NESCO ELECTRICAL PRODUCTS

C A TA L O G U E

Portable Appliance Testing Equipment Appliance Test Tags Test Instruments Workplace Safety Products Automation & Control Products Overhead and Underground Products

w w w. n e s c o . c o m . a u

NESCO Electrical Products TAKE A LOOK AT WHAT WE OFFER Customer Service Product Solutions & Systems Research & Development Product Training Technical Distribution Australia Wide Distribution Network Local Representation Marketing Full Colour Product Catalogue WEB Full Colour PDF Product Sheets Fax Friendly Documents Product After Sales Backup & Service Calibration Services

C ontents

www.nesco.com.au

TNT Series Testers High precision testing and speed Simple one button testing Large graphic display /Fail indication plus actual test results displayed Fast and easy to use Recording of results and communication via pocket PC (refer to pages 6 & 8)

Catalogue No. TNT

Virtual Demo Available www.nesco.com.au

NEW

TNT Portable Appliance Tester TNT+ Portable Appliance Tester + RCD Tester + Appliance Power Tester Included Accessories Carry bag, TNT XL-IEC fly lead, TNT EL-earth test lead, Factory calibration certificate, Instruction manual.

Catalogue No. TNT+

Optional Accessories PDA & Software ( refer to next page)

Australian made to comply with the requirements of AS/NZ3760:2001

Specifications common to TNT and TNT+ Tests Performed

Measuring Range

Test Voltage/Current

Level

Earth Bond Test

0.0 to 15 Ω

200mA

<1Ω

Insulation Test

0.0 to 10MΩ

250/500V Selectable

>1MΩ

Portable Appliance Tester

Polarity Test

/ Fail

Mains Supply Test A-N-E

LED’s

Communication and recording via Pocket PC (see pages 5 & 7)

Specifications TNT+ Only RCD Tester Trip Current

2 - 500mA

5mA steps

Trip Time

0 - 2500ms

0001s

Current Ramp Trip Test

2 - 500mA

2mA steps

Battery Backed Display

20 seconds after trip

Load Tester

2

Leakage Current

0.0 to 1999.9mA

Load Current

0.0 to 10A (Res)

Voltage

0 - 300VAC

Power Factor

0.000 to 1.000

Apparent Power

0 - 2999VA

Power

1 - 2999 W

set fail limit 5mA

TNT Series Options and Accessories Specifications Part No.

Description

TNT

Portable Appliance Tester, with Carry Bag

TNT+

Portable Appliance Tester with RCD Test + Power Measurement

Catalogue No. TNT ES-500

Common options for above TNT ES-500

Earth Strap, 500mm long

TNT 3PADP

3 Phase Adaptor lead for TNT or TNT+

TNT EL

Earth Lead with Croc Clip

TNT XL

Extension Lead Adaptor (IEC - 3 Pin Plug)

TNT CAL

Calibration Certificate for TNT

TNT+ CAL

Calibration Certificate for TNT+

TNT ISOT

Isolation Transformer, Fused with handle socket and lead

TNT-TTP

Thermal transfer printer for printing test tags on site (requires WinPATS LITE and Laptop or PC)

TNT-PDAPACK

H2210 Pocket PC, WinPATS CE, TNT-BCS Scanner, TNTCMPC Comm Adaptor, TNT-PDASC Serial Cable C/W Protective Holster

Catalogue No. TNT ISOT

Catalogue No. TNT-TTP

Software and Communications WinPATS CE

Testing and Recording Software for PocketPC (PDA)

WinPATS Lite

Testing and Recording Software for Desktop/ Laptop PC

TNT-CMPDA

Interface Connector for TNT/TNT+ and PDA (serial cable required)

TNT-CMPC

Interface Connector for TNT/TNT+ and PC (serial cable required)

1021-USB

Barcode Scanner for USB port used with LAPTOP PC

PPT2800

Industrial PDA with in-built Barcode Scanner Industrial PocketPC device (weatherproof, impact resistant with Laser Scanner built in

Catalogue No. H2210

Catalogue No. TNT-BCS

For complete specification see our website www.nesco.com.au

3

www.nesco.com.au

MARTINDALE MicroPAT+ Features Rugged design Test results are stored in the built-in memory and by using the optional software package test results can be ed to a personal computer RS-232 interface for barcode input and data output Performs Earth continuity test Insulation test Run test Earth leakage test Flash test

0 to 19.99Ω 100mA, 10A, 25A test current 0 to 19.9MΩ 500V DC test voltage 240V mains / AC supply 0 -6mA AC 0 - 30mA AC 1.5kV A.C. - Class I 3kV A.C. - Class II

Included Accessories Mains lead 1.7 mtr, earth continuity lead 1.5 mtr c/w heavy duty crocodile clip, flash test gun, instruction manual, extension lead adaptor.

Catalogue No. MicroPAT+

Optional Accessories 1021+ Barcode scanner WinPATS Lite Windows recording software (see page 6)

Catalogue No. 1021 SER

TESTING AND INSPECTION INTERVALS TABLE 4 NOTES: 1 The actual sub-environment in which the equipment is located determines the row for the environment to be used in Table 4. e.g. A computer in a non-hostile environment in an office within a factory would attract a test/inspection action in accordance with Row 3.

2 Regulatory authorities, other Standards, workplace safety requirements or manufacturers’ instructions may specify intervals appropriate to particular industries or specific types of equipment. 3 RCDs in transportable equipment shall be regarded as portable RCDs 4 The following Standards refer only to the inspection and testing method of Clause 2.3 of this Standard, but not to the intervals of testing in Table 4 above. Refer to the appropriate Standards for specific test intervals: AS 1674.2

Safety in welding and allied processes - Electrical

AS/NZS 3001Electrical installations – Re-locatable premises (including caravans and tents) and their site installations AS/NZS 3002Electrical installations – Shows and carnivals AS/NZS 3003Electrical installations –Patient treatment areas of hospitals and medical and dental practices and dialysing locations AS/NZS 3004Electrical installations –Marinas and pleasure craft at low voltage AS/NZS 3012Electrical installations –Construction and demolition sites AS/NZS 4249Electrical safety practices – Film, video and television sites

4

EXTRACT FROM AS/NZS 3760:2003 STANDARDS AUSTRALIA / STANDARDS NEW ZEALAND

TABLE 4 Testing and inspection intervals for electrical equipment (CAUTION: This page must be read in conjunction with the Standard as a whole, and particularly Clause 2.1)

Specifications Interval between inspection and tests Class of equipment

Residual Current Devices (RCDs) Operating time and push button test

Portable (d)

Fixed (e)

Portable (f)

Fixed (g)

Cord sets and power boards (h)

12 mths

Daily, or before every use, whichever is the longer

6 mths

12 mths

12 mths

6 mths

12 mths

12 mths

3 mths

6 mths

12 mths

12 mths

12 mths

3 Environment where the equipment or supply cord is NOT subject to flexing in normal use and is NOT open to abuse and is NOT in a hostile environment

5 yrs

5 yrs

3 mths

6 mths

2 yrs

2 yrs

5 yrs

4 Residential type areas of: hotels, residential institutions, motels, boarding houses, halls, hostels accommodation houses, and the like

2 yrs

2 yrs

6 mths

2 yrs

2 yrs

2 yrs

5 Equipment used for commercial cleaning

6 mths

12 mths

3 mths

N/A

12 mths

N/A

12 mths

Prior to hire

Including push-button test by hirer prior to hire

N/A

N/A

Prior to hire

3 mths

N/A

3 mths

12 mths

3mths

Class I (protectively earthed) (b)

Class II (double insulated) (c)

1 Factories, workshops, places of work or repair, manufacturing, assembly, maintenance or fabrication

6 mths

2 Environment where the equipment or supply flexible cord is subject to flexing in normal use OR is open to abuse OR is in a hostile environment

Type of environment and/or equipment (a)

Push-button test - by

6 mths

6 Hire equipment: Inspection

Test and tag 7 Repaired, serviced and second-hand equipment

After repair or service which could affect electrical safety, or on reintroduction to service.

EXTRACT FROM AS/NZS 3760:2003 STANDARDS AUSTRALIA / STANDARDS NEW ZEALAND

For complete specification see our website www.nesco.com.au

5

www.nesco.com.au

WAVECOM WinPATS CE / WinPATS lite NESCO brings to you and your company a new level of convenience and portability in mobile data collection. In conjunction with Wavecom Instruments we have combined many compact computing technologies to provide you with revolutionary methods of improving productivity and profitability. T and TNT+ introduced a new level of simplicity and The TNT functionality to the field of appliance testing and now with the latest G2 (second generation) testers these units can be interfaced with both a standard PC using WinPATS lite & with a PDA (PocketPC) using WinPATS CE. If the PDA (Pocket PC) is also fitted with a barcode scanner, the entire testing process can be virtually completely automated with no operator data input required. Simple steps are 1. Scan in barcode and appliance details 2. Plug appliance into to test, scan OK on the PDA and let the tester do the rest. 3. The test results are stored into the Pocket PC.

Once the days/weeks work is done synchronise the pocket PC with WinPATS lite on your desk top or laptop and the database is then automatically entered and updated. All you need to do then is print your reports. WinPATS CE E controls the TNT / TNT+ and stores the results obtained and with the functionality of a PocketPC, all other relevant data can be entered directly into the application rather than manual notes having to be used for entry later into a database.

Catalogue No. WinPATS CE

WinPATS lite is the main database which provides the full record keeping and reporting functions and can be updated either manually, from WinPATS CE (via a PocketPC with appropriate synchronisation software) or from any data storage type PAT unit such as the MicroPAT+. Complete packages including PDAs can be supplied, please NESCO sales for details.

Catalogue No. WinPATS Lite 6

AS/NZS 3760 and AS/NZS 3012 which provide guidelines for testing and should be taken as minimum requirements for this work as these documents are generally referred to in the relevant legislation in each of the states.

Overview Of Systems The TNT, TNT+ and the MicroPat+ can be used as stand alone testers or they can be part of powerful intergrated systems. These are flexible and scaleable packages utilising modern technologies to provide efficient and error free data entry and testing. With systems to suit virtually every business, no matter how large or small. 1021 SER Barcode Scanner The introduction of barcode scanners are making the task even easier by allowing an appliance ID number to be allocated to a single item and a barcode label or tag applied to assist with fast and accurate data input.

Portable Appliances

MicroPAT+

Using barcodes and integrating the safety testing process with an ongoing asset management regime assists in giving the customers traceability on their plant and equipment. This code gives reference to the item when ed to the Software program by asg an appliance ID to the item it gives provision to trace this item through site and location within site.

Bar Code Tags 1021 SER

Micro PAT+ This unit performs insulation and continuity tests along with a run test, leakage test and finally a flash test. This unit performs class I, class II tests as well as extension leads and can be ed to a PC. This unit differs from the TNT series in that the results from up to 1000 tests can be stored in memory for at a later date. This is particularly useful if the customer is constantly moving around a site testing equipment.

Extension Leads

Faulty Appliance Test Tags

Appliance Failed FAST

Appliance ed PC TT

TM

TA

Appliance Test Tags

Printer

WinPATS is designed for use with the Micro PAT+ . This allows the to capture test results from these units and assign sites, locations within sites, asset numbers if needed as well as giving the provision of managing and reporting on individual appliances regarding test history fault levels and specifications. There is also the provision for reporting and certificate issue through this software.

7

www.nesco.com.au

TNT The TNT is capable of testing insulation, earth bond and displaying the actual test result. Polarity and mains supply connections are indicated by l.e.d.’s. This unit is capable of testing class I, class II, appliances and also comes with an adaptor for extension leads. The unit gives an actual test result as well as a /fail indication on screen and has the facility to communicate with a PC.

Portable Appliances

TNT

TNT+ The TNT+ performs the same functions as the TNT but with the added advantages of being able to test and record RCD trip current and time, as well as load testing incorporating leakage current, load current, voltage, power factor and power in watts. As with the TNT this unit also provides the capability of ing test results to a PC.

Extension Leads

Appliance Failed RCD’s

TNT+

FAST

Appliance ed TT Portable RCD’s

TM

Socket Bar Code Scanner

PC in Office

Office Printer

Communication Option 1 PDA

WinPATS Lite

1021 USB

Communication Option 2 Laptop

WinPATS Lite

8

TA

Appliance Test Tags

Isolation Transformer TNT ISOT

Test Tag Printer

A p p l i a n ce Test Tag s EELB

FAST

MP

Electrical Equipment Log Book

Faulty appliance safety tag

NESCO Marking Pen

100 Pages

Pack of 50

suits all NESCO Tags. Writes on most surfaces.

Catalogue No. EELB

Catalogue No. MP

Catalogue No. FAST

RCDLB

RCDTT

RCD Log Book 100 Pages

RCD tag

NEW

Catalogue No. RCDLB

TTCW

NEW

Construction Wiiring Tags

Pack of 100

Used to identify temporary wiring on construction sites.

Catalogue No. TTCW-100 pack of 100 TTCW-1000 roll of 1000

Catalogue No. RCDTT

Custom Test Tags - see pages 11 & 12 for custom sheets All Nesco test tags may be customised to suit individual companies uses.

TA/TN-custom Include company logo, phone and fax numbers, e-mail and web addresses. Box layout can be changed. Talk with our sales staff for other options.

Catalogue No. TA/TN-custom

TM-custom Include company logo, phone and fax numbers, e-mail and web addresses. Box layout can be changed. Sequential inspection numbers can be requested. Talk with our sales staff for other options.

Catalogue No. TM-custom

TT/TTN-custom Include company logo, phone and fax numbers, e-mail and web addresses. Box layout can be changed up to three colour printing available. Sequential inspection numbers can be requested. Talk with our sales staff for other options.

Catalogue No. TT/TTN-custom

9

www.nesco.com.au

Ap p lian ce Test Tag s

TA/TN-series The leading test tag for industrial and construction areas. This is an industrial quality tag complete with marking pen and security clips.

TA-5 Orange 6 Monthly Jan-June

TN-5 White May/Dec

OCT

DEC

NEXT TEST DUE

PLANT NUMBER

TEST DATE

SIGNATURE

LICENCE

/

/

/

/

COMPLETE WHERE APPLICABLE

JAN

MARCH

APR

JUNE

BLUE

JUL

SEPT

YELLOW

OCT

DEC

RED

c COPYRIGHT ALL RIGHTS RESERVED DURACK PTY. LTD. REDG. DES. NO. 110703

GREEN

AUSTRALIAN MADE

OWNER NEXT TEST DUE PLEASE INFORM YOUR ELECTRICAL SERVICES IF THIS APPLIANCE IS DEFECTIVE IN ANY WAY PLANT NUMBER

TEST DATE

SIGNATURE

LICENCE

/

/

/

/

COMPLETE WHERE APPLICABLE OWNER NEXT TEST DUE PLEASE INFORM YOUR ELECTRICAL SERVICES IF THIS APPLIANCE IS DEFECTIVE IN ANY WAY

c COPYRIGHT ALL RIGHTS RESERVED DURACK PTY. LTD. REDG. DES. NO. 110703

JAN

MARCH

APR

JUNE

BLUE

JUL

SEPT

YELLOW

OCT

DEC

RED GREEN

AUSTRALIAN MADE

TN-4 Green Apr/Aug

YELLOW

OWNER

PLANT NUMBER

/

/

/

/

TEST DATE

SIGNATURE

LICENCE

COMPLETE WHERE APPLICABLE OWNER NEXT TEST DUE PLEASE INFORM YOUR ELECTRICAL SERVICES IF THIS APPLIANCE IS DEFECTIVE IN ANY WAY

c COPYRIGHT ALL RIGHTS RESERVED DURACK PTY. LTD. REDG. DES. NO. 110703

JAN

MARCH

APR

JUNE

BLUE

JUL

SEPT

YELLOW

OCT

DEC

RED GREEN

PLANT NUMBER

TEST DATE

SIGNATURE

LICENCE

/

/

/

/

CAUTION

TA-4 Yellow Oct-Dec

SEPT

AUSTRALIAN MADE

TN-3 Orange Mar/Nov

JUNE

CAUTION

TA-3 Blue July -Sept

TN-2 Blue Feb/Jul

MARCH

JUL

CAUTION

TA-2 Green April-June

TN-1 Red Jan/Sep

JAN APR

BLUE

CAUTION

TA-1 Red Jan-March

NSW ONLY

RED GREEN

AUSTRALIAN MADE

COMPLETE WHERE APPLICABLE

c COPYRIGHT ALL RIGHTS RESERVED DURACK PTY. LTD. REDG. DES. NO. 110703

PLEASE INFORM YOUR ELECTRICAL SERVICES IF THIS APPLIANCE IS DEFECTIVE IN ANY WAY

TA-6 White 6 Monthly July-Dec

TN-6 Yellow Jun/Oct

TA-7 Black Yearly

TN-R Rainbow 17 each of above colours

TA-8 Burgundy 5 Yearly

TN0B Black (no legend)

Catalogue No. TA/TN-series

TA-R Rainbow 25 each of red, green, blue, yellow

TM-series OWNER

OWNER

L I C N o. TESTING COMPANY

OWNER

OWNER

L I C N o. TESTING COMPANY

L I C N o.

L I C N o.

TESTING COMPANY

TESTING COMPANY

Heavy Duty tag using the highest quality adhesive. Suitable for use in all environments. Also available as a barcode tag.

c All Rights Reser vedc All Rights Reser vedc All Rights Reser ved c All Rights Reser ved Mitay Ser vices Pty. Ltd. Mitay Ser vices Pty. Ltd. Mitay Ser vices Pty. Mitay Ltd. Ser vices Pty. Ltd.

Insp. No. JAN

Insp. No. MARCH RED

JAN

MARCH RED

JAN

MARCH

APR

JUNE GREEN

APR

JUNE GREEN

APR

JUNE

JUL

SEPT BLUE

JUL

SEPT

BLUE

JUL

SEPT

BLUE

JUL

SEPT

OCT

DEC YELLOW

OCT

DEC YELLOW

OCT

DEC YELLOW

OCT

DEC

RED GREEN

NEXT TEST DUE

NEXT TEST DUE

/ /

/ / P L A N T N o.

Catalogue No. TM-series

/

/

/

/

Next Test Due Test Date Plant No.

service :

Licence No.N o .

Insp.

1234567

service :

Licence No.N o .

Insp.

1234567

For service :

BY DURACK P/L

1234567

NESCO (07) 3274 2466

BY DURACK P/L

CAUTION

1234567

TTN-3 Orange Mar/Nov

Ensure test is current Before operating

TT-4 Yellow Oct-Dec

TTN-4 Green Apr/Aug

Insp. No.

TT-3 Blue July -Sept

No.

CAUTION

Ensure test is current Before operating

For serviceI n: sp.

TTN-2 Blue Feb/Jul

Plant No.

Licence No.

Licence No.

TT-2 Green April-June

CAUTION

Ensure test is current Before operating

NESCO (07) 3274 2466

Next Test Due

/

/

TTN-1 Red Jan/Sep NSW ONLY

/

/

Test Date

TT-1 Red Jan-March

/ / P L A N T N o.

/

Supplied in packs of 100 with marking pen. Suitable for indoor and office use. Also available as a barcode tag.

/ / P L A N T N o.

T E S T D AT E

Next Test Due

TT/TTN-series

T E S T D AT E

/ /

For Test Date No.

blue, yellow

/ / P L A N T N o.

/ /

/ Plant

TM-5 Orange 6 Monthly Jan-June

T E S T D AT E

NEXT TEST DUE

/

TM-R Rainbow 25 each of red, green,

/ /

/

TM-8 Burgundy 5 Yearly

TM-4 Yellow Oct-Dec

T E S T D AT E

NEXT TEST DUE

Next Test Due Test Date For Plant No.

TM-3 Blue July -Sept

Insp. No.

MARCHRED JUNE GREEN

JAN

APR

BLUE YELLOW

/

TM-7 Black Yearly

Insp. No.

/

TM-2 Green April-June

CAUTION CAUTION CAUTION CAUTION

ENSURE TEST IS CURRENT ENSURE TEST IS CURRENT ENSURE TEST IS CURRENT ENSURE TEST IS CURRENT BEFORE OPERATING BEFORE OPERATING BEFORE OPERATING BEFORE OPERATING

/

TM-6 White 6 Monthly July-Dec

/

TM-1 Red Jan-March

NESCO (07) 3274 2466

BY DURACK P/L CAU TION

Ensure test is current Before operating

TT-5 Orange 6 Monthly Jan-June

TTN-5 White May/Dec

TT-6 White 6 Monthly July-Dec

TTN-6 Yellow Jun/Oct

TT-7 Black Yearly

TTN-R Rainbow 17 each of above colours

TT-8 Burgundy 5 Yearly

TT0B Black (no legend)

TT-R Rainbow 25 each of red, green, blue, yellow

NESCO (07) 3274 2466

BY DURACK P/L

Catalogue No. TT/TTN-series

TT-OF Optical Fibre Tag Used to identify cable source and destination Pack of 100

Catalogue No. TT-OF 10

Test Tag Customisation Sheet TT-Series Please re-write clearly any text you require: Phone

Number of packs required

Mobile

(Min 5 packs per colour)

Fax

Red

(

)

Address

Green

(

)

Blue

(

)

Yellow

(

)

Licence No.

Orange

(

)

Other text

White

(

)

Black

(

)

Burgundy (

)

(Logo to be supplied on business card, letterhead or suitable electronic file. Photocopies cannot be used.)

TM-Series Please re-write clearly any text you require: Phone

Number of packs required

Mobile

(Min 5 packs per colour)

Fax

Red

(

)

Address

Green

(

)

Blue

(

)

Yellow

(

)

Licence No.

Orange

(

)

Other text

White

(

)

Black

(

)

Burgundy (

)

(Logo to be supplied on business card, letterhead or suitable electronic file. Photocopies cannot be used.)

TM-Series Please re-write clearly any text you require: Phone

Number of packs required

Mobile

(Min 5 packs per colour)

Fax

Red

(

)

Address

Green

(

)

Blue

(

)

Yellow

(

)

Licence No.

Orange

(

)

Other text

White

(

)

Black

(

)

Burgundy (

)

(Logo to be supplied on business card, letterhead or suitable electronic file. Photocopies cannot be used.)

11

www.nesco.com.au

Ap p lian ce Test Tag s Test Tag Customisation Sheet NSW TT-Series Please re-write clearly any text you require: Phone

Number of packs required

Mobile

(Min 5 packs per colour)

Fax

Red

(

)

Address

Green

(

)

Blue

(

)

Yellow

(

)

Licence No.

Orange

(

)

Other text

White

(

)

Black

(

)

Burgundy (

)

(Logo to be supplied on business card, letterhead or suitable electronic file. Photocopies cannot be used.)

TM-Series Please re-write clearly any text you require: Phone

Number of packs required

Mobile

(Min 5 packs per colour)

Fax

Red

(

)

Address

Green

(

)

Blue

(

)

Yellow

(

)

Licence No.

Orange

(

)

Other text

White

(

)

Black

(

)

Burgundy (

)

(Logo to be supplied on business card, letterhead or suitable electronic file. Photocopies cannot be used.)

TM-Series Please re-write clearly any text you require: Phone

12

Number of packs required

Mobile

(Min 5 packs per colour)

Fax

Red

(

)

Address

Green

(

)

Blue

(

)

Yellow

(

)

Licence No.

Orange

(

)

Other text

White

(

)

Black

(

)

Burgundy (

)

(Logo to be supplied on business card, letterhead or suitable electronic file. Photocopies cannot be used.)

