FUENTE ESTABILIZADA DE 2 A 30V 5A
FUNCIONAMIENTO El transformador se conecta en la entrada de CA reduciendo la tensión de la línea de 110 Vca a 24 Vac. Esta tensión es rectificada por los 4 diodos rectificadores D1 a D4 (P600), que están conectados en configuración puente. Por medio del capacitor de 3300uF/40V se filtra esta tensión para obtener una tensión prácticamente continua. Esto sucede ya que durante el período ascendente del pulso el capacitor se carga y cuando llega el pulso descendente comienza a descargarse, pero como el período de tiempo es muy corto y el capacitor tiene una capacidad elevada el mismo se descargará muy poco. El condensador C2, lleva las frecuencias elevadas a tierra de manera que exista una entrada lo mas “limpia” posible al regulador de voltaje LM317. La salida de voltaje se ajusta mediante P1 de 5K. El capacitor C3 mejora la estabilidad de la tensión de salida. Como el LM317 no puede proporcionar una corriente alta, el circuito incluye dos transistores de potencia Q2 y Q3 montados en paralelo para mayor disipación. Estos transistores están a su vez controlados por Q1 que recibe la salida del regulador LM317. Las resistencias R3 y R4 están montadas en paralelo y sirven para polarizar las bases de Q2 y Q3. A la salida, dos condensadores, C4(Poliester) y C5(Electrolitico) bloquean cualquier influencia de alta frecuencia que pueda proceder de la propia carga.
LM117/217 LM317 1.2V TO 37V VOLTAGE REGULATOR ■ ■ ■ ■
■
OUTPUT VOLTAGE RANGE: 1.2 TO 37V OUTPUT CURRENT IN EXCESS OF 1.5A 0.1% LINE AND LOAD REGULATION FLOATING OPERATION FOR HIGH VOLTAGES COMPLETE SERIES OF PROTECTIONS: CURRENT LIMITING, THERMAL SHUTDOWN AND SOA CONTROL
DESCRIPTION The LM117/LM217/LM317 are monolithic integrated circuit in TO-220, TO-220FP, TO-3 and D2PAK packages intended for use as positive adjustable voltage regulators. They are designed to supply more than 1.5A of load current with an output voltage adjustable over a 1.2 to 37V range. The nominal output voltage is selected by means of only a resistive divider, making the device exceptionally easy to use and eliminating the stocking of many fixed regulators.
TO-220
D2PAK
TO-220FP
TO-3
Figure 1: Schematic Diagram
September 2004
Rev. 10
1/15
LM117/217/317 Table 1: Absolute Maximum Ratings Symbol VI - VO IO
Parameter
Value
Input-Reference Differential Voltage
Unit
40
Output Current
V
Internally Limited
Operating Junction Temperature for: Top Ptot
Power Dissipation
Tstg
Storage Temperature
LM117 LM217 LM317
-55 to 150 -25 to 150 0 to 125
°C
Internally Limited -65 to 150
°C
Absolute Maximum Ratings are those values beyond which damage to the device may occur. Functional operation under these condition is not implied.
Table 2: Thermal Data Symbol
Parameter
D2PAK
TO-220
TO-220FP
TO-3
Unit
Rthj-case
Thermal Resistance Junction-case
Max
3
3
5
4
°C/W
Rthj-amb
Thermal Resistance Junction-ambient
Max
62.5
50
60
35
°C/W
Figure 2: Connection Diagram (top view)
TO-220
TO-220FP
D2PAK
TO-3
Table 3: Order Codes
2/15
TYPE
TO-220
D2PAK
LM117 LM217 LM317
LM217T LM317T
LM217D2T LM317D2T
TO-220FP
TO-3
LM317P
LM117K LM217K LM317K
LM117/217/317 Figure 3: Basic Adjustable Regulator
Table 4: Electrical Characteristics For LM117/LM217 (VI - VO = 5 V, IO = 500 mA, IMAX = 1.5 A and PMAX = 20 W, TJ = -55 to 150°C for LM117, TJ = -25 to 150°C for LM217, unless otherwise specified). Symbol
Parameter
Test Conditions
Min.
Typ.
Max.
Unit
∆VO
Line Regulation
VI - VO = 3 to 40 V
TJ = 25°C
0.01
0.02
%/V
∆VO
Load Regulation
VO ≤ 5 V IO = 10 mA to IMAX
TJ = 25°C
0.02 5
0.05 15
mV
VO ≥ 5 V IO = 10 mA to IMAX
TJ = 25°C
20 0.1
50 0.3
%
0.3 50
1 100
µA
0.2
5
µA
1.25
1.3
V
IADJ
Adjustment Pin Current
∆IADJ
Adjustment Pin Current
VI - VO = 2.5 to 40V
VREF
Reference Voltage (between pin 3 and pin 1)
VI - VO = 2.5 to 40V IO= 10 mA to IMAX PD ≤ PMAX
∆VO/VO Output Voltage Temperature Stability IO(min) Minimum Load Current IO(max)
eN SVR
Maximum Load Current
Output Noise Voltage (percentage of VO)
IO = 10 mA to IMAX 1.2
1 VI - VO = 40 V
3.5
VI - VO ≤ 15 V
PD < PMAX
VI - VO = 40 V TJ = 25°C
PD < PMAX
B = 10Hz to 100KHz
Supply Voltage Rejection (*) TJ = 25°C f = 120Hz
1.5
5
mA A
0.4
TJ = 25°C CADJ=0 CADJ=10µF
2.2
%
66
0.003
%
65
dB
80
(*) CADJ is connected between pin 1 and ground.
3/15
LM117/217/317 Table 5: Electrical Characteristics For LM317 (VI - VO = 5 V, IO = 500 mA, IMAX = 1.5 A and PMAX = 20 W, TJ = 0 to 125°C, unless otherwise specified). Symbol ∆VO ∆VO
Parameter Line Regulation Load Regulation
IADJ
Adjustment Pin Current
∆IADJ
Adjustment Pin Current
VREF
Reference Voltage (between pin 3 and pin 1)
Test Conditions VI - VO = 3 to 40 V
Min.
