Adsl Configuration 1v692a

Customer Service Division

Shared success

Introduction  This manual helps you to configure your ZXDSL 831C (ZTE) Modem which have blue black color and old ethio telecom logo.

 This manual is also helps you to identify weather your modem is losing it’s configuration or not.  Using seven simple configuration steps you can configure and connect to the internet when ever your modem losses configuration.

 The manual is prepared for the use of both Enterprise and residential, Internet and data ADSL customers.  Enterprise ADSL’s services have service numbers mostly start with 999 or 98.  Residential ADSL’s service didn’t have service numbers, instead customer’s ID

used as service number.  For further information you can call to our free call center 994.

Important notice  Please notice that to reconfigure your modem first you should implement the five configuration steps and capture WAN IP and other related numbers when your service is working properly. Asymmetric digital subscriber line

P_002

Steps to identify configuration status  In your modem if Power and DSL light indicators didn’t have steady green light your problem is not related to configuration problem and you should call to 994 and you fault.  If power and DSL have steady green light and if internet doesn’t have blinking light you can implement the next two simple steps and identify weather your modem is losing it’s configuration or not.

Description of light indicator 1-Power indicator 2-DSL 3-Internet 4-LAN 1-4

1 2 3

4

Asymmetric digital subscriber line

P_003

Step 1. Accessing modem from internet browser.

1. Write default ZTE ZXDSL IP (http://192.168.1.1/)

2. Write “” on both fields.(For enterprise) 2. Write your own name and provided from ethio telecom during sales. (For residential).

Asymmetric digital subscriber line

P_004

Step 2. Check your modem configuration status

1. Click on Status

2. Check the status of your configuration ( From LAN IP up to Secondary DNS server)

 If there is a number in front of LAN IP, Default gateway, primary DNS server and Secondary DNS server just like seen in the picture, your problem is not related to configuration and you should also call to 994 and your fault.  If a space provided in front of LAN IP to Secondary DNS server is empty please implement the next seven simple configuration steps and reconfigure your modem. Asymmetric digital subscriber line

P_005

Steps to reconfigure ZXDSL Modem

Step 1. Accessing modem from internet browser.

1. Write default ZTE ZXDSL IP (http://192.168.1.1/)

2. Write “” on both fields.(For enterprise) 2. Write your own name and provided from ethio telecom during sales. (For residential).

Asymmetric digital subscriber line

P_006

Steps 2. Select quick setup.

1. Click on quick setup.

Asymmetric digital subscriber line

P_007

Steps 3. Configure internet connection

1. Don’t make any change, just click on next.

Asymmetric digital subscriber line

P_008

Steps 4. Select connection type.

1. Select PPP over Ethernet (PPPOE). (For Residential) 1. Select MAC encapsulation routing (MER). (For enterprise)

2. Click on next.

Asymmetric digital subscriber line

P_009

Steps 5. Configure WAN IP

1. Select Obtain an IP address automatically option. ( For Residential) 1. Select Use the following IP and Write Wan IP address.(For Enterprise) 2. Write default gateway. Your default gateway is the first two group of WAN IP numbers plus 48.1. Example: If your WAN IP is 10.131.63.194 your default gateway will be 10.131.48.1

No need to write WAN Subnet Mask, the system will fill automatically

3. Write primary and secondary DNS server address. (For enterprise) Primary: 213.55.96.166 Secondary: 8.8.8.8

5. Click on next. 4. For internet select Enable NAT but for data do not select it. .

Tip Wan IP address and other related numbers are provided by ethio Telecom during sales or you can extract it from your modem while it is working using the above 5 steps and getting back by clicking Back sign . (For Enterprise)

Asymmetric digital subscriber line

P_0010

Steps 6. Configure LAN setting.

1. Make sure DH server on LAN is enabled. (For Both)

2. Click on next.

Asymmetric digital subscriber line

P_0011

Steps 7. Check the summary and apply

1. Check weather your WAN & LAN configuration is correct or not, if not return back and correct.

2. Click on Apply. Your modem will refresh itself and start over. Asymmetric digital subscriber line

P_0012