Te s t I n st r u m en t s

C alib rati on

Calibration Calibration of test eqipment is the only means of establishing and proving that measurements obtained using that equipment are correct. This does not mean that un-calibrated test equipment is inaccurate but without any proof of an instrument’s accuracy, there is no way to confirm that readings taken are in fact correct. The process of having equipment calibrated is primarily to confirm that the equipment concerned is accurate within the manufacturer’s specifications and establishes taceability to known standsards by using commensurately higher spcification equipment to test against, all of which of course has it’s own calibration to confirm it’s status. Traceability is established only with correct certification and effectively compares individual items against national and international standards. NESCO is able to offer traceable calibration certificates with virtually all instruments sold, please consult with our sales department for additional information.

SEW Insulation Tester Checker The ITC8 can be used to check the calibration of resistance ranges of insulation testers and multimeters. Optional The ITC8 can also be ordered complete with a NATA traceable calibration certificate Catalogue No.ITC8CERT

Specifications Measuring Range

Catalogue No. ITC8

0.5Ω, Ω 1Ω Ω, 2Ω Ω, 20Ω Ω, 200Ω Ω, 1kΩ Ω, 10kΩ Ω, 20kΩ Ω, 100kΩ Ω, 1MΩ Ω, 2MΩ Ω, 10MΩ Accuracy +/- 0.05Ω & +/- 2%

(0.5Ω to 2Ω) Ω & (20Ω to 10MΩ) Ω

Transmille Electrical Instrument Test Box Provides the quick, cost efficient solution for the requirement to regularly check test instruments. Checks Insulation Testers

3 Insulation resistor values 1MΩ, 9.9MΩ, 99MΩ (1% Accuracy)

Led indication of test voltage output at 100V, 250V, 500V, 1000V 3 Continuity resistor values 0.5Ω ,2Ω ,10Ω (1% +/-20m Accuracy) AC Line voltage output for testing voltage measurement Checks RCD Testers Functional check of RCD testers via dedicated 10A socket 3 Selectable ranges: 10mA @ 150ms, 30mA @ 150ms, 150mA @30ms Indicators for Ready – Tripped - Overcurrent Checks Loop Testers Functional check of Loop testers via 10A socket Supply loop impedance Supply loop impedance + 1 offset (5% Accuracy) Dimensions – 28cm x 22cm x 9cm Calibration certificate available on request.

Catalogue No. 2080

13

www.nesco.com.au

Tes t Ins trum e n t s

Test In st r u m en t s

MARTINDALE 250/500/1000V Digital Insulation Tester

Large 4,000 count backlit digital display with analogue bar graph.



Measures insulation resistance, AV/DC voltage, continuity and resistance of electrical circuits.



Automatic zero adjust removes the resistance of the test leads.



Output test voltage is displayed during testing.



For higher accuracy testing polarisation index and dielectric absorption ratio functions are provided.

Included Accessories Batteries, test leads, instruction manual, carry case

Specifications Function

Measuring Range

MΩ

AC/DC V

250V 500V 1000V 600V

Resistance

0.1Ω –2,000MΩ

Continuity

0.01Ω – 40Ω

Catalogue No. IN2103

SEW 250/500/1000 Volt Analogue Insulation Tester High powered, high quality analogue insulation tester 3Ω Low resistance range “Live Circuit” warning beeper & indication. Automatic safety discharge once the test is completed.

5 YEAR

Displays AC voltage measurement of mains supply. Included Accessories

WARRANTY

TL-24 test leads, 1 x 0.25A 250V fuse, instruction manual, 8 x AA batteries, carry strap.

Specifications Function

Measuring Range

Scale

MΩ

1000V

0-400MΩ

500V

0-200MΩ

250V

0-100MΩ

ACV

0-600V

-

Resistance

0-3Ω

-

0-500Ω

-

Catalogue No. 1832IN

14

In su lat io n Te sters

KAISE 500/1000V Analogue Insulation Tester

High accuracy testing Timer switch enables continuous measurement, up to 3 minutes Live line detection Displays AC measurement of mains supply Dust proof & water resistant case

Included Accessories TL-5 test leads, 6 x AA batteries, instruction manual, carry strap.

Specifications Function

Measuring Range

Scale

MΩ

500V, 1000V

100MΩ & 200MΩ

ACV

0-600V

-

Resistance

0-50Ω

-

Continuity

Buzzer sounds less than 20Ω

-

Catalogue No. SK-3015

Metrohm 5kV Analogue Insulation Tester

Can be operated from internal rechargeable batteries or from an external AC supply Housed in a rugged moulded plastic case Detachable lid protects the front and provides storage for test leads Battery Indication

Included Accessories DFK0075/A test leads, mains power supply lead, internal 12v NiCad Pack, instruction manual

Specifications Function

Measuring Range

Scale

MΩ

500V, 1KV, 2.5KV, 5KV

100kΩ to 100GΩ

ACV

1000V AC

-

Catalogue No. E3511

For complete specification see our website www.nesco.com.au

15

www.nesco.com.au

I n s ula tion Tes t e r s

Test In st r u m en t s

AEMC 5KV Digital / Analogue Insulation Tester Programmable test run times and Pl ratio times Selectable smooth function enables digital filtering to stabilize readings Direct measurement and display of capacitance and leakage current. Display resistance, test voltage and run time Large dual backlit display with time, voltage and measurements shown. Auto power-down when not in use Designed to protection class 61010-1 1000V Cat III Rugged weatherproof field case. Included Accessories Accessory bag, test leads c/w 5kV rated hippo clips, rechargeable battery, power cord and manual. Model 5060 also includes Data View Lite software and cables for ing

Specifications Models

5050

5060

Test Voltage

500V 1000V 2500V 5000V

20kΩ to 2000GΩ 40KΩ to 4000GΩ 100KΩ to 10,000GΩ 200KΩ to 10,000GΩ

Voltage (selectable)

50 to 1000V / 10V increments

1000 to 5000V / 100V increments

Voltage Test/ Safety Check

0 to 1000V AC/DC

Power Source

AC or DC with 8 x NiMH rechargeable `batteries

Storage of readings over time

4kB memory

128kB memory

Storage of test results

20 Readings

128kB memory with RS-232

PC Application Software

No

Yes (included)

Report Generation

Yes

Catalogue No. 5050 16

Electromate Voltage & Continuity Probe Tester

AC/DC voltage indication up to 600V Continuity test audible & visual Voltage display fully operational even without batteries Internal basic load can be used for RCD tripping Single pole test for phase detection

Included Accessories 2 x AAA batteries

Specifications Function

Measuring Range

Display

10 Led’s

Voltage

12 ….690V AC/DC

Single pole

100…690V AC

Designed to Protection Class IEC 61010-1 600V Category III

Catalogue No. 7090

Electromate Basic DMM Digital multimeter in a handy compact housing Temperature measurements up to 1000C using thermocouple K-type sensor (supplied with wire probe type-K sensor for measurements up to 250ºC) Included Accessories Holster, wire temp probe, 9V battery

Specifications Function

Measuring Range

Voltage

500V AC/DC

Current

200mA DC

Resistance

2MΩ

Temperature

-40ºC to 1000ºC

Continuity

Buzzer

Catalogue No. 7241

SANWA Pocket DMM Loaded with functions . Auto power off. Included Accessories Case holder, instruction manual

Specifications Function

Measuring Range

Voltage

500V AC/DC

Resistance

40MΩ

Capacitance

200µF

Frequency

99.99kHz

Continuity

Buzzer sounds at less than 60Ω

Catalogue No. PM3 17

www.nesco.com.au

M ultim e te rs

Test In st r u m en t s

SANWA Analogue Multimeter When the meter is not in use the test leads & the front is protected by a hard cover. Null (zero centre) meter in DC V Drop and shock resistant meter. Included Accessories TL-21 test leads, carry strap, instruction manual, 2 x AA batteries cover closed

Specifications Function

Measuring Range

DCV

1000V

ACV

750V

DCA

0.25A

Resistance

200MΩ

Capacitance

10µF

Catalogue No. YX-360TRF

SANWA DMM with Holster A rugged DMM that feels good to use

Designed to Protection Class IEC 61010-1

Large LCD with a curved bar graph

600V Category III

Auto power off Included Accessories TL-21 test leads, holster, instruction manual Optional Accessories Catalogue No.CC1 Electromate carry case

Specifications Function

Measuring Range

ACV

750V

DCV

1000V

Current

12A AC/DC

Resistance

2MΩ

Continuity

Buzzer sounds less than 20Ω

Diode

open voltage 3V

Catalogue No. CD721 18

NEW

SANWA DMM with Hard Case Protection Versatile digital multimeter Unique clip on hard front protective cover. Designed to Protection Class IEC 61010-1

Included Accessories Instruction manual

600V Category III

Optional Accessories Catalogue No.CC1 Electromate carry case

Specifications Function

Measuring Range

DCV

500V

ACV

600V

Resistance

40MΩ

Capacitance

100µF

Frequency

100kHz

Current

400mA AC/DC

Continuity

Buzzer sounds 10 - 80Ω

Duty

10 – 90%

Diode Test

Open voltage approx.1.5VDC

Catalogue No. CD800A

SANWA Industrial DMM Versatile measurement range with great accuracy Auto power off Alarm warning for incorrect insertion of leads into the current terminals if the meter is set on the wrong function Included Accessories Holster, TL-82 test leads, K-type thermocouple, instruction manual Optional Accessories Catalogue No.CC1 Electromate carry case Test Leads, Carry Cases & Accessories (page 37 & 38)

Specifications Function

Measuring Range

Voltage

1000 AC/DCV

Current

10A AC/DC

Resistance

40MΩ

Continuity

Buzzer sounds between 5 and 120Ω

Capacitance

3000µF

Frequency

1MHz

Temperature

-20º to 300ºC -4º to 572ºF

Diode Test

Open voltage approx.3V

Designed to Protection Class IEC 61010-1 600V Category III

Catalogue No. RD700 TRMS MODEL Catalogue No. RD701 19

www.nesco.com.au

M ultim e te rs

Test In st r u m en t s Designed to Protection Class IEC 61010-1

SANWA High Standard DMM PC Series

600V Category III

Included Accessories Instruction manual, holster, TL-82 test leads, (PC510 only K-type thermocouple) Optional Accessories With (KB-RS2) cable and (PC Link/PC or PC Link Plus) software, measuring data is transferred to PC through RS232 port for data logging.

SANWA PC500 High Accuracy DMM Catalogue No. PC500

SANWA PC510 High Accuracy TRMS DMM (Temperature Measurement)

Designed to Protection Class IEC 61010-1

SANWA PC5000 4½ Digit TRMS DMM Advanced Features

600V Category III

Specifications Function

PC500

PC510

PC5000

TRMS

-





Max/Min recording

-





Voltage AC (AC+DC)

-

-



Current (AC +DC)

-

-



Temperature

-

-50ºC to 1000ºC

-

Basic accuracy

0.08%

0.08%

0.03%

Display

5000 counts

5000 counts

50,000 counts

Voltage

1000V AC/DC

1000V AC/DC

1000V AC/DC

Current

10A AC/DC

10A AC/DC

10A AC/DC

Resistance

50MΩ

50MΩ

50MΩ

Capacitance

9999µF

9999µF

9999µF

Frequency

5Hz to 125kHz

5Hz to 125kHz

5Hz to 200kHz

Continuity Buzzer

operates 20Ω−120Ω

operates 20Ω−120Ω

operates 20Ω−120Ω

Catalogue No. PC510

Designed to Protection Class IEC 61010-1

%4 to 20mA

-

-

4mA(%) to 20mA(100%)

Logic Frequency

-

-

5Hz to 2MHz

Indicates included functions

600V Category III

Catalogue No. PC5000

PC-LINK Sanwa management software

KB-RS2 ing cable

20

Catalogue No. PC-LINK

Catalogue No. KB-RS2

C lam p Meters

MULTI Leakage Clamp Meter Wide range of digital current measurements (0.01A – 300A AC) 40mm ø CT enables both leakage current and line current measurements Compact size only 162mm long Auto power off Data hold Included Accessories Carrying case, instruction manual, 2 x LR44

Specifications Function

Measuring Range

Resolution

A AC

30/300mA

0.01mA AC

30/300A

0.01A AC

Catalogue No. 140

MULTI Mini Digital AC/DC Clamp Meter Wide range of digital current measurements (0.01A – 200A AC/DC) 30mm ø CT Suitable for low current measurement in both AC and DC Ultra compact size only 146mm long Included Accessories Carrying case, instruction manual, 2 x LR44

Specifications Function

Measuring Range

Resolution

A AC

20 A AC

10mA

200A AC

100mA

20 A DC

10mA

200A DC

100mA

A DC

Catalogue No. 240

SEW 1000A AC/DC Clamp Meter Very versatile digital meter Auto ranging voltage, current and resistance functions. Data hold 400mm ø conductor size Included Accessories TL-3A test leads, carrying case, instruction manual, 1 x 9V battery

Specifications Function

Measuring Range

ACA

400/1000A

DCA

400/1000A

ACV

400/600V

DCV

400/600V

Ω

2000 Ω

Buzzer

Sounds less than 100Ω

Catalogue No. 3800CL 21

www.nesco.com.au

Cl a m p M e te r s

Test In st r u m en t s

SEW W 300A AC Analogue Clamp Meter Low cost clamp meter Only one scale in the display window at a time to avoid reading errors. 38mm ø conductor size Included Accessories TL-3A test leads, carrying case, instruction manual, 1 x AA battery

Specifications Function

Measuring Range

ACA

6/15/60/150/300A

ACV

300/600V

DCV

75V

Ω

2000 Ω

Catalogue No. ST-375

SANWA 400A Clamp Meters

Catalogue No. DCM400 & DCM400AD

Professional clamp meters

25mm ø conductor size



Data hold, range hold



DCA on DCM 400AD

Included Accessories TL-82 test leads soft carry case, instruction manual, 2 x AAA batteries

SANWA 600A AC Clamp Meters Great value 30mm ø conductor size Data hold Included Accessories TL-82 test leads (DCM60L only) soft carry case, instruction manual, 2 x AAA batteries

Catalogue No. DCM60 & DCM60L

Specifications Function

DCM400

DCM400AD

DCM60

DCM60L

40/400A

40/400A

20/200/600A

200/600A

40/400A

-

400/600V

-

Current ACA Voltage DCA ACV

400/600V

600V

Frequency (A) 20-4k 10kHz

-

-

-

(V) 4k/40k/400k/1MHz

-

-

-

Resistance

22

400Ω

400Ω

-

200Ω

SANWA 2000A AC/DC Clamp Meter 55mm ø conductor size Included Accessories TL-82 test leads carry case, instruction manual, 2 x AAA batteries

Specifications Function

Measuring Range

AC/DCA

40/400/2000A

AC/DCV

400m/4/40/400/600V

Frequency

100/1k/10k/100k/1000kHz

Resistance

400/4k/40k/400k/4000k/40MΩ

Catalogue No. DCM2000AD

MULTI Large Jaw 3000A Clamp Meter Huge CT 108mm jaw opening Measures TRMS AC current and leakage current Data hold and filter function Auto power off Included Accessories Instruction manual, carry case, 2 x AAA batteries

Specifications Function

Measuring Range

AC current

0.1mA to 3000A

Catalogue No. MCL-1100D

Electromate DMM / Open Jaw Current Measurement

NEW

Features two LCD displays Auto power off Data hold for each display Duty cycle and diode test

AC current display always functional Included Accessories Blister packaged, TL-3A test leads, 2 x AA batteries

Specifications Function

Measuring Range

Current

200A AC

Voltage

600V AC/DC

Resistance

0.1Ω to 40MΩ

Capacitance

1pF to 200µF

Frequency

0.001Hz to 9.999MHz

Catalogue No.DT2001 23

www.nesco.com.au

Sp e c ia l P urp o s e Meters & Accessories

Test In st r u m en t s

SEW RCD Tester Measures Tripping Time

Accurate digital readout of disconnection time. Measures line to earth voltage Select testing at 0 or 180 Main supply correct polarity indication by LED’s Indicates % error from input voltage fluctuation

Included Accessories Instruction manual, TL-EL 3 pin test lead, shoulder belt, 8 x AA batteries Optional Accessories TL-30 test leads

Specifications Function

Measuring Range

Fault Test Current

3-500mA

Catalogue No. 1812EL

Electromate RCD Tripper Low cost Wiring check by LED’s Test current range 10 – 35mA The RCD tripper is designed to trip RCD’s of 30mA rating or less while giving mains supply check by way of LED indicators.

Catalogue No. S-1602

24

SEW Loop Impedance Tester The complete electrical network can be analysed by scrolling through the results. Bad s, old wiring or bad earth paths are quickly identified. Included Accessories manual, TL-30 and TL-EL 3-pin test lead, shoulder belt, 8 x AA batteries

Specifications Function

Measuring Range

Loop Impedance L-E, L-N

0.03 to 2000Ω

Test currents in each loop

11.76A at 230V

Voltage L-N, L-E

50 to 230V

Earth resistance

0.01 to 2000Ω

Neutral, Line Resistance

0.01 to 2000Ω

PSC Current L-N, L-E

6kA at 230V

Catalogue No. 1826NA

HT ITALIA SPEEDTEST RCD and Loop Impedance Tester Multifunction instrument that checks manually or automatically tripping times and currents of general and selective RCD’s type A and AC, also total earth resistance, line and fault impedance with calculation of prospective short circuit current and phase sequence indication. Innovative Loop Impedance Test Function A feature of this unit is a selectable 15mA test available, to test fault loop impedance without tripping any RCD installed upstream. Innovative Automatic RCD Test Function Simply by connecting to the circuit in auto mode and waiting at the distribution boardto reset the RCD the HT2018 will perform six tests checking the RCD’s performance curve across ½, 1x and 5x it’s rating at 0 and 180. Measured results are stored and also evaluated at /fail against the standards. Included Accessories Instruction manual, factory calibration certificate and test leads. Optional Accessories HTE-LINK ing software c/w interface cable.

Catalogue No. HT 2018

Specifications See RCD & Loop Impedance functions in the HT2019 specification table page 29..

For complete specification see our website www.nesco.com.au

25

www.nesco.com.au

Sp e c ia l P urp o s e Meters & Accessories

Test In st r u m en t s

AEMC Digital Earth Resistance Tester Measures Earth Resistance 0.01 to 1999Ω Test current of up to 10mA 2 or 3 terminal measurement 4 terminal measurement soil resistivity Auto-ranging selects the optimum range Backlit display Power supply Model 4620 8 x C batteries Power supply Model 4630 AC powered and rechargeable NiMH batteries Rugged dust and rainproof case Included Accessories Instruction manual

Catalogue No. 4620 Optional Accessories Earth resistance and earth resistivity test kits - refer Nesco for details.

SEW Digital Earth Resistance Tester Measures Earth Resistance 0.01 to 1999Ω Test current of 2mA 2 or 3 terminal measurement Manual ranging 20,200,2000Ω scales Power supply 8 x AA batteries Included Accessories Red, Yellow , Green test leads, auxiliary earth spikes, measurement probe, instruction manual

Catalogue No. 4120 ER

HT ITALIA GEOTEST Earth Resistance Tester Measures Earth Resistance 0.01 to 1999Ω Test current up to 10mA 2 or 3 terminal measurement 4 terminal measurement soil resistivity Stores results Included Accessories Carry case, instruction manual, calibration certificate, 4 rods, 4 cables Optional Accessories EUROLINK 2000 ing software and interface cable

Catalogue No. HT2016 26

HT ITALIA Power Quality Analysers The HT ITALIA range of Power Quality Analysers are designed to test, measure, record and analyse single / three phase systems (with or without neutral). The instruments will display in real time the values of all fundamental electrical quantities and the trend waveforms of voltages and currents. Software provided with these units enlarges the potentialities of the instruments. From simply recording maximum demands of installations and equipment to recording voltage anomalies every 10ms HT ITALIA can accommodate these requirements in their range. Simple to use, selection of type of measurement is made by rotating a switch and pressing selection keys. HT2020E ENERGY TESTER designed to carry out a complete analysis of the power supply. HT9032 Power Quality Analyser incorporates the same features as the HT2020E combined with powerful tools for investigating anomalies and disturbance. GSC57 Total integration of a unique range of functions in one test unit. Incorporating the features of the HT9032 with advanced Installation Test Functions and with the addition of accessories Environmental Testing.

Specifications Function

HT2020E

HT9032

GSC57

Voltages







Currents







Phase and Total Active Power







Phase and Total Reactive Power







Phase and Total Apparent Power







Phase and Total Power Factor







Frequency







Harmonics (from the 2nd to the 49th for Voltage and Current)







Analysis of Voltage Anomalies





Harmonic Analysis





Phase Rotation



Leakage Current to Earth



Earth Resistance & Ground Resistivity



Insulation Resistance



Continuity (Test current up to 10A)



RCD Tripping Time & Current



Line & Loop Impedance



Calculation of Prospective Short Circuit Current



Environmental Testing (with accessories –temperature, humidity, air speed, luminosity)



Catalogue No.HT2020E

Catalogue No.HT9032

Catalogue No.GSC57

27

www.nesco.com.au

Sp e c ia l P urp o s e Meters & Accessories

Te st In st r u m en t s

Installation Tester Installation Testing is the overall term for the complete range of electrical tests which should be carried out on all new electrical installations and also on existing installations which have had additions or alterations carried out. Most electrical workers are more than familiar with the most common tests routinely carried out such as; Insulation Testing & Low Resistance (Continuity), ) apart from these there are also several other tests which are now part of almost every electrician’s list of “must do” tests before g off a job, Fault Loop Impedance, RCD Test and on 3 Phase installations, Phase Rotation. The adoption of new standards has made the previously little known Fault Loop Impedance test a virtual prerequisite (even though AS3000 does not call this a mandatory test) and RCD Testing is equally as important with these devices being commonplace.

The HT2019 Combitestt distributed by NESCO Electrical Products provides an economical alternative to a range of separate pieces of test equipment providing the entire gamut of tests in a single, handheld instrument. Low Resistance testing with >200mA test current, insulation resistance tests (with test voltages from 50V up to 1000V), multi-function RCD Testing, high current Loop Impedance tests, and <15mA Loop Impedance tests plus Phase Rotation make the HT2019 the answer. Not only does the HT2019 provide a complete testing package but all results may be saved to an internal memory and can then be transferred to a PC with an optional pack which includes software to enable fast and professional presentation of test reports for customers. This also removes any doubts about the final results, which may be raised when using a manual, hand written system as the results are directly transferred from the tester to PC.

With the advent of such new requirements, many electrical workers and companies have had to re-assess their test equipment as they either had to purchase several new testers or look at the alternative of a single multi-function tester to do everything required which is where the concept of the Installation Tester was generated.

ContinuityTest

Insulation Resistance

RCD AC Type

RCD Type A

Fault Loop Impedance 15mA Fault Loop Impedance Feature Phase Rotation RS232 Output

Catalogue No. HT2019 28

HT ITALIA COMBITEST Multifunction Instrument Measurement of Low Resistance, Insulation Resistan Line and Fault Loop Impedance measurement with Current calculation and Phase Sequence. You can store the test results inside instrument m instrument display and transfer them to a serial p management software you will be able to create Included Accessories 3-pin plug lead, instruction manual, factory ca and test leads, test probe and carry bag. Optional Accessories Catalogue No. HT-Link management softwa

Specifications Function

Measuring Range

Resolution

Voltage Insulation Resistance (Test Voltages

Continuity (Test current 200mA)

MΩ MΩ

Frequency

Hz

Line Impedance (phase – phase, phase – neu

01Ω 20 – 199.

