT-2 Main Motor..........................................3/4 HP, 115V, 1 PH Net Weight (approx) .............................................235 lbs. Shipping Weight (with stand) ............................. 390 lbs.

Complete with Floor Stand!

Quick Change Tool Post Sets

INTERCHANGEABLE WITH ALORIS TYPE TOOLHOLDERS

6 Pc. Set, Up to 12" Lathe Swing SET CONTAINS: • Tool Post Series 100 (100). • Turning & Facing Holder #1 (101). • Boring, Turning & Face Holder #2 (102). • Heavy-Duty Boring Bar Holder #4 (104). • Universal Parting Blade Holder (107). • Knurling, Turning & Facing Holder (110).

KBC TOOLS & MACHINERY


$22374 Phone:

1-800-521-5606

Fax:

1-800-322-4292

KBCTools.com

www.

LATHES •

machinery

1029

Precision Toolroom Lathe FEATURES: • All gear head, hardened and ground ways. • 9 spindle speeds, 70-1400 RPM. • 12" swing x 36" between centers. • D1-4 spindle mount, 1-1/2" bore. • 2 HP, 115/230V, 1 phase. • Net weight 925 lbs. SPECIFICATIONS: Swing Over Bed ...................................... 12" Swing Over Crosslide ......................... 7-1/2" Swing Over Gap...................................... 17" Distance Between Centers .................... 36" Spindle Mount/Bore.................... D1-4/1-1/2" Spindle Speeds (9)................. 70-1400 RPM Tailstock Taper ................................... #3 MT Tailstock Spindle Travel............................. 4" Thread Cutting Range: American (40) ........................ 4-112 TPI Metric (23)............................... .2-4.5mm Spindle Motor ....................................... 2 HP Voltage/Phase ................ 115/230V, 1 Phase Net Weight (approx.)........................ 925 lbs. Shipping Weight ........................... 1,300 lbs.

Complete with Floor Stand, Splash Guard, 3 & 4 Jaw Chucks, Steady & Follow Rest.

Model GRIP-1236E Part No. 6-660-010 Our Net Price

$2,99500

Precision Toolroom Lathe SPECIFICATIONS: Swing Over Bed .................................... 13" Swing Over Carriage ........................ 7-3/4" Swing Over Gap ............................. 18-3/4" Center Distance ..................................... 40" Spindle Mount/Bore ................. D1-4/1-1/2" Spindle Speeds (8) .............. 70-2000 RPM

Model GRIP-1340G

$3,695 00 FOR AS LITTLE AS

$84.99/mo.*

Complete with

Digital Readout

Digital Readout

INSTALLED!

INSTALLED!

$5,195 00

Part No. 6-269-008-N


FOR AS LITTLE AS

$130.99/mo.*

$119.49/mo.*

CALL FOR DETAILS *60 month term, $1.00 BUYOUT

Geared Head Bench Lathes

FEATURES: • Enclosed gearbox design provides smooth, quiet operation. • Helical cut headstock gears reduce noise. • Spindle is ed by precision tapered roller bearings. • V-way bed is induction hardened and ground. • T-slotted compound slide with four-way tool post. • Carriage mounted spindle control lever. SPECIFICATIONS: Swing Over Bed ...........................................13" Swing Over Cross Slide .......................7-25/32" Swing Through Gap ...............................18-3/4" Distance Between Centers...........................40" Spindle Mount/Bore.........................D1-4/1-3/8" Spindle Taper (W/Sleeve)..............MT-5 (MT-3) Spindle Speeds (8) ...................70 - 2000 RPM Inch Threads (40) ..........................4 - 112 T.P.I. Metric Threads (27)..........................0.2 - 6 mm Tailstock Spindle Travel/Taper ........3-3/4" /3MT Main Motor.............................2 HP, 230V, 1 PH Net Weight (approx.)..........................1,015 lbs. Shipping Weight ............................... 1,300 lbs.

Model GHB-1340 -

00

$4,499

*

13" x 40"

OR LES

Gear Head Spindle Drive!

STANDARD EQUIPMENT: • 6" 3 Jaw Direct Mount Chuck with Top Reversing Jaws. • 8" 4 Jaw Chuck. • 12" Face Plate. • 4-Way Tool Post. • Steady and Follow Rest. • Metric Change Gears. • Splash Guard. • Centers and Headstock. • Center Sleeve. • Threading Dial. • Tool Box and Tools. FOR AS LITTLE AS


Phone:

Complete with

Part No. 6-269-008 Part No. 6-269-008-F

FEATURES: • 2 HP, 230V, 1 phase. • D1-4 spindle mount, 1-1/2" bore. • 8 spindle speeds, 70-2000 RPM. • 13" swing x 40" between centers. • All gear head, hardened and ground ways.

®

Thread Cutting Range Inch (28) ................................... 4-56TPI Metric (32) ...............................0.4-7 mm Tailstock Taper .................................. #3 MT Tailstock Travel .................................. 3-3/4" Drive Motor ................. 2HP, 230V, 1 Phase Net Weight................................... 1,300 lbs. Shipping Weight ......................... 1,600 lbs.

$103.48/mo.*

S!

1-800-521-5606

CALL FOR DETAILS

*60 month term, $1.00 BUYOUT

Fax:

1-800-322-4292

*WHEN DROP SHIPPED FROM JET


KBCTools.com

www.


1030

machinery

• LATHES

Precision Toolroom Lathe

FEATURES: • All gear head, hardened and ground ways. • 16 spindle speeds, 45-1800 RPM. • 14" swing x 40" between centers. • D1-4 spindle mount, 1-1/2" bore. • 3 HP, 230V, 3 phase (2 speed). • Net weight 1,980 lbs.

Complete with Floor Stand, Foot Brake, Worklight Coolant System & Splash Guard, 3 & 4 Jaw Chucks, Steady & Follow Rest, & Microstop.

SPECIFICATIONS: Swing Over Bed .......................................................................................... 14" Swing Over Carriage............................................................................... 8-3/4" Swing Over Gap .......................................................................................... 20" Center Distance........................................................................................... 40" Spindle Mount/Bore........................................................................ D1-4/1-1/2" Spindle Speeds (16)................................................................... 45-1800 RPM Thread Cutting Range Inch (44) ..................................................................................... 4-112 TPI Metric (22)................................................................................ .45-7.5 mm Tailstock Taper.......................................................................................... 3 MT Tailstock Quill Travel ..................................................................................... 5" Drive Motor ....................................................................... 3HP, 230V, 3 Phase Net Weight ........................................................................................ 1,980 lbs. Shipping Weight ............................................................................... 2,400 lbs.

Model GRIP-1440G

Complete with

Complete with

Digital Readout

Digital Readout

Part No. 6-269-006 Part No. 6-269-006-F


$114.89/mo.*

INSTALLED!

INSTALLED!

Part No. 6-269-006-N

$6,395 00


FOR AS LITTLE AS

$159.74/mo.*

$147.09/mo.*


Precision Toolroom Lathe FEATURES: • All gear head with oil bath lubrication. • 3 HP, 230V, 1 Phase Motor - No Phase Converter Needed! • 12 Spindle Speeds. • 1-1/2 Spindle Bore. • Safety Foot Brake STANDARD EQUIPMENT: • 6" 3 Jaw Chuck • 8" 4 Jaw Chuck • Complete Coolant System • Full Length Rear Splash Guard • Foot Brake • Steady Rest • Follow Rest • Worklight • T-Slot Compound • Manual & Parts List

Heavy Duty Lathe With Single Phase Electrics!

SPECIFICATIONS: Swing Over Bed .......................................................................................... 14" Swing Over Cross Slide ......................................................................... 8-5/8" Swing Through Gap ................................................................................... 20" Distance Between Centers ......................................................................... 40" Spindle Mount / Bore .................................................................. D1-4 / 1-1/2" Spindle No. / Speeds (12) .................................................................. 40-1800 Inch Threads (40) .......................................................................... 4-112 T.P.I. Metric Threads (22) ...................................................................... 0.45-7.5mm Tailstock Spindle Travel ......................................................................... 4-3/4" Taper in Tailstock Spindle ........................................................................ MT-3 Main Motor ......................................................................... 3 HP, 230V / 1 PH Net Weight ....................................................................................... 2,650 lbs. Shipping Weight ............................................................................... 2,950 lbs.


Phone:

1-800-521-5606

Model GRIP-1440HD

Complete with

Complete with

Digital Readout

Digital Readout

Part No. 6-269-007 Part No. 6-269-007-F


$137.89/mo.*

INSTALLED!

INSTALLED!

Part No. 6-269-007-N

$7,495 00


FOR AS LITTLE AS

$183.89/mo.*

$174.69/mo.*


Fax:

1-800-322-4292

KBCTools.com

www.

LATHES •

machinery

®

1031

2 Year Parts & Labor Warranty.

Geared Head Engine Lathes

*

Complete with


Digital Readout

INSTALLED! Part No. 6-200-040 Part No. 6-200-040-A

Model GH-1340W-1 FEATURES: • All gear head, hardened & ground ways. • 13" x 40" or 14" x 40" capacity. • 12 spindle speeds, 40-1800 RPM. • D1-4 spindle mount, 1-1/2" bore. • 3 HP, 1 phase or 3 phase.

Complete w/ Floor Stand, Coolant System & Splash Guard, 3 & 4 Jaw Chucks, Steady & Follow Rest.

$6,699 00 OR

FOR AS LESS! LITTLE AS

FOR AS OR LITTLE AS

LESS!

$154.08/mo.* $183.98/mo.* Part No. 6-200-041 Part No. 6-200-041-A

Model GH-1340W-3

OR LESS!


$154.08/mo.* SPECIFICATIONS: GH-1340W-1/3 GH-1440W-1/3 Swing Over Bed......................................................13" ................................................14" Swing Over Cross Slide .....................................7-1/2" ...........................................8-1/2" Swing Through Gap................................................19" ................................................20" Distance Between Centers .....................................40" ................................................40" Spindle Mount / Bore...............................D1-4 / 1-1/2"...................................D1-4 / 1-1/2" Spindle No. / Speeds (12) ............................40 - 1800 ......................................40 - 1800 Inch Threads (40).....................................4 - 112 T.P.I. .................................4 - 112 T.P.I. Metric Threads (22) ...............................0.45 - 7.5 mm ..............................0.45 - 7.5 mm Tailstock Spindle Travel......................................4-3/4"..............................................4-3/4" Taper in Tailstock Spindle ....................................MT-3 ...............................................MT-3 Main Motor......................................3 HP, 230V / 1 PH .........................3 HP, 230V / 1 PH ........................................or 230/460V / 3 PH .......................or 230/460V / 3 PH Net Weight....................................................2,081 lbs. .......................................2,191 lbs. Shipping Weight ......................................... 2,400 lbs. ...................................... 2,500 lbs.

$7,999 00

$7,999 00

FOR AS OR LITTLE AS

LESS!

$183.98/mo.*

Part No. 6-200-042 Part No. 6-200-042-A

Model GH-1440W-1

$7,299 00

OR


$167.88/mo.*

$8,999 00

FOR AS OR LITTLE AS

LESS!

$206.98/mo.*

Part No. 6-200-043 Part No. 6-200-043-A

Model GH-1440W-3

OR LESS!


$167.88/mo.*

$8,999 00

FOR AS OR LITTLE AS

LESS!

$206.98/mo.*


Precision Toolroom Lathe SPECIFICATIONS: Swing Over Bed ................................................................................... 16" Swing Over Crosslide .................................................................... 8-7/16" Swing Over Gap ............................................................................ 21-1/4" Distance Between Centers .................................................................. 40" Spindle Mount/Bore ....................................................................... D1-6/2" Spindle Speeds (16) ........................................................... 45-1800 RPM Tailstock Spindle Travel/Taper ................................................. 4-3/4"/4MT Threading Inch (45) ...................................................................... 2-72TPI Metric (39) ............................................................................. 0.2-14 mm Spindle Motor ................................................................................. 3/6 HP Voltage/Phase .....................................................................230V, 3 Phase Net Weight (approx.) ................................................................. 3,000 lbs. Shipping Weight ......................................................................... 3,400 lbs.

FEATURES : • 16" swing x 40" between centers. • D1-6 camlock spindle with 3-point bearing . • Large 2" spindle bore. • 16 spindle speed, 45-1800 RPM. • 3/6 HP 2-speed motor wired 230V, 3-Phase. • Universal threading gearbox allows you to cut inch and metric threads without using change gears. • 1 piece cast iron base for vibration dampening. • Complete with 3-Jaw & 4-Jaw chucks, coolant system with full splash guard, worklight, microstop, and foot brake.

Phone:

1-800-521-5606

Fax:

1-800-322-4292

Model GRIP-1640GH

Complete with

Complete with

Digital Readout

Digital Readout

INSTALLED!

INSTALLED!

Part No. 6-269-009 Part No. 6-269-009-F

Part No. 6-269-009-N

$6,795 00

$8,445 00

$8,895 00

FOR AS LITTLE AS

FOR AS LITTLE AS

FOR AS LITTLE AS

$156.29/mo.*

$194.24/mo.*

$204.59/mo.*


KBCTools.com

www.


1032

machinery

• LATHES FEATURES: • 5 HP frequency drive motor runs on 1 phase or 3 phase power. • Infinetely variable speeds from 20-2500 RPM. • Easy to ready digital display for spindle speeds. • One piece cast iron base with front access to chip tray. • Inch and metric graduated dials.

Variable Speed Toolroom Lathe

STANDARD EQUIPMENT: • 3-jaw chuck (9") • Chuck guard • Steady rest • Follow rest • 4-way indexable toolpost • Coolant system with full length rear splash guard • Halogen work light • Toolbox with tools • Manual and parts list

SPECIFICATIONS: Swing over bed ......................................... 14-3/16" Bed Width ................................................... 10-1/4" Swing over cross slide .................................. 8-3/8" Swing over gap ................................................. 21" Distance between centers ................................. 40" Spindle speeds (variable) ......... 20-400-2500 RPM Standard threads (45) ............................... 2-72 TPI Metric Threads (39) .......................... 39, 0.2-14mm Spindle motor ....................................... 5 HP, 230V Spindle bore ................................................ 2-1/16" Spindle nose ................................................... D1-6 Tailstock taper ................................................ 4 MT Net Weight .............................................. 3,190 lbs.

Complete with Digital Readout

Model RML-1440VT

INSTALLED!

Part No. 6-273-050 Part No. 6-273-050-N

$13,250 00


FOR AS LITTLE AS

$356.39/mo.*

$304.75/mo.*


Engine Lathe

FEATURES: • 7.5 HP Spindle Motor, 12-speeds • 3.125" Spindle Through Hole • Solid full length casting base with front loading chip tray for easier cleaning • Adjustable over-load feed clutches • Quick reversal feed from apron • Full-length safety foot brake • Spindle jog button control • One-shot lubrication for apron, carriage, and bed ways • Multi-position adjustable feed position stops • Dual inch/metric calibrated tailstock quill with knochout tang; Heavy duty two speed tailstock • Dual inch/metric dials with quickchange sleeve

SPECIFICATIONS: Swing over bed .............................................. 17" Swing over cross slide ............................ 10.875" Swing over gap ........................................... 24.5" Distance between centers .............................. 44" Spindle hole .............................................. 3.125" Spindle nose camlock ................................. D1-6 Spindle to sleeve taper ............................ 7-4 MT Spindle speed (12 steps) .............. 36-1800 RPM Cross slide travel ........................................ 10.6" Top slide (compound) travel ........................ 4.75" Thread capacity (inches) ................. 45, 2-72 TPI Thread capacity (metric) ............... 39, 0.2-14mm Quill travel / taper .................................. 5" / 4MT Main motor .................... 7.5 HP, 230/460V, 3 PH Net weight ............................................ 3,850 lbs. Shipping weight ................................... 4,510 lbs.


Phone:

STANDARD EQUIPMENT: • 3-jaw chuck (10") • Steady rest • Follow rest • Chuck cover • Halogen work light • Thread chasing dial

• 4-position tool post • Coolant system with full-length splash guard • 3 position carriage stop • Bed mount carriage stop

Taper Turning Attachment

Part No. 6-273-064A Our Net Price $1150.00


INSTALLED!

Part No. 6-273-064 Part No. 6-273-064-N

Model ML-1740T

$13,995 00


FOR AS LITTLE AS

$373.75/mo.*

$321.89/mo.*


1-800-521-5606

Fax:

1-800-322-4292

KBCTools.com

www.

LATHES •

machinery

1033

3" Spindle Bore Engine Lathes FEATURES: • 7.3 HP mian spindle motor, 12 speeds • D1-8 camlock, 3.2" spindle bore • Hardened and ground gears and bedways • Inch dials and leadscrews • Safety foot brake STANDARD EQUIPMENT: • 3-jaw chuck (10”) • 4-jaw chuck (12") • Face plate (19") • Steady rest (8") • Follow rest (1-3") • 4-way tool post

• • • • •

Thread chasing dial Coolant system Full-Length Splash Guard Work light Standard tools


SPECIFICATIONS: CDL-2040 Swing over bed .............................................. 20" Bed width ....................................................... 12" Swing over cross slide ................................ 12.5" Swing over gap ........................................... 28.9" Distance between centers .............................. 40" Spindle Speeds (12) ..................... 16-1600 RPM Standard threads (32) ........................... 2-56 TPI Metric threads (20) .............................. 0.5-14mm Spindle Motor .......................... 7.3 HP, 230/460V Spindle Bore ................................................. 3.2" Spindle nose ................................................ D1-8 Tailstock taper ............................................. 4 MT Net Weight ........................................... 4,488 lbs. Shipping Weight .................................. 4,950 lbs.

CDL-2060 .......................... 20" .......................... 12" ....................... 12.5" ....................... 28.9" .......................... 60" ......... 16-1600 RPM ................. 2-56 TPI ............... 0.5-14mm ... 7.3 HP, 230/460V ......................... 3.2" ........................ D1-8 ....................... 4 MT ................ 4,488 lbs. ................ 6,050 lbs.

INSTALLED!

Part No. 6-273-065 Part No. 6-273-065-N

Model CDL-2040 (20" x 40")

$8,995 00

FOR AS LITTLE AS


$252.89mo.* $206.89/mo.* Part No. 6-273-066 Part No. 6-273-066-N

Model CDL-2060 (20" x 60")

$9,850 00

$12,095 00

$226.55/mo.*

$278.19/mo.*

FOR AS LITTLE AS

FOR AS LITTLE AS


Extra Large 3-1/8" Spindle Bore Lathes ®

Complete with

*

Digital Readout


INSTALLED! Part No. 6-200-025 Part No. 6-200-025-A

Model GH-1440ZX (14" x 40")

Model GH-1460ZX (14" x 40")

OR LESS!


SPECIFICATIONS:

GH-1440ZX GH-1460ZX

Swing Over Bed.................................. 14" Swing Over Cross Slide ................. 7-5/8" Swing Through Gap ..................... 23-5/8" Distance Between Centers ........ 40" / 60" Hole Through Spindle .................... 3-1/8" Spindle Mount .................................. D1-8 Spindle Taper (w/Sleeve)..... MT-7 (MT-5) Number of Spindle Speeds.................. 12 Range of Spindle Speeds . 42-1800 RPM Number of Inch Threads ...................... 61 Range of Inch Threads .......... 1-7/8" - 72" Number of Metric Threads ................... 24 Range of Metric Threads......... 05-20 mm Max. Cross Slide Travel ....................... 9" Tailstock Spindle Travel........................ 5" Taper in Tailstock Spindle................ MT-4 Main Motor ......................... 7-1/2HP, 3PH .............................. 230/460V, ....................... Prewired 230V Net Weight ................... 5,187 / 5,380 lbs. Shipping Weight .......... 6,400 / 6,600 lbs.

