HONDA CB TWISTER 210MC001
A25, Krishna Towers, 50 Sardar Patel Road, Chennai 600113 Ph : (91) (44) 22352673, 6450665, Fax : (91) (44) 22351684 email : fmsci @vsnl.com, web : www.fmsci.in
vss
Page 1 of 15
FMSCI HMN No. : 210MC001 Valid From : Valid till :
HONDA CB TWISTER Article
Description
1. General 101
Manufacturer's Name
Honda Motorcycle & Scooter India Pvt. Ltd.
102
Manufacturer's address
Plot No. 1 & 2 , Sector -3, IMT Manesat, Gurgaon.
103
Brand name
HONDA
Model
104
(a) Model Year
2010
(b) Model Identification Name
CB TWISTER
(c) Beginning Serial No.
ME4JC472H98000001
(d) End Serial No. 105 106 **
Type Minimum weight ( Refer Manual ) Right Side view of the vehicle
vss
Motorcycle
Scooter
Moped
86 kgs
Left Side view of the vehicle
Page 2 of 15
FMSCI HMN No. : 210MC001 Valid From : Valid till :
HONDA CB TWISTER 2. Engine 201
Type of Engine
202
Number of Cylinders
1
a) Bore **
50 mm
b) Stroke **
55.6 mm
c) Conrod length **
93.2 mm
203 **
Four Stroke
d) Supercharging
204 205 ** 206
Yes
e) Type and number of compressors
NA
Cubic capacity (Refer Manual)
109 cc
(a) Minimum Volume of Cylinder Head (Refer Manual)
9.3 cc
(b) No. of spark plugs per Cylinder
1
Compression Ratio (Refer Manual)
9:1
Two Stroke
No
Piston a) Material
Aluminium Alloy
b) Minimum Weight (with pin / rings / circlips) 80 gms ** 207 **
c) No. of Rings per Piston
3
d) Piston pin offset (Refer Manual) **
0.5 mm
e) Piston pin material
Steel
f) Piston pin weight
15 gms +/- 1 gm
Material
208
vss
a) Crankcase
Aluminium Alloy
b) Cylinder barrel
Aluminium Alloy
c) Cylinder head
Aluminium Alloy
d) Generator cover
Aluminium Alloy
e) Primary case cover
----
f) Clutch cover
Aluminium Alloy
g) Crankshaft cover
Aluminium Alloy
h) Gear Box cover
Aluminium Alloy
i) Ignition cover
PLASTIC
k) Cylinder head cover (valve)
Aluminium Alloy
Page 3 of 15
FMSCI HMN No. : 210MC001 Valid From : Valid till :
HONDA CB TWISTER
Material
Weight
l) Crank shaft Assembly **
STEEL
2880 gms **
m) Conrod ** (with cap, bolts and shell bearings) (Refer Manual)
STEEL
(included in the above) gms **
209
Thickness of tightened cylinder head gasket
0.25 mm +/- 0.1 mm
210
Position of Cylinder & head relative to the Crank Case
Cylinder Inclined 26 degree
208
a) Method of cooling
Air
Liquid
Air & Liquid
211 b) Type of liquid 212
Does the cylinder have a sleeve or liner If yes, material
213
Cylinder barrel – coating
Yes Material : Fe,
No
Chrome
Electrofusion
Nickel
Others : Heat Resistance Paint 214
View of Engine / Crankcase Assembly – Left Side
vss
Reed Valve
Rotary Valve
Piston Port
Poppet Valve
Method of Induction
View of Engine / Crankcase Assembly– Right Side
Page 4 of 15
FMSCI HMN No. : 210MC001 Valid From : Valid till :
HONDA CB TWISTER View of Engine/ Crankcase Assembly – Top View
View of Engine / Crankcase Assembly– Bottom Side
A) Fuel feed by Carburettor a) Make
Keihin FEI
b) Type / Model
Side Draft Variable Venturi
c) Venturi diameter
18 mm +/- 0.25 mm
d)Maximum diameter of Carburettor exit port
22 mm
e) Length of adaptor
100 mm
215
