1. 3-D view of a complete automatic Water Treatment Plant of product water output capacity of 15,000 ltrs/hr. (3 Lakh ltrs/ day). 2. The concept of a 3-D model helps the client to understand the placement of the machinery as well as the actual equipment that he is going to buy. 3. The view also explains the entire electrical works that needs to be carried out with specific capacity of Switches that needs to be installed for various machines. 4. The below 3-D image also shows how the electrical cabling tray from the Distribution box will be taken & at what height with drop points. 5. This avoids Re-work & saves money & time, which is very crucial when working on deadlines to start the project. 6. It also gives us a better understating of the layout & also helps create better possible solutions

Top view of view a Water & SodaTreatment unit with the Water & the&Labs the 1st machinery Floor & 3 Dimensional INTERNAL of Water Plant & theTreatment Labs on thePlant 1st Floor the on packaging thethe packaging the Ground Floor. Fully Automatic Line of 90 Bottles/Min. on Ground machinery Floor. FullyonAutomatic Line of 90 Bottles/Min.

Side View of the machinery on the 1st floor & the Ground floor - this is a space saving design wherein the Water Treatment Plant & the lab along with the office & a few Raw material storage areas is stored on the 1st floor to save space.

Water & Soda Unit - 3 D layout showing exact location of machinery along with utilities & clear earmarked separation of the Soda Unit from the Water unit. Also shows the minimum area to be kept free on the outside of the plant as per factory rules. This design is as per Vassthu and the flow of the goods is from south to north & then to the east.

Internal layout of the complete line for the Water Treatment Plant of 10,000 LTRS/HR. Alongwith Blow Moulding Mc for making PET bottles with automatic HANDS FREE Bottle Filling Mc & shrink packing machine. Includes a 300 Bottles/Hr. 20 ltrs Jar filling machine also.

DOUBLE LINE - 24,000 ltrs/hr. Fully automatic & completely NO TOUCH BY HAND Packaged Drinking Water project for 80 Bottles/Min. Dedicated for 1 ltrs & the second line of 60 Bottles/Min. Dedicated for 300 ml, 500 ml & 2000 ml. With a 450 Bottles/Hr. 20 Ltrs Jar Filling Machine.

3D image showing the other Utilities like the raw water tanks, Electrical Generators, Compressors etc. On the outside of the factory premises for a better understating of the layout for the client. It helps in understating of the process flow & machinery placement even before construction starts.