0.1Ω

0.01 – 19.99Ω

0.01Ω

20 – 199.9Ω

0.1Ω

200 – 1999Ω

1Ω

1 –1999Ω

1Ω

½ Rated Current

0 – 999ms

1ms

2 x Rated current

0 – 200ms

1ms

5 x Rated current

0 – 160ms

1ms

Fault Loop Impedance (phase - earth)

Fault Loop Impedance (15mA test current, without RCD tripping) RCD Tripping Time (Type AC)

RCD Tripping Current (Type AC) Phase Sequence

0.1mA Indication

For complete specification see our website www.nesco.com.au

29

www.nesco.com.au

Sp e c ia l P urp o s e Meters & Accessories

Te st In st r u m en t s

SEW Fused Low Voltage Test Lamps Low voltage test lamps are the simplest and most reliable instruments for low voltage mains testing and proving for dead. Included Accessories Lamps, carry case, instruction manual, fused lead, screw on alligator clip

Specifications Function

Measuring Range

ACV

240/415V

Lamps

2 x 15W 220V

Fuse

0.5A / 660V

Catalogue No.STL-5

SEW Phase/Motor Rotation Tester Checks open phase via lamps Checks phase rotation via lamps Checks motor rotation via lamps Motor rotation can be determined on a de-energised motor by connecting the test leads, hand turning the rotor shaft and pressing the test button. Included Accessories Carry case, instruction manual, test leads, 1 x 9V battery (for motor rotation function)

Catalogue No. ST-860

SEW Phase Rotation Meter Checks phase rotation via rotating disc Lamps indicate weather a phase is open and which phase at a glance. Robust construction, sealed against dust. Safety design, no exposed metal parts. Included Accessories Carry case, instruction manual, test leads

Catalogue No. ST-855PR

30

TEEL Digital Lightmeter Simple one hand operation Range from 20 to 200,000 Lux Resolution 0.01Lux Backlit display Max/ Data hold function Included Accessories Instruction manual, carry case, 4 x AAA batteries

Catalogue No. DLM-530

Electromate Non Infra – Red Thermometer With Laser Pointer Check for “hot ts” in electrical installations, moving objects or where actual is not practical or desirable. In-built laser sighting Selectable ˚C / ˚F measurement Automatic data hold and auto power off Backlit LCD Specifications Temperature range –20˚C to 450˚C (-4˚F to 842˚F) Power supply 9 volt battery Included Accessories

Catalogue No. DT-8811

Blister packaged

Ireland Mini Thermometers Temperature range –50ºC to +250ºC Resolution 0.1ºC / 1ºC Data hold LCD display

Catalogue No. 6201 Needle Point

Catalogue No. 6202 Surface Probe

For complete specification see our website www.nesco.com.au

31

www.nesco.com.au

Sp e c ia l P urp o s e Meters & Accessories

Test In st r u m en t s

TEEL Dual Input Temperature Meter 0.1º C or 1.0º C resolution selectable Dual thermocouple input Differential temperature measurement Maximum and reading hold function Measurement range –50 to 1300ºC (-58 to 2000ºF) Sensor K-type thermocouple Included Accessories Instruction manual, holster, 2 x TPK-01 bead probes, 1 x 9V battery Refer to accessories page 38 for optional temperature probes.

Catalogue No. DTM-307

Martindale Microwave Leakage Detector Microwave leakage detector with an audible warning device and visual LED’s for detecting exposure levels. The unit is supplied in an outer case, which contains a beaker and a thermometer. This allows measurement of the microwave power output by measuring the temperature rise in a known volume of water after a fixed period of time. Specifications Power supply 9V battery Self test function Indicators Green LED battery O.K. Yellow LED 1mW.cmsq Red LED and audible tone microwave leakage above safety levels Included Accessories Hard carry case, instruction manual, thermometer, beaker, and detector

32

Catalogue No. TEK500

SEW High Voltage Proximity Detector The tester works by proximity; it senses that radiated field which surrounds live conductors. Visual and audible alert Eight voltage detection settings 240/2k/3.3k/6k/11k/22k/33k/66k/132k/275kV AC

Catalogue No. 270HP

Complete with sunrise fitting for hot sticks High impact plastic casing Battery supply 3 x D batteries Continuous self test function Low battery indication

Also available – Catalogue No. 270HP-SB (tester complete with 1.2 metre safety stick and carry bag)

MEET Non Audible/ Visual Voltage Tester Self test function Non- volt tester 70-600V AC Continuity tester 0 –2MΩ DC polarity tester 1.5 -36V DC Microwave leakage detection >5MW/cm Included Accessories

Catalogue No. MS-148E

Blister packaged, 2 x LR44 batteries

MEET Non Test Pencil Convenient easy to use test pencil Non- volt tester 70-250V AC volt tester 70 – 600V AC Continuity tester 0 –50 MΩ DC polarity tester 1.5 -36V DC Microwave leakage detection >5MW/cm sq IP 44 rated

Catalogue No. MS-18

2 x 1.5V LR41 batteries

MEET Non Audible/ Visual/Vibrating Voltage Tester Unique tester is easy to hear with a “cricket chirp” audible alert for the presence of voltage as well as vibration and visual indication. Non- volt tester 70-600V AC Microwave leakage detection >5MW/cm Included Accessories

Catalogue No.MS-47VH

Blister packaged, 4 x LR44 batteries

MEET Non Adjustable Sensitivity Wide range of voltage detection Non- volt tester 5-1000V AC Self test function 4 x LR44 batteries

Catalogue No.MS-47NS-3

33

www.nesco.com.au

Sp e c ia l P urp o s e Meters & Accessories

Te st In st r u m en t s

SEW Tone Tracer Kit Designed for use mainly on data / communication systems Identify and trace wires or cables in a group Volume / sensitivity control Continuity and polarity tester Three colour LED display Amplifier probe Is designed to identify and trace wires within a group without damaging the insulation.

Catalogue No. 180CB Tone generator Provides a tone and also serves as a continuity and polarity tester. As well as tone a three-coloured LED displays results. Included Accessories Instruction manual, alligator clip test leads, RJ11 test plug, 2 x 9V batteries, carry case.

C-Scope Underground Cable Locator / Tracer with Depth Indicator High performance cable avoidance tool providing the ultimate information about underground services before you dig. Depth mode function displays the depth of the applied signal when using the signal generator. Fingertip controls, lightweight and rugged locator Included Accessories Soft carry bag, detector, signal generator, instruction manual

Specifications Detector LCD display shows signal strength, battery condition, and signal depth Speaker for audible detection Power supply 8 x AAA batteries Moisture and dust resistant IP65 Signal Generator Pulse / continuous switch Power supply 4 x D batteries

34

Catalogue No. CS CAT-XD

C ab le Lo cati on & Tr ad in g Eq u ipment

Martindale Elite Fuse Finder Kit For tracing 240V circuits only Included Accessories Transmitter, receiver, hard carry case, TL-83 test leads, 3-pin test lead

Specifications Transmitter Power supply from mains Automatic and manual modes of detection for faster identification Earth leakage from transmitter is nil Receiver Sensitivity adjustment via potentiometer Response – Audible and visual 6 segment bar graph 9V battery supply

Catalogue No. FD650

Pathfinder Circuit Tracer Locate, trace and isolate circuits quickly and easily. No distance limitation, track the circuit upstream from the transmitter. Traces live or de-energised circuits (using an external power supply e.g. battery) Operates on a wide range of voltages. Included Accessories Transmitter, detector, carry bag, 3 pin test lead, 9V battery supply (for detector).

Specifications Transmitter Operating Voltage

9-600V AC/DC

Fuse protected Detector Sensitivity settings

– 2,10,20,100%

Detector response

Visual 10 red LED’s Audible chirp 9V battery power supply

Catalogue No. PF620

35

www.nesco.com.au

W i r ing Te s ter s

Te st In st r u m en t s

AEMC Cable Length Meter & Fault Locator Alphanumeric TDR Fault Mapper CA7024 measures the length of electrical and communication cables up to 2000m. Indicates the distance to a fault up to 2000m in the cable (open or short) given access to only one end of a two or more conductor cable. Built –in tone generator for tracing and locating cables (optional Tone Receiver Model TRO2 is required for detection). Included Accessories Soft carry case, BNC pigtail cable with alligator clips, manual, 4 x AA batteries.

Catalogue No. CA7024

Optional Accessories Tone Receiver TRO2

AEMC Telephone/ Coaxial/ Parallel Cable Tester Graphical TDR Fault Mapper Pro Model CA7026 identifies and locates faults and the distance to them on power & communication cables up to 3500m given access to one end of a two or more conductor cable. Cable under test is displayed as an oscilloscope-like trace. Built –in tone generator for tracing and locating cables (optional Tone Receiver Model TRO2 is required for detection). Included Accessories Soft carry case, BCN pigtail cable with alligator clips, manual, 4 x AA batteries.

Catalogue No. CA7026

Optional Accessories Tone Receiver Tro2

AEMC - LAN Cable Tester Wire Mapper Pro Model CA7028 is a structured cable mapping and troubleshooting tester. It detects open circuits pairs, shorts, crossed wires, crossed pairs, reversed pairs, split pairs and shield faults.

Catalogue No.TRO2

In the event of opens and shorts TDR technology is used to indicate if the fault is at the near end or the remote end or if it is somewhere in between. It will then indicate the distance to the fault up to 150m. Service check function to detect telephone, 10BaseT, 100Mbit+ and token ring. Cable length can be measured also the unit generates a tone into all 4 pairs under test that can be used for circuit tracing (optional Tone Receiver Model TRO2 is required for detection). Included Accessories

Catalogue No. CA7028

Soft carry case, remote ID (#1), two patch cords, manual, 4 x AA batteries. Optional Accessories Tone Receiver Tro2 Wire Mapper Pro Remote Ids (#2 to 5) Wire Mapper Pro Remote Ids (#6 to 9)

36

Remote Unit

Electromate 1000V Fused Test Leads Suits most multimeters Short safety tips 500mA, 50kA fuses Type A 1000V CATIII

Catalogue No. 131301

Electromate 1000V Fused Test Leads Suits most multimeters Shuttered spike tips 500mA, 50kA fuses Type A 1000V CATIII

Catalogue No. 131347

Electromate Croc Clips To Suit 131301 or 131347 Fused Test Leads One red, one black Type A 1000V CATIII

Electromate Test Lead Set Suits 1826NA / 1813EL Meters

Catalogue No. 134273

Catalogue No. TL-30

Electromate Generic Multimeter Leads Suits most multimeters

Catalogue No. TL-3A

Blister packed

Electromate Test Lead Set Suits SK-3015/ 1800IN Electromate Test Lead Set Suits 1800IN, 1851IN, DMM etc. SANWA Test Lead Set Suits RD700 & PC500/510/5000 Electromate 3 Pin Test Lead Set Suits 1826NA, 1813EL

Catalogue No. TL-5

Catalogue No. TL-6

Catalogue No. TL-82

Catalogue No. TL-EL

37

www.nesco.com.au

Test Leads, Carry Cases & Accessories

Te st In st r u m en t s

Electromate Vinyl Carry Case Catalogue No. CC1

Soft padded protection for most multimeters

Earth Wire Reel Portable cable reel Supplied with 2 alligator clips and earth spike Complete with 50 meters of flexible 1.5mm2 30/0.25 V90 trailing lead

Catalogue No. EWR-50F

CTWR ALVEY Circuit Test Wire Reel Handy test wire reel fitted with a large stud for meter test lead connection (no cable or clip supplied)

Catalogue No. CTWR

NESCO Temperature Adaptor for DMM Suits “K” type thermocouple Suits RD700, PC 510

NESCO Bead Temperature Probe

Catalogue No. TA-100

Catalogue No. TP-01A

Type “K” –20 to 200ºC, air only

NESCO Sheath Temperature Probe Type “K” –50 to 800ºC, pointed tip

Catalogue No. TPK-03S

NESCO Surface Temperature Probe Type “K” –50 to 800ºC

Catalogue No. TPK-04

NESCO Air Temperature Probe Type “K” –50 to 800ºC

38

Catalogue No. TPK-05

Wo r k p l a c e S af et y Pr o d u ct s

NESCO Rubber Safety Mats Note: Other configurations in relation to size and voltage are available. Please consult sales office for details. All rubber safety matting are tested and tagged. Part No

Description

MATRUBBER

Rubber Safety Floor Matting - Black 1000mm x 1000mm x 6mm thick 650 Volt AC Tagged and Tested to AS2978-1995 C/W Protective Carry Bag

OHLMAT

Overhead Linesman’s Matting – Yellow 1000mm long x 350mm drop 650 Volt AC Tested to AS4202-1994

Catalogue No. MATRUBBER

ELECTROMATE Low Voltage Switchboard Rescue Kit Features

Complies with Department of Mines and Energy specifications



Only high quality components used



High visibility container - bright yellow



Clearly labelled



Easy to store and transport

If used, the fire blanket and burns dressing must be replaced with new items after a rescue has been effected. All components are available as replacement parts.

Kit comprises of: Part No

Description

SBRBAG

Rescue kit carry case

SBRT

Weatherproof torch and batteries

SBRFB

Fire Blanket

SBRBD

Multi trauma dressing

SBRSIGN

Isolation tag

SBRCROOK

1000V rescue crook

RG1000360-11

1000V insulating gloves

Catalogue No. SBRKIT

All components available as separate items Designed for the rescue of workers in live situations. Essential for all personnel working in potentially dangerous locations. The type of equipment you can’t afford not to have, but hope you never need.

For complete specification see our website www.nesco.com.au

39

www.nesco.com.au

Wo r kp lace Saf et y Pr o d u ct s

NESCO Personal Protection Equipment Kit A convenient kit to assist with safe work practices and hazards of a general nature. Kit comprises of:

Carry Bag



1 x Pair reusable ear plugs



1 x First aid kit



1 x Lockout Tag – Out of Service



1 x Pair safety glasses with lanyard



1 x Pair leather riggers gloves



1 x 4.25g SPF30+ lip balm applicator



1 x 500ml Hand cleaner



1 x Pair of ear muffs



1 x Sterile Burns treatment Dressing



1 x Lockout Tag – Do Not Operate



1 x Voltage proximity tester



4 x Respiratory P1 Dust Masks



1 x 500ml pump action bottle of SPF30+ sunscreen

Catalogue No. PPEKIT

The PPE Kit provides some of the basic personal protective equipment that can assist where hazards of a general nature may be present. Risk assessments should be carried out to determine the level of risk and control measures and or appropriate protective equipment required for each task. Also ensure that the equipment provided is a proper and comfortable fit.

MOXHAM Roof Works Kit Fall arrest kits designed for roof workers. Part No

Description

RWKIT

Kit components can be selected to suit specific applications Please sales for further information

Catalogue No. RWKIT

40

NESCO Workplace First Aid Kits Government Workplace Health & Safety Advisory Standard for First Aid in the Workplace. Contents of a First Aid Kit where the risk of injury or illness is MODERATE Generally suitable for small construction sites, manufacturing and light industry for 1 to 29 persons.

Catalogue No. SGFAKGPM

Metal Carry Case Dimensions 380 x 130 x 165mm

Wall Mounted Version in a metal box

Catalogue No. SGFAKGWM

Dimensions 460 x 350 x 175mm

NESCO Car & Travel First Aid Kits Handy personal first Aid Kit basic items. Dimensions 260 x 120 x 45mm

Catalogue No. SGFAKGB

Extension Lead Safety Clips The OSC (Orange Safety Clip) is an Australian designed and manufactured clip for holding extension leads up off the floor. It can be attached to timer by nails or screws, metal by screws or by cable ties to other items. Pack of 6 The SCC (scaffold cable carrier) is designed to extension leads on 48mmø scaffold pipe. Each clip will 7 leads in three different sizes. 3 x 1.5mm, 3 x 1.0mm and 1 x 0.75mm. If someone accidentally snags the cable, it will be released from the clip rather than dragging the clip off its mounting.

Catalogue No. OSC

Catalogue No. SCC

For complete specification see our website www.nesco.com.au

41

www.nesco.com.au

Wo r kp lace Saf et y Pr o d u ct s

Harnesses Part No

Description

Harnesses Elite

Full Body harness with multiple attachement points: ie rear buttock strap, extended dorsal, side and front D-rings. Suitable for linesman, riggers, tower workers & E.W.P work.

480S

General Purpose harness, with adjustable leg and sholder straps, dorsal D-ring, breathable triangular back. Standard type harness for poletop work. Can be worn comfortabley all day.

Pole Straps 136

Webbing pole strap and double action snap hooks with 15mm opening and 90 degree twist 1.8 meter length.

148

As above complete with length adjustment, by adjuster hook and toggle. 2.4meter length.

Lanyards 176WSA

Two No 35 (15mm gap) hooks, 35mm webbing, c/w shock absorber 1.8 meter length

176SA

Two No 35 (15mm gap) hooks, 12mm rope, c/w shock absorber 1.8 meter length

Catalogue No. Elite

Electrical Safety Sticker Kit Convenient range of labels for switchboards and control cabinets. Signs are manufactured from a durable, weather and chemical resistant synthetic material, which is U.V. stable. Kit includes

16 x “DANGER 240 VOLTS” (74mm x 105mm)



8 x “DANGER 415 VOLTS” (74mm x 105mm)



2 x “DANGER HIGH VOLTAGE” (148mm x 105mm)



2 x “LIVE WIRES” (148mm x 105mm)



1 x “SWITCHROOM” (104mm x 210mm)



1 x “DANGER ELECTRICAL EQUIPMENT”

Complete customisation of labels is available on request.

Catalogue No. ESAKIT

42

NESCO Safety Signs

4 convenient sizes to choose from – see table below



Water, chemical & U.V. resistant



Prompt delivery

Choose from our standard range or customise your own.

Size

Measurement

A

400mm x 280mm

B

195mm x 280mm

C

195mm x 135mm

D

135mm x 92.5mm

Note: To order quote – A, B, C or D after the part number relevant to the sign

Many other styles available upon request

For complete specification see our website www.nesco.com.au

43

www.nesco.com.au

Wo r kp lace Saf et y Pr o d u ct s

Safety Lockout Tags

Do not operate & out of service lockout tags are used to protect workers from potential danger.



All tags are laminated.



Standard Dimensions are 140mm x 75mm



Standard styles are listed below (standard pack size is 5)



Customised Lockout tags which can include an ID photo are available upon request

Lockout/Tagout Video Training Program Training Package for Employee Safety

10 minute video effectively conveys the importance of Lockout/Tagout in the workplace



Demonstrates the 7 steps to properly apply, and 5 steps to re-energize from, Lockout/Tagout



Provides instructions for maintaining Lockout/Tagout during shift changes



Shows how to apply, remove and maintain lockout devices



Also suitable for employee-refresher training sessions



Includes video, 10 Lockout/Tagout Procedure Employee Reference Cards, instructor’s guide and employee quiz



Additional Employee Reference Cards also available (No.499PR)

Catalogue No. 499V

44

Master Lock Model #

Description

499V

Complete Training Program w/video and 10 Employee Reference Cards

499PR

10 Lockout/Tagout Procedure Employee Reference Cards

Rotating Electrical Plug Lockouts Outward/Inward Rotation Allows for Easier Application & Storage

Surrounds the electrical plug; protects against accidental reconnection



Unique, patent-pending rotating design allows for easier installation in confined space applications



Each size roatates into istself to fit effectively into safety lockout application



Red lockout colour identifies the safety lockout application



Complete with high-visability permanent safety labels



Tough, lightweight, dielectric Xenoy® thermoplastic bodies withstand chemicals; perform effectively in extreme conditions [temperature range -50˚F (-46˚C) to +350˚F (117˚C)]

Master Lock Model #

Description

487

2-1/4” dia. x 6”x3-1/4” with cord dia. up to 3/4”

488

3”dia. x 6” with cord dia. up to 3/4”

Catalogue No. 487

Catalogue No. 488

Pneumatic Lockout Prevents Access to Compressed Air

Isolates equipment from compressed air sources



Device is applied to the male fitting, and accommodates most 1/4”, 3/8” and 1/2” fittings

Master Lock Model #

Description

465

Pneumatic Lockout (1 ea.)

Catalogue No. 465

For complete specification see our website www.nesco.com.au

45

www.nesco.com.au

Wo r kp lace Saf et y Pr o d u ct s

Lock Outs Part No

Description

Safety Lockout HASP 420

1” Diameter Jaws

421

1-1/2” Diameter Jaws

Circuit Breaker Lockouts

Catalogue No. 420 & 421

UCL-1

Miniture circuit breaker lockout

UCL-2

Moulded case circuit breaker lockout

UCL-2-EL

Moulded Case, Earth Leakage Circuit, Breaker Lockout

UCL-5

Moulded case circuit breaker lockout

Fuse Holder Lockout UFL-2

Fuse holder lockout

Catalogue No. UCL-1, UCL-2 & UCL-2-EL

Adjustable Cord Lockout MFL-1

Multi funciton cable lockout device

Lockout Padlocks LOPL

Brass baodied lockout padlock 1-1/2” shackle clearance

Lightweight Safety Padlock 410 RED

411 RED

Keyed different (vertical shackle clearance 1-1/2’) Non-conductive Xenoy lock body 1-3/4” tall Customise on site with permanent write on lables High security, reserved for safety cylinder - up to 1000,000 key changes Key retaining - ensures that padlocks are not left unlocked Keyed different (vertical shackle clearance 1-1/2”) Non- conductive Xenoy lock body 3” tall Customise on site with permanent write on labels High security, reserved for safety cylinder - up to 100,000 key changes Key retaining - ensures that padlocks are not left unlocked.

Catalogue No. UCL-5 & UFL-2

Catalogue No. MFL-1

Steel Body Padlock 3LF RED

Keyed different (vertical shackle clearance 1-1/2”) Reinforced laminated steel construction 1,400 key changes

Catalogue No. LOPL

46

Catalogue No.410 & 411 Plastic Bodied

Catalogue No. 3LF Laminated Steel

Personal Lockout Kit

Carry bag



1 x UCL-2 Moulded case circuit breaker lockout



1 x MFL-1 Multi funciton lockout



1 x padlock



1 x lockout hasp



Voltage proximity test screwdriver



2 x UCL-1 Miniture circuit breaker lockouts



Danger tags



Cable ties



Marking pen

Catalogue No. LOK

Rotating Gate Valve Lockouts Outward/Inward Roataion Allows for Easier Installation & Storage

Surrounds the valve operating handle to protect against accidental valve opening



Unique, patent-pending rotating design allows for easier installation in confined space applications



Each size rotates into itself to fit efcectively into safety tool boxes



Each size nests within the next larger size to save space in storage



Up to 4 workers can apply their personal safety locks



Red lock colour identifies the safety lockout application



Complete with high-visibility permanent safety labels that can be written-on to identify the responsible person, then erased for the next job



Tough, lightweight, dielectric Xenoy®* thermoplastic bodies withstand chemicals; perform effectively in extreme conditions [temperature range -50˚F (-46˚C) to +350˚F (177˚C)

Master Lock Model #

Measurement

480

fits 1” to 3” dia. valve handles

481

fits 2” to 5” dia. valve handles

482

fits 4” to 6.5” dia. valve handles

483

fits 6” to 10” dia. valve handles

484

fits 8” to 13” dia. valve handles

485

1 set of Nos. 480-484

Catalogue No. 481

Catalogue No. 485

* Xenoy® is a ed trademark of General Electric Corporation.