Phone:

Complete with Coolant System &Splash Guard, 3 & 4 Jaw Chucks, Steady & Follow Rest. GH-1640ZX GH-1660ZX ..........................16" ..........................10" .................. 25-7/8" ................ 40" / 60" .................... 3-1/8" ...................... D1-8 .......... MT-7 (MT-5) ...........................12 ....... 25-1800 RPM ...........................61 .............1-7/8" - 72" ...........................24 ...............05-20 mm ............................9" ........................... 5" ...................... MT-4 ........ 7-1/2HP, 3PH .............. 230/460V, ...... Prewired 230V .. 5,475 / 5,795 lbs. ... 6,700 / 7,800 lbs.

1-800-521-5606

Fax:

GH-1840ZX GH-1860ZX GH-1880ZX ....................................18" ..............................10-7/8" ..............................27-1/2" .................. 40" / 60" / 80" ............................... 3-1/8" ................................. D1-8 ..................... MT-7 (MT-5) ..................................... 12 .................. 25-1800 RPM ..................................... 61 ........................1-7/8" - 72" ......................................24 ........................ 05-20 mm ..................................... 9" ..................................... 5" ................................ MT-5 .................... 7-1/2HP, 3PH ....................... 230/460V, .................. Prewired 230V .. 5,980 / 6,245 / 6,590 lbs. .. 7,500 / 7,800 / 8,100 lbs.

1-800-322-4292

Model GH-1640ZX (16" x 40") Model GH-1660ZX (16" x 60") Model GH-1840ZX (18" x 40")

Model GH-1860ZX (18" x 60") Model GH-1880ZX (18" x 80")

FOR AS OR LITTLE AS

OR LESS!


$12,999 00

FOR AS OR LITTLE AS

LESS!

$298.98/mo.*

Part No. 6-200-027 Part No. 6-200-027-A

$12,599 00

OR


$13,599 00

FOR AS OR LITTLE AS

LESS!


$12,999 00

OR


$13,999 00

FOR AS OR LITTLE AS

LESS!


$13,199 00

OR


$14,199 00

FOR AS OR LITTLE AS

LESS!


OR LESS!


$14,999 00

FOR AS OR LITTLE AS

LESS!


OR LESS!


$356.48/mo.*

$16,499 00

FOR AS OR LITTLE AS

KBCTools.com

LESS!

$379.48/mo.*


www.

LESS!


$275.98/mo.* FEATURES: • 3-1/8" Spindle Bore. • 1 pc. solid cast iron base. • 12 spindle speeds, 42-1800 RPM or 25-1800 RPM. • 7-1/2 HP, 230/460V, 3 phase. • Universal threading and feed gearbox.

$12,499 00


1034

machinery

• LATHES

Large Bore Engine Lathes FEATURES: • 10 HP main spindle motor, 16 speeds. • D1-8 camlock, 4.12" spindle bore. • Hardened and ground gears and bedways. • Jog button, 4-way rapid traverse. • Mechanical clutch style headstock. • Inch dials and leadscrews. • Centralized lube system in headstock. • Safety foot brake.

Big 4" Spindle Bore, Clutch Spindle Drive & 4-Way Rapid Traverse


INSTALLED!

Part No. 6-273-014 Part No. 6-273-014-N

Model CDS6250C (20" x 60")

$13,795

$16,050

00

00

FOR AS LITTLE AS

FOR AS LITTLE AS

$369.15/mo.*

$317.29mo.*

Part No. 6-273-013 Part No. 6-273-013-N

Model CDS6250C (20" x 80")

$14,795 00

$17,475 00

FOR AS LITTLE AS

FOR AS LITTLE AS

$340.29/mo.* $401.93/mo.* Part No. 6-273-0145 Part No. 6-273-0145-N

Model CDS6266C (26" x 120")

$18,795 00

$22,495 00

FOR AS LITTLE AS

FOR AS LITTLE AS

$432.29/mo.*

$517.39/mo.*


STANDARD EQUIPMENT: • 3-jaw chuck (12"). • 4-jaw chuck (16"). • Face plate (19"). • Steady rest (8"). • Follow rest (1-3"). • 4-way Tool Post.

• Thread chasing dial. • Coolant system. • Full-Length Splash Guard. • Worklight. • Standard tools.

Taper Turning Attachment

Part No. 6-273-013A Our Net Price $1150.00

SPECIFICATIONS: Swing over bed ......................................................................... 20"/26" Swing over cross slide .................................................................. 11.4" Swing over gap ................................................................................ 30" Distance between centers .............................................60" / 80" / 120" Spindle speeds (range) .............................. 16 speeds (26-1700 RPM) Spindle nose/ Spindle Bore ................................... D1-8 camlock/4.12" Threads Standard (Whit-worth) .............................. 44 (7/16 to 80) TPI Threads Metric pitch .............................................. 67 (0.35 to 80) MM Tailstock Quill travel/Taper ................................................... 6" / #5 MT Main motor ........................................................ 10 HP, 230/460V, 3PH Net weight ....................................................... 4840 / 5830 / 6,930 lbs. Shipping weight ............................................ 5,500 / 6,500 / 7,600 lbs.

Heavy Duty Large Bore Engine Lathes FEATURES: • Solid full-length cast iron base. • 15 HP Spindle Motor. • 12 speeds. • Precision rigid spindle with 3 point . • Hardened and ground gears and splines. • Hardened and ground cross slideways and bedways. • Extra wide range of inch/metric threading capabilities and adjustable feed carriage stop.

Complete with STANDARD EQUIPMENT: • 3-jaw chuck (12") or (15"). • Center Sleeve. • Threading Dial. • Steady Rest. • 4-way Tool Post. • Coolant System.

• Tools & Tool Box. • Full-Length Splash Guard & Foot Brake. • Multi-Position Carriage Stop.

SPECIFICATIONS: LA-2280 Swing over bed ........................................ 22" Bed width ................................................. 15" Swing over cross slide .......................... 12.4" Width of gap with faceplate ............... 10-5/8" Distance between centers ....................... 80" Spindle speeds ....................... 13-1200 RPM Standard threads ...................... 44, 2-72 TPI Metric threads ........................ 39, 0.2-14 MM Spindle motor ..................... 15 HP, 230/460V Spindle bore ...................................... 4-1/16" Spindle nose ........................................ D1-11 Tailstock taper ..................................... M.T. 5 Net weight ..................................... 7,920 lbs. Shipping weight ............................. 8,500 lbs.

Digital Readout Includes 2-Way Rapid Traverse on Apron

LA-3080 LA-30120 LA-30160 ............................................... 30" ............................................... 15" ............................................... 22" ......................................... 10-5/8" .......................... 80" / 120" / 160" ................... 12-120 (8-800) RPM ................................ 44, 2-72 TPI ............................. 39, 0.2-14 MM ......................... 15 HP, 230/460V ......................................... 4-1/16" ........................................... D1-11 ............................................ M.T.5 ........... 7920 / 10120 / 11660 lbs. ........ 8,500 / 10,700 / 12,300 lbs.

INSTALLED! Part No. 6-273-054 Part No. 6-273-054-N

Model LA-2280 (22" x 80")

5MT Skoda H.D. live center 4-jaw chuck (24" D1-11) Face plate Taper turning attachment Micro carriage stop


Part No.

1-506-500 6-273-051A 6-273-051B 6-273-051C 6-273-051E

$253.09 2995.00 1250.00 1950.00 395.00

Phone:

$724.25/mo.*

Part No. 6-273-051 Part No. 6-273-051-N

Model LA-3080 (30" x 80")

$30,995 00

$34.075 00

FOR AS LITTLE AS

FOR AS LITTLE AS


Model LA-30120 (30" x 120")

$35,995 00

$39,950 00

FOR AS LITTLE AS

FOR AS LITTLE AS


Model LA-30160 (30" x 160")

Our Net Price

FOR AS LITTLE AS

FOR AS LITTLE AS

$654.71/mo.*

OPTIONAL EQUIPMENT Description

$32,075 00

$28,995 00

$42,995 00

$47,295 00

FOR AS LITTLE AS

FOR AS LITTLE AS

$970.83/mo.*

$1067.92/mo.*


1-800-521-5606

Fax:

1-800-322-4292

KBCTools.com

www.

LATHES •

machinery

1035

CNC Lathes

with Fanuc 0i Control FEATURES: • 10 HP servo drive spindle motor. • Big 3" plus spindle through hole. • Rigid FC30 castings with extra ribbing. • Induction hardened and ground ways. • Alloy steel gears that are hardened and ground. • Extra large precision ground ballscrews. • Spindle speed range 45-1800 RPM • Auto lube system with metered check valves. • Full enclosure. • Fanuc 0i CNC control. STANDARD EQUIPMENT: • 8" 3 Jaw Chuck. • Automatic 4 Position Electric Turret. • #5MT Tailstock. • Programmable Flood Coolant. • Automatic Lubrication System • Roller jaw steady rest

With 4 Position Electric Turret Fanuc CNC Control & 3" Spindle Bore!

• Tubular work light • Full enclosure with sliding front doors as well as rear access. • Front access slide-out chip tray • Manual and parts list for lathe • Complete manual for Fanuc 0i CNC Control.

SPECIFICATIONS: KLS-1840N/CNC Swing over bed ........................................................... 18" Swing over cross slide ............................................. 9.84" Distance between center .......................................... 39.4" Width of bed ............................................................. 13.8" Spindle nose ............................................................. D1-8 Spindle bore .................................................................. 3" Spindle taper ......................................................... M.T. #7 Spindle speeds .......................................... 45-1,800 RPM Longitudinal travel (Z axis) ....................................... 39.4" Cross slide travel (X axis) ........................................... 10" Rapid traverse speed (Z axis) ............................ 240"/min Rapid traverse speed (X axis) ............................ 120"/min Tailstock quill diameter .................................................. 3" Tailstock quill travel ....................................................... 5" Tailstock taper ....................................................... M.T. #5 Spindle motor .............................. 7.5 HP (10 HP inverter) Voltage/Phase ................................................ 230V, 3 PH AC servo motor (Z axis) ....................................... 1.13 HP AC servo motor (X axis) ........................................ 0.6 HP Net weight ......................................................... 5,236 lbs. Shipping weight ................................................ 5,800 lbs.

KLS-2660N/CNC ..................................... 26" .................................. 16.9" ..................................... 59" ..................................... 15" .................................. D1-8 ....................................... 4" .............................. M.T. #7 ................... 20-1,300 RPM .................................. 39.4" .................................. 14.4" ............................ 400"/min ............................ 320"/min ....................................... 3" ....................................... 6" .............................. M.T. #5 ................................ 10 HP ........................ 230V, 3 PH ............................. 1.13 HP ............................... 0.6 HP .......................... 8,910 lbs. .......................... 9,394 lbs.

Model KLS-1840N/CNC

Model KLS-2660N/CNC

$29,49500

$38,99500


FOR AS LITTLE AS

$666.00/mo.*

CALL FOR DETAILS



FOR AS LITTLE AS

$880.51/mo.*

CALL FOR DETAILS


CNC Lathe ®

with Anilam 4200T CNC Control

FEATURES: • Anilam 4200T CNC Control with conversational programming and 12 inch flat color screen. • Dual electronic handwheels (MPG). • 10 HP variable speed spindle motor. • 4-position automatic toolpost. • Full enclosure with sliding doors. • 3-1/8" spindle bore. • D1-8 camlock spindle mount. • Spindle ed by 2 taper roller bearings and 1 roller bearing. • Once-piece cast iron base helps absorb vibration. • Bed ways are induction hardened and precision ground. • 2-year parts and labor warranty by JET. STANDARD EQUIPMENT: • Anilam CNC Control • 4-way Automatic Programmable Toolpost • Full Enclosure with Sliding Doors • Flood Coolant System

• • • •

Automatic Lubrication System 10" 3-jaw chuck Steady rest Work light

SPECIFICATIONS: Swing over bed ........................................................... 16" Swing over cross slide ................................................ 10" Swing through gap ................................................ 25-7/8" Distance between centers ........................................... 40" Hole through spindle ............................................... 3-1/8" Spindle mount ........................................................... D1-8 Spindle Taper (w/sleeve) .............................. MT-7 (MT-5) Range of spindle speeds ........................... 80-2000 RPM Max. cross slide travel ................................................... 9" Max. Carriage travel .................................................... 35" Tailstock spindle travel .................................................. 5" Taper in tailstock spindle .......................................... MT-4 Main Motor .......................................... 10 HP, 230V, 3 PH Net Weight ........................................................ 5,566 lbs. Shipping Weight ................................................ 6,800 lbs.

Phone:

1-800-521-5606

Fax:

*

Model GH-1640ZX/CNC (16" x 40") Part No. 6-200-048 Our Net Price


1-800-322-4292

00

$30,499

KBCTools.com

www.

FOR AS LITTLE AS

$688.67/mo.*

CALL FOR DETAILS



1036

machinery

• LATHES

CNC Lathes with Anilam 4200T Control

FEATURES: • 10 HP AC frequency drive spindle motor. • Big 3" plus spindle through hole. • Rigid FC30 castings with extra ribbing. • Induction hardened and ground ways. • Alloy steel gears that are hardened and ground. • Extra large precision ground ballscrews. • Spindle speed range 7-2200 RPM. • Auto lube system with metered check valves. • Full enclosure. STANDARD EQUIPMENT: • Anilam 4200T CNC control. • 8" 3 jaw chuck. • 4-position programmable electric turret • Automatic lubrication system • Coolant system • Roller jaw steady rest • #5MT tailstock • Tubular work light • Full enclosure with sliding front doors as well as side and rear access. • Front access slide-out chip tray • Manual and parts list for lathe • Complete operation manual for Anilam 4200T CNC Control

Model CKE-2040CNC (20" x 40")

SPECIFICATIONS: CKE-2040 CKE-2060 CKE-2660 Swing over bed ......................................... 20" ................................... 20" ........................ 26" Swing over cross slide .............................. 11" .................................... 11" ..................... 16.9" Distance between center .......................... 40" ................................... 60" ........................ 60" Width of bed ......................................... 15.75" .............................. 15.75" ................... 15.75" Spindle nose ........................................... D1-8 ................................. D1-8 ...................... D1-8 Spindle bore ........................................ 3-1/16" ............................. 3-1/16" .................. 3-1/16" Spindle taper ...................................... M.T. #7 ............................. M.T. #7 ...................... 1:20 Spindle speeds ......................... 7-2,200 RPM ................... 7-2,200 RPM ........ 7-2,200 RPM Longitudinal travel (Z axis) ........................ 36" ................................... 56" ........................ 56" Cross slide travel (X axis) ......................... 11" .................................... 11" ........................ 12" Ballscrew diameter: Z axis ................................ 2", 10mm pitch ................. 2", 10mm pitch ..... 2", 10mm pitch X axis .................................. 1", 5mm pitch ................... 1", 5mm pitch ....... 1", 5mm pitch Positioning Accuracy .......................... 0.0005" ............................ 0.0005" ................. 0.0005" Repeatability ...................................... 0.0005" ............................ 0.0005" ................. 0.0002" Servo Resolution ................................ 0.0001" ............................ 0.0001" ................. 0.0001" Input Resolution ................................. 0.0001" ............................ 0.0001" ................. 0.0001" Tailstock quill diameter ........................... 2.95" ................................ 2.95" ..................... 2.95" Tailstock quill travel ..................................... 6" ...................................... 6" .......................... 6" Tailstock taper .................................... M.T. #5 ............................. M.T. #5 .................. M.T. #5 Spindle motor ....................................... 10 HP ............................... 10 HP ................... 10 HP Voltage/Phase .............................. 230V, 3 PH ...................... 230V, 3 PH ............ 230V, 3PH AC servo motor (Z axis) ...................... 2.4 HP .............................. 2.4 HP .................. 2.4 HP AC servo motor (X axis) ...................... 1.7 HP .............................. 1.7 HP .................. 1.7 HP Net weight ....................................... 5,720 lbs. ......................... 5,940 lbs. .............. 6,270 lbs. Shipping weight .............................. 6,200 lbs. ......................... 6,440 lbs. .............. 6,825 lbs.


Part No. 6-273-047

$767.61/mo.*



Part No. 6-273-048

$801.48/mo.*



Part No. 6-273-055

$868.20/mo.*


Precision CNC Live Centers

TECH-NI-COOLTM NEWLY FORMULATED HEAVY-DUTY SEMI-SYNTHETIC

FEATURES: • The centers are intended for CNC lathes. Their face parts are formed to allow easy access of the tool to the workpiece, which is an advantage with workpieces of complex shapes. • A special ring is used to set the radial clearance of the center. It also prevents cutting lubricant from leaking in the center bearing space, and so extends the operational life of the center. • Spindle-like point extends into shank where it is ed by a needle bearing, increasing rigidity, reducing point deflection and dampening vibration. Morse Taper

2 3 4 5

D

d

L

1.50" .695" 5.25" 1.85 .750 6.75 2.20 1.125 8.15 3.10 1.375 10.50


I

2.65" 3.50 3.95 4.85

Load (Lbs.)

Part No. 1-533-

Our Net Price

1300 1550 4840 7750

-152 -153 -154 -155

$268.60 284.70 332.00 417.60

Phone:

FEATURES: • The best choice in high speed CNC machining operations. • Handles the toughest metalworking applications, even in the most severe shop environments. • Provides extended tool life through increased lubrication, including exotic and hard to machine materials. • Decreases down time cleaning the machine which allows you to maintain higher productivity. • Advanced formula increases sump life, providing low foaming characteristics and gives excellent visibility of workpiece at all times.

MADE IN CZECH REPUBLIC

1-800-521-5606

Fax:

1-800-322-4292

1 Gallon Bottle


$2043 5 Gallon Pail


$9840

KBCTools.com

www.

DRILL PRESSES •

1037

High Speed Precision Drill Press

High Speed Precision Drill Press FEATURES: • Variable speeds 3200-5600 RPM. • Built-In on/off switch. • Just right for circuit board work.

machinery

FEATURES: • Infinitely variable speeds 3,500 to 12,000 RPM. • Safety interlock-motor starts when feed handle is moved. • Perfect for circuit board work.

Model CBD-6SP Part No. 6-530-004 Our Net Price 00

$145

SPECIFICATIONS: Drill Capacity: Steel ............................................ 1/8" Brass, Aluminum ..................... 13/64" Spindle RPM ......................... 3200-5600 Work Table .............................. 6-5/8"Sq. Distance - Spindle to Bench ............... 6" Spindle Travel ..................................... 1" Distance - Chuck to Column ...... 4-5/16" Drill Chuck Mount............................. JT2 Shipping Weight .......................... 20 lbs.

Model CBD-6VS Part No. 6-530-005 Our Net Price

$39500

SPECIFICATIONS: Drill Capacity: Steel....................................................... 5/64" Brass, Aluminum ..................................... 1/8" Spindle Variable Speed) .... 3500 to 12,000 RPM Work Table.......................................... 6" x 6-1/4" Distance - Spindle to Bench .................. 5-29/32" Spindle Travel .......................................... 1-3/16" Distance - Chuck to Column...................... 3-5/8" Drill Chuck Mount .......................................... JT1 Shipping Weight........................................ 50 lbs.

13-1/4" Oscillating Drill Press

®

15" Variable Speed Drill Press

TWO TOOLS IN ONE! Serve both as a regular drill press and oscillating spindle sander. Perfect for shop with limited space. Patented machines come with oversize hole and reducer rings to match different sanding drum sizes with the dust port. SPECIFICATIONS: Motor ..................................... 3/4 HP, 115V, 1725 RPM Overall Height............................................................38" Spindle Travel .......................................................3-1/4" Swing ....................................................................13-1/4 Drill Chuck ................................................................5/8" Dust Port Size .......................................................2-1/4" 12 Speeds ..............................................250-3050 RPM Table .................................................Round 12-3/8" dia. Table Swing .............................................................360" Shipping Weight .................................................130 lbs.

FEATURES: • Speeds from 400 to 5,000 RPM. • Handwheel adjustment sets the speeds. • Large 2-1/4" quill allows greater accuracy. • 3" column diameter for maximum head . • Accurate depth stop for precise hole depths.

Model W1668

Part No. 6-397-WS1668 Our Net Price

$26900

2 Year Warranty on Mechanics. 1 Year Warranty on Electric's.

Tapping Machine FEATURES: • Cone-clutch reversing mechanism in spindle head speeds tapping operations. • Lever controlled spindle movement. • Fast spindle-speed adjustment. • Adjustable depth stop.