Carburettor showing exit port
vss
Page 5 of 15
FMSCI HMN No. : 210MC001 Valid From : Valid till :
HONDA CB TWISTER B) Fuel feed by Injection NOT APPLICABLE a) Make b) Model c) Kind of fuel measurement 215
Mechanical
Electronic
Hydraulic
d) Dimensions of intake pipe at the throttle or slide location e) Number of effective fuel outlets f) Position of injectors f1) Manifold / Cylinderhead
Manifold
Cylinderhead
g) Sensors of injection system h) Actuators of injection system Injection System
NA
vss
Page 6 of 15
FMSCI HMN No. : 210MC001 Valid From : Valid till :
HONDA CB TWISTER Location of Sensors & Actuators
NA
For Two Strokes Only a) Number of Ports Total Intake 216 Transfer Boost Exhaust b) Height of Ports Intake
mm
Transfer
mm
Boost
mm
Exhaust
mm
216 c) Width of Ports
vss
Intake
mm
Transfer
mm
Boost
mm
Exhaust
mm
Page 7 of 15
FMSCI HMN No. : 210MC001 Valid From : Valid till :
HONDA CB TWISTER For Four Strokes only Inlet valves
217 **
a) Number
1
b) Diameter **
25.5 mm
c) Stem dia **
5 mm
d) Overall length **
76.6 mm
e) Weight **
22 gms (+/- 0.5 gms)
f) Number of springs per valve
1
g) Type of valve springs
Coil Spring
h) Maximum length of the spring
under a load of
i) External diameter of springs
22.6 +/- 0.2 mm
j) Diameter of spring wire
2.8 mm
k) Number of spring coils
6.5
l) Maximum free length of springs
30.82 mm
N
Exhaust valves
218 **
a) Number
1
b) Diameter **
21 mm
c) Stem dia **
5 mm
d) Overall length **
75.9 mm
e) Weight **
18 gms
f) Number of springs per valve
1
g) Type of valve springs
Coil Spring
h) Maximum length of the spring
under a load of
i) External diameter of springs
22.6 +/- 0.2 mm
j) Diameter of spring wire
2.8
k) Number of spring coils
6.5
l) Maximum free length of springs
30.82 mm
m) Diameter of pipe between manifold and first silencer
N
mm +/- 5%
Maximum valve lift 219
vss
a) Intake
5.8 mm
b) Exhaust
NA mm
Page 8 of 15
FMSCI HMN No. : 210MC001 Valid From : Valid till :
HONDA CB TWISTER 220
Tappet Rockerarm
Oscillating Lever
Direct
Hydraulic
Type of valve operation Ratio a) Rocker Arm
35 / 16.5
b) Oscillating lever
NA
c) Rocker Arm weight
41 gms
221
222
Overhead valve
Yes
No
223
Overhead CAM
Yes
No
224
Pushrod
Yes
No
225
Method of Cam shaft drive
CHAIN
CAM Timing
226
a) Inlet opens
5 Degree BTDC
b) Inlet closes
25 Degree ABDC
c) Exhaust opens
25 Degree BBDC
d) Exhaust closes
0 Degree BTDC
CAM dimensions a) Inlet **
A=28.16 +/-0.1 mm B=31.90 +/-0.1 mm
b) Exhaust **
A=28.16+/-0.1 mm B=31.90 +/-0.1 mm
227 **
vss
c) Weight of the Cam **
250 with two bearings gms
d) Number
TWO
e) Location
CYLINDER HEAD
f) Number of bearings per shaft
2
g) Inside diameter of bearings
20 +/- 0.1 mm
Page 9 of 15
FMSCI HMN No. : 210MC001 Valid From : Valid till :
HONDA CB TWISTER Cam lift in mm (dismounted camshaft) Intake Rotation Angle in Degrees
Lift in Mm
0
3.857
-5
3.888
-10
Exhaust
Rotation Angle in Degrees
Lift in mm
Rotation angle in Degrees
Lift in Mm
Rotation angle in Degrees
Lift in mm
3.857
0
3.739
3.739
+5
3.747
-5
3.653
+5
3.742
3.832
+10
3.560
-10
3.489
+10
3.661
-15
3.697
+15
