Flow Switches Pm 4zf4u

HR / HRM..MI / KI PM . . MI / KI–KV FM / GK–FM . . RI

FLOW SWITCHES ● ●

PROVEN DESIGN FOR LIQUIDS

8 TO 80 MM NB LINES

HR

●

●

BRASS OR 304 SS BODY

FM

The SW ITZER flow switches styles HR, PM, FM & GK-FM are robust piston / paddle operated instruments with very wide application capability manufactured with know-how from Honsberg, . These flow switches are for use with water, oil or other liquids. Style HR : Handles pressures upto 200 bar with several flow ranges in different line sizes suitable for W ater, Oil and other liquid application. Style HRM : Same as style HR flow switch, but with

●

PM additional 2½" (65mm) dial gauge added for direct reading of flow. Style FM / GK-FM : Ideal for low flow liquid applications. Style PM : An OEM version with adjustable setting. W hile brass version is used for non-aggressive media, the SS version is for aggressive liquids. HR & PM models have adjustable settings. Model FM / GK-FM is factory set for a fixed flow.

GENERAL SPECIFICATIONS Enclosure HR

M ax. Line Pressure GF-Nylon, weatherproof to IP:55

HR / HRM

100 bar for 8 to 50 mm Lines 50 bar for 65 & 80 mm Lines 200 bar optional

PM

16 bar

FM / GK-FM

20 bar (100 bar opt.)

HRM Gauge Case

GF-Nylon, weatherproof to IP:65

Switch Head

GF-Nylon, weatherproof to IP:55

PM

ABS, weatherproof to IP:55

FM

ABS, weatherproof to IP:55

GK-FM

Flameproof die cast Aluminium enclosure to Gr.IIA, IIB or IIC & weatherproof to IP:66

Sensor and W etted Parts

Max. W orking Temp.

70°C for FM/GK-FM – 20 bar version 110°C for all others

Connection Refer ordering matrix

Process

Refer ordering matrix

Ranges

Refer Tables 1, 2, 3 & 4

Repeatability

±1% FSR for HR/HRM (Note 1) ±3 to 4% FSR for PM & FM/GK-FM

HR/HRM

M16 PVC gland

Switching

Instrument quality SPDT microswitch or reed switch. (Notes 4, 5 & 7)

PM & FM

1 Mtr. flying lead via M16 PVC gland

Differential

≤ 30% FSR for HR / HRM ≤ 10% of max. flow for PM ≤ 50% FSR for FM/GK-FM (upto 4 LPM) ≤ 25% FSR for FM/GK-FM (above 4 LPM)

GK–FM

1/2" NPTF Std.

Electrical

Mounting

Horizontal / Vertical (For vertical pipes, flow should be from bottom to top only)

ORDERING MATRIX ENCLOSURE Weatherproof GF-Nylon switch housing, with in-line threaded connection; Adjustable field setting –––––––––––––––– HR

OPTIONS (only for HR / HRM) 0 None J One LED on cover for Indication of one switch K Two LED on cover for indication of two switches Y Max. Working Pressure of 200 bar for Line size 8 to 80 mm for HR and 8 to 25 mm for HRM

HR Flow switch with local indication, with IP:65 gauge case 2½" (65 mm) dial, 90 deg scale and ±3% accuracy –––––––– HRM Weatherproof ABS switch housing with in-line / on-line threaded connection; Adjustable field setting –––––––––––––––– PM

Note : If more than one option is required specify J, Y... etc.,

Weatherproof ABS switch housing, with threaded in-line connection; Factory setting ––––––––––––––––––––––– FM

SWITCH CODE, RATING & AVAILABILITY

Flameproof cum Weatherproof Al. die cast CIMFR approved to Gr.IIA, IIB & IIC of IS/IEC 60079–1:2007 for flameproofness and IP:66 for weatherproofness –––––––– GK-FM

DC RATING IN AMPS SWITCH CODE (SPDT)

RESISTIVE

INDUCTIVE

220V 110V 24V 220V 110V 24V

LINE SIZE (Nominal line size) 8 mm NB 10 mm NB 15 mm NB 20 mm NB 25 mm NB 32 mm NB 40 mm NB 50 mm NB 65 mm NB 80 mm NB