0.01
0.04
%/V
VO ≤ 5 V IO = 10 mA to IMAX
TJ = 25°C
0.07 25
mV
VO ≥ 5 V IO = 10 mA to IMAX
TJ = 25°C
20 0.1
70 0.5
%
0.3 50
1.5 100
µA
0.2
5
µA
1.25
1.3
V
VI - VO = 2.5 to 40 V IO = 10 mA to IMAX VI - VO = 2.5 to 40 V IO = 10 mA to IMAX PD ≤ PMAX
VI - VO = 40 V VI - VO ≤ 15 V
PD < PMAX
VI - VO = 40 V TJ=25°C
PD < PMAX
SVR
Output Noise Voltage (percentage of VO)
Unit
0.02 5
IO(max)
eN
Max.
TJ = 25°C
∆VO/VO Output Voltage Temperature Stability IO(min) Minimum Load Current Maximum Load Current
Typ.
1.2
1
B = 10Hz to 100KHz
Supply Voltage Rejection (*) TJ = 25°C f = 120Hz
3.5 1.5
10
2.2
4/15
A
CADJ=0 66
0.003
%
65
dB
80
(*) CADJ is connected between pin 1 and ground.
Figure 4: Output Current vs Input-output Differential Voltage
mA
0.4
TJ = 25°C
CADJ=10µF
%
Figure 5: Dropout Voltage vs Junction Temperature
LM117/217/317
Figure 6: Reference Voltage vs Junction
Figure 7: Basic Adjustable Regulator
APPLICATION INFORMATION The LM117/217/317 provides an internal reference voltage of 1.25V between the output and adjustments terminals. This is used to set a constant current flow across an external resistor divider (see fig. 4), giving an output voltage VO of: VO = VREF (1 + R2/R1) + IADJ R2 The device was designed to minimize the term IADJ (100µA max) and to maintain it very constant with line and load changes. Usually, the error term IADJ × R2 can be neglected. To obtain the previous requirement, all the regulator quiescent current is returned to the output terminal, imposing a minimum load current condition. If the load is insufficient, the output voltage will rise. Since the LM117/217317 is a floating regulator and "sees" only the input-to-output differential voltage, supplies of very high voltage with respect to ground can be regulated as long as the maximum input-to-output differential is not exceeded. Furthermore, programmable regulator are easily obtainable and, by connecting a fixed resistor between the adjustment and output, the device can be used as a precision current regulator. In order to optimize the load regulation, the current set resistor R1 (see fig. 4) should be tied as close as possible to the regulator, while the ground terminal of R2 should be near the ground of the load to provide remote ground sensing. Performance may be improved with added capacitance as follow: An input by capacitor of 0.1µF An adjustment terminal to ground 10µF capacitor to improve the ripple rejection of about 15 dB (CADJ). An 1µF tantalum (or 25µFAluminium electrolytic) capacitor on the output to improve transient response. In additional to external capacitors, it is good practice to add protection diodes, as shown in fig.5. D1 protect the device against input short circuit, while D2 protect against output short circuit for capacitance discharging. 5/15
LM117/217/317 Figure 8: Voltage Regulator with Protection Diodes
D1 protect the device against input short circuit, while D2 protects against output short circuit for capacitors discharging.
Figure 9: Slow Turn-on 15V Regulator
Figure 10: Current Regulator
Vref 1.25V IO = + IADJ ≈ R1 R1
6/15
LM117/217/317 Figure 11: 5V Electronic Shut-down Regulator
Figure 12: Digitally Selected Outputs
(R2 sets maximum VO)
Figure 13: Battery Charger (12V)
* RS sets output impedance of charger ZO = RS (1 + R2/R1). Use of RS allows low charging rates whit fully charged battery.
7/15
LM117/217/317 Figure 14: Current Limited 6V Charger
* R3 sets peak current (0.6A for 1 0). ** C1 recommended to filter out input transients
8/15
LM117/217/317
TO-3 MECHANICAL DATA mm.
DIM.
MIN.
A
inch
TYP
MAX.
MIN.
TYP.
11.85
B
0.96
MAX.
0.466
1.05
1.10
0.037
0.041
0.043
C
1.70
0.066
D
8.7
0.342
E
20.0
0.787
G
10.9
0.429
N
16.9
0.665
P
26.2
R
3.88
1.031
4.09
U
0.152
39.5
V
1.555
30.10
1.185
A
P
D C
O
N
B
V
E
G
U
0.161
R P003C/C 9/15
LM117/217/317
TO-220 MECHANICAL DATA DIM.
mm. MIN.
TYP
inch MAX.
MIN.
TYP.
MAX.
A
4.40
4.60
0.173
0.181
C
1.23
1.32
0.048
0.051
D
2.40
2.72
0.094
0.107
D1
1.27
0.050
E
0.49
0.70
0.019
0.027
F
0.61
0.88
0.024
0.034
F1
1.14
1.70
0.044
0.067
F2
1.14
1.70
0.044
0.067
G
4.95
5.15
0.194
0.203
G1
2.4
2.7
0.094
0.106
H2
10.0
10.40
0.393
0.409
L2
16.4
0.645
L4
13.0
14.0
0.511
0.551
L5
2.65
2.95
0.104
0.116
L6
15.25
15.75
0.600
0.620
L7
6.2
6.6
0.244
0.260
L9
3.5
3.93
0.137
0.154
DIA.
3.75
3.85
0.147
0.151
P011C 10/15
LM117/217/317
TO-220FP MECHANICAL DATA mm. DIM.
MIN.
TYP
inch MAX.
MIN.
TYP.
MAX.
A
4.40
4.60
0.173
0.181
B
2.5
2.7
0.098
0.106
D
2.5
2.75
0.098
0.108
E
0.45
0.70
0.017
0.027
F
0.75
1
0.030
0.039
F1
1.15
1.50
0.045
0.059
F2
1.15
1.50
0.045
0.059
G
4.95
5.2
0.194
0.204
G1
2.4
2.7
0.094
0.106
H
10.0
10.40
0.393
L2 L3
16
0.409 0.630
28.6
30.6
1.126
1.204
L4
9.8
10.6
0.385
0.417
L5
2.9
3.6
0.114
0.142
L6
15.9
16.4
0.626
0.645
L7
9
9.3
0.354
0.366
DIA.
3
3.2
0.118
0.126
7012510A-H
11/15
LM117/217/317
D2PAK MECHANICAL DATA mm.
inch
DIM. MIN.
TYP
MAX.
MIN.
TYP.
MAX.
