HP ProLiant DL380 G6 Server - Spare Parts

Search HP Center

New model specific parts lists

Top issues

Mechanical components

Most viewed solutions

System components

Advisories, Bulletins & Notices

New model specific parts lists

Manuals Troubleshoot a problem Setup & Install

IMPORTANT: To obtain current part number information for a specific product model, use the Standard Models page for this product family. Click here to go to the Standard Models page for all model specific information and to access the product model parts lists .

Learn & Use

The product Standard Models page now links the model SKU numbers to the spare parts list for each model found on the HP PartSurfer web site. (To report missing or incorrect parts information in PartSurfer, please use the " us" and "Missing or incorrect data" links within the PartSurfer web site utility). To lookup RoHS-compliant information in PartSurfer, use the component’s option part number or the sales order number for a system in which the component is used (available in the QuickSpecs or Standard Models page). The spare part number does not provide RoHS-compliant information.

Upgrade & Migrate HP Guided Troubleshooting RELATED LINKS

Subscribe to alerts for your product

top

Mechanical components

HP product bulletins (QuickSpecs) HP ProLiant Server Warranty Warranty information HP Proliant Server Safety and Compliance

http://h20566.www2.hp.com/portal/site/hpsc/template.PAGE/public/psi/performMaintDisplay/?sp4ts.oid=3884082&spf_p.tpst=psiContentDisplay&spf_p.prp_psiCo…

1/6

10/6/2014

HP ProLiant DL380 G6 Server - Spare Parts

Solutions to common problems More HP resources

Item

Description

Spare part number

Customer self repair

1

Access

496056-001

Mandatory 1

2

Power supply cage

496063-001

Mandatory 1

3

Fan cage

496067-001

Mandatory 1

4

Optical drive cage

496076-001

Mandatory 1

5

SFF hard drive cage

496074-001

Mandatory 1

6

PCI riser cage3

496060-001

Mandatory 1

7

Air baffle

496061-001

Mandatory 1

8

Bezel kit

496080-001

Mandatory 1

Miscellaneous hardware kit 8a

Right bezel

496080-001

Mandatory 1

8b

Left bezel

496080-001

Mandatory 1

9

LFF hard drive cage3

496075-001

Mandatory 1

10

Hard drive blank 3

392613-001

Mandatory 1

11

Power supply blank 3

409417-002

Mandatory 1

12a

Processor heatsink kit3

496064-001

Optional2

12b

Thermal kit (cleaning pad and thermal grease)3

468290-001

Optional2

Hardware kit 3 13

Hardware kit

496058-001

Mandatory 1

13a

Heatsink blank

496058-001

Mandatory 1

13b

Optical device blank

496058-001

Mandatory 1

13c

Fan blank

496058-001

Mandatory 1

13d

Full-length expansion slot cover

496058-001

Mandatory 1

13e

Low-profile expansion slot cover

496058-001

Mandatory 1

13f

PCI retainer

496058-001

Mandatory 1

13g

PCI top retainer

496058-001

Mandatory 1

13h

PCI end retainer

496058-001

Mandatory 1

13i

PCI removable retainer

496058-001

Mandatory 1

NOTE: 1 : Mandatory - Parts for which customer self repair is mandatory. If you request HP to replace these parts, you will be charged for the travel and labor costs of this service. 2 : Optional - Parts for which customer self repair is optional. These parts are also designed for customer self repair. If, however, you require that HP replace them for you, there may or may not be additional charges, depending on the type of warranty service designated for your product. 3 : Not shown in the above diagram.

top

System components

http://h20566.www2.hp.com/portal/site/hpsc/template.PAGE/public/psi/performMaintDisplay/?sp4ts.oid=3884082&spf_p.tpst=psiContentDisplay&spf_p.prp_psiCo…

2/6

10/6/2014

HP ProLiant DL380 G6 Server - Spare Parts

Item

Description

Spare part number

Customer self repair

Cooling fan 14

Hot-plug fan, 60 mm

496066-001

Mandatory 1

Power supply 15a

AC, hot-plug, 1200 W power supply

498152-001

Mandatory 1

15b

AC, hot-plug, 750 W power supply 4

511778-001

Mandatory 1

15c

AC, hot-plug, 460 W power supply 4

511777-001

Mandatory 1

15d

AC, hot-plug,1200 W CS Platinum power supply

579229-001

Mandatory 1

496069-001

Optional2

System board 16

System I/O board assembly

Riser boards 17a

3 slot PCI-E riser board (x8 x4 x4)