AC RATING

(HR / HRM & FM/GK-FM) –––––––––– 8 (HR / HRM, FM/GK-FM & PM) –––––– 10 (HR / HRM, FM/GK-FM & PM) –––––– 15 (HR / HRM, & PM) –––––––––––––– 20 (HR / HRM, & PM) –––––––––––––– 25 (HR / PM) ––––––––––––––––––––– 32 (HR / PM) ––––––––––––––––––––– 40 (HR / PM) ––––––––––––––––––––– 50 (HR) ––––––––––––––––––––––––– 65 (HR) ––––––––––––––––––––––––– 80

AVAILABILITY AVAILABILITY OF 2 × SPDT OF SPDT IN IN MODELS MODELS (REFER NOTE 4)

2

5A 250 / 125V

0.25

0.5

5.0

0.1

0.25

3.0

PM, HR / HRM, FM

HR

R

0.35A 220V 80VA * ; 25W *

0.1

0.2

1.0

NR

NR

NR

HR / HRM

HR



Values of Current & Voltage indicated are maximum. However product of switching voltage and current shall not exceed the power rating of the switch.

Code 2 – General purpose usages. Code R – Reed Switch (Note 7 – Page 3)

WETTED PARTS HRM – Flow Switch with Indicator

Brass body, 304 SS piston for HR / HRM & 304 SS Paddle for PM –––––––––––––––––––––––––– M 304 SS body, 304 SS piston for HR / HRM & 304 SS Paddle for PM –––––––––––––––––––––––––– K Bronze body, Brass piston, plastic guide assembly for FM/GK-FM – MWP : 20 bar version ––––– R Bronze body, Brass piston, Brass guide assembly for FM/GK-FM – MWP : 100 bar version –––– B (SS body not available for FM/GK-FM)

PROCESS CONNECTION

Indicating gauge is fixed to the flow switch body externally. Magnetic coupling provides total isolation between the piston inside the body and the external switch head & gauge unit.

In-line with corresponding BSPF on both sides (Refer range table) ––––––––––––––––––––––––––––––– I

Pointer travel over a 90 deg scale provides local indication with accuracy of ±3% FSR.

On-line (top) mounting – 1/2" BSPF with socket (only for PM . .KV) ––––––––––––––––––––––––––––––––– V

Note : HRM available upto 25 mm line size only.

RANGE TABLES PM . . MI / KI — In-Line Mounting Nominal Pipe Size (mm)

Setting Max. Flow Range LPM (Falling) (Note 3) LPM (Water)

PM . . KV — Top Mounting Setting Max. Flow Range LPM (Falling) (Note 3) LPM (Water)

Process Connection BSPF (inches)

Nominal Pipe Size (mm) 15

4 to 6

30

20

13 to 15

40

25

15 to 17

60

32

37 to 42

100

10

2 to 3.5

20

3/8

15

3.5 to 5

30

1/2

20

6 to 8

40

3/4

25

15 to 17

60

1

32

32 to 36

100

1¼

40

37 to 41

150

1½

40

44 to 50

150

50

60 to 70

250

2

50

47 to 53

250

Process Connection

1/2" BSPF with socket

RANGE TABLES Contd.,

NOTES

HR/HRM . . MI / KI — In-Line Mounting

1.

Accuracy & Repeatability are one and the same for all blind switches. Settings will slightly shift with varying temperature.

2.

For oil application specify oil viscosity at operating temperature and set value. Suitable upto 180 CST oils only.

3.

Maximum flow setting range is referred to as FSR herein. The maximum flow value mentioned in the range tables are based on a nominal flow velocity of 2 meter/second. The instrument can handle higher flow if the process flow velocity is more than 2 metre/second. Maximum flow corresponds to range and not with reference to line size and it is the value that can through the instrument at 2 metre/second. A higher flow can through the instrument at higher flow velocities.

4.

In model HR, an additional switch head with a SPDT switch can be fixed at the bottom of the flow switch body, to facilitate two independent settings, such as Hi-Lo. DPDT action can be provided through Auxillary relay in a separate “GH” weatherproof housing.

Setting Max. Flow Range LPM (Falling) (Note 3) LPM (Water)

Nominal Pipe Size (mm)

Process Connection BSPF (inches)

8, 10, 15, 20

0.5 to 5

10

1/4, 3/8, 1/2, 3/4

10, 15, 20, 25

2 to 12

20

3/8, 1/2, 3/4, 1

15, 20, 25

5 to 25

40

1/2, 3/4, 1

20, 25

10 to 40

60

3/4, 1

25, 32

20 to 60

100

1, 1¼

32, 40

30 to 100

135

1¼, 1½

40, 50

50 to 150

200

1½, 2

50, 65

100 to 200

275

2, 2½

65, 80

180 to 330

450

2½, 3

80

330 to 500

675

3

FM / GK–FM . . RI — In-Line Mounting Setting Range Max. Flow LPM (Water) LPM (Falling) (Note 6) (factory set)

Nominal Pipe Size (mm)

In model HRM, a second switch can not be added.