47

www.nesco.com.au

Wo r kp lace Saf et y Pr o d u ct s

Ball Valve Lockouts Fit All Major Brand Ball Valve Handles & Applications

Single-piece design is easy to apply and assures the best fit every time



Forms a triangular wedge to the pipe so that the handle can’t be turned open**



Two sizes fit the majority of applications

Master Lock Model #

Measurement

For Valve Diameters of:

476

Tough Nylon Ball Valve Lockout Device

1/4” to 1”

477

Heavy Steel Ball Valve Lockout Device

1-1/4” to 3”

Catalogue No.476

Catalogue No.477

Universal Ball Valve Lockout Device Locks Out Almost Any Quarter Turn Valve

Designed to lock out virtually any size and shape ball valve



Device clamps over valve handle; lockout arm ratchets to abut and lock against pipe at any angle**



Accommodates both standard and odd-shaped handles up to 1-1/4” thick and 1-5/8” wide



Add on the separate lockout arm (No. 479) to lock handles in throttled position and to lock out 3-, 4- and 5-way valves

Master Lock Model #

Measurement

For Valve Diameters of:

478

Universal Ball Valve Lockout Device

1-1/4” thick x 1-5/8” wide

479

Adaptor Arm for 3-, 4- and 5-way valves

1-1/4” thick x 1-5/8” wide

** When properly applied. Complete the lockout with a Master Lock safety padlock.

48

Catalogue No.478 & 479

Circuit Breaker Switch Padlock Provides the flexibility to effectively lock out breaker switches

Flexible steel cable shackle allows padlock to properly lock all types of circuit breaker lockout devices



Flexi-cable allows the lock body to be moved out of the way, and door to be closed properly



Fits the tight space constraints within circuit breaker shutoff boxes



Numerous key changes are available to minimize the possibility of unwanted key duplication

Master Lock Model #

Description

7C5RED

1-1/8” wide steel body; 4-pin cylinder; 5” flexible steel cable

Catalogue No. 7C5RED

Group Lock Box Captured key storage device, for effective lockout of large equipment

Effective alternative to requiring each authorized lockout team member to place one of their personal safety locks at every lockout point in the system



The Group Lock Box allows for each lockout point to be secured with just one designated lock. The accompanying keys are then captured by placing them in the Group Lock Box. Each authorized employee locks just one personal safety lock onto the box. the captured keys cannot be removed, nor the equipment re-energized, until all workers have removed their locks from the box.



Up to 13 workers can apply their personal safety locks



Heavy duty steel construction



Red lockout colour identifies the safety lockout application



Trilingual label clearly communicates to all workers

Master Lock Model # 498A

Catalogue No. 498A

Description

Length

Width

6”

9-1/4”

3-3/4”

Accessories for Low Voltage Insulating Gloves Accessories Part Number

Description

EOVC-9

Cowhide Overglove size 9

EOVC-10

Cowhide Overglove size 10

EOVC-11

Cowhide Overglove size 11

EOLK

Cotton knitted liner

EOLS

Seamless liner

EOBS

Single Compartment Canvas Bag

EOBT

Triple Compartment Canvas Bag

Catalogue No. EOVC

Catalogue No. EOBS

49

www.nesco.com.au

Wo r kp lace Saf et y Pr o d u ct s

Low Voltage Insulating Gloves The range of rubber gloves provides electrical workers with superior electrical protection and maximum comfort. Specifications Composition: Natural rubber specifically formulated to ensure high dielectric properties. Glove Markings: Each glove is marked with the following 1. Name of manufacturer 2. Year & month of manufacture 3. Working potential 4. Size 5. Batch number 6. IEC 903Class & Type or AS2225 Standards Mark and License No 901

Australian Standard AS-2225 Part Number

Description

RG00650360-9

650 Volt Working 5000 Volt tested 360 long insulating glove size 9

RG00650360-10

650 Volt Working 5000 Volt tested 360 long insulating glove size 10

RG00650360-11

650 Volt Working 5000 Volt tested 360 long insulating glove size 11

RG1000360-9

1000 Volt Working 10000 Volt tested 360 long insulating glove size 9

RG1000360-10

1000 Volt Working 10000 Volt tested 360 long insulating glove size10

RG1000360-11

1000 Volt Working 10000 Volt tested 360 long insulating glove size 11

RG3300360-9

3300 Volt Working 15000 Volt tested 360 long insulating glove size 9

RG3300360-10

3300 Volt Working 15000 Volt tested 360 long insulating glove size 10

RG3300360-11

3300 Volt Working 15000 Volt tested 360 long insulating glove size 11

RG4000360-9

4000 Volt Working 20000 Volt tested 360 long insulating glove size 9

RG4000360-10

4000 Volt Working 20000 Volt tested 360 long insulating glove size 10

RG4000360-11

4000 Volt Working 20000 Volt tested 360 long insulating glove size 11

International Standard IEC903

50

Part Number

Description

RG00500280-9

500 Volt Working 2500 Volt tested 280 long insulating glove size 9

RG00500280-10

500 Volt Working 2500 Volt tested 280 long insulating glove size 10

RG00500280-11

500 Volt Working 2500 Volt tested 280 long insulating glove size 11

RG1000360-9

1000 Volt Working 5000 Volt tested 360 long insulating glove size 9

RG1000360-10

1000 Volt Working 5000 Volt tested 360 long insulating glove size 10

RG1000360-11

1000 Volt Working 5000 Volt tested 360 long insulating glove size 11

RG7500360-9

7500 Volt Working 10000 Volt tested 360 long insulating glove size 9

RG7500360-10

7500 Volt Working 10000 Volt tested 360 long insulating glove size 10

RG7500360-11

7500 Volt Working 10000 Volt tested 360 long insulating glove size 11

RG17000360-9

17000 Volt Working 20000 Volt tested 360 long insulating glove size 9

RG17000360-10

17000 Volt Working 20000 Volt tested 360 long insulating glove size 10

RG17000360-11

17000 Volt Working 20000 Volt tested 360 long insulating glove size 11

Insulating Glove Accessories - See page 49

Note: All gloves are batch tested at the time of manufacture to either AS2225 or IEC903.

A u t o m a t i o n Pr o d u ct s

Remote Control

Remote Control

Typical Applications

General Description The Nesco and Electromate remote control product ranges are basic wireless switching systems used to operate almost anything. Lights, gates, security systems, pumps, in fact any device that can be switched on or off through an electrical circuit can be switched remotely. Through walls, across paddocks, over car parks, use it where running a switch wire is impractical or impossible. With over one million units sold world wide, these systems are well proven, economical and reliable. System Requirements

Security Monitoring

All systems comprise of two main components, a transmitter (Tx), which transmits a coded radio signal, and a receiver (Rx), which receives the coded signal and switches an output. The output is usually a relay that becomes the actual “switch” in the circuit. Most transmitters are battery powered, hand held units with 1, 2, 4 or 8 pushbuttons while the receivers are hard wired and permanently mounted printed circuit cards and generally located in close proximity to the load being switched. Also available are a range of accessories such as antenna, low voltage power supplies, enclosures and mounting bases. The most basic system must consist of at least one transmitter and one receiver. The actual components selected will be determined by the application. Always consult with a Nesco sales consultant if in doubt with your selected application.

Pump Control

Application Notes All distances are quoted as line of sight. Although these units will operate out of sight of each other, they are more effective and reliable when in visual . Receivers must not be mounted near equipment that emits radio interference, machinery such as variable frequency controllers, DC motors and controllers, transformers, magnets etc. When using in an industrial application, always chose a “clean” circuit to wire the receiver into. Do not leave transmitters near equipment containing induction coils such as stereo speakers as this will de-tune the transmitter. Never use this type of remote control switching device on life endangering equipment such as overhead cranes, hoists and conveyor belts. There is specialist equipment designed for these applications.

Industrial Monitoring & Control

Garden Lighting 51

www.nesco.com.au

Remote Control

A u t o m at io n Pr o d u ct s

NESCO FM Series First generation remote equipment. Operates on 27MHz with a 12 way digital decoding footprint. Coding system is -operated dipswitches on both the transmitter and receiver. To enable a transmitter to “talk” to a receiver the dipswitches in the transmitter must be in identical positions to the dip switches on the receiver. At least one third of the dipswitches should be in the on position. A 27MHz antenna is generally required for successful switching, however in ideal conditions or over short distances a piece of building wire 500mm long may be sufficient. Maximum transmission time of all fixed transmitters is 5 minutes.

FMT PET

Transmitters FMT 302

Specifications Part Number

Description

FMT PET

Single Channel 6 volt battery powered (included) Built in antenna & push button 100m range*

FMT 301 FMT 302 FMT 304

One, Two or Four Channel 9 volt battery Powered (included) Built in antenna & push button 200m range*

FMT 312E

Single Channel 12 volt DC power required Switching device required Antenna required 3km operating distance* Programmable output (requires some programming)

* Maximum distance in ideal conditions

Receivers Specifications Part Number

Description

FMR 212T

Available for 11 to 28v AC/DC power supply Single channel, *5 amp 240volt relay output non continuous

FMR202

11 to 28V AC/DC power required 2 channels, *5 amp 240volt relay output, non continuous

FMR 204

Available for 12 or 24v AC/DC power supply 4 channels, *5amp 240-volt relay output, non continuous

FMR 240

240 volt AC power required 1 channel, 10 amp 240 volt relay output

All receivers supplied as cards only *A slave relay must be used when controlling (loads) rated at 240V.

52

FMT 301

FMT 304 FMT 312E

NESCO Gigalink Series The Gigalink is the second-generation remote control, offering more power, smaller units and increased options. Although the increase in power will not increase the operating distance, it will make the system more reliable in poor reception areas. The transmitters are physically smaller and designed for easy use. The receivers offer more programmable options.

Transmitters

Single & multi channel available



LED indication of operation



9 Volt battery powered



Standard 27.195MHz frequency, others available on request



Built in antenna



Over 4 billion security combinations



Operating distance up to 150 metres nominal

GLT-2701

GLT-2702

GLT-2704

Specifications Part Number

Description

GLT-2701

Single channel

GLT-2702

Two channel

GLT-2704

Four channel

GLT-2708

Eight channel

GLT-2712E

Single channel 12V DC power required Switching device and antenna required 3km operating distance

GLT-2708

GLT-2712E

Receivers Specifications Part Number

Description

GLR 2701

10–28 Volt AC/DC power required Single channel, *5amp 240-volt relay output non continuous Programmable output modes

GLR 2702

10-28 Volt AC/DC power required Two channels, *5 amp 240-volt relay output non continuous Programmable output modes

GLR 2704

12 or 24 Volt AC/DC power supply required 4 channels, *5 amp 240volt relay output non continuous Programmable output modes

GLR 240

240-Volt AC power supply required One channel, 10-amp 240-volt relay output Programmable output modes

GLR 2708R

12 or 24 Volt AC/DC power required 8 channel, *5 amp 240 volt relay output non continuous

All Gigalink receivers supplied as cards only *A slave relay must be used when controlling loads rated at 240V.

53

www.nesco.com.au

Remote Control

A u t o m at io n Pr o d u ct s

Gigalink Output Modes The output modes on the Gigalink range of remote controls are selectable. The GLR 2701 and GLR 240 have seven different modes to select from. A series of 4 dipswitches in the centre of the card allow the to select from momentary, latching, delayed off, pulsing and flip flop modes. The GLR 2702 and GLR 2704 have two dipswitches allowing the to select momentary, latching or flip flop modes for all channels. Full instructions on programming are included with every Gigalink receiver purchased.

Accessories Catalogue No. C160

Specifications

Catalogue No. QM150

Part Number

Description

C 160 Enclosure

This enclosure is the perfect size to install any of the receiver cards except the GLR2708 Series.The lid is hinged for easy use, and a rubber insert around the door makes it weatherproof.

QM 150 Quickmount

This item makes mounting a receiver card in the C160 enclosure a breeze. Simply screw the quickmount in the enclosure and the receiver card clips into it. No need to mess around with stand off studs.

A full range of accessories are available for the Nesco and Gigalink remote controls

Antenna Specifications Part Number

Description

ANT 27S

30cm Long, supplied with mounting socket, requires a ground plane.

ANT 27M

1.2m Long, supplied with 2m of coax and a universal mounting base. Does not require a ground plane

ANT 27L

2m Long, marine grade antenna supplied with 2m of coax and universal mounting base. Does not require a ground plane

Mounting the antenna for maximum reception is important, follow the diagrams for recommended mounting positions.

Catalogue No. ANT-27M

Antenna Installation Very poor

54

Poor

OK

Good

Remote Control Systems NESCO manufactures and assembles customised REMOTE CONTROL SYSTEMS for special applications.

Gigalink Kit This kit contains a GLT2701 transmitter c/w 9V battery and GLR240 receiver mounted in a C160 IP55 P.V.C. enclosure. It has an operating distance line of site up to 50 meters without a fixed antenna and up to 150 meters with an antenna. The kit has been designed for rapid and easy installation and useful for a variety of applications such as operating pool pumps, outside lighting, warning sirens and bells.

Catalogue No. GLRK-240

School Bell System This system uses a fixed transmitter and receiver mounted in two IP55 P.V.C. enclosures supplied with two antennas. The transmitter can be wired to the existing school bell control circuit with any number of receivers installed in remote buildings coded to and controlled by the single transmitter. Providing a low cost alternative to conventional wiring. Although designed for the operation of school bells the same kit can be used to switch any electrical components up to a 3km. 240Vac Antenna

Connection Block

A 240V N

Antenna

FMT312E Transmitter 12Vdc

FMR240 10A/240V

Antenna

PSU1202 Regulator

N/C N/O

Shield C

To your control circuit Switching voltage

Cable and Connections by others

A +

N

Earth

Cable and Connections by others

Advance Control System Some applications require modifications to our standard transmitters and receivers to allow for extra features. Such as multi channel, high-low, stadium floodlight control etc. NESCO for assistance with special applications.

55

www.nesco.com.au

Fl o a t S w itc h e s

A u t o m at io n Pr o d u ct s

ATMI Float Switches Float switches are designed to control fluid level by switching a set of s when the level either rises or falls. Each individual application will determine the model of float switch required. To simplify the application criteria, Nesco has reduced the possibilities to only two models. The AT 920 series is designed for applications like sump pumps, water storage tanks and clean dams. They do not operate effecively in fluids which are fast flowing, turbulent, or have large amounts of suspended solids. The MR 76 series is designed for industrial applications. It can be used in fluids containing a large percentage of suspended solids. They are also very good in acidic or alkaline situations such as sewerage or industrial waste. All float switches supplied by Nesco Conwell have a double throw mechanism. This means they can be used for either filling or emptying purposes. Both models are available in 5, 10 and 20 metre cable lengths.

AT 920VR* Ball Float Specifications

Suitable for water with limited suspended solids



Suitable for fluids with limited turbulence



Suitable for drinking water, sump pumps



No lead or mercury



Biconical shape



Uses limit switch operated by a ball race



Switch rating 20A resistive 250V 8A Inductive 250V



Maximum operating temperature 85˚C



Dimensions 135mm x 7mm

*insert cable length 5, 10 or 20

MR 76VR*

Catalogue No. 920VR

Specifications

Industrial quality



Suitable for turbulent fluids



Suitable for acidic liquids (sewerage)



Suitable for liquids with a high level of suspended solids



Mercury switch for accuracy



Bi-conical shape to prevent solids from sticking



5 water proof compartments (will still operate with 2 compartments damaged)



Switch rating 10A resistive 250V 5A Inductive 250V



Maximum operating temperature 70˚C



Dimensions 170mm x 80mm

* insert cable length 5, 10 or 20

Catalogue No. MR 76VR

56

Timers

ANLY Multi Range Timer AH5N Features

1 second to 600 hours time range



Programmable by dip switches



24/240V AC/DC operating voltage



One timed and one selectable set of s



Supplied with Base



Surface mounting kit available [Y50]

Specifications Name

Description

Full time range

1s,10s,1m, 10m, 1h, 10h, 60h, 600h

Rated voltage

24 to 240 volts AC/DC

rating

5 Amps AC resistive

Reset time

0.2 seconds

Power consumed

2VA

Mounting base

PF083A

Surface mounting kit

Y50 & P3G-08

Size

48mm x 48mm x 84mm

Catalogue No. AH5N

AH3-RA Features

Multiple time ranges programmable by dip switches



Time ranges from 1 second to 10 minutes



24/240V AC/DC operating voltage



One timed and one selectable set of s



Supplied with Base



Surface mounting kit available [Y40]

Specifications Name

Description

Full time range

1s,10s,1m, 10m

Rated voltage

24 to 240 volts AC/DC

rating

5 Amps AC resistive

Reset time

0.1 seconds

Power consumed

2VA

Mounting base

PFO83A

Surface mounting kit

Y40 & P3G-08

Size

58mm x 40mm x 57.5mm

Catalogue No. AH3-RA 57

www.nesco.com.au

Timers

A u t o m at io n Pr o d u ct s

ANLY Multi Range Timer AH3-RC Features

Multiple time ranges programmable by dip switches



Time ranges from 6 seconds to 60 minutes



24/240V AC/DC operating voltage



One timed and one selectable set of s



Supplied with Base



Surface mounting kit available [Y40]

Specifications Name

Description

Full time range

6s, 60s, 6m, 60m

Rated voltage

24 to 240 volts AC/DC

rating

5 Amps AC resistive

Reset time

0.1 seconds

Power consumed

2VA

Mounting base

PFO83A

Surface mounting kit

Y40 & P3G-08

Size

58mm x 40mm x 57.5mm

Catalogue No. AH3-RC

AH3-RE Features

Multiple time ranges programmable by dip switches



Time ranges from 3 minutes to 30 hours



24/240V AC/DC operating voltage



One timed and one selectable set of s



Supplied with Base



Surface mounting kit available [Y40]

Specifications

58

Name

Description

Full time range

3m, 30m, 3h, 30h

Rated voltage

24 to 240 volts AC/DC

rating

5 Amps AC resistive

Reset time

0.2 seconds

Power consumed

2VA

Mounting base

PFO83A

Surface mounting kit

Y40 & P3G-08

Size

58mm x 40mm x 57.5mm

Catalogue No. AH3-RE

Off Delay Timer AH5F Features True off delay timer Times out after power is removed One set of change over s

Specifications Name Rated Voltage Time Range rating Reset time

Description 240 Volts AC 60 seconds or 30 minutes 1 change over 5 amps 0.3 seconds

Size

48mm X 48mm X 84mm

Base

PF085A

Catalogue No. AH5F

Star Delta Transition Timer TRD-N Features Adjustable run time up to 30 seconds Star to delta change time 0.1 second Available in either 240 or 415V AC Two indicating lamps for timer status

Specifications Name Time range Rated voltage rating Change over time Reset time Base Size

Description 0-30 seconds 240 to 415 volts AC 5 Amps resistive 0.1 seconds 0.3 seconds 8PFA 61mm x 49mm x 70mm

Catalogue No. TRD-N

Floatless Level Controller AFR-1 Features For use where float switches are impractical Suitable for filling and emptying Uses 8 volts AC through probes APS-3 probe holder available

Specifications Name Rated voltage Operating voltage Operating resistance Response time rating Base Size

Description 240 volts AC 8 volts AC 4KΩ 80 milli-seconds max 5 amps resistive 8PFA 61mm x 49mm x 70mm

Catalogue No. AFR-1

59

www.nesco.com.au

Timers

A u t o m at io n Pr o d u ct s

ANLY Twin Timer ATDV-NA Features Asymmetrical cyclic timing

Time ranges from 1 second to 10 minutes



110 & 240 Volt AC operation



On & off times independently adjustable

ATDV-NC Features

Asymmetrical cyclic timing



Time ranges from 6 seconds to 60 minutes



110 & 240 Volt AC operation



On & off times independently adjustable

Catalogue No. ATDV-NA

ATDV-NE Features

Asymmetrical cyclic timing



Time ranges from 3 minutes to 30 hours



110 & 240 Volt AC operation



On & off times independently adjustable

Specifications Name

Description

ATDV Full time range

1s,10s,1m, 10m

Rated voltage

110/240V AC

rating

5 Amps resistive

Reset time

0.2 seconds

Power consumed

2VA

Mounting base

8PFA

Size

61mm x 49mm x 70mm

Catalogue No. ATDV-NC

ATDV-NC Full time range

6s, 60s, 6m, 60m

Rated voltage

110/240V AC

rating

5 Amps resistive

Reset time

0.2 seconds

Power consumed

2VA

Mounting base

8PFA

Size

61mm x 49mm x 70mm

ATDV-NE

60

Full time range

3m, 30m, 3h, 30h

Rated voltage

110/240V AC

rating

5 Amps resistive

Reset time

0.2 seconds

Power consumed

2VA

Mounting base

8PFA

Size

61mm x 49mm x 70mm

Catalogue No. ATDV-NE

ANLY 3-Phase Sequence Voltage Relay ASM-170-415 Characteristic Only operational with correct power source voltage and phase sequence. Suitable for main power source and motor starter circuit to prevent damage from insufficient phases or phase reversal.

3-Phase, 3-Wire or 1-Wire



11P



Red LED (ON), Green LED (POWER)

Specifications Operating Voltage

415V AC

Allowable operating voltage range

85~110% of rated operating voltage

Rated frequency

50/60 Hz

rating

250VAC 5A resistive load

Reset time

300~600mS

Power Consumption

Approx. 2VA

Life

Mechanical: 5,000,000 times Electrical: 100,000 times

Ambient temperature

-10 ~ +50˚C

Ambient humidity

Max 85% RH

Base

11 Pin PF113A

Size

80.5 x 35 x 73.3

Catalogue No. ASM-170-415

ANLY AC Line Voltage Relay AVR Characteristic

3-Phase voltage and fault detector



Can dectect abnormal condition to prevent damages to the equipment



Auto shut-off while detecting excessive or insuffiecient voltage, range from 5% to 20% variable



Out-of-phase detection while the motor operating



Can be set up to detect excessive or insufficient voltage only



Delay and Reset time - 0~10sec adjustable tripping delay

Specifications Operating Voltage

AC(V) 415

Allowable operating voltage range

±5% ~ ±20% of rated operating voltage

Rated frequency

50/60 Hz

Detecting method

detect from supply voltage

Reset time

AVR 172: 0~10sec adjustable

rating

250VAC 5A (resistive load)

Power consumption

Approx. 3VA

Life

Mechanical: 5,000,000 times Electrical: 100,000 times

Ambient temperature

-10 ~ +50˚C

Ambient humidity

Max 85% RH

Catalogue No. AVR 172-IIT

61

www.nesco.com.au

Timers

A u t o m at io n Pr o d u ct s

ANLY Multi-function Digital Timer H5CLR Characteristic

Eleven field-selectable output modes accommodate a wide variety of applications



7-segment-display for clear display and effective monitoring



All parameters set by scroll through menus accessed from the front



Field-selectable time ranges form 0.001 second to 9999 hours



Precision control possible to 0.001 second



Four levels of key protection provided



Available on Count Up or Count Down model

Specifications Operating Voltage

AC/DC(V): 12~48 or 100~240

Allowable operating voltage range

85~110% of rated operating voltage

Rated frequency

50/60 Hz

rating

250VAC 5A (resistive load)

Reset time

Max 0.1S

Catalogue No. H5CLR

ANLY PID Temperature Controller AT01 Features

Easy to use



lock protection function



PID funciton selectable



Sensor malfunction detection function



Heating or cooling control selectable

Specifications Model

Sensor Input

Control Output

Dimensions

AT-501-PR

Pt 100

Relay 5A 250VAC

48mm x 48mm

AT-701-PR

Pt 100

Relay 5A 250VAC

72mm x 72mm

AT-501-KR

K Thermocouple

Relay 5A 250VAC

48mm x 48mm

AT-701-KR

K Thermocouple

Relay 5A 250VAC

72mm x 72mm

Specifications

62

Name

Description

Alarm output

250VAC 5A

Control method

PID, PI, P, ON/OFF

Setting

Digital setting using front keys

Indicator

7 segment display and LED

Operating voltage

AC(V): 90~260

Rated frequency

50/60 Hz

Power consumption

Approx. 3VA

Measuring accuracy

Within ±0.3% of present value or ±2˚C whichever is greater

Proportional band (P)

Up to maximum allowable setting by sensor input type

Integral time (I)

0~1999sec (1 second units)

Derivative time (D)

0~1999sec (1 second units)

Control period

0~65sec (1 second units)

Sampling period

250ms

Catalogue No. AT-501

Catalogue No. AT-701

To g g le Switches

Mounting Bases Accessories Part No.