A
4.4
4.6
0.173
0.181
A1
2.49
2.69
0.098
0.106
A2
0.03
0.23
0.001
0.009
B
0.7
0.93
0.027
0.036
B2
1.14
1.7
0.044
0.067
C
0.45
0.6
0.017
0.023
C2
1.23
1.36
0.048
0.053
D
8.95
9.35
0.352
0.368
10.4
0.393
4.88
5.28
0.192
D1 E
8 10
E1 G
0.315
8.5
0.409 0.335 0.208
L
15
15.85
0.590
0.624
L2
1.27
1.4
0.050
0.055
L3
1.4
1.75
0.055
0.068
M
2.4
3.2
0.094
R V2
0.4 0˚
0.126 0.016
8˚
0˚
8˚
P011P6G 12/15
LM117/217/317
Tape & Reel D2PAK-P 2PAK-D 2PAK/A-P 2PAK/A MECHANICAL DATA mm.
inch
DIM. MIN.
TYP
A
MAX.
MIN.
TYP.
180 13.0
7.086
C
12.8
D
20.2
0.795
N
60
2.362
T
13.2
MAX.
0.504
0.512
14.4
0.519
0.567
Ao
10.50
10.6
10.70
0.413
0.417
0.421
Bo
15.70
15.80
15.90
0.618
0.622
0.626
Ko
4.80
4.90
5.00
0.189
0.193
0.197
Po
3.9
4.0
4.1
0.153
0.157
0.161
P
11.9
12.0
12.1
0.468
0.472
0.476
13/15
LM117/217/317 Table 6: Revision History Date
Revision
01-Sep-2004
10
14/15
Description of Changes Mistake VREF ==> VO, tables 1, 4 and 5.
LM117/217/317
Information furnished is believed to be accurate and reliable. However, STMicroelectronics assumes no responsibility for the consequences of use of such information nor for any infringement of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of STMicroelectronics. Specifications mentioned in this publication are subject to change without notice. This publication supersedes and replaces all information previously supplied. STMicroelectronics products are not authorized for use as critical components in life devices or systems without express written approval of STMicroelectronics. The ST logo is a ed trademark of STMicroelectronics All other names are the property of their respective owners © 2004 STMicroelectronics - All Rights Reserved STMicroelectronics group of companies Australia - Belgium - Brazil - Canada - China - Czech Republic - Finland - - - Hong Kong - India - Israel - Italy - Japan Malaysia - Malta - Morocco - Singapore - Spain - Sweden - Switzerland - United Kingdom - United States of America www.st.com
15/15
This datasheet has been from: www.datasheetcatalog.com Datasheets for electronics components.
2N2905 2N2907 GENERAL PURPOSE AMPLIFIERS AND SWITCHES DESCRIPTION The 2N2905 and 2N2907 are silicon planar epitaxial PNP transistors in Jedec TO-39 (for 2N2905) and in Jedec TO-18 (for 2N2907) metal case. They are designed for high speed saturated switching and general purpose application. 2N2905 approved to CECC 50002-102, 2N2907 approved to CECC 50002-103 available on request. TO-18
TO-39
INTERNAL SCHEMATIC DIAGRAM
ABSOLUTE MAXIMUM RATINGS Symbol
Value
Unit
V CBO
Collector-Base Voltage (IE = 0)
-60
V
V CEO
Collector-Emitter Voltage (I B = 0)
-40
V
V EBO
Emitter-Base Voltage (I C = 0)
-5
V
-0.6
A
0.6 0.4
W W
3 1.8
W W
IC P t ot
T stg Tj
Parameter
Collector Current o
Total Dissipation at T amb ≤ 25 C for 2N2905 for 2N2907 at T case ≤ 25 o C for 2N2905 for 2N2907 St orage Temperature Max. Operating Junction Temperature
November 1997
-65 to 200
o
C
200
o
C 1/5
2N2905/2N2907 THERMAL DATA
R t hj-ca se R t hj- amb
Thermal Resistance Junction-Case Thermal Resistance Junction-Ambient
Max Max
T O-39
TO -18
58.3 292
97.3 437.5
o o
C/W C/W
ELECTRICAL CHARACTERISTICS (Tcase = 25 oC unless otherwise specified) Symb ol I CBO
Parameter
Test Cond ition s
Min.
Typ .
Max.
Un it
-20 -20
nA µA
Collector Cut-off Current (IE = 0)
V CB = -50 V V CB = -50 V
I CEX
Collector Cut-off Current (V BE = -0.5V)
V CE = -30 V
-50
nA
I BEX
Base Cut-off Current (V BE = -0.5V)
V CE = -30 V
-50
nA
o
Tc ase = 150 C
V ( BR)CBO ∗ Collector-Base Breakdown Voltage (I E = 0)
I C = -10 µA
-60
V
V ( BR)CEO ∗ Collector-Emitter Breakdown Voltage (I B = 0)
I C = -10 mA
-40
V
V (BR)EBO ∗ Emitter-Base Breakdown Voltage (I C = 0)
I E = -10 µA
-5
V
V CE(sat )∗
Collector-Emitter Saturation Voltage
I C = -150 mA I C = -500 mA
IB = -15 mA IB = -50 mA
-0.4 -1.6
V V
V BE(s at)∗
Base-Emitter Saturation Voltage
I C = -150 mA I C = -500 mA
IB = -15 mA IB = -50 mA
-1.3 -2.6
V V
DC Current G ain
IC IC IC IC IC
V CE = -10 V V CE = -10 V V CE = -10 V V CE = -10 V V CE = -10 V
hFE∗
fT
-0.1 mA -1 mA -10 mA -150 mA -500 mA
Transition F requency
V CE = -20 V I C = -50 mA
C EBO
Emitter Base Capacitance
IC = 0
V EB = -2 V
f = 100 MHz
C CBO
Collector Base Capacitance
IE = 0
V CB = -10 V
td
Delay Time
V CC = -30 V I B1 = -15 mA
tr
Rise Time
V CC = -30 V I B1 = -15 mA
ts tf
f = 1MHz
35 50 75 100 30
300
200
MHz 30
pF
8
pF
I C = -150 mA
10
ns
I C = -150 mA
40
ns
Storage Time
V CC = -6 V I C = -150 mA I B1 = -IB2 = -15 mA
80
ns
Fall T ime
V CC = -6 V I C = -150 mA I B1 = -IB2 = -15 mA
30
ns
∗ Pulsed: Pulse duration = 300 µs, duty cycle ≤ 1 %
2/5
= = = = =
f = 1MHz
2N2905/2N2907
TO-18 MECHANICAL DATA mm
inch
DIM. MIN. A
TYP.
MAX.
MIN.
TYP.
12.7
MAX.