Process Connection BSPF (inches)

8

0.4 to 9

15

1/4

10

0.4 to 14

22

3/8

15

0.4 to 23

35

1/2

5.

life of microswitch is 5 × 10 5 switching cycles for nominal load. To quench DC sparks, use a diode in parallel with inductance, ensuring polarity. A ‘R-C’ network is also recommended with ‘R’ value in Ohms equal to coil resistance and ‘C’ value in microfarads equal to holding current in Amps.

6.

For Model FM, max. flow specified herein corresponds to max. adjustable range value. It is lesser for lower range settings.

7.

Model HR is available both with microswitch and reed switch upto 32 mm line size. For sizes from 40 to 80 mm ONLY REED SW ITCH IS AVAILABLE. Customers are advised to opt for microswitch version where available as it has a higher current capacity. Reed switches are still available if customer prefers one-to-one replacement for earlier version.

8.

Model HRM is available from 8 to 25 mm NB only.

Other Models Available : HM

: All plastic version for corrosive chemicals

AM

: Air Flow

BM / BGM & GKBM : Wide Flow Range Upto 300 mm Line Size CM

: OEM version, high range

SM

: Fire fighting & Sprinkler applications

UZ

: Flow switch with 6" Dial Indicator

For further details consult Sales H.O. / Branch

MOUNTING DIMENSIONS HRM 8 – 20 MI / KI LAMP (OPTIONAL)

HRM 25 MI / KI

CABLE G LAND SW ITCH HOUSING SINGLE SW ITCH PR . CONN BSPF

36² 120

LPM

20

LPM

IN

IN

1" BSPF ADAPTOR FITTED AT EITHER ENDS

122

57

172 All dimensions are in mm

MOUNTING DIMENSIONS Contd..

PM . . KV

PM . . MI / KI M16 PVC CABLE G LAND

70.0

23.0

ABS SW ITCH H OUSING

NAME &

NAME &

46.0

RATING PLATE

1 METER LONG FLYING LEAD PIPE CUSTOMER 'S SCOPE

23.0

ABS SW ITCH H OUSING

46.0

RATING PLATE

M16 PVC CABLE G LAND

70.0

1 METER LONG FLYING LEAD

78.0

PART OF INSTRUMENT

78.0

NUT & SOCKET

PIPE CUSTOMER' S SCOPE

PADDLE 50.0

5D (min)

5D (min)

2" BSPF 1½" BSPF 1¼" BSPF 1" BSPF 3/4" BSPF 1/2" BSPF 3/8" BSPF

for for for for for for for

50 40 32 25 20 15 10

MI/KI MI/KI MI/KI MI/KI MI/KI MI/KI MI/KI

D

PADDLE 5D (min) (min)

5D (min) (min)

HR

PIPE PIPE CUSTOMER' S SCOPE CUSTOMER' S SCOPE

FM . . RI 1 METER L ONG FLYING LEAD

M16 PVC CABLE G LAND

29.0 M16 PVC CABLE G LAND

GF N YLON COVER FOR SW ITCH H OUSING NAME & RATING PLATE

43.0

RANGE L OCKNUT

ABS SWITCH HOUSING NAME & RATING PLATE

81.0 B

117.0 MAGNET OF BARIUM FERRITE

BSPF 1/2" BSPF for 15 RI 3/8" BSPF for 10 RI 1/4" BSPF for 8 RI

A TYPE HR 8 MI/KI HR 10 MI/KI HR 15 MI/KI HR 20 MI/KI HR 25 MI/KI HR 32 KI HR 40 KI HR 50 KI HR 65 KI HR 80 KI

DIM A±1

DIM B±1

122

36 SQ

172

38 SQ

128

70 SQ

220

90 DIA

230

170 DIA

PR. CONN. BSPF 1/4" 3/8" 1/2" 3/4" 1" 1¼" 1½" 2" 2½" 3"

PISTON ASSY.–BRASS 67.0

All dimensions are in mm

This is not a contractual document. Prior notification of changes in specifications is impracticable due to continuous improvement