3.295
-15
3.248
+15
3.492
-30
2.852
+30
2.092
-30
2.151
+30
2.561
-45
1.522
+45
0.797
-45
0.790
+45
1.230
-60
0.382
+60
0.258
-60
0.194
+60
0.273
-75
0.157
+75
0.157
-75
0.119
+75
0.138
-90
0.091
+90
0.087
-90
0.007
+90
0.095
-105
0.030
+105
0.015
-105
0.008
+105
0.015
-120
0.015
+120
0.011
-120
0.010
+120
0.018
-135
0.013
+135
0.012
-135
0.011
+135
0.019
-150
0.014
+150
0.012
-150
0.011
+150
0.020
A shift of +/- 2 degrees of the whole measurement is accepted Applicable to both 2 & 4 Stroke Engines 228
Type of Ignition
DC-CDI
229
Starting Devices
Kick
a) Clutch
wet
dry
b) Method of operation
Cable
Hydraulic
230
c) Weight of Clutch Basket (Refer Manual) ** 231 **
Self
Both
1.580 kg
Transmission Primary Drive a) Method of primary drive
Gear
b) If gear drive
Helical
Belt
Chain Straight Cut
Primary Drive Ratio
3.72
If gears / Chain
Drive
Driven
a) No. of teeth **
18
67
b) Thickness **
16 mm
12 mm
if belt
vss
Page 10 of 15
FMSCI HMN No. : 210MC001 Valid From : Valid till :
HONDA CB TWISTER a) Diameter of pulleys
mm
Gear Box a) Shell Material
ALUMINIUM CASTING
b) No. of speeds
4
c) Material of gears
STEEL
232 **
Gear
Ratio
No. of teeth Drive
Thickness **
Driven
Drive
Driven
First
0.314
11
35
12.2
15.2
Second
0.586
17
29
8.6
9.6
Third
0.807
21
26
10
10.1
Fourth
1.09
24
22
9.3
9.2
Fifth
NA
NA
NA
NA
NA
Sixth
NA
NA
NA
NA
NA
Secondary Drive a) Method of Secondary Drive 233 **
Chain
Shaft
b) Secondary Drive Ratio
3.00
c) If chain, No. of teeth **
Drive 14 Driven 42
Belt
d) If belt, diameter of pulleys Chassis and Suspension
3 a) Main frame type
DIAMOND
b) Material (Gussets / Tubes)
STEEL
301
vss
Page 11 of 15
FMSCI HMN No. : 210MC001 Valid From : Valid till :
HONDA CB TWISTER Frame
Front Suspension 302
a) Method of suspension
TELESCOPIC HYDRAULIC
b) Front tube O.D.
38.5 mm
c) Lower Slider O.D.
30.0 mm
Rear Suspension 303
a) Method of suspension
Mono Shock
b) Swinging Arm Type
Tubular
c) Material of Swinging Arm
Twin Shock
Rectangular Box Section
STEEL
Wheels 304
a) Front wheel rim diameter (OD)
17 Inches
b) Width
1.85 Inches
a) Rear wheel rim diameter (OD)
17 Inches
b) Width
1.85 Inches
Oil Tank Capacity
1.0 liters
305 306
Fuel Tank 307
308
vss
a) Capacity
8.0 Litres
b) Material
STEEL SHEET WITH ZN - NI PLATING
Has the fuel system an electrical pump
No
Page 12 of 15
FMSCI HMN No. : 210MC001 Valid From : Valid till :
HONDA CB TWISTER Exhaust System
4 401
Detachable baffles
No
Weight of the silencer system with bolts for fixing the same **
3.400 kgs
403
Inner diameter of the bend of the silencer
16.7 mm
404
Anti Pollution System : Description
CATALYTIC CONVERTER
402 **
5. Brakes 2
NA
b) OD of piston in caliper
25.90 mm
NA mm
Yes
No
Yes
No
c1) Internal diameter
130 +/-1.5 mm
110 +/-1.5 mm
c2) Number of linings per wheel
TWO
TWO
c3) Developed length of lining
114 +/-1.5 mm
103 +/-1.5 mm
c4) Width of lining
25 +/- 1mm
25 +/- 1mm
d) Disc Brakes
Yes
No
Yes
d1) Number of pads per wheel
NA
d2) Number of calipers per wheel
NA
d3) Caliper Material
NA
No
d4) Thickness of new disc
+/- 1 mm
NA+/- 1 mm
