DYWIDAG Tie Rods
References DYWIDAG Tie Rods for Military Wharf in Guam
i
2
Owner US Navy, Naval Base Guam, USA +++ General Contractor Black Construction Corporation, Guam, USA +++ Architect-Engineer Wilson Okamoto Corporation, Honolulu, Hawaii, USA DSI Unit DSI USA, BU Geotechnics, Long Beach, CA, USA DSI Scope Supply of approx. 8,000 m (26,000 ft.) of Tie Rods with Polyken tape wrap
Contents __________________________________________________ DYWIDAG Tie Rod Applications ................................................. 04 DYWIDAG Threadbar® Tie Rod Properties ............................. 06 Replacing A-36 Bars with DYWIDAG Threadbar®.................. 07 DYWIDAG Threadbar® Tie Rod Corrosion Protection ........... 08 Short Tie Rod Connections ......................................................... 09 Additional Geotechnical Products from DSI ............................... 11 ____________________________________________________________
3
DYWIDAG Threadbar® Tie Rod Applications Typical Applications
4
Tie Back Retaining Wall with Dean
Foundation Tie Rods
Bracing for Grade Separation
Large Horizontal Load Resistance Roof Structures
Tie Rods for Sheet Pile Constructed Wharf
Roadway Embankment Stabilization
DYWIDAG Threadbar® Tie Rod Applications Tie Rods produced from DYWIDAG THREADBAR® may be used for a variety of marine applications. Construction of marine bulkheads for various docking facilities have, for many years, benefited from the use of DYWIDAG Tie Rods. Facilities such as barge and ship docks as well as offshore platforms have found the system to be a cost effective alternative to large d iameter A36 Tie Rods with upset threads. Tie Rods produced from DYWIDAG conomical THREADBAR® offer various e and technical advantages: n Easy handling due to the coarse
thread over the entire length n Up to almost 50% less weight than
A36 bars. n No threadability or assembly
roblems resulting from damaged p or dirty threads, because of the rugged hot rolled coarse DYWIDAG threadform. n DYWIDAG Tie Rods can be ordered slightly longer than necessary to accommodate misalignments on sheet piling. They can easily be cut to the desired length eliminating need to cut and re-weld upset rods to accommodate length changes.
5
DYWIDAG Threadbar® Tie Rod Properties DYWIDAG Grade 75 (ASTM A615) Threadbar®
THREADBAR® Designation
Maximum THREADBAR® Diameter
Yield Stress
Cross Section Area
Yield Load
(fy)
(As)
(fy x As)
Nominal Weight
[in]
[mm]
[in]
[mm]
[ksi]
[MPa]
[in²]
[mm²]
[kips]
[kN]
[lbs/ft]
[kg/m]
#6 #7 #8 #9 #10 #11 #14 #18 #20 #24 #28
19 22 25 29 32 36 43 57 63 75 90
0.86 0.99 1.12 1.26 1.43 1.61 1.86 2.50 2.72 3.18 3.68
22 25 28 32 36 41 47 64 69 81 94
75 75 75 75 75 75 75 75 80 75 75
517 517 517 517 517 517 517 517 552 517 517
0.44 0.60 0.79 1.00 1.27 1.56 2.25 4.00 4.91 7.06 9.62
284 387 510 645 819 1,006 1,452 2,581 3,168 4,555 6,207
33.0 45.0 59.3 75.0 95.3 117.0 168.8 300.0 393.0 529.5 721.5
147 200 264 334 424 520 751 1,335 1,748 2,355 3,209
1.50 2.04 2.67 3.40 4.30 5.31 7.65 13.60 16.91 24.09 32.79
2.23 3.04 3.97 5.06 6.40 7.90 11.38 20.24 25.16 35.85 48.79
Warning: Avoid Welding near A722 steel. Note: Mill length = 60'-0" for #6 through #24 bars and 48'-0" for #28 bars DYWIDAG Grade 150 (ASTM A722) Threadbar® THREADBAR® Designation
1" 1-1/4" 1-3/8" * 1-3/4" * 2-1/2" * 3"
Maximum THREADBAR® Diameter
Ultimate Stress
Cross Section Area
Ultimate Load
(fu)
(As)
(fu x As)
Nominal Weight
[mm]
[in]
[mm]
[ksi]
[MPa]
[in²]
[mm²]
[kips]
[kN]
[lbs/ft]
[kg/m]
26 32 36 46 66 75
1.20 1.44 1.63 2.01 2.79 3.15
31 36 41 51 71 80
150 150 150 155 150 150
1,034 1,034 1,034 1,069 1,034 1,034
0.85 1.25 1.58 2.58 5.16 6.85
548 806 1,019 1,664 3,355 4,419
127.5 187.5 237.0 400.0 774.0 1,027.0
567 834 1,054 1,779 3,443 4,568
3.01 4.39 5.56 9.22 18.20 24.09
4.48 6.53 8.27 13.72 26.36 35.85
* Meets the strength requirements of the A 722. Warning: Avoid Welding near A722 steel. Note: Mill length = 60'-0" for 1", 1¼" and 1 " Threadbars and 45'-0" for 1¾", 2½" and 3" bars
Coupler and hexnut develop the full load of the bar ultimate load. Standard or custom made wedge washers are available for all sizes. Bearing plates can be custom made in any size and from steel material
6
conforming to ASTM A36 or ASTM A572 grade 50. All bars and accessories can be produced with double corrosion protection, hot-dip galvanized, coal-tar or fusion bonded epoxy coated.