0.500
B
0.49
0.019
D
5.3
0.208
E
4.9
0.193
F
5.8
0.228
G
2.54
0.100
H
1.2
0.047
I
1.16
0.045
L
45o
45o
D
A
G I
E
F
H
B
L C
0016043
3/5
2N2905/2N2907
TO-39 MECHANICAL DATA mm
inch
DIM. MIN. A
TYP.
MAX.
MIN.
12.7
TYP.
MAX.
0.500
B
0.49
0.019
D
6.6
0.260
E
8.5
0.334
F
9.4
0.370
G
5.08
0.200
H
1.2
0.047
I
0.9
0.035 45o (typ.)
L
D
A
G I
E
F
H
B
L
P008B 4/5
2N2905/2N2907
Information furnished is believed to be accurate and reliable. However, SGS-THOMSON Microelectronics assumes no responsability for the consequences of use of such information nor for any infringement of patents or other rights of third parties which may results from its use. No license is granted by implication or otherwise under any patent or patent rights of SGS-THOMSON Microelectronics. Specifications mentioned in this publication are subject to change without notice. This publication supersedes and replaces all information previously supplied. SGS-THOMSON Microelectronics products are not authorized for use as critical components in life devices or systems without express written approval of SGS-THOMSON Microelectonics. 1997 SGS-THOMSON Microelectronics - Printed in Italy - All Rights Reserved SGS-THOMSON Microelectronics GROUP OF COMPANIES Australia - Brazil - Canada - China - - - Italy - Japan - Korea - Malaysia - Malta - Morocco - The Netherlands Singapore - Spain - Sweden - Switzerland - Taiwan - Thailand - United Kingdom - U.S.A ...
5/5
This datasheet has been from: www.datasheetcatalog.com Datasheets for electronics components.
2N3055 MJ2955
®
COMPLEMENTARY SILICON POWER TRANSISTORS ■
■
STMicroelectronics PREFERRED SALESTYPES COMPLEMENTARY NPN-PNP DEVICES
DESCRIPTION The 2N3055 is a silicon Epitaxial-Base Planar NPN transistor mounted in Jedec TO-3 metal case. It is intended for power switching circuits, series and shunt regulators, output stages and high fidelity amplifiers. The complementary PNP type is MJ2955.
1 2 TO-3
INTERNAL SCHEMATIC DIAGRAM
ABSOLUTE MAXIMUM RATINGS Symbol
Parameter
V CBO
Collector-Base Voltage (I E = 0)
V CER V CEO
Collector-Emitter Voltage (R BE ≤ 100Ω) Collector-Emitter Voltage (I B = 0)
V EBO
Emitter-Base Voltage (I C = 0)
IC
Collector Current
IB
Base Current
P tot T stg Tj
Total Dissipation at T c ≤ 25 o C Storage Temperature Max. Operating Junction Temperature
Value NPN
2N3055
PNP
MJ2955
Unit
100
V
70
V
60
V
7
V
15
A
7
A
115
W
-65 to 200
o
C
200
o
C
For PNP types voltage and current values are negative.
August 1999
1/4
2N3055 / MJ2955 THERMAL DATA R thj-case
Thermal Resistance Junction-case
Max
o
1.5
C/W
ELECTRICAL CHARACTERISTICS (Tcase = 25 oC unless otherwise specified) Symbol
Parameter
Test Conditions
I CEX
Collector Cut-off Current (V BE = -1.5V)
V CE = 100 V V CE = 100 V
I CEO
Collector Cut-off Current (I B = 0)
V CE = 30 V
IEBO
Emitter Cut-off Current (I C = 0)
V EB = 7 V
Min.
T j = 150 o C
Typ.
Max.
Unit
1 5
mA mA
0.7
mA
5
mA
V CEO(sus) ∗ Collector-Emitter Sustaining Voltage (I B = 0)
I C = 200 mA
60
V
VCER(sus) ∗ Collector-Emitter Sustaining Voltage (R BE = 100 Ω)
I C = 200 mA
70
V
VCE(sat) ∗
Collector-Emitter Saturation Voltage
IC = 4 A I C = 10 A
I B = 400 mA I B = 3.3 A
V BE ∗
Base-Emitter Voltage
IC = 4 A
V CE = 4 A
h FE ∗
DC Current Gain
IC = 4 A I C = 10 A
V CE = 4 A V CE = 4 A
20 5
fT
Transition frequency
I C = 0.5 A
V CE = 10 V
3
MHz
Is/b ∗
Second Breakdown Collector Current
V CE = 40 V
2.87
A
∗ Pulsed: Pulse duration = 300 µs, duty cycle 1.5 % For PNP types voltage and current values are negative.
2/4
1 3
V V
1.8
V
70
2N3055 / MJ2955
TO-3 MECHANICAL DATA mm
DIM. MIN.
inch
TYP.
MAX.
MIN.
TYP.
MAX.
A
11.00
13.10
0.433
0.516
B
0.97
1.15
0.038
0.045
C
1.50
1.65
0.059
0.065
D
8.32
8.92
0.327
0.351
E
19.00
20.00
0.748
0.787
G
10.70
11.10
0.421
0.437
N
16.50
17.20
0.649
0.677
P
25.00
26.00
0.984
1.023
R
4.00
4.09
0.157
0.161
U
38.50
39.30
1.515
1.547
V
30.00
30.30
1.187
1.193
A
P
C
O
N
B
V
E
G
U
D
R
P003F 3/4
2N3055 / MJ2955
Information furnished is believed to be accurate and reliable. However, STMicroelectronics assumes no responsibility for the consequences of use of such information nor for any infringement of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of STMicroelectronics. Specification mentioned in this publication are subject to change without notice. This publication supersedes and replaces all information previously supplied. STMicroelectronics products are not authorized for use as critical components in life devices or systems without express written approval of STMicroelectronics. The ST logo is a trademark of STMicroelectronics © 1999 STMicroelectronics – Printed in Italy – All Rights Reserved STMicroelectronics GROUP OF COMPANIES Australia - Brazil - Canada - China - - - Italy - Japan - Korea - Malaysia - Malta - Mexico - Morocco - The Netherlands Singapore - Spain - Sweden - Switzerland - Taiwan - Thailand - United Kingdom - U.S.A.
4/4
http://www.st.com .
This datasheet has been from: www.datasheetcatalog.com Datasheets for electronics components.