Description

8PFA

8 pin base Din rail or surface mounting hold down clips raised center section

PF083A

8 pin base Din rail or surface mounting raised center section

PF085A

8 pin base Din rail or surface mounting recessed center section

P3G-08

8 pin socket reverse pin for surface mounting recessed center section

APS-3

Probe holder for use wih AFR-1 Holds 3 probes threaded to 6mm

Catalogue No. 8PFA & PF083A

Catalogue No. PF085A & P3G-08

Catalogue No. APS-3

ELECTROMATE Metal Toggle Switches Specifications Part No.

Description

Terminals

Pin

ETS-101QC

ON/OFF

SPST QC Terminals

2

ETS-101SC

ON/OFF

SPST Screw Terminals

2

ETS-102QC

ON/ON

SPDT QC Terminals

3

ETS-102SC

ON/ON

SPDT Screw Terminals

6

ETS-103QC

ON/OFF/ON

SPDT QC Terminals

3

ETS-103SC

ON/OFF/ON

SPDT Screw Terminals

3

ETS-123QC

MOM ON/OFF/MOM ON

SPDT QC Terminals

3

ETS-123SC

MOM ON/OFF/MOM ON

SPDT Screw Terminals

3

ETS-111QC

OFF/MOM ON

SPST QC Terminals

3

ETS-111SC

OFF/MOM ON

SPST Screw Terminals

3

ETS-112QC

OFF/MOM ON

SPDT QC Terminals

3

ETS-112SC

OFF/MOM ON

SPDT Screw Terminals

3

ETS-201QC

ON/OFF

DPST QC Terminals

4

ETS-201SC

ON/OFF

DPST Screw Terminals

4

ETS-202QC

ON/ON

DPDT QC Terminals

6

ETS-202SC

ON/ON

DPDT Screw Terminals

6

ETS-203QC

ON/OFF/ON

DPDT QC Terminals

6

ETS-203SC

ON/OFF/ON

DPDT Screw Terminals

6

ETS-223QC

MOM ON/OFF/MOM ON

DPDT QC Terminals

6

ETS-223SC

MOM ON/OFF/MOM ON

DPDT Screw Terminals

6

ETS-212QC

ON/MOM ON

DPDT QC Terminals

6

ETS-212SC

ON/MOM ON

DPDT Screw Terminals

6

ETS-213QC

MOM ON/OFF/ON

DPDT QC Terminals

6

ETS-213SC

MOM ON/OFF/ON

DPDT Screw Terminals

6

Catalogue No. ETS-1000

2-3 Pin

4-6 Pin

63

www.nesco.com.au

Swi tc he s

C o n t r o l Pr o d u ct s

ELECTROMATE ROCKER SWITCHES RS and IRS Specifications

64

Name

Description

Rating

AC 125V 20A; AC 250V 15A: DC 12V 20A



R; 35MΩ max

Insulation

R; DC 500V 100MΩ min

Dielectric Strength

AC 1500V, 1 minute

Operating temperature

-30C± 80C

Electrical life

10,000 cycles

RS-2101-1A On-Off, 15 Amp 240V, DPST 4Pin

RS-101-1A

RS-103-3B

RS-2101-1C

On-Off, 15 Amp 240V, SPST 2Pin

On-Off-On, 15 Amp 240V, SPST 3Pin

On-Off, 15 Amp 240V, DPDT 4Pin

RS-101-1B

RS-201-1A

RS-2102-2C

On-Off, 15 Amp 240V, SPST 2Pin

On-Off, 15 Amp 240V, DPST 4Pin

On-On, 15 Amp 240V, DPDT 6Pin

RS-101-7C

RS-201-2A

IRS-1

On-Off, 6 Amp 240V, SPST 2Pin

On-Off, 15 Amp 240V, DPST 4Pin

On-Off, 10 Amp 240V, SPST 3Pin

RS-103-3A

RS-203-1A

IRS-1-2C

On-Off-On, 15 Amp 240V, SPDT 3Pin

On-Off-On, 15 Amp 240V, DPDT 6Pin

On-Off, 10 Amp 240V, SPST 3Pin

C o n t r ol Pr o d u ct s

IRS-101-A

IRS-201-1A

On-Off, 10 Amp 240V, SPST 3Pin

On-Off, 15 Amp 240V, DPST 4Pin

IRS-101-1B

IRS-201-2A

On-Off, 10 Amp 240V, SPST 3Pin

On-Off, 15 Amp 240V, DPST 4Pin

IRS-101-2B

IRS-203-1A

On-Off, 15 Amp 240V, SPST 3Pin

On-Off-On, 15 Amp 240V, DPDT 6Pin

IRS-101-3B

IRS-2101-2C

On-Off, 15 Amp 240V, SPST 3Pin

On-Off, 15 Amp 240V, DPST 4Pin

IRS-101E-1C

IRS-101E-1O

On-Off, 15 Amp 240V, SPST 3Pin

On-Off, 10 Amp 240V, SPST 3Pin

Switches

65

www.nesco.com.au

Swi tc he s

C o n t r o l Pr o d u ct s

MRS and MIRS Specifications Name

Description

Rating

AC125V 6A; AC 250V 3A AC125V 10A; AC 250V 6A (A)



R; 35MΩ max

Insulation

R; DC 500V 100MΩ min

Dielectric Strength

AC 1500V, 1 minute

Operating temperature

-30C±80C

MIRS-101-2 On-Off, 6 Amp 240V, SPST 2Pin

MRS-101 On-Off, 6 Amp 240V, SPST 2Pin

MWS-01 MRS-201-3

MRS-101-2

On-Off, 6 Amp 240V, DPST 4Pin

On-Off, 6 Amp 240V, SPST 2Pin

MOM(On)-On, 10 Amp 240V, SPDT 3Pin

PBS Specifications Name

Description

Rating

AC125V 3A; AC 250V 1A



R; 20MΩ max

Insulation

R; DC 500V 100MΩ min

Dielectric Strength

AC 1000V, 1 minute

Electrical Life

50,000 cycles

EIL10R

EIL10G

EIL10A

Red in colour

Green in colour

Amber in colour

Indicator lamp 4.8mm terminal 16AMP 240V

EIL12R

EIL12G

EIL12A

Red in colour

Green in colour

Amber in colour

Indicator lamp 6.3mm terminal 16AMP 240V

EFH01 Fuse holder 10AMP 240V 6 x 30mm Specifications

66



ø6 x 30mm



20MΩ (max)



DC500V100MΩ



AC2000V/minute

PBS-11A On-Off, 1 Amp 240V

PBS-12A On-Off, 1 Amp 240V

VASS Common Plug-In Take Off Boxes Single Phase When ordering single phase take off boxes specify phase A, B or C.

Specifications Rating

Order Code

HRC Fuse 20A

S1/20/HRC

32A

S1/32/HRC

Catalogue No. SI/32/HRC

(HRC Fuse Links available if required) Cord Clamp S/CC - To grip flexible cables. Fits all Take Off Boxes.

Circuit Breaker 10A

S1/10/CB

16A

S1/16/CB

20A

S1/20/CB

25A

S1/25/CB

32A

S1/32/CB

Earth Leakage 10A

S1/10/ELCB

16A

S1/16/ELCB

20A

S1/20/ELCB

25A

S1/25/ELCB

32A

S1/32/ELCB

Catalogue No. SI/20/CB

Fitted with Earth leakage Circuit Breaker

C

A N

B

N (Neutral), A, B, or C Phases, E (Earth)

Catalogue No. SI/20/ELCB

67

www.nesco.com.au

C o n t r o l Pr o d u ct s

VASS Common Plug-In Take Off Boxes Three Phase & Neutral (Black Rating Plate) Specifications Rating

Order Code

HRC Fuse 20A

S4/20/HRC

32A

S4/32/HRC

63A

S4/63/HRC

100A

S4/100/HRC

200A

S4/200/HRC

(HRC Fuse Links available if required) 200A HRC Fused Take Off or 200A Combination Fuse Switch (CFS)

Circuit Breaker 10A

S4/10/CB

16A

S4/16/CB

20A

S4/20/CB

25A

S4/25/CB

32A

S4/32/CB

40A

S4/40/CB

50A

S4/50/CB

63A

S4/63/CB

100A

S4/100/CB

125A

S4/125/CB

160A

S4/160/CB

200A

S4/200/CB

Earth Leakage

Catalogue No. S4/63/HRC

Catalogue No. S4/20/CB

10A

S4/10/ELCB

16A

S4/16/ELCB

20A

S4/20/ELCB

25A

S4/25/ELCB

32A

S4/32/ELCB

40A

S4/40/ELCB

50A

S4/50/ELCB

63A

S4/63/ELCB

80A

S4/80/ELCB

100A

S4/100/ELCB

Fitted with Earth leakage Circuit Breaker

68

Catalogue No. S4/32/ELCB

CRITEC Surge Protection The CRITEC range of surge protection products is widely recognised in Australia as providing a level of protection. All the listed products are designed for use on the Australian 240V single phase or 415V three phase AC power system, and provide both hard wired and point of use plug-in protection. They all feature excellent transient clamping, and feature safe disconnection mechanisms at their end of life, with a visual indication given in this circumstance.

Hard Wired Solutions The hard wired protection products come packaged as convenient Din-rail mountable protectors, matching the style of common circuit breakers. They are economically priced, and are available in three surge ratings: 10kA, 40kA, and 100kA (8/20us surge impulse). The required surge rating for a particular application depends on where the protector is to be installed. The 10kA protector should only be installed at sub-s within a building. The 40kA protector is suitable for point of entry installation for buildings in a relatively low lightning activity area or a low-lying building in a built up area. It may also be used in a sub- for high lightning areas. Buildings in high lightning areas, or that are in exposed locations, should have 100kA protectors installed at their point of entry main s. Also, the higher the surge rating, the longer the likely lifetime of the product, with the 100kA surge rating being a wise choice where long life is an important consideration. If the protectors are being installed in the where the Neutral to Earth link is, then one protector should be provided from each phase conductor to neutral (i.e. one protector is required for single phase, and three protectors are required for three phase). If they are being installed in a without the N-E link (e.g. a sub-), then an extra protector should be provided from N-E. With the exception of the high energy 100kA product, the protectors feature replaceable modules. This allows a failed protector to be replaced without disturbing the wiring. In addition, the DSD1401SR275 product features alarm s. These provide a changeover set, that allows remote monitoring of the protector status.

Specifications Part number

Surge Rating

Recommended Location

Alarm s

Replacement Module

DSD11001S275

100kA

Main , high lightning area, or exposed site

No

Not available

DSD1401S275

40kA

Main , lower lightning area, or unexposed site, or sub in high lightning area

No

DSD1401S275M

DSD1401SR275

40kA

Main , lower lightning area, or unexposed site, or sub in high lightning area

Yes

DSD1401SR275M

DSD1101S275

10kA

Sub-

No

DSD1101S275M

Common specifications

Module Width: 17.5mm



Terminals: up to 35 mm2 (solid), 25 mm2 (stranded)



Maximum Continuous Operating Voltage: 275Vac

Catalogue No. DSD11001S275

DSD1401S275

DSD1401S275M

DSD1101S275

DSD1101S275M

69

www.nesco.com.au

C o n t r o l Pr o d u ct s

CRITEC Plug-in Protection These Power Line Filters are used to provide the final stage of surge protection to electrical and electronic equipment that connects via an AC power plug. The effectiveness of this simple-to-install protection is assured by virtue of it being installed close to the equipment to be protected. The product is not the cheapest available, but it does offer excellent surge ratings combined with series filtering. The product provides a very solid 20kA surge rating in each of the three modes possible at an outlet (L-N, L-E, and N-E). The protection in each of these modes uses MOV’s in combination with robust thermal disconnects to provide increased safety of the product. In addition to the regular shunt protection that is used to divert the surge current to earth, this protector features series filtering. This filtering further reduces the transient voltage getting through to the equipment, but also slows down the rate of rise of that voltage, further protecting the equipment. convenience is built into this product, with LED’s indicating correct product operation, and mounting flanges allowing wall mounting if required. Where the equipment being protected has a telephone connection, it is very important that transient protection is provided for both the AC power connection and the telephone connection. The PLFA2 RJ11 products provides this combined protection. The telephone circuitry is approved and complies with ACA requirements. The telephone circuitry is protected to the same rugged 20kA level as the AC power circuit. As well as a rugged gas arrester, the circuitry features a solid state thyristor to provide instantaneous clamping of telephone line surges to low values, and automatically resetting solid state fuses in series with each wire to provide overcurrent protection. Specifications AC Protection

Model : PRF A2



Nominal voltage: 240 Vac



Maximum Continuous Operating Voltage: 275 VAC



Maximum Line Current: 10 A



Surge rating: 20 kA 8/20us in each of L-N, L-E, and N-E modes



Aggregate surge material: 80 kA



Dimensions: 275 mm x 100 mm x 72 mm



Weight: approx. 1.5 kg



Connection: Power cord, 2 m

Catalogue No. PLF A2

AC Protection plus Telephone Line Protection

Model : PLF A2 RJ11



AC Protection as above



Telephone Protection: 20 kA 8/20us (L+L)-E



Max. Telephone Line Current: 160 mA



Connection: 2 x RJ11 sockets

Dimensions: 320 mm x 100 mm x 72 mm

70

Catalogue No. PLF A2 RJ11

ERITECH® SYSTEM 2000 Item

Description

Rod length Diameter

Rod Size

Pack

U/M

Unit Weight

Weight Units

CAR0510

AIR TERMINAL,CU,10x500mm - 711080

500

10

1

EA

0.48

KG

CAR0315

AIR TERMINAL, CU,15x300mm

300

15

1

EA

0.35

KG

CAR0515

AIR TERMINAL,CU,15x500mm - 711090

500

15

1

EA

0.75

KG

CAR1015

AIR TERMINAL,CU,15x1000mm - 711110

1000

15

1

EA

1.51

KG

CAR2015

AIR TERMINAL,CU,15x2000mm - 711010

2000

15

1

EA

3

KG

CMPR

AIR TERMINAL,CU,15x500mm, MULTIPLE POINT

500

15

1

EA

1.02

KG

Catalogue No. CMPR Catalogue No. CAR-AAR

COPPER

Franklin Rods Bases and Brackets Item

Description

Suit Rod Diameter

Pack Size

U/M

Unit Weight

Weight Units

ATBC10

BASE,AIR TERMINAL,CU,10MM - 711150

10

1

EA

0.5

KG

ATBC15

BASE,AIR TERMINAL,CU,15MM - 711160

15

1

EA

0.5

KG

RSC115

BASE,AIR TERMINAL,CU,15MM, RIDGE 711170

15

1

EA

1.07

KG

TTRC16

COUPLER,AIR TERM,CU,15MM, THREAD ROD/ TAPE

15

1

EA

0.23

KG

CBR015

BRACKET,AIR TERM,GM,15MM, PAIR - 711190

15

set 2

EA

0.9

KG

Catalogue No. ATBC

Catalogue No. RSC

Catalogue No. TTRC

Catalogue No. CBR 71

www.nesco.com.au

C o n t r o l Pr o d u ct s

ERITECH® SYSTEM 2000 Copper Downconductors Item

Description

Width

Thickness

Roll

U/M

Unit Weight

Weight Units

TC-EC-2530-50

TAPE,CU,25X3MM,ANNEALED, 50M ROLL

25

3

50

MT

34

KG

TC-ECT-253

TAPE,CU,25X3MM,TINNED, 30M ROLL

25

3

30

MT

21

KG

Suit Tape Size

Pack Size

U/M

Unit Weight

Weight Units

Catalogue No. TC-EC & TC-ECT

Downconductors Fixings Item

Description

DCC253

CLIP,TAPE,CU,25X3MM,DCC - 711220

25 x 3

50

EA

0.06

KG

DCA253

CLIP,TAPE,AL,25X3MM,DCC - 711730

25 x 3

50

EA

0.03

KG

PDC253BN

CLIPS,TAPE,PL,25X3MM,DC, BROWN - 711280

25 x 3

50

EA

0.01

KG

PDC253GY

CLIPS,TAPE,PL,25X3MM,DC, GREY - 711290

25 x 3

50

EA

0.01

KG

Catalogue No. DDC-DCA

72

Catalogue No. PDC

Downconductors Fixing Clamps Item

Description

Suit Tape Size

Pack Size

U/M

Unit Weight

Weight Units

STC253

CLAMP,TAPE,CU,25X3MM, SQUARE - 711410

25 x 3

5

EA

0.2

KG

STA253

CLAMP,TAPE,AL,25X3MM, SQUARE - 711400

25 x 3

5

EA

0.1

KG

OBC268

CLAMP,TAPE,CU,26X8MM, OBLONG - 711440

26 x 8

2

EA

0.29

KG

OBA268

CLAMP,TAPE,AL,26X8MM, OBLONG - 711440

26 x 8

2

EA

0.29

KG

PCT400

CLAMP,TAPE,CU,26X12MM, PLATE - 711450

26 x 12

1

EA

0.6

KG

BIM700

CONNECTOR,TAPE,CU/AL, 25X3MM, BIMETALLIC

25 x 3

5

EA

0.19

KG

BBBC

B-BOND,CU,26MM - 710260

26

25

EA

0.12

KG

Catalogue No. BIM Catalogue No. STC-STA

Catalogue No. PCT

Catalogue No. BBC

Catalogue No. LPC122

Smooth Weave Sysmtem

Catalogue No. LPC2855F5M

Catalogue No. OBC-OBA

Catalogue No. LPC305

Catalogue No. LPC30958 73

www.nesco.com.au

C o n t r o l Pr o d u ct s

ERITECH® SYSTEM 2000 Smooth Weave System Components Item

Description

Rod length

Rod Dia.

Pack Size

U/M

Unit Weight

Weight Units

LPC411

AIR TERMINAL,CU,5/8X18IN

18

5/8

1

EA

1.6

LB

LPC413

AIR TERMINAL,CU,5/8X36IN

1

EA

3.3

LB

LPC30958

BASE,AIR TERMINAL,BR,5/8IN, ADHESIVE

5/8

1

EA

1

LB

LPC2855F5M

ADAPTOR,AIR TERMINAL,CU, 5/8IN,F/M, SWIVEL

5/8

1

EA

7

OZ

LPC30558

BASE,AIR TERMINAL,BR,5/8IN, UNIVERSAL

5/8

1

EA

12

OZ

LPP899R

ADHESIVE CEMENT, RUBBER, FOR AIR TERMINAL BASE

1

EA

1

GAL

LPC122

250FT CABLE,SMOOTHWEAVE, 1/0 AWG,250FT

250ft

FT

55

LB

LPC122L

250FT CABLE, SMOOTHWEAVE, TINNED 1/ 0 AWG,250FT

250ft

FT

55

LB

36

5/8

Notes: LPC122 compliant with AS1768-1991 table 4.4. Suitable for use as a main current carrying conductor, for air terminations and downconductors. LPC516

CLAMP,CABLE,SMOOTHWEAVE PARALLEL,BRONZE

1

EA

2

OZ

LPC595

SPLICER,CABLE, 4 WAY, SMOOTHWEAVE

1

EA

9

OZ

LPC804

CLAMP,CABLE,CU, SMOOTHWEAVE C122,2 HOLE

100

EA

OZ

LPC810

CLIP, CABLE, CU, 35mm, ADHESIVE

1

EA

OZ

Catalogue No. LPC595

74

Catalogue No. LPC810

Catalogue No. LPC804

Catalogue No. LPC516

O v e r h e a d a nd Un d er g r o u n d

Cable ting Pits & Lids The range of plastic cable ting pits are used in conjunction with concrete or steel covers to house, protect and give ready access to power and communications cables at underground ting locations. They offer many advantages over traditional fibre reinforced cement pits and a much greater life expectancy. The pits are light in weight and can be easily transported and stored. Installation is easy with no special tools being required. The design embodies special ribbing for on site strength and stability. The pits are extendable.

Specifications Part No

Description

Length

Width

Depth

P1 P1Lide P1Lidc PIT1LST* PIT1LSL*

P1 Pit Lid Electrical Lid Communication Lid Steel Tamperproof Lid Steel Lockable

419 470 “ 470 “

155 195 “ 190 “

350

P2 P2Lide P2Lidc PIT2LST* PIT2LSL*

P2 Pit Lid Electrical Lid Communication Lid Steel Tamperproof Lid Steel Lockable

553 615 “ 612 “

180 245 “ 245 “

514

P3 P3Lide P3Lidc PIT3LST* PIT3LSL*

P3 Pit Lid Electrical Lid Communication Lid Steel Tamperproof Lid Steel Lockable

663 730 “ 725 “

243 300 “ 295 “

570

P4 P4Lide P4Lidc PIT4LST* PIT4LSL*

P4 Pit Lid Electrical Lid Communication Lid Steel Tamperproof Lid Steel Lockable

584 650 “ 644 “

281 345 “ 345 “

760

J5 J5S J5Lide J5Lidc PIT5LST* PIT5LSL* Riser 5

J5 Pit J5 Split Pit Lid Electrical Lid Communication Lid Steel Tamperproof Lid Steel Lockable Split Pit Riser for J5

650 “ 645 “ 648 “ 650

330 “ 395 “ 398 “ 330

650 “

J6 J6Lide x 2 J6Lidc x 2 PIT6LST* x 2 PIT6LSL* x 2 PIT6LST*1 PIT6LSL*1 Riser 6

J6 Pit Lid Electrical Lid Communication Lid Steel Tamperproof Lid Steel Lockable Lid Steel Tamperproof Lid Steel Lockable Riser for J6

1240 650 “ 655 “ 1310 “ 1240

440 500 “ 500 “ 500 “ 440

670

J7 J7Lide x 2 J7Lidc x 2 PIT7LST* x 2 PIT7LSL* x 2 PIT7LST*1 PIT7LSL*1

J7 Pit Lid Electrical Lid Communication Lid Steel Tamperproof Lid Steel Lockable Lid Steel Tamperproof Lid Steel Lockable

875 490 “ 478 “ 955 “

440 460 “ 495 “ 495 “

1130

Catalogue No. P1, P2, P3, P4

200

200

Catalogue No. J7

75

www.nesco.com.au

O v e r h ead an d Un d er g r o u n d

Specifications Part No

Description

Length

Width

Depth

J8 J6Lide x 2 J6Lidc x 2 PIT6LST* x 2 PIT6LSL* x 2 PIT6LST*1 PIT6LSL*1 Riser 6

J8 Pit Lid Electrical Lid Communication Lid Steel Tamperproof Lid Steel Lockable Lid Steel Tamperproof Lid Steel Lockable Riser for J8

1240 650 “ 655 “ 1310 “ 1240

440 500 “ 500 “ 500 “ 440

8895

J9 J6Lide x 3 J6Lidc x 3 PIT6LST* x 3 PIT6LSL* x 3

J9 Pit Lid Electrical Lid Communication Lid Steel Tamperproof Lid Steel Lockable

1915 650 “ 648 “

440 500 “ “ “

895

R430 R430Lid

R430Pit R430Lide

430Dia 390Dia

430Dia 390Dia

600

Pit 450 Pit 450CL Pit450SL PIT450SLHDL PIT450SLLDL

Pit 450 Lid Concrete Lid Steel Lid Steel Lockable H/D Lid Steel Lockable L/D

450 550 545 “ “

450 550 545 “ “

510

Riser450

Riser for 450

450

450

300

Pit 600 Pit600CL Pit600CLE Pit600SL PIT600SLHDL PIT600SLLDL

Pit 600 Lid Concrete Plain Lid Concrete Electrical Lid Steel Lid Steel Lockable H/D Lid Steel Lockable L/D

600 695 “ “ “

600 695 “ “ “

660

Riser600

Riser for 600

600

600

300

JTEEBAR

Teebar – For J6, J8 & J9

PIT7TBAR

Teebar for J7

200

Catalogue No. J6

Accessories MPK500

Lid lifter

Catalogue No. MPK500

Note: * is replaced by an e for electrical or c for communication or t for Telstra Lids available.