Model J-A5816

Model TM-10

Part No. 6-200-JA5816 Our Net Price


$1,69900

$64900

SPECIFICATIONS: Range of Spindle Speeds ........................... 400 to 5,000 RPM Spindle Taper ................................................................... 2 MT Quill Diameter ................................................................. 2-1/4" T-Slots number and size ............................................. 2 & 1/2" Work table weight capacity ....................... 12-1/2 x 14-1/2 lbs. Column Diameter .................................................................. 3" Drilling Capacity Cast Iron ................................................. 5/8" Drilling Capacity Mild Steel ................................................ 1/2" Quill Travel ............................................................................ 6" Table Size ...................................................... 15-1/4" x 17-3/4" Spindle Distance to Base ............................................. 47-1/2" Motor ............................ 1 HP, 115/230V, 1 PH, Prewired 115V Net Weight ................................................................... 238 lbs. Shipping Weight .......................................................... 350 lbs.

SPECIFICATIONS: Swing ................................................................. 14-5/8" Tapping Capacity Steel ................................ 5/32"- 3/8" Cast Iron....................................................... 5/32"- 1/2" Spindle Travel...................................................... 2-1/8" Max. Distance, Chuck to Table.......................... 16-1/2" Spindle Taper ..........................................................6 JT Table Size ............................................ 12-3/4" (Round) Spindle Speeds (3) ............................ 270 – 680 RPM Column Diameter................................................. 3-1/8" Motor ......................................... 1/2 HP, 115V, 1 Phase Overall Height .......................................................... 46" Base Size ........................................... 11-3/4" x 19-1/4" Net Weight........................................................ 220 lbs. Shipping Weight .............................................. 325 lbs.

Phone:

1-800-521-5606

Fax:

1-800-322-4292

KBCTools.com

www.


1038

machinery

• DRILL PRESSES

Industrial Duty Drill Presses FEATURES: • One piece cast iron head is ed by a heavy cast column for extra rigidity. • Spindles are hardened and ground, ed by stacked ball and thrust bearings. • Morse taper spindles allow a wider variety of tooling to be used. • All models complete with switch, motor, drill chuck, arbor & chuck key.

Model KBC-100B

®

MODEL KBC-250FT

Model KBC-150F



$16500

$34900

SPECIFICATIONS: KBC-100B Swing ..................................... 13" Drilling Capacity .................... 5/8" Type .................................. Bench Spindle Travel .................. 3-5/16" Spindle Taper ...................... 2 MT Column Diameter .............. 2-7/8" Table Size .................. 11-1/2" Rd Spindle Speeds ....................... 12 Speed Range (RPM) ... 230-3200 Motor .......................1/2 HP, 115V Overall Height ........................ 38" Base Dimensions ......... 10" x 17" Net Weight ...................... 101 lbs. Shipping Weight ............. 175 lbs.

MODEL KBC-100B

Floor Drill Press

FEATURES: • Hinged metal belt and pulley cover. • Quick adjustment motor mount. • Rotating ±45o tilting, crank-operated worktable with quick-release clamp. • 1/2" diameter external positive depth stop with 3-nut locking feature. • Adjustable tension spindle return spring. • Spindle ed by high quality ball bearings. • Built-in work lamp. • Drill chuck and key.

SPECIFICATIONS: Swing ................................................ 20-1/2" Drilling Capacity ........................................ 1" Chuck Size ............................................. 3/4" Spindle Travel ..................................... 4-5/8" Spindle Distance to Base ................. 46-3/4" Max. Spindle Distance to Table ........ 29-1/8" Table Size .......................... 18-5/8" x 16-1/8" Spindle Taper ....................................... MT-3 Column Diameter ................................ 3-3/8" No. of Spindle Speeds ............................. 12 Range of Spindle Speeds ..150 - 4,200 RPM Base Size .......................... 13-5/8" x 22-3/8" Motor .................... 1-1/2 HP, 1 Ph, 115/230V ......................................Prewired 115V Net Weight ....................................... 288 lbs. Shipping Weight ............................... 375 lbs.

KBC-150F KBC-250FT .................. 17" ................. 18" ................. 3/4" ................... 1" ............... Floor .............. Floor .............. 3-1/4" .......... 4-3/16" ............... 3 MT .............. 4 MT .............. 3-1/8" ............ 3-5/8" ...... 13-3/4" Rd ..16" x 18-5/8" .................... 12 .................... 9 ........ 200-2600 .........150-2020 ....3/4 HP, 115V .....1 HP, 230V .................. 64" ................. 66" ... 10-1/2" x 18" ....... 13" x 23" ........... 165 lbs. ......... 297 lbs. ........... 245 lbs. ......... 375 lbs.

Model KBC-250FT

Model JDP-20MF



$39900

$74900

Heavy Duty Drill Press

Heavy Duty Drill/Tap Machine

FEATURES: • Variable speed spindle drive (300 RPM to 2,000 RPM). • 1-1/2" drilling capacity. • 3 MT spindle with a 2-1/2" dia. quill. • Heavy cast table with coolant trough. • Power quill feed, simply select .004", .006", .009", or .012" per/rev by using dial selector. • 1-1/2 HP, 1PH or 3PH motor.

FEATURES: • Variable speeds. • 2" drilling capacity. • .0002" spindle runout. • Auto drill/tap switch. • 3 HP motor & low-voltage controls. • Complete w/coolant & machine light. • Gear driven power quill feed 4-steps. • 2-way travel for positioning workplace.

SPECIFICATIONS: Capacity ............................ 1-1/2" dia. Distance, Spindle to Column ......... 10" Column Diameter ............................ 4" Spindle Nose Taper .................... 3 MT Spindle Travel ............................... 6.5" Table Working Surface ......... 22" x 19" Spindle to Table Max. .............. 33-1/3" Spindle to Base Max. .............. 43-3/8" Motor ........... 1-1/2 HP, 230V, 1 Phase ......... or 1-1/2 HP, 230V, 3 Phase Net Weight ............................. 630 lbs. Shipping Weight ..................... 800 lbs.

Model 28 VS/ST Part No. 6-555-015 Our Net Price

$6,99500 FOR AS LITTLE AS

$160.89/mo.*

CALL FOR DETAILS


Model 20" VS 1 Phase Model Part No. 6-555-010 Our Net Price 00

$2,795

Complete with Power Feed.

Model 20" VS 3 Phase Model Part No. 6-555-011 Our Net Price

SPECIFICATIONS: Drilling Capacity, Steel ......................... 2" Tapping Capacity, Steel ......................... 1-1/4" Spindle to Center of Circle (swing) ..14" (28") Spindle Taper ........................................... 4MT Table Size ......................................... 10" x 24" Longitudinal Table Travel ..................... 10-5/8" Cross Table Travel ................................. 8-5/8" Spindle to Table Max. ................................ 22" Spindle/Quill Travel ...................................... 7" Infinitely Variable Speeds ....... 150 – 2000 RPM Motor ............ 3 HP, 3 PH, 230V Net Weight ................ 1,650 lbs. Shipping Weight ....... 2,000 lbs.

$2,79500 KBC TOOLS & MACHINERY

Phone:

1-800-521-5606

Fax:

1-800-322-4292

KBCTools.com

www.

DRILL PRESSES •

Heavy Duty Drill Press

Model 600B Complete with Foot Operated Reversing Switch

00

$3,195

FEATURES: • Gear head direct-drive of spindle. • 2-speed instant reversing motor for tapping. • X & Y table movement with graduated dials. • Up to 24" capacity spindle - table. • Rapid and fine manually operated quill feeds. STANDARD EQUIPMENT: • 2-axis t-slot work table • Graduated dials for • Geared head spindle drive “X” & “Y” handwheels • Rear rubber way cover • Manual & parts list

FOR AS LITTLE AS

$73.49/mo.*

Model GHD-40

CALL FOR DETAILS



$1,99500

SPECIFICATIONS: Distance, Spindle to Column Face .... 12" Swing ................................................. 24" Max. Dist. Spindle to Table .......... 32-1/2" Max. Dista. Spindle to Base ............... 47" Column Diameter ........................... 5-1/2" Table Size ................................. 20" x 16" Spindle Travel ................................ 6-5/8" Spindle Taper .................................. 4 MT Drilling Capacity (in mild steel) ...... 1-1/2" Spindle Speeds (8) ............. 80-950 RPM Power Feed Rates ......... .004-.007 in/rev. Motor .......... 3/4/1.5 HP; 1700/3400 RPM .......................................230V, 3 PH Net Weight .................................. 675 lbs. Shipping Weight ......................... 800 lbs.

Mini Radial Drill

SPECIFICATIONS: Distance, Spindle to Column Face ........ 11-1/4" Swing ..................................................... 22-1/2" Max. Dist. Spindle to Table .......................... 24" Column Diameter ..................................... 4-1/2" Table Size ................................. 7-1/2" x 23-3/4" Table Travel .............................. 7-1/2" x 14-1/2" Spindle Travel .......................................... 4-3/4" Spindle Taper ............................................ 4 MT Drilling Capacity (in mild steel) ................ 1-1/2" No. of Spindle Speeds .................................... 6 Range of Spindle Speeds ........... 9-1, 970 RPM Motor ...... 1.5 HP, 1700/3400 RPM, 230V, 3 PH Net Weight ............................................ 750 lbs. Shipping Weight ................................... 875 lbs.

Radial Drill Presses Model RD-750

MODEL RD-750 FEATURES: • High carbon steel spindle rigidly mounted in tapered roller bearings. • Geared spindle drive with six speeds selected by change levers. • 3 spindle feed rates selected by a single knob. • Power elevation of the arm anywhere along the column.

Model RF-35

$2,22500

Comes Complete with Floor Stand!

FEATURES: • Versatile design allows drill head to be easily positioned where needed! • Compact design, no need to set up your large drilling machine for small jobs. • Supplied complete with heavy duty floor stand as shown. SPECIFICATIONS: Drilling Capacity in Cast Iron .............. 1-5/8" In Steel .............................................. 1-1/4" Tapping Capacity in Cast Iron ................ 5/8" Spindle Taper ....................................... 3 MT Spindle Travel ..................................... 5-1/8" Spindle Speed (5) ..........340/660/1060/1665/3000 RPM Spindle Motor ................................. 1-1/2 HP Single Phase Voltage .......... 115/230V, 1 PH Spindle to Column Max ............................19" Column Diameter ................................ 4-1/2" Table Size ................................ 21-5/8" x 20" Net Weight w/Stand ......................... 640 lbs. Shipping Weight .............................. 775 lbs.

Phone:

1-800-521-5606

STANDARD EQUIPMENT: • Box Section Work Table • Coolant System • Built-in Work Light • Tool Kit

$7,29500 MODEL RD-750


Model RD-1000

FOR AS

Part No. LITTLE AS 6-269-011 $193.09/mo.* Our Net Price CALL FOR DETAILS

$8,39500


Complete with Box Table, Coolant and Worklight

SPECIFICATIONS: Model RD-750 Model RD-1000 Drilling Capacity Steel .................. 1-1/2" .......................... 1-3/4" Cast Iron ........................ 2" .......................... 2-1/2" Tapping Capacity Steel ...................... 3/4" ............................. 7/8" Cast Iron ........................ 1" .......................... 1-1/4" Column Diameter ............................. 8-1/4" .............................. 10" Distance, Spindle – Column.......... 30-1/2" ........................... 39.4" Lateral Head Travel ....................... 19-1/8" ........................... 31.5" Distance, Spindle Nose To Base ........................ 11-1/4 - 43-3/4"........... 10-1/2" - 41.92" Size of Base ............................... 50" x 25" ............... 68" x 29-1/2" Spindle Speeds ........... (6) 88 - 1500 RPM...... (8) 71 - 1800 RPM Spindle Feeds (3) . .002, .0035, .006 in/rev... (4) .005 - .021 in/rev Spindle Taper .................................... 4 MT............................. 4MT Quill Travel ....................................... 7-7/8" .......................... 9-7/8" Drive Motor ........................................ 2 HP............................ 3 HP Column Motor .................................... 1 HP............................ 2 HP Coolant Motor ................................. 1/8 HP......................... 1/8 HP Voltage/Phase.............. 230/460V, 3 Phase ..... 230/460V, 3 Phase Overall Height ................................ 85-5/8" .............................. 93" Net Weight ................................. 2,420 lbs. .................... 3,080 lbs. Shipping Weight ........................ 3,000 lbs. ................... 3,800 lbs.

Fax:

FOR AS

Part No. LITTLE AS 6-269-010 $167.79/mo.* Our Net Price CALL FOR DETAILS

MODEL RD-1000 FEATURES: • 39" maximum reach spindle to column. • 8 spindle speeds and 4 spindle feeds. • Power electric drive to raise/lower arm.


1039

1-1/2" 4MT Spindle Geared Head Heavy Duty Drill Press

FEATURES: • 8 speed geared head (80 RPM to 950 RPM). • 1-1/2" drilling capacity. • 24" swing. • 4 MT spindle taper. • Power quill feed. • Foot pedal operated instant reverse switch for tapping. • .75/1.5 HP motor, 230V, 3PH. • Net weight 675 lbs.


machinery

1-800-322-4292

KBCTools.com

www.

MODEL RD-1000


1040

machinery

• MILLING MACHINES

Vertical Bench Mill

Mini Milling Machine FEATURES: • Electronic variable spindle speeds. • R8 spindle taper with drawbar. • Vertical column tilts left-right. • Dovetail slides with tapered gibs.

FEATURES: • Manual quill feed both rapid spoke wheel and fine feed handwheel control with an easy to read, front mounted depth gage. • Head assembly is raised and lowered on the column by a crank. The head pivots 360° on the column and can be locked in any position. • Dovetail ways on table and saddle with adjustable tapered gibs. • Reversing switch.

With R8 Spindle Taper.

SPECIFICATIONS: Spindle Taper ......................... R8 Head Travel ....................... 9-7/8" Head Tilt ............ 45 degrees L/R Max. distance spindle to table .......... 11-1/2" Swing .............................. 12-3/4" Longitudinal Travel .......... 7-7/16" Cross-slide Travel ................... 4" Table Size .......... 3-5/8" x 15-3/4" Speeds .......................... Variable Speed Range ......... 0-2500 RPM Motor Size ....................... 3/4 HP Voltage ................................ 115V Shipping Weight ............. 170 lbs.

STANDARD EQUIPMENT: • Drill Chuck & Arbor. • Toolbox & Tools. SPECIFICATIONS: Drilling Capacity........................................ 1-1/4" End Mill Capacity......................................... 3/4" Swing ...................................................... 15-7/8" Max. Distance, Spindle to Table ................... 18" Spindle Taper ................................................ R8 Spindle Travel ................................................. 5" Column Diameter...................................... 4-1/2" Spindle Speeds ........................... 110-2385 (12) Table Travel .................................................. 18" Cross Slide Travel .......................................... 7" Effective Table Area .............................. 28" x 8" Overall Height......................................... 43-1/2" Motor ................................................. 2HP, 1 PH Voltage/Phase...................................230V, 1 PH Shipping Weight .................................... 650 lbs.

Model MM-12


$59500 Turret Milling Machines

Complete with Stand! (not pictured)

Model GRIP-16

1 PH - Part No. 6-275-003 Our Net Price

$1,39500

3HP Variable Speed Head!

MODEL TUM-1VS Pictured with Mitutoyo Digital Readout and KBC Table Feed

Complete with

Complete with

Complete with

2-Axis Digital Readout & Powerfeed Model TUM-1VS INSTALLED!

2-Axis Digital Readout & Powerfeed


INSTALLED!

Part No. 6-265-007 Part No. 6-265-007-F Part No. 6-265-007-M


$121.79/mo.*


$151.69/mo.*

INSTALLED!

Part No. 6-265-007-N

$6,745 00

$6,935 00

FOR AS LITTLE AS

FOR AS LITTLE AS

$155.14/mo.*

$159.51/mo.*


8-Speed Model TUM-1

FOR AS LITTLE AS


$107.99/mo.*


$4,69500 FEATURES: • Chrome quill with super precision class “7” preloaded bearings. • All mills have hardened ways. These mills will maintain “like new” accuracies over many years. • Separate manual feed has a lever for rapid quill movement and a handwheel for slow quill movement. • Positive two-way power feed tripping mechanism. • Micrometer depth stop, graduated in thousandths.

• • • • • •

Spindle drive is back geared, for maximum use of power. Reversible switch for right or left-hand operation. Counter-balanced quill & spindle for extreme sensitivity. Equipped with power down & up-feed. (Power quill feed) Integral worm & gear for accurate angular positioning. One shot lubrication.

SPECIFICATIONS: TUM-1 Table Size .............................................................................. 9" x 49" Longitudinal Travel Manual Model ................................................ 35" Longitudinal Travel w/Power Feed................................................ 31" Cross Travel .................................................................................. 12" Knee Travel ................................................................................... 16" Table To Spindle min-max. ................................................. 0-18-3/4" Spindle To Column at 90° ............................................ 6-3/4"-18-3/4" Spindle Speeds .................................................... (8) 80–2720 RPM Spindle Taper................................................................................ R-8 Power Quill Feeds (per rev.).............................. .0017"/.0032"/.0053" Quill Travel ...................................................................................... 5" Spindle Motor Step Pulley............................... 2 HP, 230/460V, 3 PH Net Weight (approx.)........................................................... 2,100 lbs. Shipping Weight ................................................................. 2,600 lbs.


Phone:

MODEL TUM-1

TUM-1VS ................................................... 9" x 49" .......................................................... 35" .......................................................... 31" .......................................................... 12" .......................................................... 16" ................................................. 0-18-3/4" .......................................... 6-3/4"-18-3/4" ............................ 70–4200 RPM (Var.)* .......................................................... R-8 ............................... .0017"/.0032"/.0053" ............................................................ 5" ............................. 3 HP, 230/460V, 3 PH ................................................ 2,200 lbs. ................................................ 2,700 lbs.

1-800-521-5606

Fax:

1-800-322-4292

KBCTools.com

www.

MILLING MACHINES •

FEATURES: • Turret head tilts to either side 90° and swivels 120° right or left. R8 taper spindle accepts all common R8 tooling. • Dovetail ways with adjustable tapered gibs under the table and saddle and on the column face. • Spindle feeds with a manually operated rapid feed lever or a fine feed handwheel. • Complete with work light and cabinet floor stand.

This benchtop mill/drill is a real work horse. Install the 3" face mill (included!), fire up the 2 HP 12-speed motor, and you will have chips flying in no time! Raise the head a lofty 18" over the large 8" x 28" table, and add the 1/2" drill chuck or R-8 collets for holding a wide array of endmills. Use the clutchtype downfeed mechanism with both rapid and micro-feed quill adjustments and the M1007 is ready for those fine milling and drilling operations.

Model M1007 2 HP 115/230V 1PH Part No. 6-397-M1007 Our Net Price

$1,45000

1041

6" x 26" Table Vertical Milling Machine

SHOP FOX® Mill / Drill

FEATURES: • 1/2" Drill Chuck. • Clutch-type Downfeed Mechanism. • Graduations are in inches. • 3" face mill.

machinery

SPECIFICATIONS: Motor size ............2 HP, 115V/230V, single-phase Spindle taper ................................................... R-8 Spindle travel ..................................................... 5" Swing ......................................................... 15-7/8" Max. distance spindle nose to table .......... 17-3/4" Column size ................................................. 4-1/2" Table size ................................................. 8" x 28" Table travel (longitudinal) .......................... 23-1/2" Table travel (cross) ............................................ 7" Drilling capacity ............................................1-1/4" Number of speeds (12) ................. 20-2,500 RPM Approximate shipping weight ................... 620 lbs.

