Checkpoint 1180 Config.docx 2b1r

1)Configure your computer network adapter to DH 2)Connect your computer to port 1 of the firewall 3)Open a browser and go to https://192.168.1.1:4434 4)The following screen will appear:

Click “Next”

5) Enter an at the next screen and click next

6) Set the time and date manually – we will configure NTP during integration

7)Enter the device name in the next screen- replace Bucharest with the appropriate office but keep the corp-eu-xxxxx-fw01 syntax Press next when complete

8) Select central management at the next screen and press next:

9) Enter your Internet IP address information:

Press next The following screen will pop up:

Press “no” and continue

10) Enter the LAN IP address and disable DH and press nest

11) Configure istrative access per below and press next:

12) Press next at license activation:

Press OK at the warning, we will activate the device during integration:

13) Configure the one time SIC using C011iers$ press next

14) Select connect to management server later and press next:

15) Select finish:

16) You can confirm the network settings be reviewing them on the device tab:

17) Any additional internal networks can be added on the routing page:

18) We are done the initial configuration, once completed please [email protected], to arrange a time for activation.

Also look through the device there is a lot of reporting included.
