Amphion Creon Owners Manual v34

creon english 10/2001

Single/ bi-wiring For bi-wiring purposes amphion creon is equipped with two pairs of binding posts (top and middle). Depending on the market area the speakers can be delivered with lintel attacted or separately. In case the two pairs of binding posts are attached with lintel (single wiring) and you want to bi-wire the lintels can be removed by loosening the end piece of the binding post.

amphion loudspeakers ltd, finland

No:

www.amphion.fi creon 8 ohm 250 W

model impedance max power

BAS Bass Adjustment System

Warning: Use only approved BAS components

Not to be used for connecting speakers to amplifier

Bi-amping In addition to finding the correct bass level for each room the BAS system can be also used for convenient biamping. The advantages of biamping are well known, especially when mixing tubes and solid state (tubes for mid and high frequensies and solid state for the bass for example). Now any amplifier combination can be easily balanced and correct bass level found via Bass Adjustment System.

Thank you for choosing amphion creon. We hope that your new speakers will provide pleasure for years to come. creons good looks are widely appreciated, but in this case looks merely follow function. Nothing has been sacrificed in order to design a quality loudspeaker, which will ensure maximum musical enjoyment while keeping a listening space livable.

amphion, Uniformly Directive Diffusion, U/D/D-technology and BAS - System are trademarks of amphion loudspeakers ltd. All rights reserved.

amphion loudspeakers ltd. P.O. Box 6 70821 Kuopio, Finland

www.amphion.fi

creon

´s Guide To enjoy fully all the features of your new loudspeakers, Please read this manual carefully and completely.