FUNCIONAMIENTO El transformador se conecta en la entrada de CA reduciendo la tensión de la línea de 110 Vca a 24 Vac. Esta tensión es rectificada por los 4 diodos rectificadores D1 a D4 (P600), que están conectados en configuración puente. Por medio del capacitor de 3300uF/40V se filtra esta tensión para obtener una tensión prácticamente continua. Esto sucede ya que durante el período ascendente del pulso el capacitor se carga y cuando llega el pulso descendente comienza a descargarse, pero como el período de tiempo es muy corto y el capacitor tiene una capacidad elevada el mismo se descargará muy poco. El condensador C2, lleva las frecuencias elevadas a tierra de manera que exista una entrada lo mas “limpia” posible al regulador de voltaje LM317. La salida de voltaje se ajusta mediante P1 de 5K. El capacitor C3 mejora la estabilidad de la tensión de salida. Como el LM317 no puede proporcionar una corriente alta, el circuito incluye dos transistores de potencia Q2 y Q3 montados en paralelo para mayor disipación. Estos transistores están a su vez controlados por Q1 que recibe la salida del regulador LM317. Las resistencias R3 y R4 están montadas en paralelo y sirven para polarizar las bases de Q2 y Q3. A la salida, dos condensadores, C4(Poliester) y C5(Electrolitico) bloquean cualquier influencia de alta frecuencia que pueda proceder de la propia carga.
LM117/217 LM317 1.2V TO 37V VOLTAGE REGULATOR ■ ■ ■ ■
■
OUTPUT VOLTAGE RANGE: 1.2 TO 37V OUTPUT CURRENT IN EXCESS OF 1.5A 0.1% LINE AND LOAD REGULATION FLOATING OPERATION FOR HIGH VOLTAGES COMPLETE SERIES OF PROTECTIONS: CURRENT LIMITING, THERMAL SHUTDOWN AND SOA CONTROL
DESCRIPTION The LM117/LM217/LM317 are monolithic integrated circuit in TO-220, TO-220FP, TO-3 and D2PAK packages intended for use as positive adjustable voltage regulators. They are designed to supply more than 1.5A of load current with an output voltage adjustable over a 1.2 to 37V range. The nominal output voltage is selected by means of only a resistive divider, making the device exceptionally easy to use and eliminating the stocking of many fixed regulators.
TO-220
D2PAK
TO-220FP
TO-3
Figure 1: Schematic Diagram
September 2004
Rev. 10
1/15
LM117/217/317 Table 1: Absolute Maximum Ratings Symbol VI - VO IO
Parameter
Value
Input-Reference Differential Voltage
Unit
40
Output Current
V
Internally Limited
Operating Junction Temperature for: Top Ptot
Power Dissipation
Tstg
Storage Temperature
LM117 LM217 LM317
-55 to 150 -25 to 150 0 to 125
°C
Internally Limited -65 to 150
°C
Absolute Maximum Ratings are those values beyond which damage to the device may occur. Functional operation under these condition is not implied.
Table 2: Thermal Data Symbol
Parameter
D2PAK
TO-220
TO-220FP
TO-3
Unit
Rthj-case
Thermal Resistance Junction-case
Max
3
3
5
4
°C/W
Rthj-amb
Thermal Resistance Junction-ambient
Max
62.5
50
60
35
°C/W
Figure 2: Connection Diagram (top view)
TO-220
TO-220FP
D2PAK
TO-3
Table 3: Order Codes
2/15
TYPE
TO-220
D2PAK
LM117 LM217 LM317
LM217T LM317T
LM217D2T LM317D2T
TO-220FP
TO-3
LM317P
LM117K LM217K LM317K
LM117/217/317 Figure 3: Basic Adjustable Regulator
Table 4: Electrical Characteristics For LM117/LM217 (VI - VO = 5 V, IO = 500 mA, IMAX = 1.5 A and PMAX = 20 W, TJ = -55 to 150°C for LM117, TJ = -25 to 150°C for LM217, unless otherwise specified). Symbol
Parameter
Test Conditions
Min.
Typ.
Max.
Unit
∆VO
Line Regulation
VI - VO = 3 to 40 V
TJ = 25°C
0.01
0.02
%/V
∆VO
Load Regulation
VO ≤ 5 V IO = 10 mA to IMAX
TJ = 25°C
0.02 5
0.05 15
mV
VO ≥ 5 V IO = 10 mA to IMAX
TJ = 25°C
20 0.1
50 0.3
%
0.3 50
1 100
µA
0.2
5
µA
1.25
1.3
V
IADJ
Adjustment Pin Current
∆IADJ
Adjustment Pin Current
VI - VO = 2.5 to 40V
VREF
Reference Voltage (between pin 3 and pin 1)
VI - VO = 2.5 to 40V IO= 10 mA to IMAX PD ≤ PMAX
∆VO/VO Output Voltage Temperature Stability IO(min) Minimum Load Current IO(max)
eN SVR
Maximum Load Current
Output Noise Voltage (percentage of VO)
IO = 10 mA to IMAX 1.2
1 VI - VO = 40 V
3.5
VI - VO ≤ 15 V
PD < PMAX
VI - VO = 40 V TJ = 25°C
PD < PMAX
B = 10Hz to 100KHz
Supply Voltage Rejection (*) TJ = 25°C f = 120Hz
1.5
5
mA A
0.4
TJ = 25°C CADJ=0 CADJ=10µF
2.2
%
66
0.003
%
65
dB
80
(*) CADJ is connected between pin 1 and ground.
3/15
LM117/217/317 Table 5: Electrical Characteristics For LM317 (VI - VO = 5 V, IO = 500 mA, IMAX = 1.5 A and PMAX = 20 W, TJ = 0 to 125°C, unless otherwise specified). Symbol ∆VO ∆VO
Parameter Line Regulation Load Regulation
IADJ
Adjustment Pin Current
∆IADJ
Adjustment Pin Current
VREF
Reference Voltage (between pin 3 and pin 1)
Test Conditions VI - VO = 3 to 40 V
Min.
0.01
0.04
%/V
VO ≤ 5 V IO = 10 mA to IMAX
TJ = 25°C
0.07 25
mV
VO ≥ 5 V IO = 10 mA to IMAX
TJ = 25°C
20 0.1
70 0.5
%
0.3 50
1.5 100
µA
0.2
5
µA
1.25
1.3
V
VI - VO = 2.5 to 40 V IO = 10 mA to IMAX VI - VO = 2.5 to 40 V IO = 10 mA to IMAX PD ≤ PMAX
VI - VO = 40 V VI - VO ≤ 15 V
PD < PMAX
VI - VO = 40 V TJ=25°C
PD < PMAX
SVR
Output Noise Voltage (percentage of VO)
Unit
0.02 5
IO(max)
eN
Max.