d5) External diameter of disc
+/-1.5 mm
NA +/-1.5 mm
d6) External diameter of pads rubbing surface d7) Internal diameter of pads rubbing surface d8) Overall friction length of pads d9) Ventilated discs
6
Rear
a) Number of pistons per caliper
c) Drum Brakes
501
Front
+/-1.5 mm
+/-1.5 mm
+/-1.5 mm
+/-1.5 mm
+/-1.5 mm Yes
No
NA +/-1.5 mm Yes
No
Radiator Radiator Core Dimensions a) Height
601 b) Width c) Depth
vss
Page 13 of 15
FMSCI HMN No. : 210MC001 Valid From : Valid till :
HONDA CB TWISTER 7
Airbox a) Air Box
Yes
No
Yes
No
b) Material 701 c) RAM Air intake opening in fairing d) Dimension
vss
Page 14 of 15
FMSCI HMN No. : 210MC001 Valid From : Valid till :
HONDA CB TWISTER
Vehicle : Honda CB Twister Optional Variant 5. Brakes
Front
d) Disc Brakes
501
Yes
No
Yes
No
d1) Number of pads per wheel
2
NA
d2) Number of calipers per wheel
1
NA
d3) Caliper Material
Aluminium Casting
NA
d4) Thickness of new disc
4+/- 1 mm
NA+/- 1 mm
d5) External diameter of disc
215.4 +/-1.5 mm
NA +/-1.5 mm
d6) External diameter of pads rubbing surface d7) Internal diameter of pads rubbing surface d8) Overall friction length of pads d9) Ventilated discs
vss
Rear
+/-1.5 mm
+/-1.5 mm
+/-1.5 mm
+/-1.5 mm
76.5 +/-1.5 mm Yes
No
NA +/-1.5 mm Yes
No
Page 15 of 15
A25, Krishna Towers, 50 Sardar Patel Road, Chennai 600113 Ph : (91) (44) 22352673, 6450665, Fax : (91) (44) 22351684 email : fmsci @vsnl.com, web : www.fmsci.in
vss
Page 1 of 15
FMSCI HMN No. : 210MC001 Valid From : Valid till :
HONDA CB TWISTER Article
Description
1. General 101
Manufacturer's Name
Honda Motorcycle & Scooter India Pvt. Ltd.
102
Manufacturer's address
Plot No. 1 & 2 , Sector -3, IMT Manesat, Gurgaon.
103
Brand name
HONDA
Model
104
(a) Model Year
2010
(b) Model Identification Name
CB TWISTER
(c) Beginning Serial No.
ME4JC472H98000001
(d) End Serial No. 105 106 **
Type Minimum weight ( Refer Manual ) Right Side view of the vehicle
vss
Motorcycle
Scooter
Moped
86 kgs
Left Side view of the vehicle
Page 2 of 15
FMSCI HMN No. : 210MC001 Valid From : Valid till :
HONDA CB TWISTER 2. Engine 201
Type of Engine
202
Number of Cylinders
1
a) Bore **
50 mm
b) Stroke **
55.6 mm
c) Conrod length **
93.2 mm
203 **
Four Stroke
d) Supercharging
204 205 ** 206
Yes
e) Type and number of compressors
NA
Cubic capacity (Refer Manual)
109 cc
(a) Minimum Volume of Cylinder Head (Refer Manual)
9.3 cc
(b) No. of spark plugs per Cylinder
1
Compression Ratio (Refer Manual)
9:1
Two Stroke
No
Piston a) Material
Aluminium Alloy
b) Minimum Weight (with pin / rings / circlips) 80 gms ** 207 **
c) No. of Rings per Piston
3
d) Piston pin offset (Refer Manual) **
0.5 mm
e) Piston pin material
Steel
f) Piston pin weight
15 gms +/- 1 gm
Material
208
vss
a) Crankcase
Aluminium Alloy
b) Cylinder barrel
Aluminium Alloy
c) Cylinder head
Aluminium Alloy
d) Generator cover
Aluminium Alloy
e) Primary case cover
----
f) Clutch cover
Aluminium Alloy
g) Crankshaft cover
Aluminium Alloy
h) Gear Box cover
Aluminium Alloy
i) Ignition cover
PLASTIC
k) Cylinder head cover (valve)
Aluminium Alloy