Catalogue No. EMARKER 76

Catalogue No. TMARKER

Catalogue No. DANGER SIGN

Underground Residential Distribution The all weather polyethylene construction requires no painting or maintenance, as protection against corrosion/moisture is not an issue. The strong but light base and turret allow easy transport and installation. The turret is easily and simply secured to the base with D head stainless steel screws. The s are resilient and easily drilled. The standard colour is green. (however beige* is available)

Accessories Part No

Description

URDQ1

Complete Short Turret Assembly - includes Turret, Base, Blank Type X & 4 D Head bolts

URDQ2

Complete Tall Turret Assembly - includes Turret, Base, Blank type X & 4 D Head bolts

URDQ1-3F

Complete Short Turret Assembly - includes Turret, Base, 3 Fuse fitted with 3 fuse holders & 1 neutral link & 4 D Head bolts

URDQ2-6F

Complete Tall Turret Assembly - includes Turret, Base, 6 Fuse fitted with 6 fuse holders & neutral link & 4 D Head bolts

*For beige add b after above P/N

Individual Components & Accessories Specifications Part No

Height

Width

Depth

Wt-kg

Turrets UTSMALL UTTALL

315 550

235 230

300 295

1.9 2.9

Matching Base UTBASE

350

550

510

3.6

Accessories Part No

Description

Bolts DHB10M

Stainless Steel D Head bolt M10 x 30mm length

s CTC280 CTC495 3F-MPS-AS-SQ 6F-MPM-AS-SQ

Blank Type X switchboard 280 h x 205 w Blank Type X switchboard 495 h x 205 w 3 fuse fitted with 3 x fuse holders & neutral link 6 fuse fitted with 6 x fuse holders & neutral link

Shrouds ISP-BK-LG-5mm ISP-BK-SM-5mm D-Head Bolt Spanners DSC-M10 3F-MPS

Termination shroud Black fire retardant PVC 150mm long x 90mm O.D. Termination Shroud Black fire retardant PVC 90mm long x 66 mm O.D.

Catalogue No. 3F-MPS

D Head Drill Socket attachment T-handle spanner 780mm length suits all D Head bolts

77

www.nesco.com.au

O v e r h ead an d Un d er g r o u n d

Underground Industrial/ Commercial Pillars Pillars and base are fire retardant and UV stabilised. Pillars are marked “Danger Electricity” Available pillar colours green / beige

Accessories Part No

Description

FPBNF1V

Fibreglass pillar vented Pillar Dimensions 760H x 450W x 33D

FPBNF1V1D

Fibreglass pillar vented single door Pillar Dimensions 760H x 450W x 33D

FPBNF1V2D

Fibreglass pillar vented two door Pillar Dimensions 760H x 450W x 33D

FPBNF2V1D

Fibreglass pillar vented single door Pillar dimensions 1300H x 450W x 330D

FPBNF2V2D

Fibreglass pillar vented two door Pillar dimensions 1300H x 450W x 330D

GSFPNF1

Type X S/ Blank/Frame Assembly (to suit FPBNF1 series) 700H x 410W x 10mm

GSFPNF2

Type X S/ Blank/Frame Assembly (to suit FPBNF2 series) 1200H x 410W x 10mm

CBNF1

Lightweight concrete base to suit FPB series 310H x 565W x 335D colour neutral

PSFB2

Security bolts & washers 4 per pillar G304 stainless steel

SLP1

Locking plate to suit padlock 1 per pillar G304 stainless steel

SLB1

Locking bolt for SLP1 1 per pillar G304 stainless steel

Pillars and base are fire retardant and UV stabilised. Pillars are marked “Danger Electricity” Available pillar colours green / beige

Accessories Part No

Description

FPB3CD1D

Fibreglass pillar single door Pillar dimensions 1280H x 710W x 280D

FPB3CD2D

Fibreglass pillar two door Pillar dimensions 1280H x 710W x 280D

GSFP3

Type X S/ Blank/Frame Assembly 1100H x 625W x 10mm

CB3

Lightweight concrete base 400H x 960W x 500D colour neutral

PSFB2

Security bolts & washers 4 per pillar G304 stainless steel

Other sizes and configurations available upon request

78

Earthing Rods & Accessories Part No

Description

Domestic Non-Extendable Earth Rods CUP1314WC

Copper domestic earth rod 13mm diameter 1.4m length complete with earth clip 10 pcs/pack

CUP1318WC

Copper domestic earth rod 13mm diameter 1.8m length complete with earth clip 10 pcs/pack

Extendable Earth Rods & Accessories CR 1518

Tapered copper earth rod 15mm diameter x 1.8 length

CR 1524

Tapered copper earth rod 15mm diameter x 2.4 length

CR 1530

Tapered copper earth rod 15mm diameter 3.0m length

BC15

Coupling

TP15

Driving point normal driving

TPS-15

Driving point hard driving

DHT15

Driving Head

Non Extendable Heavy Duty CR1918

Copper rod 19mm diameter x 1.8m length incorporates driving head and point

CR1924

Copper rod 19mm diameter x 2.4m length incorporates driving head and point

CR1930

Copper rod 19mm diameter x 3.0m length incorporates driving head and point

Note: The above is a rationalisation of the entire earth rod range. For other configurations please consult sales office. Airport Earthing Terminal AIR1918

Copper rod 19mm diameter x 1.8 length complete with earthing terminal Type AET Electrodes provide for the earthing of airport tarmac areas where any generation of static electricity could be hazardous, i.e. aircraft refuelling, servicing and cargo loading areas. The heavy duty capping has a ribbed design affording a fast, and positive earthing connection by means of earth lead connector clips. Material: Solid steel core overlaid with copper cladding; heavy bronze cap. Installation Procedure: Drive electrode into ground to required depth. Remove protuding portion of rod above cap and finish flush.

Catalogue No. AIR1918

79

www.nesco.com.au

O v e r h ead an d Un d er g r o u n d

ECA Part No ECA 1508

Rod Dia.

Cable Range

Weight (kg)

13 - 15

16 - 50mm2

0.160 2

0.145 0.150

ECA 1514

13 - 15

*35 - 150mm

ECA 1514C

13 - 15

*35 - 150mm2

A versatile double saddle clamp made of copper alloy with stainless stell U-bolt and nuts.

Catalogue No. ECA 1514

*Smaller cables within the range 16 - 35mm2 can be accommodated in Cat. No. ECA 1514 and ECA 1514C by inverting clamp casting.

ECR ECR5

13 - 15

10 - 50mm2

0.115

A single screw earth clamp. Both componenets made from brass.

Catalogue No. ECR 5

E 12 - 13

16 - 50mm2

0.112

E 1509

14 - 15

16 - 50mm

2

0.125

E 1914

17 - 19

16 - 120mm2

E 1309

0.200

Cast in copper alloy with stainless steel U-bolt, nuts and spring washers.

ECH ECH 1914

15 - 19

50 - 120mm2

0.350

Type ECH 1914 takes two cables at right angles to rod. Castings are in copper alloy. U-bolt, nuts and spring washers are stainless steel.

Catalogue No. E 1514

ECX ECX 1909

13 - 19

16 - 50mm2

0.300

ECX 1514

13 - 15

35 - 120mm2

0.300

ECX 1914

13 - 19

35 - 120mm2

0.320

Type ECX clamps take cables either at right angles or parallel to rod. Castings are in copper alloy. U-bolt, nuts and spring washers are in stainless steel.

Catalogue No. ECX 1914

ECF ECF 13

13

ECF 15

15

ECF 19

19

Two holes 11.5mm dia. on 30mm centres

0.226 0.225 0.224

Type ECF clamps are designed to connect an earth rod to an earthing strap which is drilled to match U-bolt. Casting is copper alloy. U-bolt, nuts and spring washers are stainless steel.

80

Catalogue No. ECF 13

Compression Earth Clamps Made from high conductivity copper. Used where copper earth wire is looped so as not to cut the earth wire, ensuring continuity of the Earthing System. Suits a vast range of conductors and earth rods, 12mm to 15mm dia. inclusive.

6 Profile Earthing Connector For Cable - Cable or Rod Cable Connection.

Specifications Part No

Rod Dia.

Cable Size

CO/16

12 to 15mm

16 sq mm

CO/25

12 to 15mm

25 sq mm

CO/35

12 to 15mm

35 sq mm

CO/50

12 to 15mm

50 sq mm

CO/70

12 to 15mm

70 sq mm

CO/95

12 to 15mm

95 sq mm

CO/120

12 to 15mm

120 sq mm

Die

Profile 6

U-997 or DU1315

Profile C

C Profile Earthing Connector For Rod to Cable Connection.

Specifications Part No

Rod Dia.

Cable Size

Die

C35/70

12mm

25 sq mm

U-O/DUOT

C70/95

12 to 15mm

50 - 70 - 95 sq mm

U-997/ DU1315

Earth Rod is compressed with hexagonal die prior to connection of clamp to avoid radial turning of clamp after earth connection is completed. Hexagonal Die Dimensions 12mm Diameter rod - use 38 - 130 (13mm A/F) Hex Compression Die 15mm Diameter rod - use 38 - 142 (14.2mm A/F) Hex Compression Die For Cable to Cable Connection.

Specifications Part No

Cable Run

Cable Tap

Die Size

C35/70

70 sq mm

35 sq mm

50 sq mm

50 sq mm

70 sq mm

50 sq mm

U-O or DUOT

70 sq mm

70 sq mm

95 sq mm

70 sq mm

95 sq mm

95 sq mm

C70/95

UO997 or DU-1315

E Profile Earthing Connector For Cable to Cable Connection.

Specifications Part No

Cable Run

Cable Tap

E50/70

50 sq mm

50 sq mm

70 sq mm

50 sq mm

70 sq mm

70 sq mm

Die Size U-O

81

www.nesco.com.au

O v e r h ead an d Un d er g r o u n d

Earth Rod Connection Boxes Part No

Description

ERB1

Aluminium Alloy casting 76mm high x 120mm wide x 120mm depth features a hinged lid

PIT-03

Plastic 245 high x 190 wide x 145mm depth Withstands 5 tonnes Lockable lid

Catalogue No. PIT-03

Catalogue No. ERB1

Earth Enhancing Compound Part No

Description

Earthit

20kg bag Mixture of Bentonite, Gypsum and Sodium Sulphate Features stable high conductivity providing long term low ground resistance. High expansion, low shrink characteristics, Non-toxic, Non-corrosive. Apply as a dry mix or as a pourable slurry Material Safety Data sheets are available upon request 1 bag mixes 0.03m3

Catalogue No. Earthit

Earth Mats Part No

Description

EMAT

Galvanised mild steel 1525mm x 915mm

Catalogue No. EMAT

Earth Bond Part No

Description

C70

For Commercial earthing installations - The earthing bond system provides an earth connection to the steel reinforcement, offering a virtually indestructible, stable and low resistance path to earth Bonding cable - 70mm² 3 sec current rating - 10kA Lug dia - 10mm Terminal thread - M10 Thread depth - 20mm

Catalogue No. C70

82

Copper Tape Part No

Description

TCEC253050

Tape, copper - 25 x 3mm (50m roll)

TCEC2530100

Tape, copper - 25 x 3mm (100m roll)

CET-50

Tape, copper - 50mm x 0.5 - available per meter

Flexible Copper Braids The flexible copper braids are made from numbers of flat tinned braids. Ferrules are pressed on the ends to form flat connection plates to bolt onto bus-bars or terminals. (12mm hole std)

Profile 6 Part No

Current Rating

No of Braids

FCB1-100/300

100 Amps

1

FCB1-200/300

200 Amps

2

FCB1-275/300

275 Amps

3

FCB1-350/300

350 Amps

4

FCB1-425/300

425 Amps

5

FCB1-500/300

500 Amps

6

Note: Standard length is 300mm. Other lengths are available upon request. FBCB1 prefix denotes a single hole. For 2-hole use prefix FCB2

Transformer Braid & Adaptor Plates Part No

Description

RCB3-670S

670 amp 315mm in length

AP670

Adaptor plates to suit the above 170mm x 100mm

Catalogue No. FCB1

Catalogue No. RCB3-670S

Catalogue No. AP670

83

www.nesco.com.au

O v e r h ead an d Un d er g r o u n d

Cadweld – Exothermic Welding The Cadweld Process makes it possible to produce copper/copper, copper to aluminium, copper/steel and aluminium/aluminium electrical molecular bonds with no external energy or heat source. Information Required for Orderin 1. 2. 3. 4. 5. 6.

Connection type Conductor material, size & stranding Ground Rod size Lug catalog number Pipe, nominal size, vertical or horizontal Rebar, nominal size

Four Simple Steps Step 1 Prepare conductor ends with a wire brush for welding. Place cable ends into open mould. Step 2 Close handle to lock mould halves together. Drop metal disk into crucible ensuring it is correctly seated, covering tap hole. Step 3 Deposit weld metal into crucible. Tap bottom of container to release starting material. Spread a little material on top of mould. Step 4 Close the cover and ignite with flint gun. Open the mould after 10 seconds, when meal has solidified.

Cable Grips & Accessories Range of hand woven wire cable grips is designed for hauling power cable, telephone, fiber optic cable, coaxial cable and winching rope through conduit, trenches and overhead poles. High quality galvanized steel wire is used in weaving the individual grips.

84

Closed Tubular – Single Eye and Double Eye These are for light to medium hauling of communication and power cable.

Specifications Part No Single & Double

Suit cable O.D. in mm

Max Length in mm

S.W.L. in kN

Max Tensile Load in Kg

TCG-0612 & DCG-0612

6-12mm

300

6.48

1984

TCG-0916 & DCG-0916

9-16mm

350

8.89

2720

TCG-1422 & DCG-1422

14-22mm

400

13.33

4080

TCG-2032 & DCG-2032

20-32mm

550

16.59

5080

TCG-3240 & DCG-3240

32-40mm

700

13.33

4080

TCG-4055 & DCG-4055

40-55mm

850

19.91

6096

TCG-5575 & DCG-5575

55-75mm

950

29.87

9144

TCG-7595 & DCG-7595

75-95mm

1000

40.77

12480

TCG-95114 & DCG-95114

95-114mm

1200

61.15

18720

TCG-114126 & DCG-114126

114-126mm

1300

81.54

24960

Catalogue No. TCG

Lace Up - Double Eye Generally used to electricity cable in vertical or sloping position and is also ideally suited for use in manholes where the longitudinal movement of cable caused by road vibration needs to be checked.

Specifications Part No

Suit cable O.D. in mm

Max Length in mm

S.W.L. in kN

Max Tensile Load in Kg

LCG-0612

6-12mm

300

6.48

1984

LCG-0916

9-16mm

350

8.89

2720

LCG-1422

14-22mm

400

13.33

4080

LCG-2032

20-32mm

550

16.59

5080

LCG-3240

32-40mm

700

19.91

6096

LCG-4055

40-55mm

850

29.87

9144

LCG-5575

55-75mm

950

40.77

12480

LCG-7595

75-95mm

1000

61.15

18720

LCG-95114

95-114mm

1200

81.54

24960

LCG-114126

114-126mm

1300

125.64

38460

Catalogue No. LCG

For complete specification see our website www.nesco.com.au

85

www.nesco.com.au

O v e r h ead an d Un d er g r o u n d

Swivels The swivels have been manufactured with sealed bearings and are precision machined from high-grade steel. They have been NATA certified for a 3:1 safety factor.

Part No

Description

SWI-16

6kN Swivel Clevis to Clevis

SWI-22

10kN Swivel Clevis to Clevis

SWI-33

18kN Swivel Clevis to Clevis

SWI-40

35kN Swivel Clevis to Clevis

SWI-60

50kN Swivel Clevis to Clevis

A range of fuses from 0.6kN to 62kN are available for the SWI-16 through to SWI-60. The tolerances on the fuses have been rated at ± 10%. By removing the high tensile bolt from the center, and replacing it with the fuse of your choice, you can convert the swivels into a Breakaway Fused Swivel.

Cable Rollers Features Aluminium cast rollers Semi high tensile steel 18mm axle Axle ed in sealed roller bearing

Specifications Part No

86

Height

Width

Depth

Wt-kg

C1

190

280

400

5

C2

320

280

330

5

C3

320

250

155

5.5

Catalogue No. SWI

Fiberglass Duct/Conduit Rod – “Tigerod” The fiberglass rod is supplied with detachable pulling eyes. TIGEROD is detachable and comes in 4mm, 6mm, and 8mm rod. All methods of tracing conduit from the ground will work with TIGEROD. All rod has a 1mm sheath of yellow HPDE to render it more noticeable and to protect the fiberglass from wear. The tigerod dispensing units come with a hand brake and are strong and durable. The pay-off mechanism on the dispenser has a double set of rollers to reduce wear on the sheath and rod. The rod is supplied with the dispenser units. They are short enough to be stored in the back of vans and other small, enclosed vehicles. The rod comes standard with a 1mm copper tracer wire. Simply energize the rod with your transmitter and locate your pipe with the aid of a receiver. Pull rating up to 6.5kN at 2:1 safety factor.

Part No

Rod O. D.

Length

TDUS-4080

6mm

80 Meters

TDUS-6100

8mm

100 Meters

TDUS-6125

8mm

125 Meters

TDUS-8125

10mm

125 Meters

TDUS-8200

10mm

200 Meters

Catalogue No.TDUS-8200 Catalogue No.TDUS-6125

Electricians Mini Coil Extremely versatile for electrical, telephone and computer network installations in commercial situations. Outperforming steel and nylon fish tapes, the 3mm mini-coil comes complete with end fittings and a lightweight-dispensing reel.

Part No

Rod O. D.

Length

TDUS-3060

3mm

60 Meters

TDUS-3080

3mm

80 Meters

Catalogue No. TDUS-4080 Catalogue No. TDUS-3060

For complete specification see our website www.nesco.com.au

87

www.nesco.com.au

O v e r h ead an d Un d er g r o u n d

SICAME Insulated Line Systems Mains Connection Boxes Single and three phase environmental base and cover for the protection on consumer mains. Each unit contains the HSC series (House Service Connector) providing a full sealed bi-metallic connection of copper consumer mains to Al or Cu services. Features Fully insulated and waterproof. Plug in HSC’s providing bi-metal connection of service cables and consumer mains.

Base is suitable for rear entry of consumer mains. Eliminates UV degradation of PVC consumer mains. Heavy duty polymide UV stabilised construction. IP66 rated. Clear markings. All connections made with 13mm across flats hexagon headed spanner. Cover allows for easy exit of bonding tail HSC435/1

Specifications Part No

Description

MCB1/2H

Single Phase Mains Connection Box with 2 x HSC435 connectors

MCB3/4H

Three Phase Mains Connection Box with 4 x HSC435 connectors

MCB1

Single Phase Mains Connection Boxes without HSC435 connectors

MCB3

Three Phase Mains Connection Boxes without HSC435 Connectors

Catalogue No. MCB1/2H

Underground Multi-Tap Connectors Multi position piercing connector for underground connection of two and four service connections. Features Flexible ts providing the ultimate barrier to moisture ingression. Insulation piercing on all positions. No stripping necessary. Nickel plated interior body. Ideal for pillar-box or underground pit. Totally insulated and waterproof.

Catalogue No. MUCI SERIES

Use RPS spanner see page 14

TTD Series Part No

88

No of Connections

Cable Range

Bolt Head Size

MUCI2/650

2

6-50mm

13

MUCI3/650

3

6-50mm

13

MUCI4/650

4

6-50mm

13

AVAILABLE

QUEENSLAND ONLY

SICAME Insulated Line Systems House Service Connectors House side connection - Stripped copper consumer mains Service side connection - Aluminium or copper insulated service connection made with insulation piercing technology thus stripping of insulation is not required Features Shear heads on both connections. Fully insulated, waterproof and bi-metallic. Easily fits into Mains Boxes.

Catalogue No. HSC435/1

Optional model available with insulated bonding tail and lug. Use RPS spanner see page 14

Specifications Part No

Consumer Mains side mm²

House side only strip length

Service Side Tap Range mm²

Copper Earth Tail

Bolt Head Size

HSC435

4-35

10mm

6-35

No

13mm A/F

HSC435/1

4-35

10mm

6-35

16mm²

13mmA/F

Overhead Pole/ House Fuse 100-amp single pole pigtail stick operated service fuse for house or pole mounting. Features

Range of brackets to suit all installations including replacement.



Insulation piercing connections on line and load sides.



Insulated top mounting M8 shear head bolts.



Takes up to 100 amp BS style cartridge (57mm x 22mm).



U.V. Stabilised polymeric body.



Gangable to three phase.

Specifications Part No

Description

PF100

Pole fuse up to 100 amp

PFBKT1

Pole bracket - single phase

PFBKT3

Pole Bracket - three phase

PFAB1

Adapter bracket to fit PF100 to swan neck pin

AVAILABLE

QUEENSLAND ONLY

Catalogue No. PF100

89

www.nesco.com.au

O v e r h ead an d Un d er g r o u n d

SICAME Insulated Line Systems Insulated Piercing Connectors For ing insulated mains cable to insulated service cables. TTD Series Mains - Insulated copper or Aluminium

Tap - Insulated Copper or Aluminium

Features Easy and safe to fit on energised cable.

Shear heads on all bolts.

No live metal parts are accessible and

Tightening bolts are potential free.

there is no need to strip the insulation.

Simultaneous piercing on main and tap. End cap for protection of tap Completely waterproof.

Use RPS spanner see page 14

Withstands 6kV in water. For ing bare mains cable to insulated service cables. NTD Series Mains - Bare Copper or Aluminium

Tap - Insulated Copper or Aluminium

TTD Series Mains Cable mm2

Branch Cable mm2

No of bolts

TTD051FAX

16-95

1.5-10

1

TTD101FAX

6-54

4-35

1

TTD151FAX

25-95

6-35

1

TTD201FAX

35-95

25-95

1

TTD231FAX

25-95

10-50

1

TTD241FAX

50-150

6-35

1

TTD251FAX

50-150

35-95

1

TTD301FAX

35-95

35-95

2

TTD341FAX

50-150

6-35

2

TTD351FAX

50-150

35-95

2

TTD401FAX

50-185

50-150

2

TTD431FAX

70-240

16-95

2

TTD451FAX

70-240

50-185

2

Part No

Catalogue No. TTD

NTD Series Part No

90

Bare Conductor mm²

Insulated Cable

NTD101F

Cu

Bare Cable Type

7-54

6-35

NTD151F

Cu

35-95

6-35

NTD241F

Cu

50-150

6-35

NTD301FA

Cu

7-95

35-95

NTD351F

Cu

50-150

35-95

NTD401F

Cu

50-150

50-150

NTD101AF

Alu

7-54

6-35

NTD151AF

Alu

35-95

6-35

NTD241AF

Alu

50-150

6-35

NTD301AF

Alu

7-95

35-95

NTD351AFA

Alu

50-150

35-95

NTD401AF

Alu

50-150

50-150

NTD431AF

Alu

95-240

35-95

NTD451AF

Alu

95-240

95-150

Use RPS spanner see page ?

