Develop Ineo 2p141t

develop ineo-250 Error C2557 error develop ineo-250 C2557 how to remove how to enter servic mode plz help me C2557 ATDC Sensor Failure • The scanning value of the ATDC Sensor is less than 7 % while the IU Motor is turning. • The scanning value of the ATDC Sensor is more than 19 % while the IU Motor is turning. In my experience, the amount of Developer/Starter in the tank is low. Change the Dev and run F8 in service mode. The post above relates to the mono ineo 250. Just noticed you may be talking about the ineo+ 250 which is a colour machine. If so: C2557 Abnormally low toner density detected Black TCR Sensor • TC ratio in the developing machine, which is determined by Toner replenishing amount control mechanism, is 5 % or less for a given number of times consecutively. Run the Black TCR Toner Supply from service mode. If this doesn't fix the problem, change the Black Imagining Unit. hi..as i recall there is a a reset sw on the board at the rear side..service mode....(utility+details+stop+0+0+stop+0+1) i hope it is help my dear... You need to get into service mode and look at the K toner ratio. If it's below about 7% the K toner add system should be trying to add toner. If its down to around 3-4% you might have to reset the 2557 code several times to allow the % to rise enough to satisfy the monitoring system. You will not be able to add K toner through service mode until the % gets to the minimum level. If you have a full bottle of toner, you may have a problem with the toner bottle motor, or there may be problems with the hopper assy. Poor connections at the PRCB can give this error. I had one on a C652 that was caused by the hopper harness not connected to it's connector on a brand new box. Emujo Emujo, we still don't know if it's the C250 or mono 250 tariq65 is talking about. tariq65, if you could clarify the machine model number we will be able to help you further. Just reset the pc life and run F8, code 2557 will reset. You will reset the pc life while the right door is open or else anoying buzzer will come everytime you turn ON the sw. I hope you know the right procedures on resetting pc counters. Then add little toner on developer and run F8. Some tricks you have to do in here.... Little dark copies are expected but after a week or two the copies will surely great! have fun...

Reset it, start it with the right door open, go to service mode, clear the counters for drum and developer and go to functions menu. Close the right door and start immediately the F8 function. It should work

error C2557 - Bizhub 250 Description C2557 (C-2557). Solution CAUSE: The drum was replaced without replacing the developer. SOLUTION: Replace both the drum unit and developer at the same time. Once the code occurs, developer must be replaced to properly recover. The correct procedure for replacing the drum is as follows: 1. Select Tech. Rep. Mode => Counter => Special Parts Counter => PC Life. 2. Press the Clear Key to clear the counter value. 3. Turn OFF the main power switch. 4. Open the Right Door. 5. Remove the IU. 6. Remove four screws (silver) and disassemble the Photo Conductor Unit and the Developing Unit. 7. Replace the Photo Conductor Unit. 8. Remove three screws and the Developer Scattering Prevention Plate. 9. Remove the Toner Supply Port. 10. Remove the Developer. 11. Set the developer while rotating the gear in the direction of the arrow. 12. Reinstall the Toner Supply Port. 13. Using three screws, secure the Developer Scattering Prevention Plate. 14. Install the four screws to secure the Photo Conductor Unit and Developing Unit. 15. Install the IU in the copier. 16. Turn ON the main power switch. 17. Select Tech. Rep. Mode => Function => F8 and press the Start Key. Notes : a. After replacing the developer, be sure to execute F8 under Function of Tech. Rep. Mode. b. When the main power switch is turned ON, execute F8 quickly.