STANDARD EQUIPMENT: • Floor Stand • Front & rear rubber way covers • Work light • Drawbar for R8 collets • Manual & parts list

Complete with Stand! (not pictured)

SPECIFICATIONS: Table Size .............................. 6" x 26" Longitudinal Travel ................. 14-1/2" Cross Travel .................................... 6" Quill Travel ................................ 2-3/4" Spindle Taper ................................. R8 Spindle Speeds (9) ... 230-2,520 RPM Drive Motor ............. 1 HP, 230V, 1 PH Net Weight ............................. 576 lbs. Shipping Weight .................... 695 lbs.

Model VM-12-R8 Part No. 6-380-001 Our Net Price

$2,19500

Heavy Duty Milling Machines FEATURES TUM-3VS: • 3 HP VS mill head has compound swivel mount for maximum versatility in your set-ups. • Standard R8 spindle taper accepts all common tooling for bridgeport style mills. • Hardened and ground square ways on knee and column with wide saddle to 10" x 50" ground table. FEATURES TUM-40VS: • 5 HP VS mill head tilts from side to side only for extra rigidity. • 40 NST spindle taper and precision spindle bearing enable this machine to mill 4cu/in min in mild steel. • Hardened and ground square ways on knee and column with wide saddle for proper of 10" x 50" ground table.

FEATURES BOTH MACHINES: • Infinitely variable spindle speeds. • Satin-chrome dials and chrome ball crank handles for table and cross travels. • One shot lubrication. • Front and rear way covers. • Chrome lead screws for smooth movements. • Precision spindle bearings and chromed quill. • Power quill feed with feed trip.

MODEL TUM-40VS 5 HP Motor, #40 NST Spindle Taper, Hardened & Ground Square Ways on Knee and Column.

MODEL TUM-3VS pictured with Newall Digital Readout and KBC Table Feed.

Part No. 6-265-006 Model TUM-3VS $6,095 00 FOR AS LITTLE AS

$140.19/mo.*

SPECIFICATIONS: TUM-3VS TUM-40VS Table Size ............................................... 10" x 50" .................................. 10" x 50" Longitudinal Travel Manual ............................ 32" ............................................ 32" with Power Feed ........................................ 28" ............................................ 28" Cross Travel .................................................... 16" ............................................ 16" Knee Travel ..................................................... 16" ............................................ 16" Table to spindle min/max .......................... 16-5/8"...................................... 16-5/8" Spindle to column at 90O .......................... 5" - 22" ..................................... 5" - 22" Spindle Speeds ........................... 70 - 4200 RPM........................ 70 - 4200 RPM Spindle Taper ................................................... R8...................................... NST40 Power Quill Feeds (per rev.) .. .0017/.0032/.0053 ....................... .0015/.003/.006 Quill Travel ......................................................... 5" .............................................. 5" Spindle Motor............... 3 HP, 230/460V, 3 Phase ....... 5 HP, 230/460V, 3 Phase Net Weight ............................................. 2,800 lbs. ................................. 2,900 lbs. Shipping Weight ................................... 3,200 lbs. ................................ 3,500 lbs.

Complete with

Complete with

Complete with




INSTALLED!

INSTALLED!

INSTALLED!

Part No. 6-265-006-F

Part No. 6-265-006-M

Part No. 6-265-006-N

$7,395 00

$7,545 00

$7,735 00

FOR AS LITTLE AS

$170.09/mo.*

FOR AS LITTLE AS

$173.54/mo.*

FOR AS LITTLE AS

$177.91/mo.*

Part No. 6-265-009 Part No. 6-265-009-F Part No. 6-265-009-M Part No. 6-265-009-N Model TUM-40VS $7,550 00 $8,845 00 $8,995 00 $9,185 00 FOR AS LITTLE AS

$173.65/mo.*

FOR AS LITTLE AS

$203.44/mo.*

FOR AS LITTLE AS

$206.89/mo.*

FOR AS LITTLE AS

$211.26/mo.*


Phone:

1-800-521-5606

Fax:

1-800-322-4292

KBCTools.com

www.


1042

machinery


Vertical Milling Machine

®

* ®


With Digital Readout and Power Table Feed INSTALLED!

FEATURES: • Precision bored and honed milling head. • High precision spindle bearing. • Over 10" of front to back ram travel. • Table, knee and saddle features lock. • Head tilts to left or right. • Equipped with fine downfeed. • Precision ground dovetail ways.

Model JVM-836-1 (1 PH) 8 x 36" Step Pulley

SPECIFICATIONS: JTM-1050 Table Size .............................................. 10" x 50" Longitudinal Travel Manual ............................. 35" Longitudinal Travel with Power Feed .............. 31" Cross Travel .................................................... 16" Knee Travel ..................................................... 16" Table to spindle min./max. ......................... 15-1/4" Spindle to column at 90° .................... 5-1/2" - 26" Spindle Speeds ............................. 70-3,800 RPM Spindle Taper ................................................... R8 Power Quill Feeds (per rev.) ... .0015"/.003"/.006" Quill Travel ......................................................... 5" Spindle Motor ..................... 3 HP, 230/460V, 3 PH Net Weight ............................................ 2,900 lbs. Shipping Weight .................................... 3,200 lbs.

Part No. 6-200-044


$108.08/mo.* CALL FOR DETAILS *60 month term, $1.00 BUYOUT

Part No. 6-200-045 00

$4,699

FOR AS LITTLE AS

*


SPECIFICATIONS: Spindle Taper ................................................................ R-8 Speeds........................................................ 240-1,550RPM Spindle Travel .................................................................. 5" Max. Distance Spindle to Table..................................... 14" Spindle Column Min./Max............................. 5-1/4"-15-3/4" Max. Travel X,Y ........................................... 25-1/4", 9-1/2" Size of Table .............................................. 7-7/8" x 35-3/4" Motor (TEFC) ..................... 1-1/2 HP, 230 V, 1 PH or 3 PH Net Weight........................................................... 1,544 lbs. Shipping Weight ................................................. 2,050 lbs.

®

MODEL JTM-1050 pictured with Newall Digital Readout and JET Table Feed.

SPECIFICATIONS: JTM-4VS Table Size ................................................. 9" x 49" Longitudinal Travel Manual .............................. 34" Longitudinal Travel with Power Feed ............... 30" Cross Travel ..................................................... 12" Knee Travel ...................................................... 16" Table to spindle min./max. .................... 0 - 18-3/4" Spindle to column at 90° ..................... 4-1/2" - 19" Spindle Speeds .................... 60-4,200 RPM (Var.) Spindle Taper .................................................... R8 Power Quill Feeds (per rev.) . .0017"/.0032"/.0053" Quill Travel ......................................................... 5" Spindle Motor ..................... 3 HP, 230/460V, 3 PH Net Weight ............................................. 2,420 lbs. Shipping Weight ..................................... 2,700 lbs.

STANDARD EQUIPMENT: • One-shot lubrication system. • Draw Bar • Tool box and tools.

Model JVM-836-1 (3 PH) 8 x 36" Step Pulley

Milling Machine Packages

JTM-4VS Mill


Complete with One-Shot Lubrication System, Way Covers, Draw Bar and Tool Box with Tools.

Complete with

Complete with

2-Axis Digital Readout

2-Axis Digital Readout

INSTALLED!

INSTALLED!

Part No. 6-200-008

Part No. 6-200-007

$8,499 00OR

$8,499 00OR

FOR AS LITTLE AS

LESS!

$195.48/mo.*

JTM-1050 Mill

Phone:

Part No. 6-200-009

$10,999 00OR

$10,999 00OR

$252.98mo.*

$252.98/mo.*

FOR AS LITTLE AS

LESS!

FOR AS LITTLE AS

LESS!


*


Complete with 2-axis or 3-axis Acu-Rite CNC control installed, one-shot lubrication system, front & rear way covers, mill and CNC control manual, and 2 year parts & labor warranty by JET.

2-AXIS MODEL SHOWN

Model JTM-4VS CNC (2-Axis)

SPECIFICATIONS: Table Size ................................................. 9" x 49" Longitudinal Travel Manual .............................. 34" Longitudinal Travel with Power Feed ............... 30" Cross Travel ..................................................... 12" Knee Travel ...................................................... 16" Table to spindle min./max. .................... 0–18-3/4" Spindle to column at 90° ..................... 4-1/2"–19" Spindle Speeds .................... 60-4,200 RPM (Var.) Spindle Taper .................................................... R8 Power Quill Feeds (per rev.) . .0017"/.0032"/.0053" Quill Travel ......................................................... 5" Spindle Motor ..................... 3 HP, 230/460V, 3 PH Net Weight ............................................. 2,420 lbs. Shipping Weight ..................................... 2,700 lbs.


LESS!

$195.48/mo.*

Part No. 6-200-010

CNC Vertical Milling Machines

FEATURES: • Acu-Rite CNC control - easy to learn and simple to use. • Reliable mechanical V.S. Mill head delivers full torque over entire speed range. • 9" x 49" hardened and ground table with precision hardened ground ways. • 2-axis or 3-axis programmable CNC with DRO disply for X/Y/Z axis. • 2 year parts and labor warranty by JET.

FOR AS LITTLE AS

FOR AS LITTLE AS

$448.48/mo.*

Part No. 6-200-011

$19,49900


Model JTM-4VS CNC (3-Axis)

FOR AS LITTLE AS

$505.98/mo.*

Part No. 6-200-012

$21,99900

1-800-521-5606

Fax:

1-800-322-4292


KBCTools.com

www.


CNC Mill

machinery

1043

Model KTM-3VS

with 2-Axis Acu-Rite CNC Control

(with 2-Axis Acu-Rite CNC Control) Part No. 6-273-000 Our Net Price

FEATURES: • Acu-Rite CNC control - easy to learn and simple to use. • Reliable mechanical V.S. Mill head delivers full torque over entire speed range. • 9" x 42" hardened and ground table with precision hardened ground ways. • 2-axis programmable CNC with DRO display for z-axis.


$436.89/mo.*

CALL FOR DETAILS


SPECIFICATIONS: Table Size ............................................................................................. 9" x 42" Table Travel (X-Axis) ................................................................................... 28" Saddle Travel (Y-Axis) ................................................................................. 15" Knee Travel (Z-Axis) .................................................................................... 15" Spindle Motor .................................................................. 3 HP, 230/460V, 3PH Spindle Taper ..................................................................... R-8 (NMTB-30 opt.) Max. Workload ..................................................................................... 750 lbs. Net Weight ......................................................................................... 2,400 lbs. Shipping Weight ................................................................................ 2,900 lbs.

2 or 3 Axis CNC Mills FEATURES: • Acu-rite control is easy to learn and simple to use! • Exclusive "Quill Release" feature for manual operation. (3-axis version) • 3 HP R8 taper E.V.S. head runs on 1 PH or 3 PH power. • 60-4500 spindle speeds w/back gears for maximum torque at low speeds. • 10" x 50" table 32"(x) 14"(y) 4" (z) with control.

Electronic Variable Speed Head

Model KTM3VKF (2-Axis Acu-Rite CNC Control) Part No. 6-273-0015 Our Net Price

$21,49500

SPECIFICATIONS: Table Size .................................................... 10" x 50" Table Travel (X-Axis) ............................................. 30" Saddle Travel (Y-Axis) ........................................... 14" Knee Travel (Z-Axis) ............................................. 15" Ram Travel ............................................................ 22" Quill Travel w/ CNC Control .................................... 4" Quill Dia. ........................................................... 3.375" Spindle Motor ..................... 3 HP, 230V, 1 or 3 Phase Spindle Taper ........................................................ R-8 Max. Workload ............................................... 850 lbs. Net Weight .................................................. 3,300 lbs. Shipping Weight .......................................... 3,800 lbs.

FOR AS LITTLE AS

$494.39/mo.*

CALL FOR DETAILS


Model KTM3VKF (3-Axis Acu-Rite CNC Control) Part No. 6-273-011 Our Net Price 00

$25,495

FOR AS LITTLE AS

$575.68/mo.*

CALL FOR DETAILS


KTM-5VKF CNC Mill

with 3-Axis Acu-Rite CNC Control FEATURES: • 5 HP AC frequency drive variable speed spindle motor. • 40NST spindle taper allows heavier cuts than R8 taper mills. • Meehanite castings. • Precision ground ballscrews. • Ultra precision ground spindle with a ABEC-7 bearings. • Auto lube system. • Acu-Rite 3-axis CNC control. • Hardened and ground square ways.

STANDARD EQUIPMENT: • 3-axis Acu-Rite CNC control • Electronic variable spindle speeds • Hardened and ground square ways • Front & rear way covers • Automatic lubrication system • Drawbar for NST-40 collets • Manual & parts list for mill • Complete operation manual for Acu-Rite CNC control

SPECIFICATIONS: Table Size ........................................................................... 12" x 50" Table Travel (X-axis) .................................................................... 30" Saddle Travel (Y-axis) .................................................................. 15" Knee Travel (Z-axis) .............................................................. 15-1/2" Ram Travel ............................................................................ 26-3/4" Quill Travel w/CNC Control ............................................................ 4" Quill Dia. ................................................................................. 4.173" Spindle Motor ................................................ 5 HP, 230V, 1 or 3 PH Spindle Taper ..................................................................... MNTB-40 Max. Workload ..................................................................... 850 lbs. Net Weight ......................................................................... 3,300 lbs. Shipping Weight ................................................................ 3,700 lbs.

Phone:

1-800-521-5606

Fax:

Model KTM-5VKF (with 3-Axis Acu-Rite CNC Control) Part No. 6-273-0016 Our Net Price


$643.42/mo.*

CALL FOR DETAILS


1-800-322-4292

KBCTools.com

www.


1044

machinery


3-Axis CNC Bed Mills FEATURES: • 7.5 HP AC frequency drive variable speed spindle motor. • Meehanite castings. • Precision ground ballscrews. • Ultra precision ground spindle with a ABEC-7 bearings. • Auto lube system. • Coolant system with chip pan + splash guards. • Metal telescoping way covers on "Y" Axis. • Air power drawbar. • Programmable spindle RPM and coolant on/off. • Hardened and ground square ways.

Model TW-32QI

(3-Axis Bed mill w/ Anilam #3300 CNC Control) Part No. 6-273-002 Our Net Price

$33,29500

FOR AS LITTLE AS

$751.80/mo.*

CALL FOR DETAILS


Model TW-40QI

(3-Axis Bed mill w/ Anilam #3300 CNC Control) Part No. 6-273-004 Our Net Price

$44,65000

SPECIFICATIONS: TW-32QI Table Size ........................................ 12" x 50" Travel (X, Y + Z) .................... 32" x 18" x 18" Spindle Column ........................................ 20" Spindle To Table ................................ 4"–24" Quill Travel ............................................... 5.5" Quill Diameter ...................................... 4.173" Quill Feed Rates ........................................ (3) Spindle Motor .......... 7.5 HP, 230V, 1 or 3 PH Spindle Speeds Variable ........ 60-6,000 RPM Spindle Taper ................... NST-40 or CAT-40 Max. Table Load ............................. 1,000 lbs. Net Weight ..................................... 4,300 lbs. Shipping Weight ............................. 4,900 lbs.

FOR AS LITTLE AS

$1,008.20/mo.*

CALL FOR DETAILS


TW-40QI .................................. 18" x 59" ............ 32" x 18-1/2" x 18-1/2" ........................................ 18.9" .............................. 3-1/2"–26" .......................................... 5.5" ...................................... 4.173" ............................................ (3) .......... 7.5 HP, 230V, 1 or 3 PH ......................... 60-6,000 RPM ................... NST-40 or CAT-40 ................................. 1,320 lbs. ................................. 6,050 lbs. ................................. 6,700 lbs.

3-Axis CNC Bed Mills with Tool Changer

FEATURES: • Ac Digital Brushless Servo Spindle and Axis motors and drives. • 8,000 RPM spindle, CAT-40 spindle taper. • ATC (20 Tools, carousel-type). • 12" x 50" or 18" x 59" Hardened and ground table with hardened and ground dovetail ways. • Handwheels on X & Y-axis. • Hardened and Ground Box ways on Y & Z-axis. • Metal telescoping way cover on front Y-axis. • Programmable flood coolant system with vertical splash guard and chip/coolant pan. • Overhead arm-mount of control with special Manual/DRO operating mode. • Auto Lube system with metered Check valves. • Halogen work light.

Model TW-32MCO

(with Anilam #6300 CNC Control & 20 Tool ATC) Part No. 6-273-0041 Our Net Price

$44,95000

FOR AS LITTLE AS

$1,014.97/mo.*

CALL FOR DETAILS


Model TW-40MCO

(with Anilam #6300 CNC Control & 20 Tool ATC) Part No. 6-273-0042 Our Net Price

$54,95000

FOR AS LITTLE AS

$1,229.23/mo.*

CALL FOR DETAILS


SPECIFICATIONS: TW-32MCO Table Size .................................................. 12" x 50" Table Travel ........................................................ 32" Saddle Travel ...................................................... 20" Vertical Travel ..................................................... 20" Spindle Column .................................................. 20" Spindle To Table ..................................... 3.93"-23.6" Spindle Motor ............................. 10 HP, 230V, 3 PH Spindle Speeds .................................. 70-8000 RPM Spindle Taper ............................................... CAT-40 Coolant pump .............................................. .025 HP T-slots ................................................................ 5/8" Boring capacity ........................................... 8.0" Dia. Milling capacity ........................................ 2.5 in3/min Maximum Workload ..................................... 850 lbs. Net weight ................................................. 3800 lbs. Packing dimensions ......................... 72" x 86" x 88" Shipping Weight ....................................... 4,400 lbs.


TW-40MCO ........................................18" x 59" ................................................40" ................................................ 20" ................................................ 22" ............................................. 22.5" ...................................3.54"-27.16" ........................ 10 HP, 230V, 3 PH ................................70-8000 RPM .......................................... CAT-40 ......................................... 0.25 HP ............................................... 5/8" ........................................ 8.0" Dia. ..................................... 2.5 in3/min ...................................... 1,320 lbs. ....................................... 6050 lbs. .............................. 79" x 76" x 98" ...................................... 6,700 lbs.

Phone:

1-800-521-5606

MODEL TW-40MCO

Fax:

1-800-322-4292

KBCTools.com

www.


High Precision Compact Machining Centers MODEL JM-450 (VERTICAL) FEATURES: • Anilam #6300M 3-Axis CNC Control. • 10 HP (peak) AC servo spindle motor. • 10 tool carousel Type ATC or 20 tool arm type ATC with 1.5 sec. tool change time. • Spindle RPM over-ride on control. • 60-9000 RPM without manual gear changes. • Fully ribbed massive cast iron frame for extra dampening during heavy cuts. • Direct coupled servo motors for ultra precision. • All AC digital servo motors (X, Y + Z) • CAT-40 taper spindle. • Precision linear ways on for smooth rapid traverse and high accuracy. • Full enclosure. • Auto lubrication unit with metered check valves. • Flood coolant (programmable M8) • Halogen work light. • Oversized precision ground ball screws.

machinery

MODEL JM-450 SHOWN

MODEL JH-450 (HORIZONTAL) FEATURES: • 7.5 HP (Peak) AC Digital Brushless Servo Spindle Motor, 30-Taper Spindle, 60-10,000 RPM • All AC Digital Brushless Servo Motors (X, Y, Z) • 14" x 22" Table • 17.7" x 13.8" x 13.8" Travels • Anilam 6300i 3-axis CNC control. • Conversational, G-code, or CAM • Up to 1180 ipm rapids; Accurate High Spped Machining Built in. • Auto lubrication system. • Halogen work light. • Flood coolant (programmable M8) and Full Enclosure. • 20 tool arm type ATC (BT-30)

SPECIFICATIONS: JM-450 (VERTICAL) JH-450 (HORIZONTAL) Table Size ........................................... 12" x 22" .................................. 14" x 22" Table Travel (X-Axis).................................. 17.8" ......................................... 17.8" Saddle Travel (Y-Axis) ............................... 13.8" ......................................... 13.8" Column Travel (Z-Axis) .............................. 13.8" ......................................... 13.8" Spindle Center to Column.......................... 12.8" ...................................... 6.5-20" Spindle to Table ................................ 4" – 17.8" ................................... 1.4–15" Spindle Motor (peak)............ 10 HP, 230V, 3 PH ................... 7.5 HP, 230V, 3PH Spindle Taper ......................................... CAT-40 ..................................... CAT-30 Speed Range .............................. 60-9,000 RPM ........................ 60-10,000 RPM Max. Work Load (Distributed)................ 330 lbs. .................................... 330 lbs. X, Y, + Z Axis Servo Motors .................... 1.9 HP ...................................... 1.3 HP Rapid Travel (X, Y & Z).......................1280"/min ................................. 1180"/min Min. Input Increment ............................ 0.00004" ..................................... 0.0001" Tool Storage Cap. ....... 10 (20 w/opt. ARM ATC) ............................................. 20 Max. Tool Dia. .............................................. 2.5" ........................................... 2.5" Max. Tool Length............................................. 6" .............................................. 6" Max. Tool Weight .................................... 6.6 lbs. ..................................... 6.6 lbs. Tool Change Time ..6 sec. (1.5 sec. w/opt. ATC) ....................................... 6 sec. Net Weight.......................................... 3,300 lbs. ................................. 4,413 lbs. Shipping Weight ................................ 3,900 lbs. ................................. 5,000 lbs.