Catalogue No. NTD

AVAILABLE

QUEENSLAND ONLY

CCW and CAW Series For ing bare mains cable to insulated service cables. CCW Series Bare copper to insulated PVC or XLPE copper or aluminium service cable. CAW Series Bare aluminium to insulated PVC or XLPE copper or aluminium service cable. Features Aluminium cast rollers Piercing on all tap connectors Conforms to Australian Standard AS4396

Catalogue No. CAW235

Disconnection of service by easy removal

Catalogue No. CAW35

of the connecctor from the mains

Bi-metallic tap section Simple M8 socket operation Two tap (CAW235) available Use RPS spanner see page 14

Specifications Part No

Mains Range

O.D. mm

Tap Range

Shear Heads

CAW235

7/1.75 to 19/3.75 A1

5-19

2 x 6-35mm2 A1/Cu

Yes

CAW35

7/1.75 to 19/3.75 A1

5-19

1 x 6-35mm2 A1/Cu

Yes

CCW35

7/1.00 to 19/3.00 Cu

3-14

1 x 6-35mm2 A1/Cu

Yes

Catalogue No. CCW35

Suspension Clamps Features Suitable for angles up to 30 degrees Hinged aluminium alloy body with stainless steel fasteners Reinforced hanging eye to stop wear through vibration

Specifications Part No

SC435

Cable Size mm² 2 Core

3 Core

4 Core

50

35,50

25,35

SC450 SC470

50 95

70

SC495

95

SC4150

150

AVAILABLE

QUEENSLAND ONLY

91

www.nesco.com.au

O v e r h ead an d Un d er g r o u n d

SICAME Insulated Line Systems Strain Clamps for Service, ABC Mains & Sub Mains Part No

Cable Size mm²

Features

PC63F27A

2 x 6 to 4 x 35

Wedge action Range taking - one clamp suits a range of cable sizes 2, 3, or 4 core cables Suitable for everyday loadings Suits closed or open eye pole s Simple to install

BCST-2025-3PA

2 x 25

Catalogue No. PC63F27A

Bolted action Can be used as a suspension fitting by rotating blocks Simple to install

BCST-4035-3PA

4 x 25 and 4 x 35

Bolted action Can be used as a suspension fitting by rotating blocks

Catalogue No. BCST-2025-3PA

Simple to install PA10/1

4x25-50 and 2 x 25-50

Bolted action for full tension Removable clevis pin Aluminium strap

Catalogue No. BCST-4035-3PA

17mm across flat nuts suit ratchet spanner PA11/1

4 x 50-95 and 2 x 50-95

Bolted action for full tension Removable clevis pin Aluminium strap 17mm across flat nuts suit ratchet spanner

PA122

4 x 95 -150

Bolted action for full tension Removable clevis pin Aluminium strap 17mm across flat nuts suit ratchet spanner

Catalogue No. PA11/1 AVAILABLE

QUEENSLAND ONLY

92

Installation Accessories Part No

Description

Features

6707BC

Running Sheave for LV ABC and bare conductor

Sheave can be used for all sizes of mains cable including 4 x 95 & 4 x 150mm² cable on intermediate, angle or end poles. Cast aluminium construction. Can be mounted vertically or can be suspended. Working Load 1134kg (2500lbs). Safe and easy to adjust and use.

BR50-S

Ratchet Buckle & Strap

For the attachment of Sheave bracket. Safe working load 21.6kN. Webbing fixed at spool. Plate hook sewn to strap and used for hooking onto attachment point. Strap length 1200mm.

RPS13/17-6H RPS13/17-6HSH

Ratchet Spanner 260mm length Ratchet Spanner 200mm length

13mm across flats and 17mm across flats in one spanner. Reversible ratchet. Suits all sizes of insulation piercing connectors for cables 1.5mm2 up to 240mm2, most strain clamps and suspension clamps. 6 point hex (double sided). Comfortable grip. Well balanced, lightweight.

CS050 CS095 CS150

For 50mm2 LV ABC For 95mm2 LV ABC

Cable Stripping tool removes the tough polyethylene insulation of low voltage aerial bundled cable. Quick, safe and easy

For 150mmc LV ABC 12870

Service Cable Comealongs

Conductor range 2 x 16 to 4 x 35mm² Maximum working load 200kg. Failing load 1250 kg

PP1514

Insulated cable test point

Reusable

CIE100

Core separation tool

Suitable for LVABC up to and including 4 x 95mm²

PMR87

Core separation wedge

Suitable for LV ABC up to and including 4 x 95mm²

CES3

Cable end seal 16-25mm²

Each cap contains a compound providing complete waterproofing and ensures cap retention on cable

CES4

Cable end seal 35-50mm²

CES5

Cable end seal 70-95mm²

AVAILABLE

CES7

Cable end seal 120-150mm²

QUEENSLAND ONLY

93

www.nesco.com.au

O v e r h ead an d Un d er g r o u n d

SICAME Insulated Line Systems Preinsulated Compression Sleeves Features

Limited and full tension 24 to 150mm2



Suits common 12 tonne-crimping tool.

Specifications Part No

Mains Cable Size mm²

Die A/F mm

MJPT25CG MJPT35-25CG

25 35

25 25

17.3 17.3

MJPT35CG MJPT50-25CG

35 50

35 25

17.3 17.3

MJPT50-35CG MJPT50CG

50 50

35 50

17.3 17.3

MJPT70-35CG MJPT70-50CG

70 70

35 50

17.3 17.3

MJPT70CG MJPT95CG

70 95

70 95

17.3 17.3

MJPT95CG MJPT120CG

95 120

95 120

21.5 21.5

MJPT150CG

150

150

21.5

Catalogue No. MJPT SERIES

Preinsulated Bi-Metal Lugs Specifications Part No

Cable Size mm²

Length

Die A/F

TAU16

16

87

14.0

TAU25

25

87

14.0

TAU35

35

92

17.3

TAU50

50

92

17.3

TAU70

50

92

17.3

TAU70-21

50

115

21.5

TAU95

95

92

17.3

TAU95-21

95

115

21.5

TAU150

150

115

21.5

Catalogue No. TAU SERIES AVAILABLE

QUEENSLAND ONLY

94

Photo Electric Outdoor Lighting Controls Built in time delay prevents false cycling caused by lightning flashes or stray headlights. Specifications Housing: UV stabilized high-impact polypropylene Photocell: I inch cium sulfide light sensitive Turn-On: 1 to 3 foot –candles Turn-on/Turn-off Ratio: Switch type: Single pole, single throw. position at night normally closed. Temperature Range: -40degree to 170degree F. Power consumption: 1.1 watts average at 120 VAC. Rated life: 5,000 operations minimum at rated load. Voltage: 208-277 Rating: 1800VA

Specifications Part No

Description

P68275LA30

Photoelectric cell

M2AF

Base to suit conforms to NEMA standards Wood pole, cross arm or wall mounting including all weather locking type receptacle.

Helical Fittings Deadends for Aerial Service Cable Features Specifically designed for weathering, corrosion and vibration performance, tensile load and high temperature conditions.

Easy to install, economical and neat appearance. Application For terminating insulated aluminium or aerial copper service cables direct to house “j” hook without the need for separate insulator installation. There are no span limits in normal urban usage.

Twisted Conductors Conductor Area (sq mm)

Construction Core

Part No.

6

2, 3 & 4

GSG-160-DI-19

10

2

GSG-160-DI-19

10

2, 3 & 4

GSG-180-DI-19

16

2

GSG-180-DI-19

16

3&4

GSG-220-DI-20

Standard Pack

Colour Code

10

red

10

white

10

yellow

95

www.nesco.com.au

O v e r h ead an d Un d er g r o u n d

Power Line Aviation Markers - for Conductors up to 25mm Two piece sphere clamps together around the conductor. Intended for use in accordance with Standards Australia requirements. Installation: On de-energised lines by hand installation or live line tools. Part No

Description

PAM30*

30cm Diameter

PAM60*

60cm Diameter

*Please indicate the colour required by adding the relevant suffix to the catalogue number. Standard Colours W = White Y = Yellow R = Red O = Orange

Fittings for Aluminium Based Conductors – (AAC, AAAC & ACSR) Deadends & Splices Rated Holding Strengths: On aluminium conductors of homogenous stranding, the UTS of the deadend is equal to that of the conductor. On ACSR conductors, the holding strength of the deadend is equal to 100% of the strength of the Aluminium strands plus 10% of the strength of the steel core. They are designed to terminate primary, secondary and neutral wire conductors.

96

AAC/AAAC

ACSR

Cond. Dia. (mm)

Part No.

Standard Pack

Colour Code

7/1.75

-

5.25

AFG-053

50

purple

7/2.25

-

6.75

AFG-068

50

brown

7/2.50

-

7.50

AFG-075

40

blue

7/3.00

-

9.00

AFG-090-CL

40

red

7/3.75

-

11.25

AFG-113-CL

25

black

7/4.50

-

13.50

AFG-135-CL

15

green

7/4.75

-

14.30

AFG-143-CL

10

blue

19/3.25

-

16.30

AFG-163-CL

10

orange

13/3.75

-

18.80

AFG-188-CL

15

black

37/3.00

-

21.00

AFG-210-CL

10

red

19/4.75

-

23.80

AFG-240-LT-CL

10

blue

Fittings for Galvanised Conductors Rated Holding Strengths: The UTS of the steel fitting approximates that of their equivalent conductors.

Typical Australian Strands

Conductor Dia. (mm)

Part No.

Standard Pack

Colour Code

1/2.50

2.50

GFG-025-CL

50

blue

1/3.15 1/3.24

3.15 3.24

GFG--031-CL

7/1.25

3.75

GFG-038-CL

50

green

3/2.00

4.25

GFG-043-CL

50

yellow

7/1.60

4.80

GFG-048-CL

50

black

3/2.75

5.50

GFG-055-CL

75

white

7/2.00

6.00

GFG-060-CL

50

yellow

7/2.75

8.25

GFG-083-CL

20

white

7/3.25 19/2.00

9.75 10.00

GFG-100-CL

7/3.75

11.25

GFG-113-CL

15

black

7/4.00

12.00

GFG-120

15

black

19/2.75

13.75

GFG-138

10

white

19/3.25

16.25

GFG-163

10

orange

50

20

red

yellow/orange

Splice for Galvanised Steel Conductors Features Easily applied



Used for ing and repair

No special tooling required



Long life

Same material as conductor

Conductor Stranding

Conductor O.D. (mm)

Part No.

Standard Pack

Colour Code

3/2.00

4.31

GFS-043

30

yellow

7/1.60

4.80

GFS-048

30

black

3/2.75

5.93

GFS-055

30

white

7/2.00

6.00

GFS-060

50

yellow

7/2.75

8.25

GFS-083

40

white

7/3.25 19.2.00

9.75 10.00

GFS-100

25

orange yellow

7/3.75

11.30

GFS-113

20

black

7/4.00

12.00

GFS-120

15

black

19/2.75

13.80

GFS-138

10

white

19/3.75

16.30

GFS-163

10

orange

97

www.nesco.com.au

O v e r h ead an d Un d er g r o u n d

Splice for Aluminium & ACSR Conductors When used with ACSR conductor this preformed conductor splice will hold a minimum tension amounting to the full strengthof the aluminium strands plus 10% of the steel core strength. Conductivity will be up to 75% that of the unspliced conductor: Easily applied



Used for ing and repair

No special tooling required



Long life

Same material as conductor

98

Conductor Stranding

Conductor O.D. (mm)

Part No.

Standard Pack

Colour Code

7/1.75

5.25

AFS-053

70

purple

3/4/1.75

5.25

70

purple

7/2.25

6.75

AFS-068

50

brown

7/2.50

7.50

AFS-075

35

blue

6/1/2.50

7.50

AFS-075

35

blue

3/4/2.50

7.50

AFS-075

35

blue

7/3.00

9.00

20

red

6/1/3.00

9.00

AFS-090

20

red

4/3/3.00

9.00

AFS-909-AW

20

red

7/3.75

11.25

25

black

6/1/3.75

11.25

FTS-113

10

black

4/3/6.75

11.25

AFS-113-AW

15

black

7/4.50

13.50

AFS-135

15

green

7/4.75

14.30

AFS-143

13

blue

6/4.75+7/1.60

14.30

13

blue

19/3.25

169.25

10

orange

30/7/2.5

17.50

15

blue

19/3.75

18.75

AFS-188

5

black

37/3.00

21.00

AFS-210

5

red

30/7/3.00

21.00

5

red

19/4.75

23.75

5

blue

Part No. ASCR

AFS-053

AFS-090

AFS-113

FTS-143 AFS-163 FTS-175

FTS-210 AFS-240

Fittings for Agricultural Net Systems Steel Line Splice Specially designed splices give optimum strength while making them easy to work with, as no special tools are required.

Specifications Part No

Conductor O.D. mm

Colour Code

Box Quantity

SLS0600S

6.10mm

Yellow

50

SLS0735S

7.50mm

Blue

30

Insulators & Line Hardware Dimensions Part No

A

B

C

D

E

Thread

Pin

Min Failing Load

Low Voltage - Porcelain SHLV1

54

57

39

17

R17

N/A

N/A

9kN

SHLV2

76

80

54

17

R12

N/A

N/A

20kN

PLV

91

82

52

N/A

R11

Patt B

B/100/3.5

7kN

Note: Dimensions & Performance characteristics in accordance with AS3608, 1989. Threads in accordance with AS2947.3, 1989.

Dimensions Part No

Voltage

Creepage

A

B

C

D

E

Thread

Pin

Min F.L

High Voltage - Porcelain P11

11kV

180

106

ø140

ø76

R13

R16

Patt ‘A’

A/130/7

7kN

P22

22kV

420

168

ø228

ø113

R13

R16

Patt ‘C’

C150/11

11kN

P33

33kV

534

194

ø279

ø113

R13

R16

Patt ‘C’

C/200/11

11kN

Note: Dimensions and Performance characteristics in accordance with AS2947, 1989. Thread and Insulator Pin in accordance with AS1154, Part 2, 1985.

Catalogue No. PLV

Catalogue No. SHLV

Catalogue No. ???

99

www.nesco.com.au

O v e r h ead an d Un d er g r o u n d

Guy Strain Insulators - Porcelain Dimensions Part No

A

B

C

D

E

F

G

H

I

J

K

Min F.L

GY2

73

41

44

73

44

146

ø22

51

ø22

37

37

71kN

GY3

115

57

67

115

57

216

ø38

51

ø38

63

62

222kN

GY4

115

57

67

115

57

280

ø38

51

ø38

95

95

222kN

Note: Dimensions and Performance characteristics in accordance with AS1137, Part 4 1981 AS3609, 1989.

Disc Insulators - Porcelain & Glass Specifications Part No

Description

Material

Total Creepage

Min F.L.

Std Pack

D70S

Ball & Socket 16mm

Porcelain

295

70kN

6

D70C

Tongue & Clevis

Porcelain

295

70kN

6

D70SG

Ball & Socket 16mm

Glass

295

70kN

6

D70CG

Tongue & Clevis

Glass

295

70kN

6

Note: Dimensions in accordance with AS2947, 1989.

Synthetic (Composite) - Distribution Strain Insulators Specifications

10 0

Part No

Nominal Voltage kV

Number of Sheds

Length mm

Tensile Rating kN

1515-OH

11

4

315

70

2515-OH

22

6

440

70

3515-OH

33

10

525

70

Bus-Bar Insulators Material Stand off insulators are moulded from, recognised flame resistant fibreglass reinforced polyester compound. They feature shatter resistance and height tolerance closer than commonly available in porcelain insulators. Moisture and heat resistance of insulators is higher than conventional plastic insulators. Cantilever Strength One end of the insulator is bolted to a flat plate and a force is applied to the insert on the other end in a direction parallel to the end at a distance from the plate equal to the insulators height. NOTE: the voltage rating is only meant to be a guide for indoor service. Insulators mounted within a suitable electrical cabinet are considered indoors even though the cabinet is outdoors. An insulator will withstand its rated voltage continuously but industry standards or other specifications may require a different spacing from conductors of ground for a particular voltage. Wet or dirty conditions may require derating an insulator.

SM51 SM76

SM35

Styles Specifications

SM35

SM51

SM76

Tensile Strength (lbs)

600

1000

1500

Torque Strength (ft lbs)

10

20

40

Voltage withstand

10

15

25

Screw (mm)

8

8

10

Weight

55

90

240

Insulator Pins Shank

Stem

Diameter

Length

Thread Length

Thread Length

Min Failure Load

A

B

C

J

B100

3.5kN

16

140

50

98

B

A130

7

20

165

80

128

A

C1507

7

20

165

80

148

C

C15011

11

24

165

80

148

C

C20011

11

24

165

80

198

C

C3007

7

24

165

80

298

C

Part No

101

www.nesco.com.au

O v e r h ead an d Un d er g r o u n d

Line Hardware Eyebolts All eyebolts are forged and then hot dipped galvanised to AS1650. Supplied with nut.

Part No. and Diameter Length mm

16mm O.D.

20mm O.D.

150

EB16X150

–

200

EB16X200

–

250

EB16X250

–

300

EB16X300

EB20X300

350

EB16X350

EB20X350

400

EB16X400

EB20X400

450

EB16X450

EB20X450

500

EB16X500

EB20X500

2000

–

EB20X2000

Catalogue No. EB

Eyebolts with Earth Tag Specifications Length mm

Part No Diameter 16mm

250

EB16250T

350

EB16350T

450

EB16450T

650

EB16650T

Note: Supplied with 2 nuts and 2 washers

Catalogue No. EB C/W Earth Tag

Open Eyebolts / Hook Bolts Part No. and Diameter

10 2

Length mm

16mm O.D.

20mm O.D.

250

OEB16X250

–

350

OEB16X350

OEB20X350

450

OEB16X450

–

Catalogue No. OEB

JHOOKCE

Service Hooks / J Hooks Specifications Part No

Description

CSH150

M12 x 150 Coach Screw (J Hook)

JHOOKCE

M12 x 150 Coach Screw (Closed Eye Design)

JHOOKT

M12 x 150 Coach Screw (J Hook) with Earth Tag

JHOOKTTH

M12 x 150 J Hook with thread & 2 nuts & Earth Tag

LPIN

M12 x 150 fitted with split pin & washer

IPSNG

M12 x 150 Swan neck with Patt B thread

COMB

M12 x 150 combination J hook fuse pin

JHOOKTTH

JHOOKT

CSH150

Hook Bracket Possible applications Intermediate, angle or strain poles: - banded to concrete poles with strainless steel strap - bolted timber poles Temporarily attached to concrete or timber pole with strap and ratchet buckle assembly to running sheave. Conforms to the requirements for hook bracelets in AS 3766 - mechanical fittings for low voltage aerial bundled cables.

Specifications Part No

Description

IBHB12

Hook Bracket 16mm O.D. 12kN Failing Load

IBHB24

Hook Bracket 20mm O.D. 24kN Failing Load

Catalogue No. IBHB

Eye Nuts Specifications Part No

Description

ENQ16

M16 Thread

ENQ20

M20 thread

Catalogue No. ENQ

Crossarm Braces Specifications Part No

Description

650T

650 x 40 x 6 Galvanised steel Crossarm Brace

1000T

1000 x 40 x 6 Galvanised steel Crossarm Brace

For complete specification see our website www.nesco.com.au

103

www.nesco.com.au

O v e r h ead an d Un d er g r o u n d

Gain Blocks For mounting crossarms

Specifications Part No

Description

GB100

100 mm diameter Cast aluminium alloy

GB125

125 mm diameter Cast aluminium alloy

GB150

150 mm diameter Cast aluminium alloy

Pole Steps Specifications Part No

Description

PLST

M16 x 250 Drive in Pole Step

Galvanised Forged Bolts Specifications Part No

Description

XOX (dia) (len)

Available in 12, 16 & 20 mm diameter in various lengths.

Coachscrews Specifications Part No

Description

CS (dia) (len)

Available in 12 & 16mm diameter in various length

Washers & Nuts Specifications

10 4

Part No

Description

W12000FG

M12 Galvanised Round

W16000FG

M16 Galvanised Round

W20000FG

M20 Galvanised Round

W16SQUARE

50 x 50 x 3 – 18mm hole Galvanised Square

W20SQU

50 x 50 x 3 – 22mm hole Galvanised Square

W20SQUARE

75 x 75 x 6 – 22mm hole Galvanised Square

N12

12mm nut

N16

16mm nut

N20

20mm nut

Shackle Straps Specifications Part No

Description

STRAP190

Straight shackle strap 190 x 40mm

STRAP235

Offset shackle strap 235 x 40mm

SHSTRAP2

U Strap –130 x 80 x 6mm – 1 x 18, 2 x 14mm holes

Aluminium Pole Caps Specifications Part No

Description

AD301

Aluminium Pole Cap 300mm in diameter

AD352

Aluminium Pole Cap 350mm in diameter

AD401

Aluminium Pole Cap 400mm in diameter

Uniseal ting Compounds For Aluminium and Copper ting Electropar’s ting compounds are formulated to improve ting conductivity and inhibit oxidation and corrosion between ting areas. ting compound should always be applied to the surfaces of all aluminium, aluminium to copper and copper to copper connections prior to compression or bolting. EP Uniseal (Grey, 350gm tube) EP Uniseal consists of a lithium based 180°C stable grease and zinc particles. The base grease prevents water and contaminants interfering with the connection and prevents the formation of surface oxides. The zinc particles work to break down existing oxide on the conducting surfaces when those surfaces are brought together under pressure. EP Uniseal is ideal for aluminium to aluminium and aluminium to copper and copper to copper compression or bolted ts.

Quick Reference Chart EP Uniseal is suitable for Bolted ts: Aluminium Bolted ts: Copper Non Tension Compression Fittings Use with solid Aluminium Conductors

Catalogue No. UNISEAL

For complete specification see our website www.nesco.com.au

105

www.nesco.com.au

O v e r h ead an d Un d er g r o u n d

Scratch Brushes The use of a suitable scratch brush to remove any existing oxide film, dirt or grease from the conductor is essential to ensure a sound electrical connection.

Specifications Part No

Description

ORB-1

White Scratch Brush for use on Aluminium

ORB-2

Black Scratch Brush for use on Copper

Split Bolt Clamps Manufactured to E.S.A.A. specification from hard drawn brass. Accommodates two maximum conductors specified in the table below. Electro tinned finish can be supplied when specified.

Part No.

Max Conductor Size

Width of Slot

Std Pack

Electro Tinned

Area mm²

Area mm²

B22Brass

B22T

16

5.10

5.30

100

B24Brass

B24T

35

7.65

8.30

50

B25Brass

B25T

70

10.70

10.90

25

B26Brass

B26T

95

12.46

12.90

20

B28Brass

B28T

185

15.75

18.50

5

Natural Brass

Aluminium to Aluminium Bolted Conectors Aluminium Parallel Clamp Type APC For combinations of aluminium and S.C.A. conductors. a heavy-duty aluminium clamp which uses stainless steel U-bolts to provide high pressure over a wide conductor range. Tapered bell mouths and modified V-groove minimise cold flow and prevent conductor strands from splaying. Conductor Range

Run Part No.

