Jindal Hydrogen Gas Dryer 5u552a

Refrigerated Hydrogen Gas Dryer We offer qualitative refrigerated hydrogen gas drier that is immensely used to assure low humidity level inside the generators. Our hydrogen gas drier is also used to increase the prevention process of corrosion and stress in rolor retaining ring. Manufactured from the quality raw materials, our refrigerated air dryers are highly durable and reliable. Refrigerated hydrogen gas drier provided by us is highly efficient, thus needs less energy and provides excellent performance. Refrigerated hydrogen gas drier is very easy to use and install. We are well renowned as one of the overriding refrigerated hydrogen gas drier manufacturers, based in India. Application To ensure very low humidity levels inside the generator and improvement in instalation also enhances prevention of stress and corrosion rolor retaining. Operation The system comprises two heat exchangers.the hydrogen shell and lube type called precooler in which temperature of hydrogen reduces around 25 to 30oC the cooled hydrogen now enters the second heat exchanger named evaporator further cooling up to 0oC to 3oC is accomplished in this h.e. the set dew point is adjustable.the cooling coil inside the evaporator have propelled through a refrigeration system due to low temperature in evaporator the moisture in the H 2 condeneses and converts in water form the water is collected in a well protected condensate collector and can be drained out when desired leaving the evaporater H 2 again travels to pre cooler where it has dual functions of cooling the input H 2 and outgoing leaving dry H 2 is again rises to a safe tem H 2 of around 25oC to 40oC before entering the generator to reduce stress on the system. Advantage of Jindal Refrigerated Driers Over Conventional Driers • • • •

Highly efficient in taking away moisture from gas. Only 8 Hrs. per day (24 Hrs.) service is sufficient No need to replace or regenerate silica gel Energy efficient and have great saving in energy consumption

Refrigerated Type Hydrogen Drier Specifications. Model 200101 Hydrogen Gas Flow Rate Temperature of H2 Gas at intel Temperature of H2Gas at outlet Pressure of H2Gas at inlet Thermal Load Design Pressure Flange Connection Dew point at evaporator Power point at evaporator Designed for maximum ambient Temperature Dimensions of the system Total pressure drop in Drier H2Circuit Power consumption Colour : Shade Welds : All Butt welds All fillet welds

40Nm 3/Hr 60oC 30oC 4Kg/cm2C 130 kgal/hr(Min) 10kg./cm2C NB 50 3o to 5o C(Adjustable) 415VAC 50H 2 -3c 50oC As per DRG No. 200101Jel/HD /99/06 8MM wg. 2KVA (Max ) 280(IS - 5) 100% X-Ray Tested. 100% DPT Tested