Model JM-450 Vertical

Part No. 6-273-009L Our Net Price 00

$43,995

Model JH-450 Horizontal


$48,99500

FOR AS LITTLE AS

$993.41/mo.*

CALL FOR DETAILS


FOR AS LITTLE AS

$1,106.31/mo.*

CALL FOR DETAILS


High Precision Vertical Machining Center FEATURES: • Anilam 6300 3-Axis CNC control. • 33.5" x 20" x 20" Travels. • All AC Digital Brushless Servo Motors (X, Y, Z). • Up to 800 ipm rapids; Accurate high speed machining built in. • 20" x 39.4" Table • 15 HP (peak) AC Digital Brushless Servo spindle motor. • 20 tool ATC (Optional 20 tool Arm type ATC with 1.8 sec. tool change time.) • Spindle RPM over-ride on control. • 60-9000 RPM without manual gear changes. • Fully ribbed massive cast iron frame for extra dampening during heavy cuts. • Direct coupled servo motors for ultra precision. • Auto lubrication unit with metered check valves. • CAT-40 taper spindle. • Solid boxed ways. FEATURES: • Full enclosure. • All AC Digital Brushless Servo • Flood coolant with chip flush. Motors X, Y + Z • Halogen work light. • 15 HP Servo Spindle Motor • Ultra Precision ground ball screws. • 33.5" x 20" x 20" Travels • Axis positioning accuracy +/- 0.0002". • Axis repeatability +/- 0.0001". • 1,000 lbs. Table Load Capacity

• 20 Tool ATC - Full Enclosure

SPECIFICATIONS: Table Size .......................................................... 20" x 39.4" Table Travel (X-Axis).................................................... 33.5" Saddle Travel (Y-Axis) .................................................... 20" Column Travel (Z-Axis) ................................................... 20" Spindle Center to Column............................................... 21" Spindle to Table ..................................................... 4" – 24" T-slots (number x width) ....................................... 5 x 0.55" Coolant pump ........................................................... 1/4 HP Spindle Motor ............................................................ 15 HP Voltage/Phase ................................................... 230V, 3 PH Spindle Taper ........................................................... CAT-40 Speed Range............ 60-9000 RPM (12000 RPM Optional) Max. Work Load (Distributed)................................ 1000 lbs.

Phone:

1-800-521-5606

Fax:

X Axis .......................................................................... 2 HP Y Axis .......................................................................... 2 HP Z Axis ....................................................................... 3.3 HP Rapid Travel (X, Y & Z) ...........................................800"/min Min. Input Increment ................................................ 0.0001" Tool Holder ............................................................... CAT-40 Tool Storage Capacity ...................................................... 20 Max. Tool Diameter ...................................................... 3.15" Max. Tool Length............................................................. 10" Max. Tool Weight .................................................... 15.4 lbs. Tool Change Time ....6 sec./1.8 sec. with ATC Optional Arm Net Weight ............................................................ 9,900 lbs. Shipping Weight ................................................ 10,700 lbs.

1-800-322-4292

KBCTools.com

www.

Model JM-850S (Box Ways) Part No. 6-273-017 Our Net Price


$1,319.72/mo.*

CALL FOR DETAILS



1045

1046

machinery

• BANDSAWS

Horizontal Bandsaw

Horizontal/Vertical Bandsaw SPECIFICATIONS: Round Capacity at 90o ...................5" Rectangle Capacity at 90o.......5" x 6" Blade Size .....1/2" x 0.025" x 64-1/2" Blade Speeds (SFPM) ..80, 120, 200 Motor...................1/2 HP, 115V, 1 PH Net Weight ............................115 lbs. Shipping Weight .................. 150 lbs.

SPECIFICATIONS: Horizontal Capacity: Round .......................... 4-1/2" Rectangular .......... 4-1/4" x 6" Blade Size ......... 1/2" x 64-1/2" Speeds (3) .... 65/120/220 FPM Motor ......... 1/2 HP, 115V, 1 PH Net Weight .................. 120 lbs. Shipping Weight .......... 150 lbs.

STANDARD EQUIPMENT: • Vertical Worktable. • Carbon Steel Blade. • Adjustable Material Stop.

Extra Savings When You Tool Up Your Machine Now! 1/2" x 64-1/2" 10/TPI Carbon Blade Part No. 6-495-010B Our Net Price $9.10 Special Pricing † $8.19

Model HVBS-56M 5" x 6"

Extra Savings When You Tool Up Your Machine Now!

Model BAH-5


$26500

† Special pricing applies with purchase of machine.

1/2" x 64-1/2" 10/TPI Carbon Blade Part No. 6-200-032B Our Net Price $9.10 Special Pricing † $8.19


$37900


Horizontal/Vertical Bandsaw

Horizontal/Vertical Bandsaw FEATURES: • 7" round, 7" x 11" rectangular capacity. • Hydraulic feed control. • Built in coolant system. • 4 blade speeds. • 3/4" x 93" blade. • Portable - take this machine to the job and plug it in. • 3/4 HP, 115V, 1 phase. • Net weight 325 lbs. • Shipping weight 400 lbs.

Model BAH-712


Model HVBS-7MW 7" x 12"

$79500


FEATURES: • 7" round, 7" x 11" rectangular capacity. • Hydraulic feed control. • Built in coolant system. • 4 blade speeds. • 3/4" x 93" blade. • Portable - take this machine to the job and plug it in. • 3/4 HP, 115V, 1 phase. • Net weight 325 lbs. • Shipping Weight 400 lbs.

$94900 Extra Savings When You Tool Up Your Machine Now! 3/4" x 93" 8/TPI Carbon Blade Part No. 6-280-005B Our Net Price $13.10 Special Pricing † $11.79

OR LESS!



3/4" x 93" 8/TPI Carbon Blade Part No. 6-200-033B Our Net Price $13.10 Special Pricing † $11.79 † Special pricing applies with purchase of machine.

Horizontal Bandsaw FEATURES: • 9" round, 3" x 16" or 9" x 13" rectangular capacity @ 90o. • Hydraulic feed control. • Built in coolant system. • 4 blade speeds. • 1" x 129" blade. • 1-1/2 HP, 115/230V, 1 phase. • Net weight 625 lbs. • Shipping weight 800 lbs. Extra Savings When You Tool Up Your Machine Now! † Special pricing applies with purchase of machine.

Model BAH-916 Part No. 6-271-025 Our Net Price

$199500 Supplied with Box Rail Guide Arm

1" x 129" 10/TPI Carbon Blade Part No. 6-271-025B Our Net Price $18.55 Special Pricing † $16.70


Phone:

1-800-521-5606

Fax:

1-800-322-4292

KBCTools.com

www.

BANDSAWS •

Variable Speed 10" Miter Saw

Complete with Input & Output Roller Tables

machinery

1047

Model BAH-1018M-VS Part No. 6-280-015 Our Net Price


FEATURES: • 10" round, 10" x 16"or 6" x 18" rectangular capacity at 90o. • Miter design with swivel saw bow. • Hydraulic feed control. • Built in coolant system. • Variable blade speeds. • 1" x 136.8" blade. • 2 HP, 230/460V, 3 phase. • Net weight 995 lbs. • Shipping Weight 1,300 lbs.

$96.49/mo.*

CALL FOR DETAILS


Extra Savings When You Tool Up Your Machine Now! 1" x 136.8" 10/TPI Carbon Blade Part No. 6-280-015B Our Net Price $19.15 Special Pricing † $17.24

1" x 136.8" 4-6/TPI High Speed Blade Part No. 6-280-015HSB Our Net Price $62.10 Special Pricing † $55.89


®

Swivel Head Bandsaws

FEATURES: • Unique design features a swivel head for mitre cutting structurals, pipe and tubing. • Swivel head ranges from 90O to 45O, while the stock remains in the same position. • Large, easy-to-read scale for positioning saw head. • Quick-positioning vise lessens set-up time. • Large handwheel and built-in gauge for easy blade tensioning. • Coolant is distributed through the blade guides. • Full adjustable hydraulic downfeed with separate on/off valve.


$4,59900

OR LESS!

10" x 14" (3 Phase) Model MBS-1014W-3 Part No. 6-200-037 Our Net Price 00

$4,599

SPECIFICATIONS: MBS-1014W-1 Round Capacity at 90O .....................................10" O Round Capacity at 45 ......................................9" Rectangle Capacity at 90O .....................10" x 14" Rectangle Capacity at 45O .......................9" x 10" Blade Size................................1" x 0.032" x 130" Blade Wheel Speed (SFPM) ...82, 132, 210, 330 Motor (TEFC) ......................2 HP, 1 Phase, 230V ....................... Prewired 230V Net Weight ............................................1,067 lbs. Shipping Weight .................................. 1,400 lbs. Extra Savings When You Tool Up Your Machine Now! † Special pricing applies with purchase of machine.

*

10" x 14" (1 Phase) Model MBS-1014W-1

OR LESS!


FOR AS LITTLE AS

$105.78/mo.*

CALL FOR DETAILS


FOR AS LITTLE AS

$105.78/mo.*

CALL FOR DETAILS


MBS-1014W-3 ..........................................10" ............................................9" ................................10" x 14" ..................................9" x 10" ..................1" x 0.032" x 130" ..................82, 132, 210, 330 ......3 HP, 3 Phase, 230/460V ...............................1,067 lbs. ............................... 1,400 lbs.

1" x 130" 10/TPI Carbon Blade Part No. 6-200-036B Our Net Price $16.00 Special Pricing † $14.40

Roll-In® Horizontal Mitre Saw FEATURES: • Automatic shut-off. Frame Swings • Carbide guide inserts. 45O Either Way • Quick setting vise. For Mitre Cuts! • 3 Speed: 70/140/240. • Adjustable cast guide arms. • Cast iron blade wheels. • 4 roller conveyors to accommodate easy part loading (2 on each side). • Vise can be moved to either right or left side to accommodate the swivel position of the head to the part. • One year limited warranty, lifetime warranty on the frame and base. SPECIFICATIONS: Capacity - Round................................................................14" Model HS1418 Rectangular ......................................................13" x 18" Part No. 6-398-009 at 45O Round.............................................................12" Our Net Price at 45O Rectangular.............................................7" x 18" Blade Size ..................................................................1" x 166" 00 Blade Speeds (3) ....................................................70/140/240 Blade Wheel Diameter.........................................................14" Motor.................................................2 HP, 230/460V, 3 Phase Net Weight.................................................................1,400 lbs. Shipping Weight ...................................................... 1,600 lbs. FOR AS LITTLE AS $193.09/mo.* Extra Savings When 1" x 166" 4-6/TPI You Tool Up Your High Speed Blade CALL FOR DETAILS *60 month term, $1.00 BUYOUT Machine Now! Part No. 6-398-009HSB Our Net Price $75.45 † Special pricing applies Special Pricing † $67.91 with purchase of machine.

$8,395

Phone:

1-800-521-5606

Fax:

1-800-322-4292

Complete with Built-in Coolant System!

KBCTools.com

www.


machinery

1048

®

• BANDSAWS

13" x 21" Horizontal Bandsaw

* *WHEN DROP SHIPPED FROM JET

FEATURES: • 13" round or 13" x 21" rectangular capacity at 90°. • Hydraulic feed control. • Automatic frame raise at end of cut. • Infinetely variable blade speeds from 66-264 SFPM. • Carbide blade guides with rollers. • Built in coolant system. • 1-1/4" x 161-1/2" blade. • 3 HP, 230/460V, 3 Phase. • Net weight 1,276 lbs. • 2-year parts and labor warranty by JET.

STANDARD EQUIPMENT: • (1) 1-1/4" x 161-1/2" bi-metal blade • Built-in coolant system • Adjustable material stop • Manual & parts list

Model HBS-1321W Part No. 6-200-038 Our Net Price

SPECIFICATIONS: Round Capacity at 90O .....................................13" Round Capacity at 45° .................................. 13" Rectangle Capacity at 90° ................... 13" x 21" Rectangle Capacity at 45° ............. 13" x 15-1/2" Blade Size ................. 1-1/4" x 0.032" x 161-1/2" Blade Wheel Speed (var.) ............ 66-264 SFPM Motor (TEFC) ..................... 3 HP, 230/460v, 3PH Net Weight ........................................... 1,276 lbs. Shipping Weight .................................. 1,576 lbs.

$8,29900

OR LESS!

FOR AS LITTLE AS

$190.88/mo.*

CALL FOR DETAILS


Full Automatic Cycle Variable Speed Bandsaw FEATURES: • 10" round capacity. • 1" bi-metal blade. • Variable blade speeds. • 2 HP, 230/460V, 3PH motor. • Net weight 1,140 lbs.

Infinitely Variable Blade Speeds.

SPECIFICATIONS: Capacity - Round ........................................ 10" Round Solids ............................... 5" Rectangular ........................ 9" x 10" Auto Cycle Length of Cut min/max. ..... 1/2"/16" Blade Size ............................. 1" x .035" x 132" Main Drive Motor ..... 2 HP, 230/460V, 3 Phase Blade Speeds (Vari.) .................... 80-290 FPM Net Weight ........................................ 1,140 lbs. Shipping Weight ............................... 1,500 lbs.

Model BAH-1010AVS Part No. 6-280-025 Our Net Price 00

$8,495

Extra Savings When You Tool Up Your Machine Now! 1" x 132" 4-6/TPI High Speed Blade Part No. 6-280-025HSB Our Net Price $59.70 Special Pricing † $53.73

FOR AS LITTLE AS

$195.39/mo.*

CALL FOR DETAILS



Automatic Cycle Bandsaws FEATURES: • 12" or 15" round capacity. • Cast iron construction. • Full auto cycle. • 3 HP drive motor. • 1" bi-metal blade. • Net weight 1,800 or 2,200 lbs.

Model BS-12A

Model BS-15A



$8,79500

$10,69500

FOR AS LITTLE AS

FOR AS LITTLE AS

$245.99/mo.*

$202.29/mo.*

CALL FOR DETAILS


CALL FOR DETAILS


SPECIFICATIONS: BS-12A BS-15A Capacity (90°O Only) Round .......................12" .................................................. 15" Capacity (90 Only) Square ....................... 9" .................................................. 14" Rectangular ................................................. 5" x 13" .......................................... 6" x 16" Minimum Length of Cut ...................................... 1/2" ................................................. 1/2" Blade Size .................................................. 1" x 150" ........................................ 1" x 168" Main Drive Motor ................... 3 HP, 230/460V, 3 PH ................... 3 HP, 230/460V, 3 PH Blade Speeds (6) .. 45, 75, 90, 120, 150, 240 SFPM ... 47, 80, 95, 127, 158, 250 SFPM Net Weight ................................................ 1,800 lbs. ....................................... 2,200 lbs. Shipping Weight ....................................... 2,000 lbs. ....................................... 2,500 lbs.

MODEL BS-15A

These machines are fully automatic, simply preset the number of cuts, adjust the stock feed for the desired length of the cut and this saw will repeat the automatic cycle and switch to off when finished or when the stock is exhausted.


Phone:

Extra Savings When You Tool Up Your Machine Now! † Special pricing applies with purchase of machine.

1-800-521-5606

Fax:

1" x 150" 4-6/TPI High Speed Blade Part No. 6-275-007HSB Our Net Price $66.85 Special Pricing † $60.17

1-800-322-4292

1" x 168" 4-6/TPI High Speed Blade Part No. 6-275-009HSB Our Net Price $73.95 Special Pricing † $66.56

KBCTools.com

www.

BANDASAWS •

machinery

1049

Vertical Bandsaws MODEL BAV-360

MODEL BAV-450

BAV-360 Part No. 6-395-025 Our Net Price

$2,72500

MODEL BAV500WF

BAV-500WF with weight feed attachment

BAV-450 Part No. 6-395-027 Our Net Price


$3,14500

$5,29500

FOR AS LITTLE AS

FOR AS LITTLE AS

$72.34/mo.*

$121.79/mo.*

CALL FOR DETAILS

CALL FOR DETAILS



FEATURES: • Quality construction - all models are built on a solid cast iron frame. Cast iron blade Variable Speeds wheels with rubber tires for traction are mounted on shafts with taper roller bearings. Built-in Blade Welder • Large cast iron work tables tilt R & L and F & B. • Infinitely variable speed on all models. This allows you to select the most efficient speed (FPM) for each piece quickly and easily. • All models come complete with a built-in blade welder SPECIFICATIONS: Model BAV-360 Model BAV-450 Model BAV-500WF with grinder wheel, worklight and blade shear that will Table Size................................................ 22" x 20" .................22-1/4" x 19-5/8" .................29-1/8" x 26-3/4" weld blades up to the saw capacity. Table Tilt • Fully adjustable blade guide for workpieces of Degrees R & L................................................ 15 ........................................15 ........................................15 varying thicknesses. With hardened blade guides. Degrees F & B.................................................. 8 ........................................15 ........................................15 An adjustable carbide face pad backs up the blade. Table Height...................................................... 39" .......................................38" .......................................39" Extra Savings When You Tool Up Your Machine Now! Cutting Capacity Width ............................................................. 14" .......................................18" .......................................20" SPECIAL † Our Item Part No. Net Price PRICING! Thickness ........................................................ 7" .......................................10" .................................14-1/2" Blade Width ............................................ up to 1/2" .............................1/8"- 5/8" ................................1/8"- 1" 6-395-025B $11.90 Carbon Flexback Welded $10.71 Band 3/8" x 119-1/2" 10/TPI Blade Length ............................................ 119-1/2" ..............................140-1/2" ..............................159-1/2" Motor.............................. 1 HP, 115/230V, 1 Phase ....1 HP, 115/230V, 1 Phase ....2 HP, 230/460V, 3 Phase 6-395-027B 16.50 Carbon Flexback Welded 14.85 Band 1/2" x 140-1/2" 10/TPI Cutting Speeds FPM (Inf. Variable)...... 82 to 413 . ..............................82 to 384 ...............................82-1496 Dimensions (HxWxD)..................... 64" x 21" x 37" ............. 80" x 27-1/2" x 44" ....................78" x 32" x 46" 6-396-015B 20.70 Carbon Flexback Welded 18.63 Band 3/4" x 159-1/2" 8/TPI Net Weight ................................................ 730 lbs. ...............................836 lbs. ............................1,320 lbs. Shipping Weight ....................................... 850 lbs. ........................... 1,000 lbs. ........................... 1,500 lbs. † Special pricing applies with purchase of machine.

®

Roll-In® Gravity Feed Saw

Self-Feed Vertical Bandsaw

FEATURES: • Accurate gravity feed with hydraulic speed control and depth stop. • 4 blade speeds to select from. • Accepts blades from 1/4" - 3/4" wide. • Rugged simple construction for easy maintenance and long service life.

FEATURES: • Swivel vise for mitering. • Four blade speeds (70, 140, 280, 580) sfpm. • Hydraulic feed control.