Page 3 of 15
FMSCI HMN No. : 210MC001 Valid From : Valid till :
HONDA CB TWISTER
Material
Weight
l) Crank shaft Assembly **
STEEL
2880 gms **
m) Conrod ** (with cap, bolts and shell bearings) (Refer Manual)
STEEL
(included in the above) gms **
209
Thickness of tightened cylinder head gasket
0.25 mm +/- 0.1 mm
210
Position of Cylinder & head relative to the Crank Case
Cylinder Inclined 26 degree
208
a) Method of cooling
Air
Liquid
Air & Liquid
211 b) Type of liquid 212
Does the cylinder have a sleeve or liner If yes, material
213
Cylinder barrel – coating
Yes Material : Fe,
No
Chrome
Electrofusion
Nickel
Others : Heat Resistance Paint 214
View of Engine / Crankcase Assembly – Left Side
vss
Reed Valve
Rotary Valve
Piston Port
Poppet Valve
Method of Induction
View of Engine / Crankcase Assembly– Right Side
Page 4 of 15
FMSCI HMN No. : 210MC001 Valid From : Valid till :
HONDA CB TWISTER View of Engine/ Crankcase Assembly – Top View
View of Engine / Crankcase Assembly– Bottom Side
A) Fuel feed by Carburettor a) Make
Keihin FEI
b) Type / Model
Side Draft Variable Venturi
c) Venturi diameter
18 mm +/- 0.25 mm
d)Maximum diameter of Carburettor exit port
22 mm
e) Length of adaptor
100 mm
215
Carburettor showing exit port
vss
Page 5 of 15
FMSCI HMN No. : 210MC001 Valid From : Valid till :
HONDA CB TWISTER B) Fuel feed by Injection NOT APPLICABLE a) Make b) Model c) Kind of fuel measurement 215
Mechanical
Electronic
Hydraulic
d) Dimensions of intake pipe at the throttle or slide location e) Number of effective fuel outlets f) Position of injectors f1) Manifold / Cylinderhead
Manifold
Cylinderhead
g) Sensors of injection system h) Actuators of injection system Injection System
NA
vss
Page 6 of 15
FMSCI HMN No. : 210MC001 Valid From : Valid till :
HONDA CB TWISTER Location of Sensors & Actuators
NA
For Two Strokes Only a) Number of Ports Total Intake 216 Transfer Boost Exhaust b) Height of Ports Intake
mm
Transfer
mm
Boost
mm
Exhaust
mm
216 c) Width of Ports
vss
Intake
mm
Transfer
mm
Boost
mm
Exhaust
mm
Page 7 of 15
FMSCI HMN No. : 210MC001 Valid From : Valid till :
HONDA CB TWISTER For Four Strokes only Inlet valves
217 **
a) Number
1
b) Diameter **
25.5 mm
c) Stem dia **
5 mm
d) Overall length **
76.6 mm
e) Weight **
22 gms (+/- 0.5 gms)
f) Number of springs per valve
1
g) Type of valve springs
Coil Spring
h) Maximum length of the spring
under a load of
i) External diameter of springs
22.6 +/- 0.2 mm
j) Diameter of spring wire
2.8 mm
k) Number of spring coils
6.5
l) Maximum free length of springs
30.82 mm
N
Exhaust valves
218 **
a) Number
1
b) Diameter **
21 mm
c) Stem dia **
5 mm
d) Overall length **
75.9 mm
e) Weight **
18 gms
f) Number of springs per valve
1
g) Type of valve springs
Coil Spring
h) Maximum length of the spring
under a load of
i) External diameter of springs
22.6 +/- 0.2 mm
j) Diameter of spring wire
2.8
k) Number of spring coils
6.5
l) Maximum free length of springs
30.82 mm
m) Diameter of pipe between manifold and first silencer
N
mm +/- 5%
Maximum valve lift 219