496057-001

Optional2

17b

PCI-X riser board4

496077-001

Optional2

17c

1 slot PCI-E x16 riser board4

496078-001

Optional2

Backplanes boards 18

Power supply backplane

496062-001

Optional2

19

Systems Insight Display subassembly

496073-001

Optional2

20

HP Trusted Platform Module

505836-001

No3

21

SFF SAS backplane4

507690-001

Optional2

22

LFF SAS backplane4

496079-001

Optional2

462594-001 - Controller only

Mandatory 1

SAS Storage controller boards (Add-on options) 23a

HP Smart Array P212/Zero Memory Controller 462828-B214

23b

HP Smart Array P212/256 MB Controller 462834- 462594-001 - Controller only 462974-001 - 256MB Memory module B214

Mandatory 1

23c

HP Smart Array P410/256 MB Controller 462862- 462919-001 - Controller only 462974-001 - 256MB Memory module B214

Mandatory 1

23d

HP Smart Array P410/512 MB with BBWC Controller 462864-B214

462919-001 - Controller only 462975-001 - 512MB Memory module

Mandatory 1

23e

HP Smart Array P410/512MB with FBWC 578230- 462919-001 - Controller only 462975-001 - 512MB Memory module B214

Mandatory 1

23f

HP Smart Array P410/1G with FBWC 572532B214

23g

HP Smart Array P411/256 MB Controller 462830- 462918-001 - Controller only 462974-001 - 256MB Battery Backed Write Cache B214 (BBWC) memory module

Mandatory 1

23h

HP Smart Array P411/512 MB with BBWC Controller 462832-B214

Mandatory 1

23i

HP Smart Array P411/512MB Flash Backed Write 462918-001 - Controller only Mandatory 1 578882-001- 512MB Flash Backed Write Cache (FBWC) Cache 578229-B214 module 587324-001 - Flash Backed Write Cache (FBWC) capacitor pack

23j

HP Smart Array P411/1G Flash Backed Write Cache 572531-B214

462919-001 - Controller only Mandatory 1 505908-001 - Flash Backed Write Cache (FBWC) module - 1GB 587324-001 - Flash Backed Write Cache (FBWC) capacitor pack

462918-001 - Controller only 462975-001 - 512MB Battery Backed Write Cache (BBWC) memory module - 72B wide - Does not include batteries

462918-001 - Controller only Mandatory 1 505908-001 - Flash Backed Write Cache (FBWC) module - 1GB 587324-001 - Flash Backed Write Cache (FBWC)

http://h20566.www2.hp.com/portal/site/hpsc/template.PAGE/public/psi/performMaintDisplay/?sp4ts.oid=3884082&spf_p.tpst=psiContentDisplay&spf_p.prp_psiCo…

3/6

10/6/2014

HP ProLiant DL380 G6 Server - Spare Parts capacitor pack 23k

HP Smart Array P800/512 BBWC Controller 381513-B214

398647-001 - Controller only 398645-001 - 512MB Memory module

Mandatory 1

23l

HP Smart Array P812/1G Flash Backed Cache Controller 487204-B214

587224-001 - Controller only 505908-001 - 1GB Flash Backed Write Cache (FBWC) module 587225-001 - Flash Backed Write Cache (FBWC) capacitor pack

Mandatory 1

462975-001

Mandatory 1

Memory modules 24

512MB Battery Backed Write Cache (BBWC) memory module - 72B wide, does not include batteries 4

RDIMM 4 25a

PC3-8500 (DDR3-1066) 4GB (RoHS)

501535-001

Mandatory 1

25b

PC3-8500 (DDR3-1066) 8GB

519201-001

Mandatory 1

25c

PC3-10600 (DDR3-1333) 2GB (RoHS)

501533-001

Mandatory 1

25d

PC3-10600 (DDR3-1333) 4GB (RoHS)

501534-001

Mandatory 1

UDIMM 4 26a

PC3-10600 (DDR3-1333) 1GB (RoHS)

501539-001

Mandatory 1

26b

PC3-10600 (DDR3-1333) 2GB (RoHS)

