Fuse box diagram Locate fuses and relays

Fuse box diagram Jeep Grand Cherokee 1999-2004 For the Jeep Grand Cherokee second generation 1999, 2000, 2001, 2002, 2003, 2004 model year. Fuse box located. The fuse is on the lower instrument just to the left of the steering column. A label is stamped on the fuse cover to identify each fuse for ease of replacement.

Fuse box diagram.

legend.

Cavity

Fuse

Description

1

Spare

2

Spare

3

10 Amp Red

Headlight High Beam Left

4

15 Amp Lt. Blue

Flasher

5

25 Amp Natural

Radio/Amplifier

6

15 Amp Lt. Blue

Park Lights

7

10 Amp Red

Interior Lights

8

15 Amp Lt. Blue

Overhead Console, Rear Wiper, IP Lights, Rear Flipper Glass Solenoid

9

20 Amp Yellow

Power Outlets

10

20 Amp Yellow

Adjustable Pedals

11

10 Amp Red

Rear Window Defroster Indicator

12

10 Amp Red

Auto Shut Down Relay/ "Fuel"

13

Spare

14

10 Amp Red

Headlight Low Left

15

10 Amp Red

Headlight Low Right

16

10 Amp Red

Headlight High Right

17

10 Amp Red

Instrument Cluster, Diagnostic Connector

18

30 Amp

Trailer Tow

19

10 Amp Red

Antilock Brakes

20

10 Amp Red

Ignition Run

21

10 Amp Red

Ignition Run/Start – PDC

22

10 Amp Red

Ignition Run/Start

23

15 Amp Lt. Blue

Brake Switch

24

15 Amp Lt. Blue

Fog Lamps

25

20 Amp Yellow

Accessory Delay Relay (Sunroof)

26

15 Amp Lt. Blue

Cigar

27

15 Amp Lt. Blue

Rear Fog Lamps (If Equipped)

28

10 Amp Red

Body Control Module, Acc/ Run

29

10 Amp Red

Rear Wiper Switch, Washer Motors

30

15 Amp Lt. Blue

Radio

31

10 Amp Red

Ignition Start

32

10 Amp Red

Ignition Run/Start-Airbag

33

10 Amp Red

Ignition Run/Only – Airbag

C1

20 Amp

Wiper (Circuit Breaker)

C2

20 Amp

Seats (Circuit Breaker)

C3

Spare

Underhood Fuses (Power Distribution Center) Jeep Grand Cherokee 1999-2004. Your vehicle is equipped with an electrical power distribution center located in the engine compartment near the battery. This power center houses plug-in “Cartridge” fuses which replace in-line fusible links. The power center also contains “Mini” fuses and plug-in full and mini ISO relays. A label inside the latching cover of the center identifies each component for ease of replacement, if necessary.

fuse box diagram.

1. Blower motor 40A 2. Junction bus power 40A 3. Junction bus pwr lamps 50A 4. ABS pump 40A 5. TCM power 30A 6. ASD 30A 7. Junction block pwr 50A 8. Ignition starter 40A 9. (not used) 10. Radiator fan relay 40A 11. (Empty, for IOD fuse storage) 12. Power windows 50A 13. OSS pump 60A 14. Ignition switch 40A 15. JB power 50A (IOD) 16. 02 sensor 15A 17. Cluster / Data link 10A 18. Horn 15A 19. PCM 10A 20. OSS module 20A 21. AC clutch 15A 22. ECM 10A 23. Cabin heater relay 15A 24. Fuel pump 20A 25. ABS main relay 20A 26. Injectors 15A 27. Rear pwr outlet 20A 28. TCM 15A 29. Fuel pump 30. Starter motor 31. TCM 32. Wiper On/Off 33. Wiper Hi-Low 34. Rear 02 sensor/Viscous cabin heater 35. Backup lamp 36. AC clutch 37. Horn 38. Auto Shut Down 39. OSS module/Glow plug 40. OSS pump/Glow plug