Stranding

Overall Dia.

Stranding

Overall Dia.

Weight Each kg

APC 112

19/3.75 to 61/3.25

18.8 to 29.3

7/3.75 to 37/3.00

11.3 to 21.0

0.936

APC 1122

19/3.75 to 61/3.25

18.8 to 29.3

19.3.75 to 61/3.25

18.8 to 29.3

1.22

Catalogue No. APC 10 6

Tap

TO Series Clamps These connectors are made form virgin ingot aluminium and are for equal and unequal conductors of aluminium. Steel-cored aluminium and copper. Clamps are available with aluminium, stainless steel and galvanised steel hardware. All clamps are supplied with FJ ing compound and sealed in plastic bags. When ordering clmaps with hardware, use ‘A’ for aluminum; ‘SS’ for stainless steel and ‘GS’ for galvanised steel.

Conductors Part No.

Run and Tap

Diameter

Length mm

Weight kg

TO-4/12

7/1.35 to 7/3.75

4mm to 12mm

35

.1

TO-7/19

7/2.50 to 19/3.75

7mm to 19mm

51

.237

TOD-4/12

7/1.35 to 7/3.75

4mm to 12mm

70

.2

TOD-7/19 TOD-7/19 “SP” TODSC-7/19

7/2.50 to 19.3.75

7mm to 19mm

95

.475 .5

TOT-7/19

7/2.50 to 19/3.75

7mm to 19mm

143

.8

Catalogue No. TOD SERIES

Catalogue No. TO SERIES

Aluminium Line Clamps Type AL & ALD A universal line tap for equal and unequal combinations of aluminium and ACSR conductors. Castings are high strength aluminium alloy, hardware stainless steel. Prefilled with t compound. Conductor Range

Run

Tap

Stranding

Overall Dia.

Stranding

Overall Dia.

Fig.

Lmm

Weight Each kg

AL43

7/1.70 to 7/3.75

5.10 to 11.3

7/1.70 to 7/3.75

5.10 to 11.3

1

35

0.085

ALD58

7/1.75 to 7/4.50

5.25 to 13.5

7/1.75 to 7/4.50

5.25 to 13.5

2

70

0.142

ALD75

7/2.5 to 19/3.75

7.5 to 19.0

7/2.5 to 19/3.75

7.5 to 19.0

3

95

0.330

Part No.

107

www.nesco.com.au

O v e r h ead an d Un d er g r o u n d

Aluminium to Copper Bolted Connectors CTC Series - Consumer Tee Connectors These connectors allow for multiple consumer connection to be made where a number of split bolt clamps can be connected to the tinned copper conductor compressed into main aluminium connector body. Connector is cast in virgin ingot aluminium alloy. Available with aluminium, stainless steel or galvanised steel hardware and supplied with FJ ting compound.

Run Conductor Range

Copper Conductor

Minimum

Maximum

Weight kg

CTC-1-250

7/2.75

7/2.25

19/3.75

225

2CTC-1-250

7/2.75

7/2.25

19/3.75

350

Part No.

Catalogue No. CTC SERIES

Aluminium to Copper Bi-Metal PGI SERIES Material is forged aluminium clamp friction welded copper insert for making copper connections. The clamps have serrated transverse grooves for maximum conductor and use galvanised steel bolts with Belville washers to prevent thermal ratcheting under cyclic loads. Conductor Range

Aluminium Run

Dimensions

Copper Tap

Area mm2

Overall Dia.

Area mm2

Overall Dia.

Length

No & size of Bolts

PGI 16072

16-70

5.1-11.7

6-50

3.0-9.0

40

2xM8

PGI 251502

25-150

6.3-15.7

10-95

4.1-12.5

48

2xM8

PGI 351853

35-185

7.5-17.5

35-185

7.5-17.4

95

3xM10

Part No.

Catalogue No. PGI SERIES

Copper to Copper Bolted Connectors Parrallel Groove Clamp

10 8

Part No.

Description

PG2595

M10 Single Bolt PG Clamp for ing Copper Conductors 25-95sq mm to a 6mm flat surface

G-70-150

M12 Double Bolt PG Clamp for ing Copper Conductors 70-150sq mm, 7mm, 1kg

G-120-240

M12 Double Bolt PG Clamp for ing Copper Conductors 120-240sq mm, 72mm, 1.2kg

Catalogue No. PG2595

Copper to Copper Bolted Connectors Type CBC A heavy-duty bonding clamp that accepts a wide range of copper cables. Castings are high-strength copper alloy. Hardware is stainless steel. Neoprene washers capture bolts, aiding installation.

Type CBC-X A three-piece bonding clamp. the central spacer separates run and tap cables. Provides high pressure and confines the cable strands. Castings are high copper alloy. hardware is stainless steel.

Type G - Two Bolt Clamp Type PG - Single Bolt Clamp Suitable for tap or parallel connections. Castings are high-strength copper alloy. Stainless steel bolts are captured for single spanner instrallation. Conductor Range

Run

Tap

Area mm2

Overall Dia.

Area mm2

Overall Dia.

Weight Each kg

CBC3

70 to 95

10.70 to 12.60

4 to 95

2.5 to 12.60

0.23

CBC4

120 to 150

14.21 to 15.75

16 to 150

5.10 to 15.75

0.425

25 to 95

6.42 to 12.60

16 to 95

5.1 to 112.60

0.27

Part No.

CBC3X

Conductor Range Part No.

Area mm2

Overall Dia.

Length

Bolt Size

No. of Bolts

Weight Each kg

G 2595

25 to 95

6.42 to 12.60

60

M10

2

.350

PG 2595

25 to 95

6.42 to 12.60

30

M10

1

.180

NOTE: The above range is for tap connections. When used for parallel connections the range is 10mm2 to 95mm2 (4.05 to 12.60mm)

Catalogue No. CBC

Catalogue No. PG2595

109

www.nesco.com.au

O v e r h ead an d Un d er g r o u n d

Rising Mains Connectors Tee Off Connectors Used in multi-level buildings where tee-off from main conductor is connected to the main switchboard on each floor. For both Aluminium and Copper Mains to Aluminium and Copper Tee. Made from High Strength Aluminium and Gunmetal, fitted with stainless steel hardware. Belleville Washers fitted when cast in Aluminium. Please nominate Aluminium or Gunmetal when oredering by adding an “A” or “G” to the end of Catalogue Number.

Tee off Copper or Aluminium

Aluminium Main Part No.

Minimum

Maximum

Minimum

Maximum

RMC 55

19/1.53 35sq mm 7.65mm Dia.

37/2.03 120sq mm 14.21mm Dia.

7/1.35 10sq mm 4.05mm Dia.

19/1.53 35sq mm 7.65mm Dia.

RMC 86

37/2.25 150sq mm 15.75mm Dia.

61/2.25 240sq mm 20.25mm Dia.

7/1.35 10sq mm 4.05mm Dia.

19/2.14 70sq mm 10.7mm Dia.

RMC 104

61/2.52 300sq mm 22.68mm Dia.

61/2.85 400sq mm 25.65mm Dia.

7/1.35 10sq mm 4.05mm Dia.

19/2.14 70sq mm 10.7mm Dia.

Catalogue No. RMC SERIES

Bolted Connectors for Copper Cables Versaclamp Type RV A three piece multi-purpose Clamp providing parallel and T-connections over a wide range of cable sizes. Casting are copper alloy. Hardware is stainless steel. Cable Range

Main

Tap

Area

Part No.

Min

OD

Max

Area

OD

Min

Max

Min

Max

Min

Max

RV3

50

95

8.90

12.60

50

95

8.90

12.60

RV4

120

240

14.21

20.25

16

35

5.10

7.65

RV5

120

300

14.21

22.68

35

95

7.65

12.60

RV6

120

240

14.21

20.25

120

240

14.21

20.25

RV8

300

800

22.68

37.05

35

150

7.65

15.75

for tin plated connectors, add “P” to catalogue number: eg. RV4-P Dimensions

Part No.

11 0

Fig.

B

H

J

W

RV3

1

46

58

10

48

RV4

1

38

58

8

50

RV5

1

45

58

10

48

RV6

2

54

70

10

57

RV8

1

49

77

10

65

Catalogue No. RV SERIES

Distribution & Transmission Switchgear Dropout Fuses Expulsion Type C Standard Base Units & Accessories Type Designation

Rated Voltage (U) k V.

Rates Current (in) AMP

Rated Breaking Capacity kA. (sym)

Bill kV.

Creepage to Earth mm.

Arc Shortening Rod

72297/12

XS108

12

100

8/6

125

300

YES

72298/15

XS128

12/24

100

8/6

150

475

YES

72299/27

XS236

24/36

100

6/4

170

600

YES

Part No

Accessories Part No

Description

69196

Mounting Bracket - Standard Z

69196/3

Mounting Bracket - ZWA

69195

Mounting Bracket - NEMA

69194

Mounting Bracket - Direct to Pole

70584

Earth Kit. - Top — M10 x 150mm Lg Stainless Steel.

69341/2

Earth Kit. - Top — M10 x 200mm Lg Steel HDG

69894/2

Earth Kit. - Bottom — M10 x 120mm Lg Steel HDG

70450

Earthing Stirrup Kit. - Bottom

69961

Spark Gap Assembly

72906/12

Fuse Holder - 12/24kV 8/6kA 100A 366mm Lg. (with ARC Shortening Rod)

72906/24

Fuse Holder - 24/36kV 6/4kA 100A 458mm Lg. (with ARC Shortening Rod)

70410

Disconnect Blade - 12/24kV 300A 383mm Lg

71846/12

Replacement 12kV Fuse Holder for Older “RE” Style Dropouts

71846/24

Replacement 24kV Fuse Holder for Older “RE” Style Dropouts

Disconnector (Isolator) Rocking Insulator Disconnector 3 Phase Open Airbreak Switch Type PR3

Accessories Part No

Description

69118

PR3 12kV 630 amp with Flicker Arcing Horns Requires 21636 Crossarm Kit plus Operating Kit

69119

PR3 24kV 630 Amp with Flicker Arcing Horns Requires 18590 Crossarm Kit plus Operating Kit

69120

PR3 36kV 630 Amp with Flicker Arcing Horns Requires 24296 Crossarm Kit plus Operating Kit

Catalogue No. PR3 111

www.nesco.com.au

O v e r h ead an d Un d er g r o u n d

Distribution & Transmission Switchgear Dropout Fuses Expulsion Type C Isolators and Fused Isolators – Standard Base Units & Accessories Part No

Type

Rated Short-Time Current 1s

Rated voltage (Ue) V

Rated Current (Ie) AMP

Rated Making Capacity I/Ie

Rated Breaking Capacity I/Ie

Clearance to Earth mm.

NZ4284 SEQEB

LVI

20kA

480

630

1

1

32

NZ4298

LVI

36kA

480

800

1

1

32

NZ4296 SECV

LVI

36kA

480

1600

–

–

32

NZ4286 SECV

LVFI

20kA

480

400

1

1

32

NZ4286 SEQEB

LVFI

20kA

480

630

1

1

32

NZ4211A

LVFI

36kA

480

800

1

1

32

Accessories Part No

Description

69298/1

Compression Bolt Kit M12 x 30 Bolt + Nut + Fl. & Sp. Washer S/S

Qty. Reqd/Sw. = 2 or 4

69297/1

‘U’ Bolt Kit M8 S/S, Clamp Range = Ø8 min. - Ø22 max.

Qty. Reqd./Sw. = 2 or 4

69297/2

‘U’ Bolt Kit M8 S/S, Clamp Range = Ø8 min. - Ø16.5 max

Qty. Reqd./Sw. = 2 or 4

69293/1

Two Bolt Clamp M8 x 65 S/S, Clamp Range = Ø3 min - Ø22 max.

Qty. Reqd./Sw. = 2 or 4

69293/2

Two Bolt Clamp M10 x 65 S/S, Clamp Range =Ø3 min. - Ø22 max.

Qty Reqd./Sw. = 2 or 4

71235

Single Bolt Cable Clamp Clamp Range = Ø5.1 min. - Ø22.7 max.

Qty Reqd./Sw. = 2

Disconnector Type UHSB (Unitised) with Pump Type Handle Standard Base Units & Accessories Crossarm

Part No.

Timber

Load Breaking

Steel

Flicker Blade

Duogap

Pole

Mid

Rated

–

Top Mtg

Pole Mtg

Voltage (U) kV

Normal

BIL kV

12

630A

125

70209/1

11 2

70209/15

❮

70209/16

❮

❮ ❮

❮

❮

12/24

630A

150

❮

❮

12/24

630A

150

Fuselinks – AK1 Expulsion fuselinks Certificate of conformance to AS 1033.1 - 1990 Class AK1 @ 12kV & 24kV in NGK STANGER C type Dropouts. Also suitable for use up to 36kV in single & Dual Vented Dropout Units.

Specifications AMPS

Type K Speed Description & Part No

AMPS

Type K Speed Description & Part No

1

ZXC705-01BK37

20

ZXC705-20BK37

2

ZXC705-02BK37

25

ZXC705-25BK37

3

ZXC705-03BK37

31

ZXC705-31BK37

5&6

ZXC705-06BK37

40

ZXC705-40BK37

8

ZXC705-08BK37

50

ZXC705-50BK37

10

ZXC705-10BK37

63

ZXC705-63BK37

12

ZXC705-12BK37

80

ZXC705-80BK37

16

ZXC705-16BK37

100

ZXC705-100BK37

AMPS

Dual Range Surgeproof & Part No

3/10

(‘C’) ZXC705-310BK37

6/20

(‘F’) ZXC705-620BK37

10/30

(‘J’) ZXC705-1030BK37

Where AK1 performance is not required use ZM instead of AK1 Fuselinks.

Catalogue No. ZXC705 Series

For Dual Range ‘SURGEPROOF’ ratings with AK1 performance use: 3/10 (‘C’) Dual Range ‘SURGEPROOF’ instead of standard 3K Fuselink 6/20 (‘F’) Dual Range ‘SURGEPROOF’ instead of standard 6K Fuselink 10/30 (‘J’) Dual Range ‘SURGEPROOF’ instead of standard 10K Fuselink. Application & Time-Current Data available on request. Note: Flexible Head Adaptors Part No69231/1 (for 1-32 Amp Fuselinks) or 69231/2 (for 40-100 Amp Fuselinks) must be used with older style Top-Latched Dropouts Units.

Single Phase Hook Stick Operated Isolators (Disconnectors) Single Insulator - Type MVI — Standard Base Units & Accessories Rated Short current 1s

Rated Voltage (U) k V.

Rates Current (in) AMP

Bill kV.

Creepage to Earth mm.

70416

20kA

12/24

630

125

300

70414

20kA

24

630

150

475

70423/1

20kA

24/36

630

170

600

Part No

The above Part Numbers do not include Mounting Brackets and Clamps Refer to accessories table below. 70416NSW

20kA

12/24

630

125

300

70414NSW

20kA

24

630

150

475

The above Part Numbers include mounting bracket for underhung or 60 degree, c/w Flicker Horns & Earth - but no C- clamps - Refer to accessories table over page.

113

www.nesco.com.au

O v e r h ead an d Un d er g r o u n d

Fuse Switch Disconnectors & House Service Units for LV ABC Protection and Isolation at transformer low voltage supply at consumer feeder at a change in cable conductor cross section at a change from overhead to underground short circuit protection Sectionising connection and disconnection of network sections connection of overhead to underground

Single Phase Part No

Description

Features

FSD100

100 amp 415V Fuse Switch Disconnector

IPC Terminal for 6-95mm2 AL/Cu cable Accepts standard round fuse 22.2 x 57 BS1362 and can be operated using a pig tail type standard extractor stick Corrosion proof and weather resistant

FSD160

160 amp 415V Fuse Switch Disconnector

IPC Terminal for 6-95mm2 AL/Cu cable Accepts DIN (NH) size 00 fuse links AS2005.21.1 and can be operated using a standard hook stick Corrosion proof and weather resistant

FSD401

400amp 415V Fuse Switch Disconnector

Tunnel connector 2 x 50 - 185 mm2 Al/Cu cable Accepts DIN (NH) size 1 & 2 fuse links and can be operated using a standard hook stick Corrosion proof and weather resistant

FSD631

630 amp 415V Fuse Switch Disconnector

Terminal Palms suit lugs with M12 Accepts DIN (NH) size 2 or 3 fuselinks (630A max) and can be operated using a standard hook stick Corrosion proof and weather resistant

FSD160-3

160 amp 415V Fuse Switch Disconnector

Assembled as 3 Phase Gang Operated Disconnector IPC terminal for 6-95mm2 Al/Cu Cable Hinged lid accepts DIN (NH) size 00 fuse links AS 2005.21.1 and can be operated using a standard hook stick Corrosion proof and water resistant

FSD250

250 amp 415V Fuse Switch Disconnector

Assembled as 3 phase Gang Operated Disconnector IPC Terminals 95-150mm2/Tunnel Terminals 95-150mm2 or terminal palms available Hinged lid accepts DIN (NH) size 1 & 2 fuse links and can be operated using a standard hook stick Corrosion proof and water resistant

FSD400

400amp 415V Fuse Switch Disconnector

Assembled as 3 Phase Gang Operated Disconnector IPC terminal 95-150mm2/ Tunnel Terminals 95-150mm2 or terminal palms available Hinged lid accepts DIN (NH) size 1 & 2 fuse links and can be operated using a standard hook stick Corrosion proof and water resistant

Three Phase

11 4

HSFEKIT House Service Fuse Extractor Kit - “The Extractor” Features

For The extraction of House Service Fuses



Also used for disconnecting dropout fuses, isolators & fuse switch disconnectors.



Can be used to attach the HP-275 proximity tester (page no ??)



The kit consists of 3 x 1.8 metre fibreglass Sticks 1 x 1.2 metre fibreglass sticks with sunrise fitting 1 x fuse extractor head 1 x 4 pocket yellow carry bag



Head section is rated at 100kV per 300mm and complies with IEC 855



Australian made

Catalogue No. HSFEKIT

Hot Sticks can be used for many applications on overhead powerlines and a wide variety of specialised fittings and tools are available to suit the ‘sunrise’ head attachment.

Accessories Part No

Description

P10044

Disconnect hook for attachment to sunrise fitting Other accessories available upon request

Catalogue No. P10044

Protective Cable Cover “Tiger Tails” Work safely, prevent disasters and accidents caused by electric shocks by covering high voltage electric wires with the DB Torapoli Pipe (tiger tails). Features

The highly visible stripe design of yellow and black is recognisable as a caution sign.



It’s resistant against all types of weather.



Polyethylene ensures complete electric insulation.



Special shape and special-processed t assure the permanent connection.



Any desired length can be achieved.



Easily coupled together

Catalogue No. TORAEA

Accessories Part No

Description

TORAEA

Tiger Tail Yellow & Black, 2.5 meter in length 35mm in diameter, Tested to 15kV

115

www.nesco.com.au

O v e r h ead an d Un d er g r o u n d

Telescopic Hot Sticks Mainly used for the removal of Pole Service Fuses and Dropout fuses. Features and Benefits

The triangular shape allows ease of use.



Rated at 100kV per foot.



The fluorescent tip section is highly visible and has a foam core.



Strong aluminium alloy head incorporates corona discharge and includes a captive Belleville washer to hold universal attachments securely.

Ordering Information

Specifications Part No

Extended Length (Nominal Meters)

Retracted Length (Nominal Meters)

Weight

Storage Case Part No

HV-208

2.43

0.67

1.40

C-208

HV-212

3.80

1.48

1.66

C-30

HV-312

3.80

1.00

1.52

C-10

HV-216

5.00

1.53

2.26

C-30

HV-220

6.43

1.58

2.92

C-30

HV-225

7.80

1.63

3.68

C-40

HV-230

9.21

1.68

4.55

C-40

HV-235

10.06

1.72

5.50

C-40

HV-240

12.00

1.75

6.50

C-40

Catalogue No. HV-***

Catalogue No. 5455-10PTU

Accessories

Accessories Part No

Description

5455-10PTU

Pig Tail Pole Fuse Extractor Head for use with telescopic sticks

P10044

Disconnect hook for attachment to sunrise fitting

Catalogue No. P10044

11 6

Barrier Fencing Mesh Re-usable, high durability barrier fencing Mesh. UV resistant, high visibility. Manufactured in different weights to suit applications. Mesh is easy to erect and provides far greater levels of protection than barrier tape Features

Manufactured from polypropylene



UV stabilised



Bagged for protection/storage

Catalogue No. BMO

Specifications Colour

Size

Weight

Part Number

Orange

1mtr x 50mtrs

8kg

BMO1X50M

Green

1mtr x 50mtrs

8kg

BMG1X50M

Note: Other colours available upon request

Underground Warning Tape The most economical way of warning excavators of buried services below ground. Our tapes can be printed with any text in any language, any colour and any size, manufactured to your specifications. Standard texts are available ex-stock. Features

Material - High quality linear low density polyethylene.



Lead free pigments with virgin grade film.



Excellent chemical resistance.



Elongation - Machine direction 350% min - Transverse direction 300% min



Tensile Strength - Machine direction 20N/mm2 - Transverse direction 20N/mm (nominal)

Manufactured in accordance with AS/NZS 2648.1 1995 and AS/NZS 4275 Part O 1995. Various thicknesses of polyethylene available.

Specifications Text

Colour

Size

Part Number

DANGER-BURIED ELECTRIC CABLE BELOW

orange

150mm x 0.1mm x 500m

UGWTE150500

DANGER-BURIED COMMUNICATION CABLE BELOW

white

150mm x 0.1mm x 500m

UGWTC150500

Other Texts available include Gas, Irrigation, Sewer, Water, Diesel & Fibre Optic. Note: Other dimensions available upon request

For complete specification see our website www.nesco.com.au

117

NESCO Electrical Products Brisbane Head Office

NESCO OVERVIEW NESCO is an Importer, Exporter and Manufacturer distributing throughout Australia and are now recognised as one of Australia’s leading distributors of electrical products. NESCO specialise in Test and Measurement, Portable Appliance Testing products, Domestic and Industrial Heating, Overhead and Underground Power Distribution products, Busway for industrial applications and Industrial Automation Products. NESCO’s head office is in Brisbane with further warehousing and representation in Townsville, Rockhampton, Newcastle, Sydney, Melbourne, Adelaide and Perth. This Coverage allows us to service our customer base right throughout Australia and is the main reason that NESCO is the choice of many of the world’s Electrical Manufacturers when seeking quality distribution in Australia.

NESCO Electrical Products Townsville

NESCO Electrical Products New South Wales

Our marketing and distribution is primarily directed through the wholesale distribution chains with whom we have developed and maintain close working relationships, providing both product knowledge and suitable product for their end customers. In house training by our individual Product Managers is available in our modern well equipped training room. This facility is also available for private use by customers of Nesco. NESCO is dedicated to the pursuit of the highest levels of customer service and satisfaction, providing products which meet the customer’s needs with knowledge and back-up facilities to match.

NESCO Electrical Products Victoria

NESCO Electrical Products Western Australia

E & EO. All specifications are subject to change without notice. Whilst every care has been taken in preparation, we cannot be held responsible for typographical errors.

Queensland Brisbane Head Office NESCO Electrical Products Address 54 Standish Street, Salisbury, QLD, 4107 Phone +61 7 3274 2466 FAX +61 7 3274 2970 E-mail [email protected]

Sydney & NSW NESCO Electrical Products Address 2/1-3 Whyalla Place, Prestons NSW, 2170 Phone +61 2 9826 8088 FAX +61 2 9826 8188 E-mail [email protected]