Model VSF14

SPECIFICATIONS: Capacity under guide ............... 14-1/2" Throat ......................................... 8-3/4" Maximum Blade Travel ..................... 9" Table Size ....................... 18-1/2" x 30" Blade Size ................ 1/4" - 3/4" x 120" Blade Speeds .. 70/140/270/525 SFPM Motor .................. 1 HP, 115/230V, 1PH Net Weight .............................. 585 lbs. Shipping Weight ...................... 700 lbs.


$2,49900 Extra Savings When You Tool Up Your Machine Now! 1/2" x 120" 10/TPI Carbon Blade Part No. 6-200-047B Our Net Price $12.25 Special Pricing † $11.03

Model EF


$3,69500

SPECIFICATIONS: Height Capacity..........................14-1/2" Throat Capacity............................8-1/2" Table Size ...................18-1/2" x 30-1/2" Blade Width ...................................1/8-1 Floor Space Req. ..40" x 30-1/2" x 63" Motor .......1 HP, 1 PH 115/230V, 60 Hz Net Weight ................................551 lbs. Shipping Weight ...................... 675 lbs.

Phone:

1-800-521-5606

FOR AS LITTLE AS


$84.99/mo.* CALL FOR DETAILS



1/2" x 120" 10/TPI Carbon Blade Part No. 6-398-005B Our Net Price $12.25 Special Pricing † $11.03


Fax:

1-800-322-4292

KBCTools.com

www.


1050

machinery

• BANDSAWS With Power Table Feed Variable Speeds Blade Welder

Vertical Bandsaws

MODEL BAV-500PF

MODEL BAV-700PF

FEATURES: • Built on cast iron frames with heavy duty construction throughout. • Use heavy cast iron blade wheels with rubber tire liners for traction and quiet operation. • Reinforced cast iron tables. • Standard with variable electric power table feed, 12-1/2" travel. • Infinitely variable blade speeds so you can select the most efficient cutting speed for a wide variety of materials. • Built-in blade welder (Capacity 5/64" - 1") with work light and grinding wheel. • Complete with built-in blade welder, variable blade speeds, worklight, chipblower, and power table feed.

Model BAV-500PF With Variable Electric Table Power Feed


$5,79500 Extra Savings When You Tool Up Your Machine Now! † Special pricing applies with purchase of machine.

FOR AS LITTLE AS



3/4" x 159-1/2" 8/TPI Carbon Flexback Welded Band* Part No. 6-396-025B Our Net Price $18.95 Special Pricing † $17.06

Model BAV-700PF With Variable Electric Table Power Feed


$6,09500

FOR AS LITTLE AS



SPECIFICATIONS Model BAV-500PF Model BAV-700PF Table Size...................................................26-3/4" x 29-1/8"............................................26-3/4" x 29-1/8" Table Tilt (R & L) .................................................................5.....................................................................5 Table Stroke (power) ................................................12-1/2" ...........................................................12-1/2" Table Feed Rate.....................................................0-5 ft/min........................................................0-5 ft/min Cutting Capacity Width ..............................................................................20" .................................................................28" Thickness ................................................................12-7/8" ...........................................................12-5/8" Cutting Speeds (FPM) .............................................82-1496 .........................................................65-1292 Blade Width .................................................................1/8-1" .............................................................1/8-1" Blade Length............................................................159-1/2" ...............................................................161" Motor.............................................2 HP, 230/460V, 3 Phase ..............................2 HP, 230/460V, 3 Phase Net Weight.............................................................1,386 lbs. ......................................................1,606 lbs. Shipping Weight ................................................... 1,650 lbs. ......................................................1,950 lbs.

Roll-In® Vertical Tilt Frame Bandsaw FEATURES: • Large 14" x 20" cutting capacity at 90°, 14" x 13" at 45°. • Infinitely variable blade speeds from 50-400 ft/min via A.C. inverter speed control - full motor torque through entire speed range! • Infinitely variable feed from 0-150 lbs. (via. air/hydraulic system). • Tilt frame design enables you to make angle cuts without having to move the stock.

Roll-In® Extra-Deep Throat Vertical Saw

SPECIFICATIONS: Capacity at 90°............................. 14" x 20" Capacity at 45° (R or L) ............... 14" x 13" Table ................................ 31-1/2" x 25-1/2" Vise Max. Opening ................................ 20" Height of Vise Jaws................................. 6" Blade Speeds Infinitely Var. .. 50-400 ft/min Blade Size .................................... 1" x 160" Feed Pressure Var. .................... 0-150 lbs. Drive Motor .............. 2 HP, 230/460V, 3 PH Floor Space.................................. 60" x 66" Overall Height........................................ 80" Shipping Weight .......................... 1,300 lbs.

Model DT-1340 Part No. 6-398-012 Our Net Price

$7,29500

Model TF-1420 Part No. 6-398-006 Our Net Price

FOR AS LITTLE AS

$167.79/mo.*


$11,19500


FOR AS LITTLE AS

$257.49/mo.*


Extra Savings When You Tool Up Your Machine Now! † Special pricing applies with purchase of machine.

1" x 160" 10/TPI Carbon Flexback Welded Band Part No. 6-398-006B Our Net Price $21.65 Special Pricing † $19.49


1" x .035" x 160" 4-6/TPI High Speed Blade Part No. 6-398-006HSB Our Net Price $71.60 Special Pricing † $64.44

Phone:


FEATURES: • Extra large capacity 40" throat. • Variable blade speeds 70-500 SFPM. • Adjustable blade guides accept 1/4" - 3/4" blade widths. • Ridgid welded steel frame. • Big 24-1/4" x 51-1/4" precision ground steel worktable. • Aluminum blade wheels with urethane rubber "tires."

1-800-521-5606

Fax:

3/8" x 181" 10/TPI Carbon Blade Part No. 6-398-012B Our Net Price $21.70 Special Pricing † $19.53

SPECIFICATIONS: Capacity under guide .................................. 13" Throat .......................................................... 40" Table size .............................. 24-1/4" x 51-1/4" Table till (JM-1220) ......................... 15OR, 10CL Table height ................................................ 39" Blade size ..................................... 3/8" x 15'-1" Blade speed infinitely variable ... 70-500 SFPM Drive motor .............. 2 HP, 230/460V, 3 Phase Dimensions ...................... 30"H x 76"W x 30"D Shipping Weight ............................... 1,200 lbs.

1-800-322-4292

KBCTools.com

www.

BANDSAWS •

Vertical Bandsaws for Wood Cutting

machinery

1051

Vertical Bandsaws

MODEL WS-14

FEATURES: • Cuts wood, plastics, brass, aluminum & other non-ferrous materials. • 1/4" - 1" blade capacity. • Cast iron table with rip fence & mitre gauge. • Cast iron blade wheels with rubber “tires”. • Magnetic switch for on/off. • Heavy duty blade guides w/carbide side guides & ball bearing backup.

FEATURES: Both Models • One piece cast iron table tilts 10° L 45° R. • Complete with motor & controls, floor stand and mitre gage. NOTE: Some assembly required. FEATURES: Model WS-14 • Top blade wheel has an adjustable slide bracket type blade tension regulator.

Model NFS-450

FEATURES: Model WS-18 • Accepts blades from 1/8" - 1-1/2" wide. • Powerful 1-1/2 HP motor gets the job done fast. • Low voltage magnetic switch control.


$2,39500

Model WS-14 Part No. 6-800-003 Our Net Price

FOR AS LITTLE AS

Model NFS-600 Part No. 6-398-030 Our Net Price

$24900

$3,59500



Model WS-18 Part No. 6-800-010 Our Net Price

For Non-Ferrous Metals and Wood Cutting

00

$745

SPECIFICATIONS: Model WS-14 Model WS-18 Table Size........................................... 14" x 14" .................................... 18" x 18" Table Tilt ......................................... L 10° R 45°.................................... L 10° R 45° Cutting Capacity Width.....................................................13-3/4".............................................. 18" Thickness .............................................. 5-1/2".......................................... 9-1/2" Blade Size ......................................... 1/2" x 93"..................... 1/8" - 1-1/2" x 124" Motor ........................... 3/4 HP, 115/230V, 1 PH .......... 1-1/2 HP, 115/230V, 1 PH Range Of Speeds (3)................ 2420/1230/700 ............................... 280/420/680 Dimensions (LxWxH) ................ 20" x 25" x 65" ........................... 21" x 15" x 72" Net Weight (approx.) ............................ 174 lbs. ...................................... 319 lbs. Shipping Weight .................................. 240 lbs. ..................................... 400 lbs.

®

14" Wood/Metal Vertical Bandsaw

Exclusive gear box design allows wood/metal model saws to be used for a wider variety of metal, wood, non-ferrous metal and plastic cutting applications.

.....492/984/1410/4264 ........ 19-5/8" x 27-1/2" ........................ 0 - 45° ........................ 37-3/8" ........................... 2 HP ..... 230/460V, 3 Phase ................... 1,100 lbs. ................... 1,300 lbs.

1/2" x 170" 10/TPI Carbon Flexback Welded Band Part No. 6-398-030B Our Net Price $21.55 Special Pricing † $19.40 † Special pricing applies with purchase of machine.

14" Bandsaw

FEATURES: • Precision ground cast iron table. • Cast iron frame & wheels. • Deluxe extruded aluminum fence and rails. • Ball bearing blade guides. • Cabinet type stand (full storage). • Quick change blade release/tensioning.

Model J-8201K Part No. 6-200-J8201K Our Net Price

$99900 SPECIFICATIONS: Under Guide .................................................... 6" Under Guide with Riser Block ....................... 12" Throat Depth ........................................... 13-1/2" Blade Size ........................ 3/8" x .025" x 92-1/2" Cutting Speeds Wood ..................... 3,300 SFPM Cutting Speeds Metal ..... 39, 57, 78, 107, 142, 196, 278 SFPM Table Tilt to Right .......................................... 45° Table Tilt to Left ............................................. 15° Table Height at 90° ........................................ 68" Table Size ............................................. 14" x 14" Miter Gauge Groove .......................... 3/4" x 3/8" Motor ................... 1 HP, 115V, 1 PH, 1,725 RPM Floor Space Required ................. 20" x 16" x 68" Net Weight ............................................. 280 lbs. Shipping Weight ..................................... 300 lbs.

1-800-521-5606

NFS-600 ........................ 23-5/8" ........................ 11-3/4" ...................... 1/4" - 1" ............................ 170"

3/8" x 145" 10/TPI Carbon Flexback Welded Band Part No. 6-398-025B Our Net Price $16.80 Special Pricing † $15.12

Many features only found on much larger and more expensive machines. Features, miter gauge, hinged wheel covers, and 4" dust port. This bandsaw will be a reliable shop fixture for many years to come.

FEATURES: • Cast iron frame. • Solid, one-piece steel base for extra stability. • Conveniently located on/off switch. • 2 Year Warranty.

Phone:

SPECIFICATIONS: NFS-450 Cutting Width ................ 17-3/4" Cutting Height ............... 11-3/4" Blade Size ................... 1/4" - 1" Blade Length..................... 145" Cutting Speeds FPM-4 ..........492/984/1410/4264 Table Size............ 19-5/8" x 22" Table Tilt ........................ 0 - 45° Table Height.................. 36-5/8" Drive Motor ................... 1.5 HP Voltage ........115/230V, 1 Phase Net Weight................... 671 lbs. Shipping Weight ......... 850 lbs.


Fax:

Model W1706 Part No. 6-397-W1706 Our Net Price

$54900 SPECIFICATIONS: Motor ....... 1 HP, single-phase, TEFC, 1725 RPM Voltage .................................................. 115/230V Blade Size ................... 93-1/2" (1/8" to 3/4" wide) Table Size ................................. 14" x 14" x 1-1/2" Max. Cutting Height .......................................... 6" Table Tilt .................................... 45O right, 10O left Blade Speeds ......................... 1500 & 3200 RPM Shipping Weight ....................................... 256 lbs

1-800-322-4292

KBCTools.com

www.


1052

machinery

• SAWS

Heavy Duty 16" Cut-Off Saw

®

FEATURES: • Self-centering vise has dual jaws for burr-free cuts. • Sturdy oil bath gear box design. • Magnetic starter wtih overload protection. • Cutting head swivel up to 45° for miter cuts. • Control handle has built-in spring loaded trigger switch. • 2 year warranty.

J-F225 Coldsaw

FEATURES: • Heavy-duty cast iron frame upper and lower. • 5 HP, 230/460V, 3 Phase motor, Prewired 230V. • 16" x 1" bore abrasive wheel. • 2" capacity solid bar, 3" pipe. • Vise swivels to 45O. • 3000 RPM spindle. • Net weight 210 lbs. • Shipping weight 350 lbs.

SPECIFICATIONS: Motor .................. 1 HP, 115V, 1 PH Blade Speed ..................... 52 RPM Blade Size ........................ 225 mm Round @ 90° ....................... 2-1/2" Round @ 45° ............................. 2" Square @ 90° ...................... 2-1/4" Net Weight .......................... 84 lbs. Shipping Weight ................ 100 lbs.

Model COS-16 Part No. 6-100-010 Our Net Price

$54900

Model J-F225 Part No. 6-200-JF225 Our Net Price


$84900

16" x 5/32" x 1" CGW General Purpose Reinforced Cut-Off Wheel Part No. 1-602-35584 Our Net Price $13.70 † Special pricing applies Special Pricing † $12.33 with purchase of machine.

®

Non-Ferrous High Speed Manual Cold Saw

FEATURES: • Mitering capabilites - stops at 90°, 45° left and 45° right. • Double self-centering vise for burr-free cuts. • Two cutting speeds. • Includes one high speed NF 350mm blade. • 2 year warranty. SPECIFICATIONS: Cutting Capacity for Tubing: Round at 90° (in.) .................. 4-1/2" Round at 45° (in.) .................. 3-1/2" Square at 90° (in.) ...... 4-1/4 x 4-1/4 Square at 45° (in.) ...... 3-1/2 x 3-1/2 Rectangle at 90° (in.) .. 5-1/2 x 3-3/4 Rectangle at 45° (in.) .. 3-1/2 x 3-1/2 Cutting Capacity for Solid: Round at 90° (in.) .......................... 3 Round at 45° (in.) .................. 2/1/02 Square at 90° (in.) ................... 3 x 3 Square at 45° (in.) ...... 2-1/2 x 2-1/2 Blade size (mm) ............ 350 x 32 x 3.4 Blade Speeds 1,750 RPM, 3,500 RPM Maximum Vise Opening ................... 6" Motor ........................ 2 HP, 230V, 3 PH Net Weight .............................. 683 lbs. Shipping Weight ...................... 850 lbs.

®

FEATURES: • Sturdy gear box design. • Manually cuts from 45° left to 45° right. • Miter stops at 90°, 45°, and 45° right. • Double self-centering vise for burr-free cuts. • Two cutting speeds. • Includes one high speed 350mm blade. • 2 year warranty. SPECIFICATIONS: Cutting Capacity for Tubing: Round at 90° (in.) .................. 4-1/2" Round at 45° (in.) .................. 3-1/2" Square at 90° (in.) ...... 4-1/4 x 4-1/4 Square at 45° (in.) ...... 3-1/2 x 3-1/2 Rectangle at 90° (in.) .. 5-1/2 x 3-3/4 Rectangle at 45° (in.) .. 3-1/2 x 3-1/2 Cutting Capacity for Solid: Round at 90° (in.) .......................... 2 Round at 45° (in.) .................. 1/3/04 Square at 90° (in.) ................... 2 x 2 Square at 45° (in.) ...... 1-3/4 x 1-3/4 Blade size (mm) ............ 350 x 32 x 2.5 Blade Speeds .......... 44 RPM, 88 RPM Maximum Vise Opening ................... 6" Motor ........................ 2 HP, 230V, 3 PH Net Weight .............................. 794 lbs. Shipping Weight ...................... 925 lbs.

Model CK350-2K

Model FK350-2K

Part No. 6-200-CK350 Our Net Price

Part No. 6-200-FK350 Our Net Price

$3,99500

$4,19500

FOR AS LITTLE AS

FOR AS LITTLE AS

$91.89/mo.*

$96.49/mo.*

CALL FOR DETAILS

CALL FOR DETAILS



6400 Shark Hunter Mako™

SMOKE / GRAY

FEATURES: • Contemporary Design offers a universal fit. • Lightweight lens/frame combination eliminates the need for replacement lenses. • Features a 10-base single curve lens. • Meets ANSI Z87.1 standards. • Available in a True View lens. • 100% U.V. Protection.


Ferrous Manual Cold Saw

SMOKE / CLEAR

SMOKE / CLEAR POLYNIUM PLUS Description (Frame / Lens)

SMOKE / TRUVIEW CLEAR

Phone:

1-800-521-5606

Smoke Smoke Smoke Smoke

Fax:

/ / / /

Clear Gray Trueview Clear Polynium Plus

1-800-322-4292

Part No. 1-709-

Our Net Price

-055 -060 -065 -070

$3.10 3.65 4.15 3.75

KBCTools.com

www.

SURFACE GRINDERS •

Surface Grinding Machine

1053

STANDARD EQUIPMENT: • Cabinet Floor Stand. • Grinding Wheel & Wheel Mount. • Toolbox With Tools. • Manual & Parts List.

FEATURES: • Wheel spindle travel by precision lead screw for accuracy and reliability. • Uses standard 7" x 1/2" x 1-1/4" surface grinding wheels. • Roller ball table ways for smooth and easy operation. • Includes cabinet floor stand as pictured. • At this price every shop can afford the convenience of having their own surface grinder.

Model SG-612


$2,79500

SPECIFICATIONS: Table Working Surface............................................ 6" x 12" Max. Longitudinal Travel .......................................... 12-5/8" Max. Cross Travel ...................................................... 6-5/8" Max. Distance Spindle to Table...................................... 11" Spindle Motor................................. 3/4 HP, 115/230V, 1 PH Spindle Speeds ................................................. 3,450 RPM Wheel Size ............................................... 7" x 1/2" x 1-1/4" Vertical Handwheel Graduations................................ 0005" Crossfeed Handwheel Graduations ............................ .001" Net Weight .............................................................. 550 lbs. Shipping Weight with stand ................................... 700 lbs.


Part No.

6" x 12" Magnetic Chuck 6" x 12" Magnetool® Mag. Chuck

9-600-612 8-302-050

Our Net Price

$269.00 810.00

Comes Complete with Cabinet Floor Stand!

Surface Grinding Machine FEATURES: • Ultra high column with maximum 21" spindle to table. • Roller ways for smooth effortless table travel. • Double "V" saddle ways, H-frame column design and heavyweight construction gives this machine exceptional rigidity. • Cartridge spindle with ABEC-7 precision spindle bearings. • Oversize spindle housing and flange mount design allows heavier grinds than with other similar size machines. • Complete with full coolant system, 6" x 18" permanent magnetic chuck, grinding wheel and wheel mount.

STANDARD EQUIPMENT: • 6" x 18" Magnetic Chuck • Complete Coolant System • Grinding Wheel & Wheel Mount • Balancing Base & Arbor • Table Mount Diamond Dresser • Leveling Pads • Toolbox With Tools • One Shot Lube System

Model KGS-618M SPECIFICATIONS: Table Working Surface ........................... 6" x 18" Max. Table Travel....................... 8-1/2" x 19-1/2" Max. Distance Spindle to Table..................... 21" Max. Grinding Wheel Size ....... 8" x 3/4" x 1-1/4" Spindle Speed .................................. 3,450 RPM Spindle Motor.................................... 2 HP, 3 PH Voltage........................................................ 230V Downfeed Handwheel Per Rev. ............... .050" Downfeed Handwheel Per Grad. .......... .0002" Crossfeed Handwheel Per Rev. ................ .100" Crossfeed Handwheel Per Grad. ............ .0005" Net Weight .......................................... 2,250 lbs. Shipping Weight ................................. 2,500 lbs.

machinery

FOR AS LITTLE AS

Part No. 6-273-003 Our Net Price 00

$6,295

Now with 8-1/2" x 19-1/2" Table Travel! 21" Spindle To Table!

$144.79/mo.*

CALL FOR DETAILS


GET THIS MACHINE COMPLETE WITH OPTIONAL DIGITAL READOUT SYSTEM INSTALLED! Our Net Price

Description

Part No.