vss
a) Intake
5.8 mm
b) Exhaust
NA mm
Page 8 of 15
FMSCI HMN No. : 210MC001 Valid From : Valid till :
HONDA CB TWISTER 220
Tappet Rockerarm
Oscillating Lever
Direct
Hydraulic
Type of valve operation Ratio a) Rocker Arm
35 / 16.5
b) Oscillating lever
NA
c) Rocker Arm weight
41 gms
221
222
Overhead valve
Yes
No
223
Overhead CAM
Yes
No
224
Pushrod
Yes
No
225
Method of Cam shaft drive
CHAIN
CAM Timing
226
a) Inlet opens
5 Degree BTDC
b) Inlet closes
25 Degree ABDC
c) Exhaust opens
25 Degree BBDC
d) Exhaust closes
0 Degree BTDC
CAM dimensions a) Inlet **
A=28.16 +/-0.1 mm B=31.90 +/-0.1 mm
b) Exhaust **
A=28.16+/-0.1 mm B=31.90 +/-0.1 mm
227 **
vss
c) Weight of the Cam **
250 with two bearings gms
d) Number
TWO
e) Location
CYLINDER HEAD
f) Number of bearings per shaft
2
g) Inside diameter of bearings
20 +/- 0.1 mm
Page 9 of 15
FMSCI HMN No. : 210MC001 Valid From : Valid till :
HONDA CB TWISTER Cam lift in mm (dismounted camshaft) Intake Rotation Angle in Degrees
Lift in Mm
0
3.857
-5
3.888
-10
Exhaust
Rotation Angle in Degrees
Lift in mm
Rotation angle in Degrees
Lift in Mm
Rotation angle in Degrees
Lift in mm
3.857
0
3.739
3.739
+5
3.747
-5
3.653
+5
3.742
3.832
+10
3.560
-10
3.489
+10
3.661
-15
3.697
+15
3.295
-15
3.248
+15
3.492
-30
2.852
+30
2.092
-30
2.151
+30
2.561
-45
1.522
+45
0.797
-45
0.790
+45
1.230
-60
0.382
+60
0.258
-60
0.194
+60
0.273
-75
0.157
+75
0.157
-75
0.119
+75
0.138
-90
0.091
+90
0.087
-90
0.007
+90
0.095
-105
0.030
+105
0.015
-105
0.008
+105
0.015
-120
0.015
+120
0.011
-120
0.010
+120
0.018
-135
0.013
+135
0.012
-135
0.011
+135
0.019
-150
0.014
+150
0.012
-150
0.011
+150
0.020
A shift of +/- 2 degrees of the whole measurement is accepted Applicable to both 2 & 4 Stroke Engines 228
Type of Ignition
DC-CDI
229
Starting Devices
Kick
a) Clutch
wet
dry
b) Method of operation
Cable
Hydraulic
230
c) Weight of Clutch Basket (Refer Manual) ** 231 **
Self
Both
1.580 kg
Transmission Primary Drive a) Method of primary drive
Gear
b) If gear drive
Helical
Belt
Chain Straight Cut
Primary Drive Ratio
3.72
If gears / Chain
Drive
Driven
a) No. of teeth **
18
67
b) Thickness **
16 mm
12 mm
if belt
vss
Page 10 of 15
FMSCI HMN No. : 210MC001 Valid From : Valid till :
HONDA CB TWISTER a) Diameter of pulleys
mm
Gear Box a) Shell Material
ALUMINIUM CASTING
b) No. of speeds
4
c) Material of gears
STEEL
232 **
Gear
Ratio
No. of teeth Drive
Thickness **
Driven
Drive
Driven
First
0.314
11
35
12.2
15.2
Second
0.586
17
29
8.6
9.6
Third
0.807
21
26
10
10.1
Fourth
1.09
24
22
9.3
9.2
Fifth
NA
NA
NA
NA
NA
Sixth
NA
NA
NA
NA
NA
Secondary Drive a) Method of Secondary Drive 233 **
Chain
Shaft
b) Secondary Drive Ratio
3.00
c) If chain, No. of teeth **
Drive 14 Driven 42
Belt
d) If belt, diameter of pulleys Chassis and Suspension
3 a) Main frame type
DIAMOND
b) Material (Gussets / Tubes)
STEEL
301
vss
Page 11 of 15
FMSCI HMN No. : 210MC001 Valid From : Valid till :
HONDA CB TWISTER Frame
Front Suspension 302
a) Method of suspension
TELESCOPIC HYDRAULIC
b) Front tube O.D.
38.5 mm
c) Lower Slider O.D.