TJ = 25°C
∆VO/VO Output Voltage Temperature Stability IO(min) Minimum Load Current Maximum Load Current
Typ.
1.2
1
B = 10Hz to 100KHz
Supply Voltage Rejection (*) TJ = 25°C f = 120Hz
3.5 1.5
10
2.2
4/15
A
CADJ=0 66
0.003
%
65
dB
80
(*) CADJ is connected between pin 1 and ground.
Figure 4: Output Current vs Input-output Differential Voltage
mA
0.4
TJ = 25°C
CADJ=10µF
%
Figure 5: Dropout Voltage vs Junction Temperature
LM117/217/317
Figure 6: Reference Voltage vs Junction
Figure 7: Basic Adjustable Regulator
APPLICATION INFORMATION The LM117/217/317 provides an internal reference voltage of 1.25V between the output and adjustments terminals. This is used to set a constant current flow across an external resistor divider (see fig. 4), giving an output voltage VO of: VO = VREF (1 + R2/R1) + IADJ R2 The device was designed to minimize the term IADJ (100µA max) and to maintain it very constant with line and load changes. Usually, the error term IADJ × R2 can be neglected. To obtain the previous requirement, all the regulator quiescent current is returned to the output terminal, imposing a minimum load current condition. If the load is insufficient, the output voltage will rise. Since the LM117/217317 is a floating regulator and "sees" only the input-to-output differential voltage, supplies of very high voltage with respect to ground can be regulated as long as the maximum input-to-output differential is not exceeded. Furthermore, programmable regulator are easily obtainable and, by connecting a fixed resistor between the adjustment and output, the device can be used as a precision current regulator. In order to optimize the load regulation, the current set resistor R1 (see fig. 4) should be tied as close as possible to the regulator, while the ground terminal of R2 should be near the ground of the load to provide remote ground sensing. Performance may be improved with added capacitance as follow: An input by capacitor of 0.1µF An adjustment terminal to ground 10µF capacitor to improve the ripple rejection of about 15 dB (CADJ). An 1µF tantalum (or 25µFAluminium electrolytic) capacitor on the output to improve transient response. In additional to external capacitors, it is good practice to add protection diodes, as shown in fig.5. D1 protect the device against input short circuit, while D2 protect against output short circuit for capacitance discharging. 5/15
LM117/217/317 Figure 8: Voltage Regulator with Protection Diodes
D1 protect the device against input short circuit, while D2 protects against output short circuit for capacitors discharging.
Figure 9: Slow Turn-on 15V Regulator
Figure 10: Current Regulator
Vref 1.25V IO = + IADJ ≈ R1 R1
6/15
LM117/217/317 Figure 11: 5V Electronic Shut-down Regulator
Figure 12: Digitally Selected Outputs
(R2 sets maximum VO)
Figure 13: Battery Charger (12V)
* RS sets output impedance of charger ZO = RS (1 + R2/R1). Use of RS allows low charging rates whit fully charged battery.
7/15
LM117/217/317 Figure 14: Current Limited 6V Charger
* R3 sets peak current (0.6A for 1 0). ** C1 recommended to filter out input transients
8/15
LM117/217/317
TO-3 MECHANICAL DATA mm.
DIM.
MIN.
A
inch
TYP
MAX.
MIN.
TYP.
11.85
B
0.96
MAX.
0.466
1.05
1.10
0.037
0.041
0.043
C
1.70
0.066
D
8.7
0.342
E
20.0
0.787
G
10.9
0.429
N
16.9
0.665
P
26.2
R
3.88
1.031
4.09
U
0.152
39.5
V
1.555
30.10
1.185
A
P
D C
O
N
B
V
E
G
U
0.161
R P003C/C 9/15
LM117/217/317
TO-220 MECHANICAL DATA DIM.
mm. MIN.
TYP
inch MAX.
MIN.
TYP.
MAX.
A
4.40
4.60
0.173
0.181
C
1.23
1.32
0.048
0.051
D
2.40
2.72
0.094
0.107
D1
1.27
0.050
E
0.49
0.70
0.019
0.027
F
0.61
0.88
0.024
0.034
F1
1.14
1.70
0.044
0.067
F2
1.14
1.70
0.044
0.067
G
4.95
5.15
0.194
0.203
G1
2.4
2.7
0.094
0.106
H2
10.0
10.40
0.393
0.409
L2
16.4
0.645
L4
13.0
14.0
0.511
0.551
L5
2.65
2.95
0.104
0.116
L6
15.25
15.75
0.600
0.620
L7
6.2
6.6
0.244
0.260
L9
3.5
3.93
0.137
0.154
DIA.
3.75
3.85
0.147
0.151
P011C 10/15
LM117/217/317
TO-220FP MECHANICAL DATA mm. DIM.
MIN.
TYP
inch MAX.
MIN.
TYP.
MAX.
A
4.40
4.60
0.173
0.181
B
2.5
2.7
0.098
0.106
D
2.5
2.75
0.098
0.108
E
0.45
0.70
0.017
0.027
F
0.75
1
0.030
0.039
F1
1.15
1.50
0.045
0.059
F2
1.15
1.50
0.045
0.059
G
4.95
5.2
0.194
0.204
G1
2.4
2.7
0.094
0.106
H
10.0
10.40
0.393
L2 L3
16
0.409 0.630
28.6
30.6
1.126
1.204
L4
9.8
10.6
0.385
0.417
L5
2.9
3.6
0.114
0.142
L6
15.9
16.4
0.626
0.645
L7
9
9.3
0.354
0.366
DIA.
3
3.2
0.118
0.126
7012510A-H
11/15
LM117/217/317
D2PAK MECHANICAL DATA mm.
inch
DIM. MIN.
TYP
MAX.
MIN.
TYP.
MAX.
A
4.4
4.6
0.173
0.181
A1
2.49
2.69
0.098
0.106
A2
0.03
0.23
0.001
0.009
B
0.7
0.93
0.027
0.036
B2
1.14
1.7
0.044
0.067
C
0.45
0.6
0.017
0.023
C2
1.23
1.36
0.048
0.053
D
8.95
9.35
0.352
0.368
10.4
0.393
4.88
5.28
0.192
D1 E
8 10
E1 G
0.315
8.5
0.409 0.335 0.208
L
15
15.85
0.590
0.624
L2
1.27
1.4
0.050
0.055
L3
1.4
1.75
0.055
0.068
M
2.4
3.2
0.094
R V2
0.4 0˚
0.126 0.016
8˚
0˚
8˚
P011P6G 12/15
LM117/217/317
Tape & Reel D2PAK-P 2PAK-D 2PAK/A-P 2PAK/A MECHANICAL DATA mm.
inch
DIM. MIN.