Z Axis Mitutoyo DRO Y & Z Axis Mitutoyo DRO Z Axis Newall DRO Y & Z Axis Newall DRO

6-273M-003Z 6-273M-003YZ 6-273N-003Z 6-273N-003YZ

$1250.00 1865.00 1450.00 2065.00

Surface Grinding Machine with Z-Axis Rapid Traverse FEATURES: • Precision cartridge type spindle with ABEC class 7 angular ball bearings. • 1-1/2 HP, V-3 Grade spindle motor. • One piece cast base for rigidity and maximum absorption of vibration. • Double "V" saddle ways for tight tolerance work. • High column gives 18" spindle to table capacity. • Alloy steel slide ways with precision steel roller balls for smooth and easy traverse of the table. • Power rapid elevation of spindle eliminates tedious cranking of head into position.

Model SGS-816R Part No. 6-273-006 Our Net Price

$7,99500

MODEL SGS-816R Shown With Optional Overhead Dresser

Comes With Rapid Power Elevation!

FOR AS LITTLE AS

$183.89/mo.*

SPECIFICATIONS: Table Working Surface........................... 6-1/4" x 16" Max. Table Travel......................................... 8" x 17" Max. Distance Spindle to Table .......................... 18" Grinding Wheel Size ...................... 8" x 1/2" x 1-1/4" Spindle Speed ........................................ 3,500 RPM Spindle Motor....................................... 1.5 HP, 3 PH Voltage ...................................................... 230/460V Downfeed Handwheel Per Rev. ........................ 0.1" Downfeed Handwheel Per Grad. .................... .001" Downfeed Handwheel Microfeed .................. .0001" Crossfeed Handwheel Per Rev. ........................ 0.2" Crossfeed Handwheel Per Grad. .................... .001" Crossfeed Handwheel Per Vernier Scale....... .0001" Net Weight ................................................ 1,430 lbs. Shipping Weight ....................................... 1,600 lbs.

CALL FOR DETAILS



6" x 12" Magnetic Chuck 8" x 15" Magnetool® Mag. Chuck Coolant System Overhead Parallel Dresser Extra Wheel Flange Z Axis Mitutoyo DRO Y & Z Axis Mitutoyo DRO Z Axis Newall DRO Y & Z Axis Newall DRO

Phone:

Part No.

9-600-618 8-302-113 6-273-005A 6-273-005B 6-273-005C 6-273M-005Z 6-273M-005YZ 6-273N-005Z 6-273N-005YZ

1-800-521-5606

Fax:

STANDARD EQUIPMENT: • Wheel Balancing Base & Arbor • 1 Pc. Grinding Wheel & Wheel Mount • Worklight • One Shot Lubrication • Power Rapid Elevation • Complete Low Voltage Electrics • Toolbox With Tools • Manual & Parts List

Our Net Price

$379.00 1195.00 485.00 485.00 75.00 1125.00 1725.00 1325.00 1925.00

1-800-322-4292

KBCTools.com

www.


1054

machinery

• SURFACE GRINDERS

3-Axis Automatic Surface Grinding Machine

Complete with 8" x 20" Magnetic Chuck & Flood Coolant System!

FEATURES: • 10" x 20" capacity. • 3 axis automatic with incremental downfeed and electronic auto crossfeed. • 3 HP, 3 PH spindle motor. • Automatic lubrication. • 8" x 1" x 1-1/4" wheel. • Net weight 3,696 lbs. • Heavy cast iron base absorbs vibration. • Roller ways for table travel. • Precision cartridge type direct drive spindle. • Use full automatic mode or manual.

STANDARD EQUIPMENT: • 8 x 20 Magnetic Chuck • Flood Coolant System • Grinding wheel • Wheel flange • Wheel balancing base • Wheel balancing arbor • Diamond table dresser base and tip • Leveling bolts and pads • Work light • Toolbox with tools

Model KGS-1020AHD Part No. 6-273-012 Our Net Price

FOR AS LITTLE AS

$328.79/mo.*

SPECIFICATIONS: Table travel ................................................... 23.6" Saddle travel ................................................. 11.4" Spindle motor/phase ............................ 3 HP, 3PH Voltage ................................................... 230/460V Spindle speed ...................................... 3500 RPM Grinding wheel .............................. 8" x 1" x 1-1/4" Vertical graduation .................................... 0.0005" Vertical revolution ....................................... 0.100" Auto downfeed increment .......... 0.0001" 10 steps Spindle center to table ..................................... 21" Machine net weight ............................... 3,696 lbs. Shipping Weight .................................... 4,300 lbs.

CALL FOR DETAILS

$14,29500



Part No. 6-273-

Our Net Price

Kanetsu 10 x 20 electric chuck & control Paper filter & magnetic separator coolant system Extra wheel flange DRO system (Acu-Rite 2-axis, 12x18) Overhead parallel dresser.

-012A -012B -012C -012D -012E

$4695.00 2350.00 75.00 2750.00 485.00

3-Axis Auto Feed Surface Grinding Machine

SPECIFICATIONS: Max. Table Travel ........................................... 10" x 20-1/2" Max. Distance Spindle to Table ............................... 19-1/2" Grinding Wheel Size ................................ 8" x 1/2" x 1-1/4" Spindle Speed.................................................... 3500 RPM Spindle Motor/Hydraulic Motor.................................... 2 HP Voltage/Phase ............................................ 230/460V, 3 PH Manual Downfeed Per Vernier.................................. .0001" Manual Crossfeed Per Vernier Scale ....................... .0001" Automatic Longitudinal Feed (var. hyd.) ........... 16-80 FPM Automatic Cross Feed (var. elec.) ............................. 0-5/8" Auto Down Feed Increments ................................... .0001" Net Weight ...........................................................2,900 lbs. Shipping Weight ................................................. 3,400 lbs.

FEATURES: • 10" x 20" capacity. • Precision cartridge type spindle with ABEC class 7 angular ball bearings. • 2 HP, V-3 Grade spindle motor. 3-axis auto-feed. • Double vee saddle ways for tight tolerance work. • One piece cast base for rigidity and maximum absorption of vibration. • “V” and flat Turcite® ways for smooth longitudinal travel. • Solid state variable automatic crossfeed. • High column gives 19-1/2" spindle to table capacity. • Variable hydraulic table traverse. • Automatic lubrication.

Model SGS-1020AHD


$17,45000

STANDARD EQUIPMENT: • 8" x 19.6" Permanent Magnetic Chuck • Combination DustSuction/Coolant System • Overhead Parallel Dresser • Wheel Balancing Base & Arbor • Grinding Wheel & Wheel Mount • Automatic Lubrication • Diamond Wheel Dresser • Work light • Toolbox With Tools • Manual & Parts List

FOR AS LITTLE AS

$401.35/mo.*

CALL FOR DETAILS

*60 month term $1.00 BUYOUT

OPTIONAL EQUIPMENT Part No.

Our Net Price

6-273-010C 6-273M-010Z 6-273M-010YZ 6-273N-010Z 6-273N-010YZ

$75.00 1125.00 1995.00 1325.00 2195.00

Description

Extra Wheel Flange Z Axis Mitutoyo DRO Y & Z Axis Mitutoyo DRO Z Axis Newall DRO Y & Z Axis Newall DRO

Complete with Chuck, Overhead Dresser & Dust/Suction Coolant System!

ABILITY

FLAMM

FEATURES: • The best choice in all dedicated grinding applications. HEALTH • Specially formulated for high coolant flow operations when low foaming is critical. SPECIFIC • Formula has been enhanced to improve tool finish and provide superior rust protection. • Does not interfere with magnetic 1 Gallon Bottle chucks, and is clear and clean allowing greater visibility of your work piece. Part No. 1-123-060 • Biodegradeable and exhibits excellent Our Net Price safety with ease of disposal. Must 65 comply with local regulations.

GRINDZAL™ PURE SYNTHETIC GRINDING COOLANT.

REACTIVITY

HAZARD

5 Gallon Pail


$7940

$16


Phone:

1-800-521-5606

Fax:

1-800-322-4292

KBCTools.com

www.

SURFACE GRINDERS •

machinery

1055

3-Axis Auto Feed Surface Grinders FEATURES: • 3-axis automatic feed, machine will automatically grind to a preset size. • Precision cartridge type spindle with ABEC class 7 angular ball bearings for maximum accuracy and long, trouble free operation. • Extra wide double "V" saddle ways lined with turcite for smooth travel and long life. Holds tight tolerances even when side grinding. • Automatic lubrication system for easy maintenance and extended machine life. • One piece cast base for rigidity and maximum absorption of vibration. • Solid state electric control for variable electric cross feed. • Rapid spindle travel up/down. STANDARD EQUIPMENT SGS-1230AHD: • Combination DustSuction/Coolant System • 12" x 30" Electro-Magnetic Chuck • Variable Power Chuck Control • Overhead Parallel Dresser

STANDARD EQUIPMENT SGS-1640AHD: • Magnetic Separator & Paper Filter Coolant System • 16" x 40" Electro-Magnetic Chuck • Variable Power Chuck Control • Overhead Parallel Dresser

Model SGS-1230AHD Part No. 6-273-020 Our Net Price 00

$21,995

FOR AS LITTLE AS

$505.89/mo.*

CALL FOR DETAILS


Model SGS-1640AHD Part No. 6-273-025 Our Net Price

$33,99500

MODEL SGS-1640AHD

FOR AS LITTLE AS

$767.61/mo.*

CALL FOR DETAILS


3 Axis Auto Feed Surface Grinders

SPECIFICATIONS: MODEL 1230AHD MODEL 1640AHD Table Size ............................................................... 10-1/4" x 32" .....................................16" x 40" Max. Table Travel ..............................................13-1/2" x 31-3/4"...............................17-3/4" x 43" Max. DIstance Spindle to Table ........................................23-1/2" ..............................................23" Max. Grinding Wheel Size..................................14" x 1-1/4" x 5" ...............................14" x 2" x 5" Spindle Speed .............................................................1750 RPM ..................................1750 RPM Spindle Motor .......................................................................5 HP .....................................7-1/2 HP Voltage/Phase .....................................................230/460V, 3 PH ..........................230/460V, 3 PH Manual Downfeed Per Vernier....................................... .00005" ......................................000025" Manual Crossfeed Per Grad. .............................................0005" ..........................................0005" Automatic Longitudinal Feed (Var. Hyd.)....................16-80 FPM..................................16-80 FPM Automatic Crossfeed (Var. Elec.)........................................0-5/8" ..........................................0-5/8" Net Weight ....................................................................4,400 lbs. ...................................6,260 lbs. Shipping Weight .......................................................... 5,000 lbs. .................................. 6,800 lbs.

STANDARD EQUIPMENT: • Magnetic Separator & Paper Filter Coolant System • 20" x 40" or 20" x 60" Electro-magnetic Chuck with Variable Chuck Control • Overhead Parallel Dresser • Wheel Balancing Base • Grinding Wheel & Wheel Mounting Flange • Wheel Balancing Arbor • Diamond Table Dresser • Toolbox with Tools • On-site Start Up Installation

Price Includes Start-Up Installation!

FEATURES: • 3-axis automatic feed, machine will automatically grind to a preset size. • Precision cartridge type spindle with ABEC class 7 angular ball bearings for maximum accuracy and long, trouble free operation. • Heavy duty construction with moving column for crosstravel. Table is mounted directly on bed ways eliminating the "saddle" for higher precision and up to 2,400 lb. workpiece weight capacity. • Automatic lubrication system for easy maintenance and extended machine life. • Solid state electric control for variable electric cross feed. • Rapid spindle travel up/down.


$48,95000

Model SGS-S2460AHD Part No. 6-273-036 Our Net Price

FOR AS LITTLE AS

00

$68,495

$1105.29/mo.*

CALL FOR DETAILS




$1430.56/mo.*

CALL FOR DETAILS


Phone:

FOR AS LITTLE AS

$1,532.23/mo.*

CALL FOR DETAILS


SPECIFICATIONS: MODEL 2040AHD MODEL 2060AHD Table Size ......................................................... 19-2/3" x 39-1/4" ...................... 19-2/3" x 59-1/4" T-Slot ..............................................................................3 x 9/16" .....................................3 x 9/16" Longitudinal Travel............................................................43-1/4" ..............................................63" Crossfeed Travel............................................................. 20-1/4"............................................ 22" Table Speed ............................................................. 16-80 ft/min .............................. 16-80 ft/min Grinding Wheel Size................................................ 16" x 2 "x 5" ............................. 16" x 2" x 5" Wheel Speed............................................................. 1,750 RPM ............................... 1,750 RPM Spindle Motor ........................................ 10 HP, 230/460V, 3 PH ............. 10 HP, 230/460V, 3 PH Vertical Graduation ......................................................... .0001"....................................... .0001" Vertical Revolution .......................................................... .0200"....................................... .0200" Auto Down Feed Increments (10 steps) ........... .0002" - .0020" ......................... .0002" - .0020" Net Weight ................................................................. 11,000 lbs...................................12,000 lbs. Shipping Weight ........................................................ 11,900 lbs. ............................... 13,500 lbs.

1-800-521-5606

Fax:

1-800-322-4292

KBCTools.com

www.

MODEL S2460AHD .................................... 24" x 60" ..................................... 3 x 9/16" .............................................. 65" .............................................. 22" ................................ 16-80 ft/min ............................... 16" x 2" x 5" ................................. 1,750 RPM .............. 10 HP, 230/460V, 3 PH ....................................... .0001" ....................................... .0200" .......................... .0002" - .0020" ..................................13,200 lbs. ................................. 15,400 lbs.


1056

machinery

• SURFACE GRINDERS

Centerless Grinder FEATURES: • An automatic lubrication system keeps the spindles and bearings under constant pressure lubrication. • Both the grinding wheel and regulating wheel spindles are made of high quality nickelchrome-molybdenum steel. Three tapered segment bearings are used on each spindle to make a double bearing system.

STANDARD EQUIPMENT: • STD Thru-feed Workrest w/Blade • Regulating Wheel with Flange • Grinding Wheel with Flange • Manual & Parts List • Toolbox with Tools • Wheel Extractor • Coolant System • Balancing Arbor

SPECIFICATIONS: Grinding Capacity Standard Workrest ......................................................... .04"-1.25" Special Workrest ............................................................... 1.25"-2" Grinding Wheel ......................................... 305D x 150W x 127B mm Regulating Wheel ....................................... 200D x 150W x 90B mm Regulating Wheel Speed (7) ....................................... 15-310 RPM Grinding Wheel Motor............................. 7-1/2 HP, 230/460V, 3 PH Regulating Wheel Motor .......................................................... 1 HP Rapid Feed Handwheel Per Rev. .................................................................................. .25" Graduations ......................................................................... .0025" Micro Feed Handwheel Per Rev. ................................................................................ .001" Graduations ....................................................................... .00005" Regulating Wheel Feed Per Rev. .................................................................................... .2" Graduations ........................................................................... .002" Net Weight (approx.) ....................................................... 2,640 lbs. Shipping Weight .............................................................. 3,300 lbs.

Model CTG-12 Part No. 6-565-010 Our Net Price

$28,90000

Universal Cylindrical Grinders

FOR AS LITTLE AS


MODEL G20P-50CII

FEATURES: • Cartridge type wheel spindle is equipped with four super precision angular class 7 (ABEC) bearings ensure high accuracy. • Universal table with variable speeds can swivel +3O/-5O (G20P) and +7O/-9O (G25P) for cylindricity corrections and taper grinding applications. • Slideways, leadscrews are continuously lubricated by an auto-lube system to ensure long service life and maintain maximum accuracy. • Optional internal grinding attachment swings down into working position easily and quickly. • Mitsubishi PLC control, on auto-infeed model, uses a menu-driven LCD touch screen, which is easy to learn and easy to set. Simply fill in the blanks to set total grinding amount, rough increment, fine increment, sparkout es, feeding direction, parking position, and retracting clearance, and press cycle start to complete automatic grinding cycle.

STANDARD EQUIPMENT: • Grinding wheel with flange • Balancing arbor • Coolant system • Auto lubrication system • Dressing attachment (fixed at tailstock)

• • • •

Leveling screws with blocks Wheel extractor 5C level type collet closer Operation manual with parts list

Model G20P-50CII+5C 8" x 20" Automatic Infeed Part No. 6-520-022 Our Net Price

$26,49500

FOR AS LITTLE AS


Model G25P-50CII+5C 10" x 20" Automatic Infeed Part No. 6-520-024 Our Net Price

$35,29500

FOR AS LITTLE AS

$796.96mo.* CALL FOR DETAILS *60 month term, $1.00 BUYOUT

MANY OPTIONAL ACCESSORIES ALSO AVAILABLE – PLEASE INQUIRE.


Phone:

SPECIFICATIONS G20P-50CII G25P-50CII Capacity Distance Between Center ................................... 20" ........................................... 20" Swing Over Table .................................................. 8" ........................................... 10" Max. Load Held b/w Centers ....................... 176 lbs. .................................... 176 lbs. Wheelhead Swiveling Angle (R&L) .................................... Fixed ....................................... ± 30O Hydraulic Rapid Traverse .................................. N/A ...................................... 1-3/4" Automatic Infeed (CII Model).................. 0.0001"~4" ................................0.0001"~4" Infeed of Handwheel per Grad. ............... Ø0.0001".................................. Ø0.0001" per Rev. ...................... Ø0.01"...................................... Ø0.01" Grinding Wheel Dia. x Width x Bore.......................14" x 1-1/2" x Ø3".....................14" x 1-1/2" x Ø5" Wheel Speed (50/60 Hz)......................... 1960 RPM................................ 1960 RPM Table Swiveling Angle (R & L) .................................+3O/-5O ........................................±7O/9O Traverse Speed (3 steps) ............2.8/4.9/8.3 in./min.............................................N/A Traverse Speed (Inf. Var.-Hydraulic) ................. N/A ..................................... 2"~40" Handwheel per Revolution .............................. 0.35" ....................................... 0.39" Workhead Swiveling Angle (R & L)...................................... N/A ..................................+30O/-90O Center Taper .................................................... MT3 ........................................ MT3 Spindle Speed ..................... 150/264/356/480 RPM ............150/264/356/480 RPM Tailstock Center Taper ......................................... MT3 ........................................ MT3 Motor Wheel Spindle Motor ............. 3 HP, 230V, 3PH ..................... 5 HP, 230V, 3PH Net weight ................................................... 3,600 lbs. ................................ 4,510 lbs. Shipping Weight .......................................... 4,700 lbs. ................................ 5,600 lbs.

1-800-521-5606

Fax:

1-800-322-4292

KBCTools.com

www.

machinery

SANDERS •

1057

Belt Sander/Grinder FEATURES: • 2" x 48" belt and 6" grinding wheel. • Use sanding belt horizontal or vertical. • Safety shield & guard for grinding wheel. SPECIFICATIONS: Belt Size ........................................... 2" x 48" Wheel Size ................................................. 6" Speed .......................................... 3,600 RPM Motor ......................... 1/4 HP, 115V, 1 Phase Net Weight .......................................... 57 lbs.

2"Belt Sander 1/2 HP MODEL 2FSM FEATURES: • 2" x 48" Belt. • Direct drive 1/2 HP, 115V, 1 Phase motor. • Tilt Table. • Full hinged guard for quick belt change. • 48 lbs.

Part No. 2-002-2FSM Our Net Price

Model 2486


$23500

$38500 Disc & Belt Sander

Disc & Belt Sander FEATURES: • 9" Disc and 6" x 48" belt. • Can be switched from horizontal to vertical. • Table can be switched from disc side to belt side and tilts 45° R&L. • Complete with floor stand. NOTE: Shipped partially assembled.

FEATURES: • 6" disc and 4" x 36" belt. • Can be switched from horizontal to vertical. • Cast table can be used with disc or belt.

SPECIFICATIONS: Belt Size ................................... 6" x 48" Belt Speed ........................ 2,300 SFPM Disc Size ........................................... 9" Disc Speed ......................... 3,000 RPM Motor ................ 3/4 HP, 115V, 1 Phase Net Weight ............................... 117 lbs. Shipping Weight ....................... 140 lbs.