501540-001

Mandatory 1

Processors 4, 5 27a

2.13 GHz Intel Xeon processor L5506

513597-001

Optional2

27b

2.26 GHz Intel Xeon processor L5520

508567-001

Optional2

27c

1.86 GHz Intel Xeon processor E5502

490075-001

Optional2

27d

2.00 GHz Intel Xeon processor E5504

490074-001

Optional2

27e

2.13 GHz Intel Xeon processor E5506

506013-001

Optional2

27f

2.26 GHz Intel Xeon processor E5520

490073-001

Optional2

27g

2.40 GHz Intel Xeon processor E5530

490072-001

Optional2

27h

2.53 GHz Intel Xeon processor E5540

490071-001

Optional2

27i

2.67 GHz Intel Xeon processor X5550

490070-001

Optional2

27j

2.80 GHz Intel Xeon processor X5560

490069-001

Optional2

27k

2.93 GHz Intel Xeon processor X5570

506012-001

Optional2

27l

3.33-GHz Intel Xeon processor W5590

589014-001

Optional2

27m

2.40-GHz Intel Xeon processor L5530

536584-001

Optional2

27n

2.66-GHz Intel Xeon processor X5650

594884-001

Optional2

27o

2.80-GHz Intel Xeon processor X5660

594883-001

Optional2

27p

2.93-GHz Intel Xeon processor X5670

594882-001

Optional2

Storage hard drives Hot-plug SFF SAS 4 28a

36GB, 15,000 RPM, dual port

418397-001

Mandatory 1

28b

72GB, 10,000 RPM, dual-port

389346-001

Mandatory 1

28c

72GB, 15,000 RPM, dual-port

418398-001

Mandatory 1

28d

146GB, 10,000 RPM, dual-port, 6G

507283-001

Mandatory 1

28e

146GB, 10,000 RPM, dual-port

418399-001

Mandatory 1

28f

146GB, 15,000 RPM, dual-port

504334-001

Mandatory 1

28g

300GB, 10,000 RPM, dual-port, 6G

507284-001

Mandatory 1

28h

300GB, 10,000 RPM, dual-port

493083-001

Mandatory 1

Hot-plug SFF SATA 4 29a

120GB, 5,400 RPM, 1-year warranty

459322-001

Mandatory 1

29b

250GB, 5,400 RPM, 1-year warranty

460426-001

Mandatory 1

Hot-plug LFF SAS 4 30a

72GB, 15,000 RPM, dual-port

389343-001

Mandatory 1

30b

146GB, 15,000 RPM, dual-port

488058-001

Mandatory 1

30c

300GB, 15,000 RPM, dual-port, enterprise

488060-001

Mandatory 1

30d

400GB, 10,000 RPM, dual-port

456896-001

Mandatory 1

30e

450GB,15,000 RPM, dual-port

454274-001

Mandatory 1

30f

750GB, 7200 RPM, dual-port, 1-year warranty

461288-001

Mandatory 1

30g

1TB, 7200 RPM, dual-port, 1-year warranty

461289-001

Mandatory 1

Hot-plug LFF SATA 4 31a

160GB, 7200-RPM, 1-year warranty

483095-001

Mandatory 1

31b

250GB, 7,200 RPM, 3G

459318-001

Mandatory 1

http://h20566.www2.hp.com/portal/site/hpsc/template.PAGE/public/psi/performMaintDisplay/?sp4ts.oid=3884082&spf_p.tpst=psiContentDisplay&spf_p.prp_psiCo…

4/6

10/6/2014

HP ProLiant DL380 G6 Server - Spare Parts 31c

500GB, 7,200 RPM, 1-year warranty

459319-001

Mandatory 1

31d

750GB, 7,200 RPM, 1-year warranty

459320-001

Mandatory 1

31e

1TB, 7200 RPM, 1-year warranty

454273-001

Mandatory 1

Optical drives 4 32

Slimline CD-ROM drive

399401-001

Mandatory 1

33

Slimline 8x/24x DVD-ROM drive

397928-001

Mandatory 1

34

Slimline 24x CD-RW/DVD-ROM

399959-001

Mandatory 1

35

Slimline 8x DVD+R/RW

399402-001

Mandatory 1

36

Serial ATA (SATA) DVD-ROM optical disk drive 12.7 mm slimline

481428-001

Mandatory 1

37

Slimline Serial ATA (SATA) DVD-RW optical disk 481429-001 drive - 12.7 mm height

Mandatory 1

Cables 4 38a

SAS Backplane power cable

496070-001

Mandatory 1

38b

2nd SAS SFF backplane power cable

514217-001

Mandatory 1

39

Optical drive data and power cable

496071-001

Mandatory 1

40

AC power cord

142258-001

Mandatory 1

41

Smart Array P410i/P410/P411 battery cable

488138-001

Mandatory 1

42

MiniSAS data backplane cable

498426-001

Optional2

153099-001

Mandatory 1

Batteries 4 43

System battery, 3.3 V, lithium

44a

Battery module - For Battery Backed Write Cache 462976-001 (BBWC)

Optional2

Rack mounting hardware kit 4 45a

Hardware mounting kit LFFG6

574898-001

Optional2

45b

Hardware mounting kit

574765-001

Optional2

NOTE: 1 : Mandatory - Parts for which customer self repair is mandatory. If you request HP to replace these parts, you will be charged for the travel and labor costs of this service. 2 : Optional - Parts for which customer self repair is optional. These parts are also designed for customer self repair. If, however, you require that HP replace them for you, there may or may not be additional charges, depending on the type of warranty service designated for your product. 3 : No - Some HP parts are not designed for customer self repair. In order to satisfy the customer warranty, HP requires that an authorized service provider replace the part. These parts are identified as 'No' in the Illustrated Parts Catalog. 4 : Not shown in the above diagram. 5 : All processors in this HP ProLiant server must have the same cache size, speed, number of cores, and rated maximum power consumption.