30.0 mm
Rear Suspension 303
a) Method of suspension
Mono Shock
b) Swinging Arm Type
Tubular
c) Material of Swinging Arm
Twin Shock
Rectangular Box Section
STEEL
Wheels 304
a) Front wheel rim diameter (OD)
17 Inches
b) Width
1.85 Inches
a) Rear wheel rim diameter (OD)
17 Inches
b) Width
1.85 Inches
Oil Tank Capacity
1.0 liters
305 306
Fuel Tank 307
308
vss
a) Capacity
8.0 Litres
b) Material
STEEL SHEET WITH ZN - NI PLATING
Has the fuel system an electrical pump
No
Page 12 of 15
FMSCI HMN No. : 210MC001 Valid From : Valid till :
HONDA CB TWISTER Exhaust System
4 401
Detachable baffles
No
Weight of the silencer system with bolts for fixing the same **
3.400 kgs
403
Inner diameter of the bend of the silencer
16.7 mm
404
Anti Pollution System : Description
CATALYTIC CONVERTER
402 **
5. Brakes 2
NA
b) OD of piston in caliper
25.90 mm
NA mm
Yes
No
Yes
No
c1) Internal diameter
130 +/-1.5 mm
110 +/-1.5 mm
c2) Number of linings per wheel
TWO
TWO
c3) Developed length of lining
114 +/-1.5 mm
103 +/-1.5 mm
c4) Width of lining
25 +/- 1mm
25 +/- 1mm
d) Disc Brakes
Yes
No
Yes
d1) Number of pads per wheel
NA
d2) Number of calipers per wheel
NA
d3) Caliper Material
NA
No
d4) Thickness of new disc
+/- 1 mm
NA+/- 1 mm
d5) External diameter of disc
+/-1.5 mm
NA +/-1.5 mm
d6) External diameter of pads rubbing surface d7) Internal diameter of pads rubbing surface d8) Overall friction length of pads d9) Ventilated discs
6
Rear
a) Number of pistons per caliper
c) Drum Brakes
501
Front
+/-1.5 mm
+/-1.5 mm
+/-1.5 mm
+/-1.5 mm
+/-1.5 mm Yes
No
NA +/-1.5 mm Yes
No
Radiator Radiator Core Dimensions a) Height
601 b) Width c) Depth
vss
Page 13 of 15
FMSCI HMN No. : 210MC001 Valid From : Valid till :
HONDA CB TWISTER 7
Airbox a) Air Box
Yes
No
Yes
No
b) Material 701 c) RAM Air intake opening in fairing d) Dimension
vss
Page 14 of 15
FMSCI HMN No. : 210MC001 Valid From : Valid till :
HONDA CB TWISTER
Vehicle : Honda CB Twister Optional Variant 5. Brakes
Front
d) Disc Brakes
501
Yes
No
Yes
No
d1) Number of pads per wheel
2
NA
d2) Number of calipers per wheel
1
NA
d3) Caliper Material
Aluminium Casting
NA
d4) Thickness of new disc
4+/- 1 mm
NA+/- 1 mm
d5) External diameter of disc
215.4 +/-1.5 mm
NA +/-1.5 mm
d6) External diameter of pads rubbing surface d7) Internal diameter of pads rubbing surface d8) Overall friction length of pads d9) Ventilated discs
vss
Rear
+/-1.5 mm
+/-1.5 mm
+/-1.5 mm
+/-1.5 mm
76.5 +/-1.5 mm Yes
No
NA +/-1.5 mm Yes
No
Page 15 of 15
Related Documents 171j1w
Manual Honda Cb 110 535b2j
May 2021 0
Manual Honda Cb 125s 1q2828
December 2019 95
Honda Cb Twister(110cc) Manual 4f2e1y
November 2019 45
Honda Cb 250 - Manual Taller 2w6u14
December 2019 54
Manual Honda Cb 150 Invicta 20758
November 2019 517
Honda Cb 125 K5 152k6f
September 2022 0More Documents from "Rahul Naik" 3t3d3b
Honda Cb Twister(110cc) Manual 4f2e1y
November 2019 45
International Finance-factors Affecting International Investments 61636c
February 2022 0
Outsourcing 3x4710
April 2022 0
Objective Question On Marketing Management Pdf 4k3fu
December 2019 71
I Offer My Life Lyrics And Chords (key _ E).pdf 353n67
December 2019 423
