Wheelbuilder.com :: Aerodynamic Data

Aerodynamic Data

Aerodynamic Data

Troubleshooting

Wheelbuilder spent a day in the San Diego Low Speed Wind Tunnel with the objective of comparing our AeroJacket disc covers to uncovered wheels and disc wheels. The obvious advantage of racing with a disc cover is cost, however this data quantifies the performance advantage.

Zipp Hub ID Guide

Wheels tested:

Installation

Uncovered 30mm aluminum rim Uncovered Zipp 404 tubular Zipp 900 Tubular Disc (flat) Zipp Sub-9 (toroidal bulge) AeroJacket on Zipp 808 tubular AeroJacket on 30mm aluminum rim

Search

Advanced search

Shop by Brand Choose a manufacturer

Wheelbuilder.com AeroJacket Disc Comparision

Sign in ?

Cart is empty Testimonials Wheelbuilder's ability to help you build a wheel that is perfectly suited to your needs is second to none! There is no place else I would ever trust to handle my wheel needs or the Read more »

Andy Lakatosh - BIG Picture Cycling Nov 3, 2015 I recently took delivery of a new set of track wheels that Wheelbuilder.com made for me. These are the best training/race wheels I have ever had. The component combination they Read more »

Matthew Diefenbach Nov 3, 2015

Conclusions A covered wheel has dramatically lower aerodynamic drag than an uncovered wheel. Disc cover performance is virtually identical to disc wheels through the entire range of yaw angles: 0-30 degrees. A covered 81mm deep wheel outperformed flat disc wheels in every wind condition. The covered Zipp 808 has less drag than the fastest disc wheel tested beyond 10 degrees of yaw. A typical 30mm training wheel with disc covers approaches the performance of a flat disc at 7.5 degrees of yaw, but exceeds performance of all disc wheels tested at wind angles greater than 12.5 degrees. The lens-shape on a disc-cover's non-drive side causes wind to around it like a wing, producing forward thrust. This effect is more pronounced on covered shallow wheels beyond 20 degrees of yaw. Discussion Drag on flat discs is nearly identical with wind traveling from rider's left or right sides. AeroJacket disc covers are asymmetric, with a flat drive-side and lens-shaped non-drive side, so drag differs depending on wind direction. The most favorable direction is with the wind traveling over the rider's right shoulder. For this reason we tested in both wind directions i.e., we ran the test forward and backwards and averaged the data. We ran the tests on the 30mm covered wheel (DT Swiss RR 585) twice on the advice of the wind tunnel staff who were, frankly, astonished by the results.

Read testimonials

Click here to purchase an AeroJacket!

Want to post yours?

Aerodynamics vs. Weight In evaluating race wheel performance, riders optimize aerodynamics, wheel weight and inertial forces. In triathlon and time trials, aerodynamics are overwhelmingly influential. On a flat course, 80% of your power is used to overcome wind resistance ("drag"), so improving your wheel aerodynamics has the most significant impact on racing faster. On flat or rolling courses, wheel weight is trivial relative to the dominant aerodynamic drag forces. Weight matters only when steep and prolonged grades are present. Covers weigh 350-400g, which is so small relative to the mass of you and your bike that the differences in wheel inertia are unperceivable. Wheel inertial forces are nearly insignificant because inertial forces are a function of acceleration. Focus on Aerodynamics!