SPECIFICATIONS: Belt Size ........................................... 4" x 36" Disc Size .................................................... 6" Belt Speed ................................ 2,000 SFPM Disc Speed .................................. 3,450 RPM Table Size ..................................... 5" x 7-1/2" Motor ......................... 1/4 HP, 115V, 1 Phase Size ....................................... 20" x 16" x 12" Net Weight (approx.) .......................... 42 lbs.

Model 9648


Model 6436


$13500

$25900 Abrasive Belt Grease Sticks

Combination Sander

Universal in use. No “loading” or “glazing”. Light-bodied grease - that spreads out thinly remains “wet” on the belt - and provides lubrication by penetrating the coated abrasive surface. Prevents clogging and leaves the abrasive grit free to cut clean and smooth. For all belt polishing operations - on all metals, plastic and glass.

FEATURES: • Precision ground cast iron table. • Quick change belt release. • Safety disconnected type switch. • Cabinet style stand with power coated paint. • Heavy-duty mitre gauge. • Dust port and all ball bearing construction.

1-800-521-5606

Part No. 1-442-F26 Our Net Price

$475

No. F-90 White Tallow Base Lubricant w/ High Melting Point

SPECIFICATIONS: Motor ... 1HP 115/230V, Single Phase, 3,450 RPM Belt Size .................................................... 6" x 48" Disc Size .......................................................... 10" Belt Speed ............................................ 2,300 FPM Net Weight ................................................ 170 lbs. Shipping Weight ........................................ 250 lbs.

Phone:

2-1/2"x 8" Tube

No. F-26 All-Purpose Lubricant

1 HP motor offers plenty of torque for all your sanding operations and the weight of our heavy cast iron construction and full cabinet stand keeps vibration in check while offering a very attractive package. The cabinet is 100% usable for storage to help take away shop clutter.

Fax:

Model W1676


$46900

1-800-322-4292

Pure tallow base mixture, serves as lubricant and also fills and closes the belt with a heavy bodied grease film. When applied to fine grit size coated abrasive belts, it permits a glazing or burnishing action. When applied to coarse grit belt operations the grease film is heavy enough to stay on the belt under severe conditions.

KBCTools.com

www.

2-1/2"x 8" Tube

Part No. 1-442-F90 Our Net Price

$490 KBC TOOLS & MACHINERY

1058

machinery

• SANDERS

Heavy-Duty Combination Sander

1-1/2 HP Dust Collector

Unlike many belt-driven sanders that require adjustments, the SHOP FOX® W1712 uses a direct ball bearing drive from the motor to the sanding disc and belt deliver a maintenance and vibration free positive torque flow.

A powerful new dust collector. Features an extra heavy duty 12" steel impeller and 1-1/2 HP motor that runs on 115V. FEATURES: • Powder coated paint. • Approximately 1280 CFM of air suction capacity. • Balanced steel radial fin 12" impeller. • 6" inlet with removable "Y" fitting with two 4" openings. • 2 year warranty.

FEATURES: • Precision ground cast iron tables. • Quick change belt release. • ON/OFF toggle switch with safety key. • Cabinet style stand with power coated paint. • Heavy-duty mitre gauge. • 2" and 2-1/2" dust port. • Shielded ball bearing construction.

SPECIFICATIONS: Motor .... 1-1/2 HP, 110V, single-phase, 3450 RPM Motor Amp Draw ................................. 115V - 16A Portable Base Sizes ................... 21-1/2" x 33-1/2" Bag Volume ..................................... 5.4 cubic feet Height (with bags inflated) ............................... 78" Static Pressure ............................................... 10.1" Standard Bag Filtration ........................ 30 Microns Net Weight ................................................ 108 lbs. Shipping Weight ........................................ 160 lbs.

SPECIFICATIONS: Motor ............... 1-1/2HP 115V, 12A, ............. Single Phase, 1,725 RPM Belt Size ............................. 6" x 48" Disc Size ................................... 12" Belt Speed ........................ 878 FPM Disc Speed ................... 1,725 RPM Net Weight ......................... 178 lbs. Shipping Weight ................. 230 lbs.

Model WS1712

®

Model WS1685



$59900

$26900

Combination Belt & Disc Finishing Machine

®

FEATURES: • 6" x 48" Abrasive belt finisher and 10" abrasive disc. • Two cast iron tilting tables for mitering applications. • Dust collection shrouds on belt and disc. • Full access to the belt when tilted in the horizontal position. • 2 year warranty.

6" Industrial Belt Finishing Machine

FEATURES: • Table tilts 45° out, and 20° in for all angle finishing operations. • Adjustable dust deflector and dust chute. • Completely enclosed drums and guarded sanding belt. • Fine thread adjustment for simple and easy belt tracking. • 2 year warranty.

SPECIFICATIONS: Belt Size ............................................... 6" x 48" Belt Speed .................................... 1,650 SFPM Belt Table Size ............................... 6" x 10-1/2" Disc Size ...................................................... 10" Disc Speed ...................................... 2,100 RPM Disc Table Size ............................... 7-1/2" x 13" Table Slots .................................................. 5/8" Table Tilt ............................................... 45° Out Motor ..................................... 1 HP, 115V, 1 PH Net Weight ............................................ 215 lbs. Shipping Weight ................................... 300 lbs.

SPECIFICATIONS: Belt Size ............................................... 6" x 48" Belt Speed .................................... 2,850 SFPM Table Tilt ................................... 45° Out, 20° In Platen ....................................... 7-3/8" x 14-3/4" Motor . 1-1/2 HP, 115/230V, 1PH Prewired 115V Overall Dimensions 25-1/2" x 19" x 57-1/2" (width when belt is in horizontal position) Net Weight ............................................ 290 lbs. Shipping Weight ................................... 375 lbs.

Model J-4210K

Model J-4300A

Part No. 6-200-J4210K Our Net Price

Part No. 6-200-J4300A Our Net Price

$77900

$1,14900

®

Industrial Combination Belt & Disc Finishing Machine

FEATURES: • Belt operates at any angle. • Powered by a heavy-duty, UL/CSA approved, 1-1/2HP TEFC motor. • Contour, finishing, mitering, flat finishing, beveling and precision. • Fully machined balanced disc runs vibration free. • 2 year warranty.

2 Year Warranty! 2 Year Warranty on mechanics. 1 year Warranty on Electrics.


Phone:

Model J-4200A Part No. 6-200-J4200A Our Net Price

$1,59900

1-800-521-5606

Fax:

SPECIFICATIONS: Belt Size ..................................................... 6" x 48" Belt Speed .......................................... 2,850 SFPM Belt Table Size ............................... 7-3/8" x 14-3/4" Belt Table Tilt .......................... 45° Out, 20° Platen Disc Size ........................................................... 12" Disc Speed ........................................... 1,960 RPM Disc Table Size .................................. 12" x 16-3/8" Disc Table Tilt ................................. 45° Out; 20° In Miter Gauge Groove .............................. 3/8" x 3/4" Motor ...................................... 1-1/2HP, 115V, 1 PH Net Weight ................................................. 327 lbs. Shipping Weight ......................................... 350 lbs.

1-800-322-4292

KBCTools.com

www.

SANDERS / IRONWORKERS • ®

FEATURES: • Optimum speed of 1,960 RPM, which is ideal for both metal and wood finishing. • Fully machined, balanced disc runs vibration free. • Plain and compound miters are easily obtained by using the standard die-cast aluminum miter gauge. • 2 year warranty.

FEATURES: • Heavy duty cast iron construction. • Handwheel for raising and lowering table. • Powerful 2 HP direct drive motor with reversing switch. • For use on all materials; wood, metal, plastics, etc.

SPECIFICATIONS: Disc Size .............................................. 12" Disc speed .............................. 1,960 RPM Table Size ............................. 12" x 16-3/8" Table tilt .............................. 45° out, 20° in Miter gauge groove ................... 3/8" x 3/4" Motor 1-1/2HP, 115/230V, 1PH - Prewired 115V Overall Dimensions ........... 16" x 19" x 43" Net Weight .................................... 234 lbs. Shipping Weight ........................... 300 lbs.

SPECIFICATIONS: Diameter of Disc ............................... 20" Drive Motor ..... 2 HP, 230/460V, 3 Phase Spindle Speed ...................... 1725 RPM Table Size ................................ 27" x 14" Overall Height ................................... 54" Net Weight ................................ 410 lbs. Shipping Weight ........................ 550 lbs.

Model DS-20

Model J-4400A


Part No. 6-200-J4400A Our Net Price

$1,24900

$1,14900

FEATURES: • Complete punching system. • Hydraulic system charged. • Punch strippers. • Direct drive pump. • Coupling wrench. • Fully guarded. • Integral lifting lug. • Comfortable operating height.

1059

Disc Sander/ Grinder

12" Industrial Disc Finishing Machine

"Jaws Jr." 25 Ton Ironworker

machinery

25 Ton Capacity

SPECIFICATIONS: Rated capacity....................................25 Ton Throat.........................................................7" Max. capacity..................1" dia. - 5/16" plate Largest standard punch & die .......................1-1/16" punch - 1-1/4" die Open height (die cavity)..........................8.0" Shut height (die cavity) ...........................7.0" Stroke......................................................1.0" Motor ........................1 HP, 110/220V, 1 PH , .........................3 gal. cap. 1- 4" cylinder Base................................................29" x 32" Height.......................................................54" Weight...............................................825 lbs.



$96.49/mo.*

CALL FOR DETAILS


"Jaws IV" Ironworkers FEATURES: • Complete punching system. • Fully guarded. • Remote foot pedal operation. • Punch strippers. • Low rake angle on shear blades. • Shear blades reversible for extra long life. • Fast adjusting hold down bars.

50 Ton Capacity Part No. 6-700-210 Our Net Price

55 Ton Capacity Part No. 6-700-215 Our Net Price

$6,57500


FOR AS LITTLE AS

$151.23/mo.*

CALL FOR DETAILS


Phone:

1-800-521-5606

$164.43/mo.*

CALL FOR DETAILS


Fax:

SPECIFICATIONS: 50 Ton PUNCHING Max. Capacity ..................... 1" dia. in 5/8" plate Work Height ........................................... 37-5/8" FLAT BAR SHEAR Max. Width ......................................... 1/2" x 10" Max. Thickness .................................... 3/4" x 4" Max. Round Capacity .................................. 3/4" Max. Square Capacity ................................. 3/4" Work Height ........................................... 35-1/2" ANGLE SHEAR Max. Size ........ 4" x 4" x 1/4" x or 3" x 3" x 3/8" Work Height ........................................... 40-3/4" GENERAL SPECS. Rated Capacity ....................................... 50 Ton Throat Depth .................................................. 7" Open Height ............................................. 8-1/8" Shut Height .................................................... 7" Stroke ....................................................... 1-1/8" Electric Motor Standard .................. 5 HP, 3 PH, 208/240V, 14 amp Hydraulic Pump Size .. 3-1/2 gpm - single stage Valve Pressure ................................... 2,500 psi Reservoir ............................................. 7 gallons Cylinder ........................................... 2-1/2" Ram Base Dimensions ................... 28-1/4" x 38-1/2" Height ........................................................... 54" Net Weight ......................................... 1,400 lbs. Shipping Weight ................................ 1,550 lbs.

1-800-322-4292

KBCTools.com

www.

55 Ton .......... 1-1/16" dia. in 5/8" plate ...................................... 37-1/2" ............. 1/2" x 12" or 3/8" x 14" .................................... 3/4" x 4" ........................................... 7/8" ........................................... 7/8" ...................................... 34-3/4" .. 4" x 4" x 1/4" or 3" x 3" x 3/8" ............................................ 40" ...................................... 55 Ton ........................................ 7-1/2" .............................................. 8" ........................................ 6-3/4" ........................................ 1-1/4" ............................. 5 HP, 3 PH, 208/240V, 14 amp .......... 3-1/2 gpm - single stage .................................. 2,600 psi ................................... 7 gallons ............................... 2-1/2" Ram ............................ 36" x 42-1/2" ............................................ 59" ................................. 2,250 lbs. ................................. 2,350 lbs.


1060

machinery

• SHEETMETAL EQUIPMENT

Hand Shearing Machine

3 In 1 Sheetmetal Machines

FEATURES: • Hardened and tempered blades. • Long handle provides plenty of shearing torque. • Ideal machine for shearing metal, sheet, steel, bars and rods.

Combination Shear, Brake & Roll - 20 Gauge Mild Steel Capacity!

30" MODEL FEATURES: • Includes: 1 female die, 6 male dies, back gauge & shear stock hold down. • Net Weight: 286 lbs. • Shipping Weight: 386 lbs.


40" MODEL FEATURES: • Includes: 1 female die, 6 male dies. • Net Weight: 440 lbs. • Shipping Weight: 634 lbs.

$12990

30" Model


$39800

Universal Box & Pan Brakes TENNSMITH hand brakes provide an economical means of performing a wide range of sheet metal bending and forming operations. These brakes are of all steel welded construction with truss rods for easy adjustment, bronze bushings which reduce wear and plastic clamp handle grips.

40" Model


SPECIFICATIONS: Blade Length .............................................. 12" Handle Length ............................................ 30" Net Weight ............................................ 54 lbs.

$71760

SPECIFICATIONS: HBU48-22 HBU48-16 Capacity, Mild Steel .................................... 22 GA. ...................... 16 GA. Bending Length .......................................... 48-1/4" ...................... 48-1/4" Maximum Depth Of Body ................................... 3" .............................. 4" Maximum Lift Of Beam .................................... 7/8" ........................ 1-1/4" Front To Rear Beam Adjustment ..................... 1/8" ........................... 5/8" Minimum Reverse Bend ................................ 5/16" ............................ 1/4" Min. Flange In Cap. Material ........................... 3/8" ............................... 1" Finger Widths .......................................... 2, 3 & 4" ................... 2, 3 & 4" Shipping Weight ........................................ 350 lbs. ..................... 580 lbs.

HBU48-12 ...................... 12 GA. ..................... 48-1/4" .............................. 4" ....................... 1-1/2" .............................. 1" ........................... 1/4" .............................. 1" ................... 2, 3 & 4" ................. 1,500 lbs.

MODEL HBU48-16

Model HBU48-22 Part No. 6-700-035 Our Net Price

$1,03500 Model HBU48-16 Part No. 6-700-040 Our Net Price

$1,56500 Model HBU48-12 Part No. 6-700-045 Our Net Price 00

$3,675

MODEL HBU48-12 FOR AS LITTLE AS

$84.53/mo.*

CALL FOR DETAILS

Price Includes Stand! F.O.B. FACTORY – TENNESSEE


10-1/2" MultiMaster® Snips

Slip Rolls Model SR24


F.O.B. FACTORY – TENNESSEE

$99500 Model M300

Part No. 1-552-M300

FEATURES: Our Net Price • Combines long cut of 00 tinners's snips with the strength of compound action. • Great for making long, fast cuts in several types of material including: paper, plastic, sheet metal, aluminum, vinyl siding, screening and many more. • Compound action multiplies the force of the hand by 5 times. • Cuts up to 20-gauge steel. • Non-slip, serrated jaws and non-slip textured grips.

$00


Phone:

Model SR36


$1,16000

Complete with Heavy Duty Floor Stand!

SPECIFICATIONS: MODEL SR24 Capacity, Mild Steel............................... 20 GA. Max. Forming Length .................................. 24" Diameter Of Rolls.......................................... 2" Min. Forming Radius ..................................... 1" Wire Grooves..........................3/16", 1/4", 5/16" Shipping Weight with stand ................ 375 lbs.

1-800-521-5606

Fax:

MODEL SR36

MODEL SR36 .......................... 22 GA. ................................ 36" .................................. 2" .................................. 1" ...........3/16", 1/4", 5/16" ......................... 475 lbs.

1-800-322-4292

KBCTools.com

www.

SHEETMETAL EQUIPMENT •

machinery

16 Gauge Foot Squaring Metal Shears Model 36

Model 52



$2,07500

1061

Ask For A Complete Tennsmith Catalog!

$2,69500

SPECIFICATIONS: MODEL 36 Maximum Shearing Capacity, Mild Steel ........................................................................... 16 GA. Maximum Shearing Capacity, Stainless Steel .................................................................. 20 GA. Maximum Cutting Length .......................................................... 37" Back Gauge Range ................................................................... 30" Front Gauge Range ................................................................... 37" Floor Space, Gauges In Position ....................................................................... 45" x80" Overall Dimensions, Less Gauges, L x W x H ........................................................ 46-1/2" x 27" x 42" Shipping Weight ................................................................. 950 lbs.

MODEL 52 ...................................... 16 GA. ...................................... 20 GA. ..................................... 52-1/4" ............................................ 30" ............................................ 37" .................................. 60" x 80" ......................... 61" x 36" x 42" ................................. 1,100 lbs.

SPECIFICATIONS: Max. Shearing Capacity, Mild Steel ..................................... 16 GA. Max. Shearing Capacity, Stainless Steel ............................. 20 GA. Max. Cutting Length........................ 52-1/4" Floor Space, Gauges In Position................................. 60" x 80" Overall Dimensions Less Gauges .................61"L x 25"W x 42"H Strokes Per Minute, Full Length .......................................... 40 Max. Operating Pressure ................ 65 psi Shipping Weight ......................... 1,300 lbs.

Air-Operated 16 Gauge Metal Squaring Shears


52" 16 Gauge Hydraulic Shears

Model 52A

Model 52H



$5,14500

$6,19500

FOR AS LITTLE AS

$118.34/mo.*

FOR AS LITTLE AS

$142.49/mo.*

CALL FOR DETAILS

CALL FOR DETAILS





SPECIFICATIONS: Max. Shearing Capacity Mild Steel ....................................... 16 GA. Stainless Steel ............................... 20 GA. Max. Cutting Length ........................ 52-1/4" Back Gauge Range ............................... 30" Front Gauge Range ............................... 37" Strokes Per Minute, Full Length................. 60 Maxi. Operating Pressure................... 60 PSI Motor ........................ 3 HP, 230/460V 3 PH Shipping Weight .......................... 1,500 lbs.

Model 16-18 Notcher Combination Rotary Machines

With Standard Blades Part No. 6-700-075 Our Net Price

$1,19500

Optional Tab (Will also do standard notch)

With Tab Blades Part No. 6-700-080 Our Net Price

$1,27000


SPECIFICATIONS: Max. Capacity Notching, Mild Steel .............................. 16 GA. Max. Capacity Piercing, Mild Steel................................ 18 GA. Notch..................................................................... 6" x 6" x 90° Dim., Handle Removed, (LxWxH)..................... 19" x 18" x 15" Shipping Weight with stand ......................................... 350 lbs. Replacement Notcher Blades - Set Of 4 Regular Blades $350.00 Tab Blades $475.00

Phone:


1-800-521-5606

Fax:

1-800-322-4292

Complete with 6 Sets Assorted Rolls for Burring, Wiring, Crimping & Beading! SPECIFICATIONS: Maximum Capacity, Mild Steel ............. 22 GA. Throat ........................................................... 7" Distance, Shaft Center To Center................. 2" Shipping Weight .................................... 67 lbs. F.O.B. FACTORY – TENNESSEE

KBCTools.com

www.

Model R22 Part No. 6-700-085 Our Net Price

$91900 KBC TOOLS & MACHINERY

Machinery 215322

Overview 4q3b3c

More details 26j3b

Related Documents 171j1w

Machinery 215322

Fluid Machinery 3234x

Machinery Checklist 2q5s4z

Grievance Handling Machinery 4h6l37

Fluid Machinery Lecture Notes 7g2

Basic Machinery Vibrations.pdf 394a1a

More Documents from "Huron Industrial Supply" 51552t

Machinery 215322

Toolroom Accessories 6p5u9

Prince Hydraulics - Rd-5000 Directional Control Valves - Mono Block - Offered By Prc Industrial Supply 1e2b6e

Visonic Mcs-730 Data Sheet 235s54

Honeywell Hd45ip 5n232r

Mircom Adc0360a Manual 413x48