Replacing A36 Round Bars with Threaded Ends to Equivalent DYWIDAG THREADBAR®
DYWIDAG THREADBAR® ASTM A615
A36 A36 BAR [inches] 3/ 4 1 1-1/4 1-1/2 1-3/4 2 2-1/4 2-1/2 2-3/4 3 3-1/4 3-1/2 3-3/4
[mm] 19 25 32 38 44 51 57 64 70 76 83 89 95
Tensile Stress Area* [in²] 0.33 0.61 0.97 1.41 1.90 2.50 3.25 4.00 4.93 5.97 7.10 8.33 10.11
[mm²] 215 391 625 910 1,226 1,613 2,097 2,581 3,181 3,852 4,581 5,374 6,523
Yield* Strength [kips] 12.0 21.8 34.8 50.7 68.4 90.0 117.0 144.0 177.0 214.9 255.6 299.9 364.0
[kN] 53 97 155 226 304 400 520 641 787 956 1,137 1,334 1,620
Nominal Weight [lbs/ft] 1.50 2.67 4.17 6.01 8.18 10.68 13.52 16.69 20.19 24.03 28.21 32.71 37.55
[kg/m] 2.2 4.0 6.2 8.9 12.2 15.9 20.1 24.8 30.1 35.8 42.0 48.7 55.9
Equivalent THREADBAR®
Size [mm/designation] 19 (#6) Grade 75 19 (#6) Grade 75 22 (#7) Grade 75 25 (#8) Grade 75 29 (#9) Grade 75 32 (#10) Grade 75 36 (#11) Grade 75 43 (#14) Grade 75 57 (#18) Grade 75 57 (#18) Grade 75 57 (#18) Grade 75 57 (#18) Grade 75 63 (#20) Grade 80
Yield Load (fy x As) [kips] 33.0 33.0 45.0 59.3 75.0 95.3 117.0 168.8 300.0 300.0 300.0 300.0 393.0
[kN] 147 147 200 264 334 424 520 751 1,335 1,335 1,335 1,335 1,748
Nominal Weight [lbs/ft] 1.50 1.50 2.04 2.67 3.40 4.30 5.31 7.65 13.60 13.60 13.60 13.60 16.70
[kg/m] 2.23 2.23 3.04 3.97 5.06 6.40 7.90 11.38 20.24 20.24 20.24 20.24 24.85
* Round bar with thread cut into bar. For comparison with upset ended tie rods use area of rod x 36 ksi to get yield strength
7
DYWIDAG Tie Rod Corrosion Protection An important element in the long term durability of a Tie Rod system is corrosion protection. DSI offers various corrosion protection systems to meet on site conditions and degree of exposure. Possible solutions are: n The well known DYWIDAG Double
orrosion Protection (D) System. C Ideal for the most aggressive environments n Hot dip galvanizing in accordance
with ASTM A153 n Fusion bonded epoxy coating
per ASTM A775 or ATSM A934
n Coal tar epoxy n Petroleum wax tape wrapping n Polyken 980/955 tape coating system
D threadbar® - exposed section
D threadbar® - cross section area
Typical Permanent Tie Rod with Double Corrosion Protection (D) (Highly Recommended for Permanent Applications in Agressive Enviroments)
Double C-Channels
Spiral Wrap Spacer
Concrete Dean
Steel Pipe Welded to Bearing Plate Protective Cap
Seal
Bearing Plate Grease or Cement Grout Sheet Pile
8
DYWIDAG Threadbar® Factory Injected Cement Grout Corrugated Plastic Sheath
Short Tie Rod Connection Short bolts are needed to connect a standard sheet pile wall or a modular sheet pile wall to a load distributing double channel beam. This can be done with DYWIDAG THREADBAR®.
DYWIDAG Tie Rods can also be prestressed, to align sheet pile walls.
n Wide range of accessories available
Features and advantages:
n Available with double corrosion
n Continuous coarse DYWIDAG thread
The required length of the bar depends on the height of the sheet pile profile, the width of the beam, the plate thickness and the nut length.
protection system
n Approved by many construction
authorities worldwide
n Can be cut to any length n Conformance to ASTM A615 n Weldable accessories
and ASTM A722
n Stock lengths up to 60 ft, but
can be cut to any lengths.
Double C-Channels Bearing Plate
Hex Nut
Spacer Plate (optional)
Beam (optional) Sheet Pile
9
References Walker Road Canadian Pacific Railway Temporary Railroad Diversion Structure in Windsor, Ontario
i
10
Owner Canadian Pacific Railway +++ General Contractor FACCA Inc. 747 County Road, Ruscom, Ontario N0R 1R0 +++ Engineer MTO Contract 2007-3042 Walker Road R Grade Separation, Dillon Consulting / Facca Incorporated DSI Unit DSI Canada Ltd., Eastern Division, Gormley, Canada SUSPA-DSI Scope Supply of 1000 m of 63 mm diameter GEWI® Threadbar