TYP
A
MAX.
MIN.
TYP.
180 13.0
7.086
C
12.8
D
20.2
0.795
N
60
2.362
T
13.2
MAX.
0.504
0.512
14.4
0.519
0.567
Ao
10.50
10.6
10.70
0.413
0.417
0.421
Bo
15.70
15.80
15.90
0.618
0.622
0.626
Ko
4.80
4.90
5.00
0.189
0.193
0.197
Po
3.9
4.0
4.1
0.153
0.157
0.161
P
11.9
12.0
12.1
0.468
0.472
0.476
13/15
LM117/217/317 Table 6: Revision History Date
Revision
01-Sep-2004
10
14/15
Description of Changes Mistake VREF ==> VO, tables 1, 4 and 5.
LM117/217/317
Information furnished is believed to be accurate and reliable. However, STMicroelectronics assumes no responsibility for the consequences of use of such information nor for any infringement of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of STMicroelectronics. Specifications mentioned in this publication are subject to change without notice. This publication supersedes and replaces all information previously supplied. STMicroelectronics products are not authorized for use as critical components in life devices or systems without express written approval of STMicroelectronics. The ST logo is a ed trademark of STMicroelectronics All other names are the property of their respective owners © 2004 STMicroelectronics - All Rights Reserved STMicroelectronics group of companies Australia - Belgium - Brazil - Canada - China - Czech Republic - Finland - - - Hong Kong - India - Israel - Italy - Japan Malaysia - Malta - Morocco - Singapore - Spain - Sweden - Switzerland - United Kingdom - United States of America www.st.com
15/15
This datasheet has been from: www.datasheetcatalog.com Datasheets for electronics components.
2N2905 2N2907 GENERAL PURPOSE AMPLIFIERS AND SWITCHES DESCRIPTION The 2N2905 and 2N2907 are silicon planar epitaxial PNP transistors in Jedec TO-39 (for 2N2905) and in Jedec TO-18 (for 2N2907) metal case. They are designed for high speed saturated switching and general purpose application. 2N2905 approved to CECC 50002-102, 2N2907 approved to CECC 50002-103 available on request. TO-18
TO-39
INTERNAL SCHEMATIC DIAGRAM
ABSOLUTE MAXIMUM RATINGS Symbol
Value
Unit
V CBO
Collector-Base Voltage (IE = 0)
-60
V
V CEO
Collector-Emitter Voltage (I B = 0)
-40
V
V EBO
Emitter-Base Voltage (I C = 0)
-5
V
-0.6
A
0.6 0.4
W W
3 1.8
W W
IC P t ot
T stg Tj
Parameter
Collector Current o
Total Dissipation at T amb ≤ 25 C for 2N2905 for 2N2907 at T case ≤ 25 o C for 2N2905 for 2N2907 St orage Temperature Max. Operating Junction Temperature
November 1997
-65 to 200
o
C
200
o
C 1/5
2N2905/2N2907 THERMAL DATA
R t hj-ca se R t hj- amb
Thermal Resistance Junction-Case Thermal Resistance Junction-Ambient
Max Max
T O-39
TO -18
58.3 292
97.3 437.5
o o
C/W C/W
ELECTRICAL CHARACTERISTICS (Tcase = 25 oC unless otherwise specified) Symb ol I CBO
Parameter
Test Cond ition s
Min.
Typ .
Max.
Un it
-20 -20
nA µA
Collector Cut-off Current (IE = 0)
V CB = -50 V V CB = -50 V
I CEX
Collector Cut-off Current (V BE = -0.5V)
V CE = -30 V
-50
nA
I BEX
Base Cut-off Current (V BE = -0.5V)
V CE = -30 V
-50
nA
o
Tc ase = 150 C
V ( BR)CBO ∗ Collector-Base Breakdown Voltage (I E = 0)
I C = -10 µA
-60
V
V ( BR)CEO ∗ Collector-Emitter Breakdown Voltage (I B = 0)
I C = -10 mA
-40
V
V (BR)EBO ∗ Emitter-Base Breakdown Voltage (I C = 0)
I E = -10 µA
-5
V
V CE(sat )∗
Collector-Emitter Saturation Voltage
I C = -150 mA I C = -500 mA
IB = -15 mA IB = -50 mA
-0.4 -1.6
V V
V BE(s at)∗
Base-Emitter Saturation Voltage
I C = -150 mA I C = -500 mA
IB = -15 mA IB = -50 mA
-1.3 -2.6
V V
DC Current G ain
IC IC IC IC IC
V CE = -10 V V CE = -10 V V CE = -10 V V CE = -10 V V CE = -10 V
hFE∗
fT
-0.1 mA -1 mA -10 mA -150 mA -500 mA
Transition F requency
V CE = -20 V I C = -50 mA
C EBO
Emitter Base Capacitance
IC = 0
V EB = -2 V
f = 100 MHz
C CBO
Collector Base Capacitance
IE = 0
V CB = -10 V
td
Delay Time
V CC = -30 V I B1 = -15 mA
tr
Rise Time
V CC = -30 V I B1 = -15 mA
ts tf
f = 1MHz
35 50 75 100 30
300
200
MHz 30
pF
8
pF
I C = -150 mA
10
ns
I C = -150 mA
40
ns
Storage Time
V CC = -6 V I C = -150 mA I B1 = -IB2 = -15 mA
80
ns
Fall T ime
V CC = -6 V I C = -150 mA I B1 = -IB2 = -15 mA
30
ns
∗ Pulsed: Pulse duration = 300 µs, duty cycle ≤ 1 %
2/5
= = = = =
f = 1MHz
2N2905/2N2907
TO-18 MECHANICAL DATA mm
inch
DIM. MIN. A
TYP.
MAX.
MIN.
TYP.
12.7
MAX.
0.500
B
0.49
0.019
D
5.3
0.208
E
4.9
0.193
F
5.8
0.228
G
2.54
0.100
H
1.2
0.047
I
1.16
0.045
L
45o
45o
D
A
G I
E
F
H
B
L C
0016043
3/5
2N2905/2N2907
TO-39 MECHANICAL DATA mm
inch
DIM. MIN. A
TYP.
