Cisco Catalyst 9300 Series Switches Overview What are the Cisco Catalyst 9300 Series Switches? The Cisco Catalyst 9300 Series Switches are the next generation of enterprise-class stackable access-layer switches that are part of the new Cisco Catalyst 9000 Family. These switches also full IEEE 802.3at PoE+, UPoE, modular and field-replaceable network modules, redundant fans, and power supplies. In addition, the Cisco Catalyst 9300-based models a variety of uplink modules for both copper and fiber uplink . These models add even more flexibility to the interface choices that you can make in a single Cisco Catalyst 9300 Switch or in a stack of Cisco Catalyst 9300 Switches.

Check Cisco Catalyst 9000 Series Switches 3D Model. Cisco Catalyst 9300 Series Switch configurations

Model

Total 10/100/1000 or Multigigabit Copper Ports

Default AC Power Supply

C930024T

24

350WAC

C930048T

48

350WAX

Available PoE Power

C930024P

24 POE+

715WAC

445W

C930048P

48 POE+

715WAC

437W

Cisco StackWise480

Cisco StackPower

Yes

Yes

C930024U

24 Cisco UPOE

1100WAC

830W

C930048U

48 Cisco UPOE

1100WAC

822W

C930024UX

24 Multigigabit Cisco UPOE (100 Mbps or 1, 2.5, 5, or 10 Gbps)

1100WAC

490W

Can I stack Cisco Catalyst 9300 with the 3850? These switches do not stack together. Features are packaged differently between these platforms, they use different U architectures, and the platforms do not have the same scaling, making stacking with them impossible. Are the network modules shared between the Cisco Catalyst 9300 and 9500? No, the network modules are not shared between the Catalyst 9300 and 9500 because the ASIC, depth, and form factors are different for these product lines. Can the Cisco Catalyst 9300 act as a wired switch? The Catalyst 9300 switch provides connectivity for wired endpoints and wireless endpoints by connecting wireless access points. With the SD-Access architecture, the wired and wireless endpoints gets the same experience. What are the ed uplink modules in the Cisco Catalyst 9300? The Catalyst 9300 s the following new uplink modules. All modules are ed across all 9300 platforms: 4 x 1 Gigabit Ethernet network module 4 x 1, 2.5, 5, or 10 Gigabit Ethernet network module 8 x 10 Gigabit Ethernet network module 2 x 40 Gigabit Ethernet network module Are the uplinks between the Cisco Catalyst 9300 and the 3850 interchangeable? All existing 3850 uplink modules may be used in the Catalyst 9300 platforms. However, the new 9300 uplinks modules are not ed on the 3850 platforms. What about service modules for the Cisco Catalyst 9300? There are no service modules for the Catalyst 9300. All functions are embedded into the platform. Where can I purchase an SSD module for the Cisco Catalyst 9300? Cisco-approved SSD modules will be made available in the future. What management ports are available on the Cisco Catalyst 9300? This switch comes with a 10/100/1000 Ethernet dedicated management port on the backside of the switch right above the console port. This port is in a separate VRF instance called “Mgmt-vrf” in order to segment the management traffic from the global routing table of the switch. Can I use both console ports on Cisco Catalyst 9300 simultaneously? No. When you use the USB console, the RJ-45 console receives the output of the USB console as well. This design

allows the to see when the USB console port is in use. This capability is useful for remote s. Does the Cisco Catalyst 9300 Switch auto-baud on the console port? No. What type of airflow do the Cisco Catalyst 9300 Switches ? The airflow on the Catalyst 9300 is “front and sides” to back airflow. What pluggable transceiver modules do the Cisco Catalyst 9300 Switches ? Cisco Gigabit Ethernet Transceiver Modules

Cisco Gigabit Ethernet Transceiver Modules for Catalyst 9300 Series

Minimum Software Release Required Network Device

Transceiver Module DOM

C9300-24T C9300-24P C9300-24U C9300-24XU C9300-48T C9300-48P C9300-48U

Cisco IOS Release

GLC-T GLC-TE GLC-LH-SM GLC-LH-SMD GLC-SX-MM GLC-SX-MMD GLC-EX-SMD GLC-ZX-SM GLC-ZX-SMD GLC-BX-D GLC-BX-U CWDM SFP SFP-GE-S SFP-GE-L SFP-GE-T SFP-GE-Z DWDM SFP DWDM SFP (add.) GLC-BX40-D-I GLC-BX40-DA-I GLC-BX40-U-I GLC-BX80-D-I GLC-BX80-U-I

XE 16.5.1a

GLC-TE

XE 16.6.1

Cisco 10-Gigabit Ethernet Transceiver Modules

Cisco 10-Gigabit Ethernet Transceiver Modules for Catalyst 9300 Series

Minimum Software Release Required Network Device

C9300-24T C9300-24P C9300-24U C9300-24XU C9300-48T C9300-48P C9300-48U (With C9300-NM-8X for 10G uplink modules)

Transceiver Model

SFP-10G-LR SFP-10G-SR SFP-10G-LRM SFP-10G-ER SFP-10G-ZR SFP-10G-SR-S SFP-10G-LR-S SFP-10G-ER-S SFP-10G-ZR-S SFP-10G-BXD-I SFP-10G-BXU-I SFP-10G-BX40D-I SFP-10G-BX40U-I DWDM SFP10G CWDM SFP10G SFP-H10GB-CU1M SFP-H10GB-CU3M SFP-H10GB-CU5M SFP-H10GBACU7M SFP-H10GBACU10M SFP-10G-AOC1M SFP-10G-AOC2M SFP-10G-AOC3M SFP-10G-AOC5M SFP-10G-AOC7M SFP-10G-AOC10M

DOM

Software Release

—

XE 16.5.1a

Cisco 40-Gigabit Ethernet Transceiver Modules

Cisco 40-Gigabit Ethernet Transceiver Modules for Catalyst 9300 Series

Minimum Release Required Network Device

Transceiver Model DOM

C9300-24T C9300-24P C9300-24U C9300-24XU C9300-48T C9300-48P C9300-48U (With C9300-NM-2Q modules)

for

40G

uplink

QSFP-40G-SR4 QSFP-40G-CSR4 QSFP-40G-LR4 QSFP-40G-ER4 QSFP-H40G-CU1M QSFP-H40G-CU3M QSFP-H40G-CU5M QSFP-H40G-ACU7M QSFP-H40GACU10M QSFP-40G-SR-BD QSFP-40G-SR4-S QSFP-40G-LR4-S QSFP-40G-ER4 WSP-Q40GLR4L

Software Release

XE 16.5.1a

What is the SKU mapping between the Cisco Catalyst 3850 and 9300?

3850 PIDs

9300 PIDs

Short description

WS-C3850-24T

C9300-24T

Catalyst 9300 24-port data only switch

WS-C3850-24P

C9300-24P

Catalyst 9300 24-port PoE+ switch

WS-C3850-24U

C9300-24U

Catalyst 9300 24-port UPOE switch

WS-C385024XU

C930024UX

Catalyst 9300 24-port mGig and UPOE switch wireless security tips

WS-C3850-48T

C9300-48T

Catalyst 9300 48-port data only switch

WS-C3850-48P

C9300-48P

Catalyst 9300 48-port PoE+ switch

WS-C3850-48U

C9300-48U

Catalyst 9300 48-port UPOE switch