MAX.
MIN.
12.7
TYP.
MAX.
0.500
B
0.49
0.019
D
6.6
0.260
E
8.5
0.334
F
9.4
0.370
G
5.08
0.200
H
1.2
0.047
I
0.9
0.035 45o (typ.)
L
D
A
G I
E
F
H
B
L
P008B 4/5
2N2905/2N2907
Information furnished is believed to be accurate and reliable. However, SGS-THOMSON Microelectronics assumes no responsability for the consequences of use of such information nor for any infringement of patents or other rights of third parties which may results from its use. No license is granted by implication or otherwise under any patent or patent rights of SGS-THOMSON Microelectronics. Specifications mentioned in this publication are subject to change without notice. This publication supersedes and replaces all information previously supplied. SGS-THOMSON Microelectronics products are not authorized for use as critical components in life devices or systems without express written approval of SGS-THOMSON Microelectonics. 1997 SGS-THOMSON Microelectronics - Printed in Italy - All Rights Reserved SGS-THOMSON Microelectronics GROUP OF COMPANIES Australia - Brazil - Canada - China - - - Italy - Japan - Korea - Malaysia - Malta - Morocco - The Netherlands Singapore - Spain - Sweden - Switzerland - Taiwan - Thailand - United Kingdom - U.S.A ...
5/5
This datasheet has been from: www.datasheetcatalog.com Datasheets for electronics components.
2N3055 MJ2955
®
COMPLEMENTARY SILICON POWER TRANSISTORS ■
■
STMicroelectronics PREFERRED SALESTYPES COMPLEMENTARY NPN-PNP DEVICES
DESCRIPTION The 2N3055 is a silicon Epitaxial-Base Planar NPN transistor mounted in Jedec TO-3 metal case. It is intended for power switching circuits, series and shunt regulators, output stages and high fidelity amplifiers. The complementary PNP type is MJ2955.
1 2 TO-3
INTERNAL SCHEMATIC DIAGRAM
ABSOLUTE MAXIMUM RATINGS Symbol
Parameter
V CBO
Collector-Base Voltage (I E = 0)
V CER V CEO
Collector-Emitter Voltage (R BE ≤ 100Ω) Collector-Emitter Voltage (I B = 0)
V EBO
Emitter-Base Voltage (I C = 0)
IC
Collector Current
IB
Base Current
P tot T stg Tj
Total Dissipation at T c ≤ 25 o C Storage Temperature Max. Operating Junction Temperature
Value NPN
2N3055
PNP
MJ2955
Unit
100
V
70
V
60
V
7
V
15
A
7
A
115
W
-65 to 200
o
C
200
o
C
For PNP types voltage and current values are negative.
August 1999
1/4
2N3055 / MJ2955 THERMAL DATA R thj-case
Thermal Resistance Junction-case
Max
o
1.5
C/W
ELECTRICAL CHARACTERISTICS (Tcase = 25 oC unless otherwise specified) Symbol
Parameter
Test Conditions
I CEX
Collector Cut-off Current (V BE = -1.5V)
V CE = 100 V V CE = 100 V
I CEO
Collector Cut-off Current (I B = 0)
V CE = 30 V
IEBO
Emitter Cut-off Current (I C = 0)
V EB = 7 V
Min.
T j = 150 o C
Typ.
Max.
Unit
1 5
mA mA
0.7
mA
5
mA
V CEO(sus) ∗ Collector-Emitter Sustaining Voltage (I B = 0)
I C = 200 mA
60
V
VCER(sus) ∗ Collector-Emitter Sustaining Voltage (R BE = 100 Ω)
I C = 200 mA
70
V
VCE(sat) ∗
Collector-Emitter Saturation Voltage
IC = 4 A I C = 10 A
I B = 400 mA I B = 3.3 A
V BE ∗
Base-Emitter Voltage
IC = 4 A
V CE = 4 A
h FE ∗
DC Current Gain
IC = 4 A I C = 10 A
V CE = 4 A V CE = 4 A
20 5
fT
Transition frequency
I C = 0.5 A
V CE = 10 V
3
MHz
Is/b ∗
Second Breakdown Collector Current
V CE = 40 V
2.87
A
∗ Pulsed: Pulse duration = 300 µs, duty cycle 1.5 % For PNP types voltage and current values are negative.
2/4
1 3
V V
1.8
V
70
2N3055 / MJ2955
TO-3 MECHANICAL DATA mm
DIM. MIN.
inch
TYP.
MAX.
MIN.
TYP.
MAX.
A
11.00
13.10
0.433
0.516
B
0.97
1.15
0.038
0.045
C
1.50
1.65
0.059
0.065
D
8.32
8.92
0.327
0.351
E
19.00
20.00
0.748
0.787
G
10.70
11.10
0.421
0.437
N
16.50
17.20
0.649
0.677
P
25.00
26.00
0.984
1.023
R
4.00
4.09
0.157
0.161
U
38.50
39.30
1.515
1.547
V
30.00
30.30
1.187
1.193
A
P
C
O
N
B
V
E
G
U
D
R
P003F 3/4
2N3055 / MJ2955
Information furnished is believed to be accurate and reliable. However, STMicroelectronics assumes no responsibility for the consequences of use of such information nor for any infringement of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of STMicroelectronics. Specification mentioned in this publication are subject to change without notice. This publication supersedes and replaces all information previously supplied. STMicroelectronics products are not authorized for use as critical components in life devices or systems without express written approval of STMicroelectronics. The ST logo is a trademark of STMicroelectronics © 1999 STMicroelectronics – Printed in Italy – All Rights Reserved STMicroelectronics GROUP OF COMPANIES Australia - Brazil - Canada - China - - - Italy - Japan - Korea - Malaysia - Malta - Mexico - Morocco - The Netherlands Singapore - Spain - Sweden - Switzerland - Taiwan - Thailand - United Kingdom - U.S.A.
4/4
http://www.st.com .
This datasheet has been from: www.datasheetcatalog.com Datasheets for electronics components.
More Documents from "Julyo Gonzales" 1u3725
Fuente-0-30v-5a 71h3y
February 2021 0
04 - Fraud Risk Management A Guide To Good Practice.docx 2w6pt
October 2019 118
Disfagia 4a2q2z
November 2019 90
2c82t
June 2021 0
Ensayo De Contenido De Humedad De Agregados 2v1165
August 2020 0
